SERVICE MANUAL

Production change notice :
Attachment direction of fan(FN902).
Direction of inhalation of air.
(Page 11, 17 and 62.)
Part No.
Filter-net-B (Page-63 NO. 19 )
610 292 3179
610 297 5383
Owner's manual for PLC-XF30 only.
610 293 5073
(009MY6A).
610 293 5080
610 293 5097
610 293 5103
Owner's manual for PLC-XF30N only.
610 297 8032
(009MY6AA).
610 297 8049
610 297 8056
610 297 8063
610 297 8070
Owner's manual for PLC-XF30NL only.
610 297 5383
(009MY6AL).
Serial No.
PLC-XF30 .
G1601001~G2101420
PLC-XF30N .
G1X01001~G1Z01130
PLC-XF30N L .
G1X01061~G1Y01120
Note : About the model before change.
