- Page 1 CHAuFFE-PIsCINE COMMERCIAL POOl HEAT PumP Owner’s Manual PRINTED IN CANADA...
-
Page 2: Table Of Contents
Table of contents Introduction General safety Instructions Thermeau models’ specifications Installation Instructions location water piping Electrical Bonding Bonding and plumbing step-by-step instructions Electrical Connections Electrical Diagrams service Analyzer Control Electronic Temp. Controls Initial startup meaning of Display Codes Troubleshooting Requesting Assistance or service... -
Page 3: Introduction
In general, compared to other types of pool heaters, such as gas or oil- fired, the THERmEAu pool heat pump has a lower heating capacity on a BTu/hr basis. Therefore, it needs to operate for a longer time to accomplish the desired results. - Page 4 Please read carefully whenever you call to request service for your heater, you must know your complete model and serial numbers. You can find this information on the name plate located on the right side of your heater. Please also record the purchase date of your device and your dealer’s name, address, and telephone number.
-
Page 5: General Safety Instructions
General Safety Instructions We care for our customers we have provided important safety messages in this manual and on your heater. Always read and obey all safety messages. IMPORTANT The ImPORTANT sign calls attention to a note that provides important information or information essential to the completion of a task. - Page 6 CAUTION All electrical connections must be done by a qualified electrician and according to the local electrical codes. Always cut off the unit’s main power whenever the access panel is open or removed. Always install the machine outdoors (unless otherwise approved by the manufacturer), while respecting the minimal clearances needed for proper operation and heating.
-
Page 7: Thermeau Models' Specifications
A robust and reliable product line ModEl TH-150 TH-150-3 TH-200 TH-200-3 TH-200-3A BTu 80 water / 80 air / 142,000 – 6 150,000 – 6.2 185,000 – 5.6 200,000 – 6.1 200,000 – 6.1 80 % humidity BTu 80 water / 80 air / 132,000 –... -
Page 8: Installation Instructions
The THERmEAu pool heat pump is designed for outdoor installation and should not be installed in a fully enclosed area, such as a shed, garage, etc., unless ventilation is provided to ensure adequate air exchange for proper operation. -
Page 9: Water Piping
Water piping IMPORTANT The piping sequence is as follows: pool pump > filter > heater > pool. Auto- mated chlorine distribution systems, if used, must be placed downstream of the heater to minimize harm to the pool equipment. use rigid PVC piping if possible (sCH40 or sCH80). -
Page 10: Multiple Heat Pump Connections
Multiple Heat Pump Connections All plumbing on multiple heat pump installations must be done in parallel. An equal flow of water to each heat pump is important for optimum operation. NOTE: It may be necessary to adjust water pressure switch if a unit is installed below the water level. -
Page 11: Electrical
Electrical CAUTION The wiring of your THERmEAu pool heat pump should be performed by a qualified electrician in accordance with local requirements. WARNING The unit must always be deactivated before opening the access panel. Bonding WARNING Because all metals have different electrical potentials, all metal and electrical components of the pool system must be bonded together. -
Page 12: Electrical Connections
Electrical Connections WARNING The installation of the THERmEAu pool heater should be performed by a cer- tified electrician. To connect the electricity, you must unscrew the four screws of the front panel, then slide the electric cable in the hole located on the left or the right side of the base, and then insert it in the control box. -
Page 13: Electrical Diagrams
OwNER’s mANuAl CHAuFFE-PIsCINE COMMERCIAL POOl HEAT PumP... -
Page 14: Service Analyzer Control
Service Analyzer Control The control panel is factory set to display the temperature in Fahrenheit degrees. Heating mode Temperature Compressor running and parameter Heating mode display To raise the desired Access temperature or to to parameters change parameters To lower the desired temperature or to change parameters Fig. - Page 15 Buttons: Press the sET button to change between modes and use the up and down arrows to change the selected mode’s settings. Modes available are : POOL Allows you to change the pool water temperature set point. Allows you to change the spa water temperature set point. Changes between pool and spa settings.
- Page 16 For 2 wire remotes 1. Bring up « POl » setting and arrow temperature down until pool setting reads « off ». 2. Bring up « sPA » setting and arrow temperature up until spa setting reads 104. 3. set unit to the « POl » mode. 4.
-
Page 17: Initial Startup
Connection to AquaLink, Compool, Hayward, AquaLogic or any other 2 wire remote system with their own thermostat : • Remove gray jumper from terminals 1 and 2 on TB1 • Bring the two wires from the remote system to terminals 1 & 2 on Terminal Block 1 (TB1) •... -
Page 18: Meaning Of Display Codes
Meaning of Display Codes Service Analyzer Codes most problems will be detected by the service analyzer and a code will be displayed on the digital display of your heater. Display Meaning of codes The desired programmed temperature point is lower than 60°F (15°C). LP &... -
Page 19: Troubleshooting
Troubleshooting The pool heater is not running. Heat pump control set to OFF. Raise temperature set point above 60°F (15°C). Desired water temperature unit will automatically restart is reached. when the water temperature goes below the set point. main breaker is tripped. Reset it. - Page 20 There is water around the unit. while your THERmEAu pool To check if the water really is a heater is in the heating mode,...
-
Page 21: Requesting Assistance Or Service
Requesting Assistance or Service IMPORTANT All service will be handled by an Authorized service Center. warranty may be voided if service is not done by an Authorized service Representative. Do not return the heater to your dealer as they do not provide service. Before calling for assistance or service, please check the “Troubleshooting”... -
Page 22: Maintenance
Maintenance Dirt can accumulate on the evaporator. You can easily remove it by using a water spray without damaging the small aluminum fins. The cleaning of the cabinet can be done with the help of a brush and soap. Winterizing First, you must turn the breaker off. -
Page 23: Pool Heat Pump Warranty
(5) years limited warranty. During the first (1) year, the costs incurred by the parts and labor needed to repair the compressor will be the responsibility of Thermeau Industries inc. During years two (2), three (3), four (4) and five (5), only parts will be covered by the warranty. - Page 24 CHAuFFE-PIsCINE COMMERCIAL POOl HEAT PumP...
