BN68-01352B-01
PDP-TELEVISION
(P
D
LASMA
Owner's Instructions
Before operating the unit,
please read this manual thoroughly,
and retain it for future reference.
ON-SCREEN MENUS
Picture In Picture (PIP)
Energy Saving
TELETEXT
(Option)
SRS TruSurround XT
Digital Natural Image engine
Register your product at www.samsung.com/global/register
Record your Model and Serial number here for future reference.
▪ Model _______________ ▪ Serial No. _______________
P
)
ISPLAY
ANEL
Advertisement
Table of Contents
Related Manuals for Samsung PS-63P76FD
Summary of Contents for Samsung PS-63P76FD
-
Page 1: Energy Saving
Picture In Picture (PIP) Energy Saving TELETEXT (Option) SRS TruSurround XT Digital Natural Image engine Register your product at www.samsung.com/global/register Record your Model and Serial number here for future reference. ▪ Model _______________ ▪ Serial No. _______________ BN68-01352B-01 Downloaded From TV-Manual.com Manuals... -
Page 2: User Instructions
DVB-T signals. Although this TV set follows the DVB-T specification, maintaining compatibility with the future coming DVB-T digital terrestrial broadcasts is not guaranteed. Several functions may not be available in some countries. © 2007 Samsung Electronics Co., Ltd. All rights reserved. Downloaded From TV-Manual.com Manuals English - 2... -
Page 3: Table Of Contents
Contents General Information Function Description User Instructions ..........2 Time Features ..........24 Checking Parts ..........4 Language / Blue Screen / Melody / Using the Stand-Base ........4 Light Effect / Energy Saving / ... -
Page 4: Checking Parts
Checking Parts Owner’s Instructions Remote Control/ Power Cord Cloth-Clean Warranty Card/ AAA Batteries Registration Card/ Safety Guide Manual Cover-Bottom / Screws (2ea) Ferrite Core (PS-50P96FD/PS-58P96FD, Refer to page 58) Sold Separately S-Video Cable Antenna Cable Component Cables Audio Cables Video Cable PC Cable Scart Cable PC Audio Cable... -
Page 5: Control Panel
Control Panel Front (or Side) Panel PS-50P96FD/PS-58P96FD PS-63P76FD ➢ The product colour and shape may vary depending on the model. 1 SOURCE C/P. Displays a menu of all of the available input Press to change channels. In the on-screen sources (TV, Ext.1, Ext.2, AV, S-Video, menu, use the C/P. -
Page 6: Connection Panel
Connection Panel Side Panel (PS-58P96FD) ➢ The product colour and shape may vary depending on the model. 1 HDMI IN 3 3 Headphones jack Connect to the HDMI jack of a device with You can connect a set of headphones if you HDMI output. - Page 7 1 POWER IN 9 HDMI IN 1, HDMI IN 2 Connect the supplied power cord. − Connect to the HDMI jack of a device with HDMI output. These inputs can also be used 2 Connecting external Audio Devices as a DVI connection with separate analog Connect RCA audio signals from the TV to an audio inputs.
-
Page 8: Viewing The Remote Control
% Remote control setup normal broadcast ^ Selects a target device to be @ Teletext size controlled by the Samsung * Teletext mode selection remote control (TV, DVD, (LIST/FLOF) STB, CABLE, VCR) ( Teletext sub page &... -
Page 9: Switching Your Television On And Off
Installing Batteries in the Remote Control Lift the cover at the back of the remote control upward as shown in the figure. Install two AAA size batteries. ➢ Make sure to match the “+” and “–” ends of the batteries with the diagram inside the compartment. -
Page 10: Viewing The Menus
Viewing the Menus Press the MENU button. Picture The main menu is displayed on the screen. Mode : Dynamic Its left side has five icons: Picture, Sound, Channel, Setup, Contrast Brightness and Input. Sharpness Colour Press the ▲ or ▼ button to select one of the icons. Tint G 50 R 50... - Page 11 Select your country or area by pressing the ▲ or ▼ button. Plug & Play Press the ENTER/OK button. The message Some DTV functions may not be available. Some DTV functions may not be available. Digitally Scan? Digitally Scan? is displayed. ➢...
