3.8 Channel Scan
Your radio can scan the 8 channels to any activity. This allows to find
other radios without having to change the channel.
To activate this feature:
a. Press and old the and
scanning will start immediately, with SC displayed on the
screen and the channel number cycling through the channels.
When a signal is detected, the unit will pause on that channel, while
receiving the signal and for a further 3 seconds.
b. Press the PTT button to stop scanning and talk on that channel,
or press the or button to manually start the scanning.
c. To stop the scanning, press the
standby mode.
3.9 Monitor Feature
You can use the Monitor feature to check for weaker signals in the
current channel.
a. Press and hold the and
receiving icons "RX" appears on the display.
Your handset will pick up any signals on the current channel.
b. Press the button to stop the monitoring
4.0 To Lock the Buttons
With the buttons lock you can still transmit (TX), or call the current
channel, but you can not change the volume. To activate this
feature;
In the standby mode, press and hold the
icon appears on the LCD screen.
To unlock the buttons
Press and hold again the
disappears on the LCD screen.

5. Auxiliary Features

5.1 Power Saving
Your PMR unit has special circuitry designed to extend the life of
your battery. When the unit is not used for 4 seconds, it will
automatically switch into a low power mode. The Power
feature does not affect the PMR ability to receive
transmissions. When a signal is detected, it automatically
returns to full power mode.
button at the same time and channel
button and return to
button at the same time. The
until the
button until the icon
5.2 Low Battery Meter Indicator
The PMR can detect the low battery level when battery
voltage goes low. The battery icon will display the low
battery status as follows.
When battery voltage at low battery level. The empty battery
symbol will appear at this stage and continue to blink
The battery icon will continue to blink until it totally drain
the battery voltage.
Note: To have good communication, once the battery reach
in low battery level, replace the batteries into new ones.
5.3 Microphone/Earphone/Charger Jack
The SMR 130 is equipped with and auxiliary microphone, earphone,
and charge jack located at the opposite side of PTT button.
Note: It requires a microphone/earphone with a 2.5mm, 3-pole
jack connector and this is not supplied with your SMR 130.
5.4 Using a Hands free kit (Headset)
You can plug a hands free kit into the
right side of your FX-238 handset. With
hands free kit, by pressing the PTT button
to transmit and talk with other radios
5.4 Specifications
Channels Available
Output Power (TX)
Range
Channel Frequency Table
Channel Frequency (MHz)
1 446.00625
2 446.01875
3 446.03125
4 446.04375
8 Channels
0.5 W
Up to 5 Km.
Channel Frequency (MHz)
5 446.05625
6 446.06875
7 446.08125
8 446.09375
