- Page 1 Instruction Manual Silver Fridge Freezer LFC50S12 Fridge Freezer LFC50W12 LFC50S_W12_IB_Running Change_121209_Annie.indd 1 12年12月9日 下午6:30...
- Page 2 LFC50S_W12_IB_Running Change_121209_Annie.indd 2 12年12月9日 下午6:30...
-
Page 3: Table Of Contents
Contents Unpacking ............................ 4 Location ..................................5 Reversing the Door Swing ........................... 5 Levelling the Unit ..............................9 Cleaning Before Use .............................. 9 Before Using Your Unit ............................9 Product Overview ........................10 Operation ........................... 11 Switching On Your Unit ............................11 Adjusting the Temperature ..........................11 Noises Inside the Unit! ............................11 Shopping for Chilled Foods ..........................12... -
Page 4: Unpacking
Thank you for purchasing your new Logik Fridge Freezer. We recommend that you spend some time reading this instruction manual in order that you fully understand all the operational features it offers. Read all the safety instructions carefully before use and keep this instruction manual for future reference. -
Page 5: Location
INSTALLATION Location When selecting a position for your unit you should make sure the floor is flat and firm, and the room is well ventilated with an average room temperature of between 16°C and 32°C. Avoid locating your unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct sunlight as it may increase the electrical consumption. - Page 6 INSTALLATION 2. Remove the 2 screw covers first, then undo the screws underneath. 2. Remove the 2 screws on the back. 3. Lift the top cover away from the fridge. 4. Remove the three screws, then remove the upper hinge that hold the door in place.
- Page 7 INSTALLATION 6. Take off the middle hinge by removing the screws. Lift the lower door and place it on a padded surface to prevent it from scratching. Remove the screws’ covers and place unscrew them to the opposite side. 7. Move the bottom bushing and bottom bushing cap of the lower door to the opposite side.
- Page 8 INSTALLATION 11. After placing the freezer door, screw the middle hinge back onto the opposite Middle hinge side of the unit. Ensure the freezer door is aligned horizontally and vertically, so that the seals are closed on all sides before finally tightening the hinge. 12.
-
Page 9: Levelling The Unit
INSTALLATION Levelling the Unit To do this adjust the two levelling feet at the front of the unit. If the unit is not level, the doors and magnetic seal alignments will not be covered properly. Cleaning Before Use Wipe the inside of the unit with a weak solution of bicarbonate soda. Then rinse with warm water using a ‘wrung-out’... -
Page 10: Product Overview
Product Overview Internal Light & Thermostat Control Dial Upper Fridge Door Shelf Adjustable Glass Shelves Salad Bin Bottom Fridge Door Shelf Freezer Freezer Drawers Door Adjustable Feet Egg Tray Ice Tray LFC50S_W12_IB_Running Change_121209_Annie.indd 10 12年12月9日 下午6:31... -
Page 11: Operation
Operation Switching On Your Unit 1. Connect the mains cable to the mains socket. The internal temperature of your unit is controlled by a thermostat. There are seven settings, of which position 7 is the coldest and position OFF turns the unit off. -
Page 12: Shopping For Chilled Foods
Shopping for Chilled Foods • Take a quick look at the chilled food package and make sure it is in perfect condition. • Try to keep chilled food together whilst shopping and on the journey home as this will help to keep the food cold. -
Page 13: Preparations For Freezing
Preparations for Freezing • Use quality food and handle it as little as possible. Freeze food in small quantities as it freezes faster, takes less time to defrost and enables you to control the quantity you need better. • Leave cooked food to cool completely. Chill food before freezing if possible. • Consider how you will want to cook the food before freezing it. -
Page 14: Cleaning
Cleaning Defrosting The freezer compartment of this unit is frost-free. With proper use, there should not be any frost accumulated. However, in case of improper use of the freezer compartment, frost might build up in the freezer compartment after the unit has been used for a period of time. Scrape e away the frost using a plastic scraper (not included). -
Page 15: Maintenance
Maintenance Changing the Internal Light The internal light is a LED light. It cannot be changed by the user; please contact your service agent. Care When Handling / Moving the Unit Hold the unit around its sides or base when moving it. Under no circumstances should it be lifted by holding the edges of the top surface. -
Page 16: Specifications
Specifications Model LFC50S12 / LFC50W12 Appliance Category Category 7 (Refrigerator – Freezer) Overall Dimension (W x D x H) 501 x 560 x 1525 mm Total Gross Volume 175 L Fresh Food Storage Compartment 119 L Volume Frozen Food Storage Volume... -
Page 17: Safety Warnings
Safety Warnings For your continued safety and to reduce the risk of injury or electric shock, please follow all the safety precautions listed below. • Read all instructions carefully before using the unit and keep them for future reference. • Retain the manual. If you pass the unit onto a third party, make sure to include this manual. • Keep ventilation openings in the unit enclosure clear of obstructions. - Page 18 Normal energy Increased energy consumption consumption Installation site In a ventilated room. In an enclosed, unventilated room. Protected from direct sunlight. In direct sunlight. Not situated near to a heat source Situated near to a heat source (radiator, oven). (radiator, oven). Where the ideal ambient room Where there is a high ambient temperature is approx 20°C.
- Page 19 NOTE: If you require a replacement for any of the items listed below, please quote their corresponding part numbers: Replacement Part Part Number Adjustable Glass Shelf 503601040008 Salad Bin 501117810148 Small Freezer Drawer 50111721000C Large Freezer Drawer 501107030009 Egg Tray 501119710072 Ice Tray 501113810004...
- Page 20 LFC50S_W12_IB_Running Change_121209_Annie.indd 20 12年12月9日 下午6:31...
- Page 21 LFC50S_W12_IB_Running Change_121209_Annie.indd 21 12年12月9日 下午6:31...
- Page 22 LFC50S_W12_IB_Running Change_121209_Annie.indd 22 12年12月9日 下午6:31...
- Page 23 LFC50S_W12_IB_Running Change_121209_Annie.indd 23 12年12月9日 下午6:31...
- Page 24 LFC50S_W12_IB_Running Change_121209_Annie.indd 24 12年12月9日 下午6:31...