-
Page 12: Viewing External Signal Sources
15 Press the ◄ or ► button to select Month, Day, Year, Hour, or Plug & Play Minute. Set these by pressing the ▲ or ▼ button. Set the current time. ➢ You can set the Month, Day, Year, Hour, or Minute Month Day Year directly by pressing the numeric buttons on the remote... -
Page 13: Editing Device Names
Editing Device Names You can give a name to the external source. Input Press the MENU button to display the menu. Source List : TV Edit Name Press the ▲ or ▼ button to select Input, then press the Anynet+(HDMI-CEC) ENTER/OK button. -
Page 14: Storing Channels Manually
Storing Channels Manually ➢ Not available in DTV or external input mode. Channel You can store television channels, including those received via Country : United Kingdom cable networks. Auto Store Manual Store When storing channels manually, you can choose: Channel Manager ... -
Page 15: Adding / Locking Channels
Adding / Locking Channels ➢ Not available in DTV or external input mode. Channel Using the Channel Manager, you can conveniently lock or add Country : United Kingdom channels. Auto Store Manual Store Press the MENU button to display the menu. Channel Manager ... -
Page 16: Sorting The Stored Channels
Sorting the Stored Channels ➢ Not available in DTV or external input mode. Channel This operation allows you to change the programme numbers Country : United Kingdom of the stored channels. Auto Store Manual Store This operation may be necessary after using the auto store. Channel Manager ... -
Page 17: Fine Tuning Channel Reception
Fine Tuning Channel Reception ➢ Not available in DTV or external input mode. Channel If the reception is clear, you do not have to fine tune the Country : United Kingdom channel, as this is done automatically during the search and Auto Store ... -
Page 18: Changing The Picture Standard
Changing the Picture Standard You can select the type of picture which best corresponds to Picture your viewing requirements. Mode : Dynamic Press the MENU button to display the menu. Contrast Brightness Press the ENTER/OK button to select Picture. Sharpness Colour Press the ENTER/OK button again to select Mode. -
Page 19: Configuring Detailed Settings On The Picture
Configuring Detailed Settings on the Picture You can set detailed picture settings. Picture Press the MENU button to display the menu. Mode : Movie Contrast Press the ENTER/OK button to select Picture. Brightness Press the ▲ or ▼ button to select Detailed Settings, then Sharpness Colour press the ENTER/OK button. -
Page 20: Selecting The Picture Size
Selecting the Picture Size You can select the picture size which best corresponds to your Picture viewing requirements. More Press the MENU button to display the menu. Size : Auto Wide Screen Mode : 16 : 9 Press the ENTER/OK button to select Picture. -
Page 21: Digital Nr / Active Colour / Dnie / Movie Plus
Digital NR / Active Colour / DNIe / Movie Plus Press the MENU button to display the menu. Press the ENTER/OK button to select Picture. Select the required option by pressing the ▲ or ▼ button, then press the ENTER/OK button. Available options: Digital NR, Active Colour, DNIe, Movie Plus When you are satisfied with your setting, press the ENTER/OK... -
Page 22: Sound Features
Sound Features Press the MENU button to display the menu. Sound Press the ▲ or ▼ button to select Sound, then press the Mode : Custom Equalizer ENTER/OK button. SRS TS XT : Off Select the required option by pressing the ▲ or ▼ button, then Auto Volume : Off ... -
Page 23: Selecting The Sound Mode (Depending On The Model)
Selecting the Sound Mode (depending on the model) The DUAL I-II button displays/controls the processing and output of the audio signal. When power is switched on, the mode is automatically preset to either “DUAL-I” or “Stereo”, depending on the current transmission. Type of broadcast On-screen indication Regular broadcast... -
Page 24: Time Features
Time Features Press the MENU button to display the menu. Setup Press the ▲ or ▼ button to select Setup, then press the Plug & Play Language : English ENTER/OK button. Time Press the ▲ or ▼ button to select Time, then press the Game Mode : Off ... -
