Fiat Bravo/Brava Workshop Manual page 439

Electrical equipment
Interconnections
Bravo-Brava
98 range
55.
T r i m level: ELX - H S X - H G T
Electric f r o n t w i n d o w s
Components key
3 Power fuse box:
A 30A protective fuse for injection system (60A for
TD versions)
B 40A protective fuse for ignition system
C 30A fuse protecting additional options
D 80A protective fuse for junction unit
4 Junction unit
10 Earth for battery on bodyshell
11 Battery
12 Ignition switch
22 Left dashboard earth
35 Dashboard/left front door cables connection
36 Dashboard/right front door cables connection
42 Right dashboard earth
73 Left front electric w i n d o w control panel
74 Right electric front w i n d o w control panel
75 Right electric front w i n d o w control panel
in left front door
76 Left front electric w i n d o w motor
77 Right front electric w i n d o w motor
91 Power relay
293 Fuse carrier base on dashboard cable
C 25A fuse protecting Electric rear w i n d o w s (non existent
for the SX versions)
D 2 5 A fuse protecting A . B . I , control unit; Central locking
control unit
330 A.B.I, control unit
N.D. Ultrasound welding taped in cable loom
o c Dashboard/left front door cables connection. Trim level: ELX - HSX - HGT
GV n.d.
NV287
N22
RG n.d.
GN28A
RV 330A
RN28A
AL289
ER28A
AN28A
SV 330A
CN 330A
■
■
■
■
N79
RG51
■ RV 75
RN80
A110B
GN79
BR67 — '
AN 78 — '
■ S75 —
■ CN 73
_.. ..
AB78
///
I
l\
I
* Variant connection for versions with alarm
** Variant connection for versions with automatic transmission
g g Dashboard/right front door cables connection. Trim level: ELX - HSX - HGT
GH n.d.
ZB 330A ■
LB 7 0 * *
SN n.d.
* * L B 6 8
SN52
■ AB74
A 1 1 1 B
■ A N 74
L R 6 8
N Z 5 2
H R 6 8
H 111A
Variant connection for versions with alarm
* Variant connection for versions with air conditioning
The cables in the wiring diagram are marked
46
Print no. 506.670/18
