Part Number Index - Land Pride RCR2560 Parts Manual

Section 2: Decks
Deck
Applies to RCR2560, RCR2572
Ref . Part No. Part Description
dwg15872 Drawing Image Number
1. 803-231C NUT WING 3/8-16 PLT
2. 312-399H SHIELD WELDMENT
3. 312-400H SHIELD MOUNT BRACKET WELDMENT
4. 804-013C WASHER LOCK SPRING 3/8 PLT
5. 802-159C HHCS 5/16-18X1 GR5
6. 804-009C WASHER LOCK SPRING 5/16 PLT
7. 826-035C GEARBOX RC61SS 1:1.46 INCREASE
8. 803-299C NUT HEX FLG TOP LK 3/4-10 PLT
9. 312-611D BLADE BOLT ACCESS COVER
9. 312-647D BLADE BOLT ACCESS COVER
10. 803-024C NUT LOCK 5/8-11 PLT
10. 803-021C NUT HEX 5/8-11 PLT
11. 804-022C WASHER LOCK SPRING 5/8 PLT
12. 804-021C WASHER FLAT 5/8 SAE PLT
13. 312-608D HITCH STRAP
13. 312-646D HITCH STRAP
14. 802-051C HHCS 5/8-11X1 1/2 GR5
14. 802-053C HHCS 5/8-11X1 3/4 GR5
15. 803-013C NUT LOCK 3/8-16 PLT
16. 802-064C HHCS 3/4-10X2 GR5
16. 802-212C HHCS 3/4-10X2 1/2 GR5
16. 802-065C HHCS 3/4-10X2 1/4 GR5
17. 312-602D SKID SHOE
18. 802-466C PLOW 3/8-16X1 1/4 GR5
19. 803-170C NUT HEX TOP LOCK 1 1/8-12 PLT.
20. 804-147C WASHER FLAT 1 HARD ASTMF436 PN
21. 312-388H 27 OVAL DISHPAN WELDMNT(OMNI)
21. 312-404H 15 ROUND DISHPAN WLDMNT(OMNI)
22. 820-137C CUTTER BLADE 1/2 X 4 X 25 CCW
22. 820-193C CUTTER BLADE 1/2X4X25 LL CCW
23. 802-277C BLADE BOL 1 1/8-12X3 7/16 W/KY
24. 804-012C WASHER FLAT 3/8 SAE PLT
25. 803-095C NUT HEX SLOTTED 1-14
26. 805-017C PIN COTTER 3/16 X 1 3/4 PLT
27. 802-064C HHCS 3/4-10X2 GR5
28. 805-163C PIN HITCH CAT. 2-1 FORGED
29. 312-386H RCR2572 DECK WELDMENT
29. 312-402H RCR2560 DECK WELDMENT
30. 804-025C WASHER FLAT 3/4 SAE PLT
31. 804-023C WASHER LOCK SPRING 3/4 PLT
32. 803-026C NUT LOCK 3/4-10 PL
32. 803-027C NUT HEX 3/4-10 PLT
33. 312-607D HITCH BRACE
34. 805-142C PIN CLEVIS 3/4 X 3 1/2 PLT
35. 122-076D PW PIVOT TUBE LONG
36. 805-143C PIN HAIR COTTER .120 PLT
37. 802-070C HHCS 3/4-10X6 GR5
38. 312-610D SPACER TUBE 1 1/8 OD X 3 1/8
39. 312-609D PIVOTING UPPER HITCH
40. 817-050C GEARBOX SHAFT PROTECTOR
41. 827-010C BUSHING 7/8ID X1 1/8OD,1 3/4LG
42. 804-036C WASHER FLAT 5/16 SAE PLT
43. 804-070C FLAT WASHER 1 SPECIAL
44. 312-075D BLADE SPACER 16 GA .06 THICK
44. 312-082D BLADE SPACER 18 GA .05 THICK
44. 312-089D BLADE SPACER 20 GA .04 THICK
08/29/11
Table of Contents
RCR2560, RCR2572, RCR2584 & RCR2684 Rotary Cutter 312-459P

Part Number Index

Comments
(S/N 232953-)
(S/N 232953-)
(S/N 232953-)
(S/N 232953-)
(S/N 232953-)
RCR2572
RCR2560
Replaced by 803-024C
Replaced by 803-024C
RCR2572
RCR2560
(S/N 286260+)
(S/N 286259-)
RCR2572
RCR2560
Standard (Quantity 2 per cutter)
Optional Low Lift Blade (Quantity 2
per cutter)
Shown
RPBY 803-026C
RPBY 803-026C (S/N 286259-)
(S/N 286260+)
(S/N 286259-)
(S/N 220346-)
(S/N 232954-)
As Required
As Required
As Required
Land Pride
Revision
Rev 2; Use up stock
Rev 1; Use up stock
Rev 1; Use up stock
Rev 1; Use up stock
Rev. 2
Rev 1; Use up stock
Rev 2; Use up stock
Rev 1; Use up stock
Rev. 2
Rev 1; Use up stock
11