Page 25: Language / Blue Screen / Melody / Light Effect / Energy Saving / Hdmi Black Level
Language / Blue Screen / Melody / Light Effect / Energy Saving / HDMI Black Level Press the MENU button to display the menu. Setup Press the ▲ or ▼ button to select Setup, then press the Plug & Play ... -
Page 26: Using The Game Mode
Using the Game Mode When connecting to a game console such as PlayStation Setup Xbox , you can enjoy a more realistic gaming experience by Plug & Play selecting game menu. Language : English Time Press the MENU button to display the menu. Game Mode : Off ... -
Page 27: Wall- Mount Adjustment (Sold Separately)
Wall- mount adjustment (Sold separately) (PS-50P96FD) Once the wall mount is installed, the position of your TV can be easily adjustable. Rear Panel Auto Wall-Mount Serial Cable(1P to 1P)(Not supplied) Entering the menu Press the MENU button to display the menu. Setup Press the ▲... -
Page 28: Viewing The Picture In Picture (Pip)
Viewing the Picture in Picture (PIP) You can display a sub picture within the main picture. In this Setup way you can watch TV programme or monitor the video input More from any connected devices. Wall-Mount Adjustment Energy Saving : Off ... -
Page 29: Screen Burn Protection
Screen Burn Protection To reduce the possibility of screen burn, this unit is equipped Setup with screen burn prevention technology. This technology More enables you to set picture movement up/down (Vertical Line) Wall-Mount Adjustment Energy Saving : Off ... -
Page 30: Setting Up Your Pc Software (Based On Windows Xp)
Windows and your particular video card. But even if your actual screens look different, the same, basic set-up information will apply in almost all cases. (If not, contact your computer manufacturer or Samsung Dealer.) Right click the mouse on the Windows Desktop, then click on Properties. -
Page 31: Display Modes
Display Modes Both screen position and size will vary depending on the type of PC monitor and its resolution. The resolutions in the table are recommended. (All resolutions between the supported limits are supported) D-Sub Input Horizontal Vertical Pixel Clock Sync Polarity Mode Resolution... -
Page 32: Setting The Pc
Setting the PC ➢ Preset to the PC mode by pressing the SOURCE button. Setup Press the MENU button to display the menu. Plug & Play Language : English Press the ▲ or ▼ button to select Setup, then press the Time ... -
Page 33: Setting The Home Theatre Pc
Setting the Home Theatre PC You can view higher quality pictures by configuring the screen Setup settings in PC Mode. Plug & Play If you set the Home Theatre PC function to On, you can Language : English Time ... -
Page 34: Previewing The Dtv Menu System
Previewing the DTV Menu System ➢ The company does not guarantee the normal operation of the DTV menu for countries other than the 6 supported countries (England, Germany, France, Italy, Spain, Austria) because only these country standards are supported. In addition, when the country of the broadcast stream differs from the country selected by the current user, the string appearing in the channel banner, Info, Guide, Channel List,... -
Page 35: Displaying Programme Information
Language Language Audio Language Audio Language Subtitle Language Subtitle Language Teletext Language Teletext Language Preference Preference Primary Audio Language Secondary Audio Language Primary Subtitle Language Move Enter Exit Secondary Subtitle Language Primary Teletext Language Secondary Teletext Language ➢ The sub-items of the CI Menu may vary depending on the CAM model. -
Page 36: Operating The Dtv Menu
Operating the DTV Menu Viewing the DTV Menu After installing your antenna system and TV with appropriate connectors. Plug in the AC main power and switch on the TV. Press the D.MENU button to bring up the DTV menu. The main menu appears on the screen. - Page 37 1.3 Edit Favourite Channels Channel You can edit your favourite channels using the colour buttons. Auto Store ➢ In the case of DTV mode, OK or Select can be used as the Manual Store ENTER/OK button. Edit Favourite Channels ...
