Important Information
The R2500 is a 250 constant current welding power source
based on IGBT technology. The Inverter drive circuitry operates
above the audio frequency spectrum making the R2500 virtu-
ally silent in operation. The high operational frequency also
means that the R2500 is able to respond quickly to changing
arc dynamics, making for a very smooth , stable arc.
The R2500 is capable of TIG welding with the addition of an
external TIG control unit (TIG300).
INSTRUCTION MANUAL
To maintain continued developments of our products we reserve the right to alter specifications as quoted without prior notice
R2500
Newarc Equipment Ltd.
UK's Leading Manufacturer Of Welding Equipment
Newcastle +44 (0) 191 295 0111
Aberdeen +44 (0) 1224 771 063
www.newarc.co.uk
Description
MMA unit
Processes

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R2500 and is the answer not in the manual?

Questions and answers

Related Manuals for NewArc R2500

Summary of Contents for NewArc R2500

  • Page 1 R2500 is able to respond quickly to changing arc dynamics, making for a very smooth , stable arc. The R2500 is capable of TIG welding with the addition of an external TIG control unit (TIG300). INSTRUCTION MANUAL Newarc Equipment Ltd.

  • Page 3: Table Of Contents

    3.2 - Connecting to mains supply______________________________________________ 6 SECTION 4 — OPERATION 4.1 - Description of Controls__________________________________________________ 4.2 - Operation_____________________________________________________________ SECTION 5 — FAULT FINDING AND MAINTENANCE 5.1 - MMA Welding Problems________________________________________________ 5.2 - Maintenance__________________________________________________________ SECTION 6—PARTS BREAKDOWN 6.1 - Component Locations__________________________________________________ 6.2 - Parts List_______________________________________________________________ R2500...

  • Page 4: Welding And Earth Return Cables

    The safe handling of gas cylinders Pay attention to fire and safety regulations in force at the The R2500 uses argon when TIG welding using the TIG300. welding site. This is an inert gases and can displace oxygen in the at- mosphere leading to asphyxiation.

  • Page 5: Section 2 - Specification

    R2500 is able to respond quickly to changing arc dynamics, making for a very smooth , stable arc. The R2500 is capable of TIG welding with the addition of an external TIG control unit (TIG300).

  • Page 6: Section 3 - Installation

    SECTION 3 — INSTALLATION 3.1 Siting the R2500 Site the R2500 on a clean dry surface, preferable • Strip approximately 150mm of insulating sheath off the end above ground level. • of the mains cable, strip back the insulation on the four Make sure there is at least 20cm clearance at the front, •...

  • Page 7: Section 4 - Operation

    Mode switch - Selects the welding mode. understood the TIG300 manual. Current control - Adjusts the machines output current. Connect the TIG300 to the R2500 as per the diagrams in • the TIG300 manual. Power indicator - indicates mains power, lights up when Turn the mode switch to TIG remote, All control of the •...

  • Page 8: Section 5 - Fault Finding And Maintenance

    Note! All Electric shocks are potentially fatal, switch the machine off and unplug from the mains supply before carrying out any maintenance work. It is very important that the R2500 is regularly maintained. The amount of use and the working environment must be taken into account when scheduling the maintenance periods.

  • Page 9: Section 6-Parts Breakdown

    SECTION 6 — PARTS BREAKDOWN 6.1 Parts Locations R2500...

  • Page 10: Parts List

    SECTION 6 — PARTS BREAKDOWN 6.2 R2500 Parts list Item no. Description Part No. Cable clamp M00825 Main switch 3P/70A M70072 Mains input PCB M90543 Fuse 2A M00274 Switch PCB M90558 Plastic foot M00096 Control PCB M90127A Auxiliary transformer M00289...
  • Page 12 Tel: +44 (0)191 295 0111 Tel: +44 (0)1224 771063 Fax: +44 (0)191 295 0077 Fax: +44 (0)1224 724536 Website: www.newarc.co.uk e-mail: sales@newarc.co.uk Guarantee New-Arc Equipment Ltd warrants that its goods and services are guaranteed to meet the specific performance under the stated conditions of use. New-Arc cannot be held responsible for general wear and tear or for failure occurring due to misuse or abuse arising out of circumstances outside the stated conditions of use.
