Positioning The Microphone - Sennheiser e606 Instructions For Use Manual

Positioning the microphone

Loudspeaker of a guitar amplifier
Position
In order to prevent interference due to crosstalk between
adjacent sound sources, try to position the microphone so
that the interfering sound source is located in the angle
area of the highest cancellation of the microphone
(approx. 135°; see polar diagram)
4
Resulting sound
Many trebles,
aggressive sound
Less trebles, more
lower mids,
smoother sound
Balanced, natural
sound
Less trebles, more
lower mids,
smoother sound
Commentary
Microphone directed
towards the dome of
the loudspeaker.
Good starting position:
Microphone directed
towards the middle
between dome and
edge of the loud-
speaker. If necessary,
turn the microphone by
approx. 30° towards
the edge.
Microphone directed
towards the edge of
the loudspeaker.