- Page 38 1.4 Channel List Channel List BBC TWO All Channels-All You can display a list of all channels or your favourite channels. Press the ▲ or ▼ button to select Channel List, then 1. Test Card ‘M’... 40. BBC NEWS24 806 arte 2.
- Page 39 To view programme information, press the ▲/▼/◄/► button to select a programme of your choice, then press the INFO button. ➢ Information such as the channel number, programme title and running time, status bar, and brief summary of the highlighted programme will be displayed in the top right corner of the screen.
- Page 40 2.4 All Channels and Favourite Channels Guide In the EPG menu, you can display all channels or favourite Now & Next Guide channels. Full Guide Press the green button repeatedly to toggle between the all Scheduled List and favourite channels list. Default Guide : Full Guide ...
- Page 41 3.2 Preference Language This menu consists of 6 sub-menus: Audio Language Primary Audio Language, Secondary Audio Language, Subtitle Language Primary Subtitle Language, Secondary Subtitle Language, Teletext Language Primary Teletext Language, and Secondary Teletext Preference Language. Using this feature, users can select one of the languages (English, German, Italian, Swedish, French, Welsh, Gaelic, Move Enter...
- Page 42 4. Setup Setup This menu consists of 8 sub-menus: Menu Transparency : Medium Menu Transparency, Parental Lock, Subtitle, Subtitle Mode, Parental Lock Audio Format, Digital Text, Time Zone, and System. Subtitle : On 4.1 Menu Transparency Subtitle Mode : Normal ...
- Page 43 4.3 Subtitle / Subtitle Mode / Audio Format / Digital Text Setup You can use various settings to suit your personal preferences. Menu Transparency : Medium Press the ▲ or ▼ button to select required menu (Subtitle, Parental Lock ...
- Page 44 Time Zone − Product Information System You can view your product information. For service or repair, please contact a Samsung approved dealer. Press the ENTER/OK button with Product Information Move Enter Return selected. The product information menu is displayed.
- Page 45 − Common Interface Installing the CI Card Application Info. a. Purchase the CI CAM module by visiting your nearest Type: CA dealer or by phone. Manufacturer: Canal Plus b. Insert the CI CARD into the CAM in the direction of Info: Top Up TV the arrow until it fits.
-
Page 46: What Is Anynet
What is Anynet+? Anynet+ is an AV network system that enables an easy-to-use AV interface for users by controlling all connected AV devices through the Anynet+ menu when Samsung Electronics AV devices are connected. Connecting Anynet+ Devices The Anynet+ system supports AV devices supporting Anynet+ only. -
Page 47: Setting Up Anynet
Setting Up Anynet+ The following settings are to use Anynet+ functions. Using the Anynet+ Function View TV Select Device Press the Anynet+ button. Record Press the ▲ or ▼ button to select Setup, then press the Menu on Device ... -
Page 48: Recording
Anynet+ Menu The Anynet+ menu changes depending on the type and status of the Anynet+ devices connected to the TV. Anynet+ Menu Description View TV Switches from Anynet+ to TV broadcast mode. Select Device Your TV connects to the corresponding device. Record Starts a recording. -
Page 49: Listening Through A Receiver
Listening through a Receiver You can listen to sound through a receiver instead of the TV speaker. Press the Anynet+ button. Press the ▲ or ▼ button to select Receiver, then press the ENTER/OK button. View TV Press the ◄ or ► button to select to On, then press the Select Device ... -
Page 50: Teletext Feature (Depending On The Model)
Teletext Feature (depending on the model) Most television stations provide written information services via teletext. The index page of the teletext service gives you information on how to use the service. In addition, you can select various options to suit your requirements by using the remote control buttons. - Page 51 The teletext pages are organized according to six categories: Part Contents Selected page number. Broadcasting channel identity. Current page number or search indications. Date and time. Text. Status information. FASTEXT information. ➢ Teletext information is often divided between several pages displayed in sequence, which can be accessed by: ...
-
Page 52: Wall Mount Kit Specifications (Vesa)
Samsung is not liable for these kinds of accidents. ➢ Samsung is not liable for product damage or personal injury when a non-VESA or non-specified wall mount is used or the consumer fails to follow the product installation instructions. -
Page 53: Setting Up Your Remote Control
Setting Up Your Remote Control After it has been set up properly, your remote control can operate in five different modes: TV, VCR, Cable, DVD, or Set-Top Box. Pressing the corresponding button on the remote control allows you to switch between these modes, and control whichever piece of equipment you choose. ➢... - Page 54 Downloaded From TV-Manual.com Manuals English - 54...
-
Page 55: Remote Control Codes
Remote Control Codes Brand Code Brand Code SAMSUNG 000 001 002 003 004 005 077 078 079 MITSUBISHI 019 034 041 046 ADMIRAL MONTGOMERY WARD AIWA 002 025 AKAI 004 027 032 MULTITECH 002 005 025 038 AUDIO DYNAMICS 007 026 007 008 018 026 037 062 064 BELL&HOWELL... -
Page 56: Cable Box
PIONEER 004 018 020 044 WARNER AMEX 014 022 040 ZENITH 017 029 035 037 045 REGAL SAMSUNG SET-TOP BOX Product Code Ground wave STB 000 001 002 008 013 000 004 008 013 CABLE STB 000 003 008 013... - Page 57 SAMSUNG DVD Product Code Product Code 000 001 002 Home Theater VCR COMBO 014 015 016 DVDR 003 004 HDD Record COMBO BD Record 005 006 TWIN TRAY COMBO VCR COMBO 007 008 009 010 011 STB DVD COMBO VCR Record...
-
Page 58: How To Assemble The Stand-Base (Depending On The Model)
Always store the TV upright. Troubleshooting Before contacting the Samsung after-sales service, perform the following simple checks. If you cannot solve the problem using the instructions below, note the model and serial number of the television and contact your local dealer. -
Page 59: Specifications
Specifications The descriptions and characteristics in this booklet are given for information purposes only and are subject to modification without notice. Model Name PS-50P96FD PS-58P96FD PS-63P76FD Screen Size (Diagonal) 50 inch 58 inch 63 inch PC Resolution 1920 x 1080 @ 60 Hz... -
Page 60: Correct Disposal Of This Product
Correct Disposal of This Product (Waste Electrical & Electronic Equipment) (Applicable in the European Union and other European countries with separate collection systems) This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life. - Page 61 Se tem algumas dúvidas ou comentários sobre os produtos Samsung, contacte por favor a nossa linha de apoio a clientes Samsung. Obrnite se na SAMSUNG WORLD WIDE (GLOBALNI SAMSUNG) V primeru vprašanj ali pripomb v zvezi z izdelki Samsung se obrnite na center za pomoč strankam SAMSUNG. Contacte con SAMSUNG WORLD-WIDE Si tiene alguna pregunta o comentario referente a nuestros productos, por favor contacte con nuestro Servicio de Atención al Cliente.
- Page 62 BELGIUM 0032 (0)2 201 24 18 www.samsung.com/be 844 000 844 www.samsung.com/cz CZECH REPUBLIC Distributor pro Českou republiku: Samsung Zrt., česka organizační složka Vyskočilova 4, 14000 Praha 4 DENMARK 70 70 19 70 www.samsung.com/dk FINLAND 030-6227 515 www.samsung.com/fi 3260 SAMSUNG(726-7864) FRANCE www.samsung.com/fr...
