Panasonic DMR-EX75EB Quick Setup Manual

What is Q Link?
Q Link enables you to connect this unit to a Q Link-
equipped Panasonic TV and perform various linked
functions.
The following systems from other manufacturers have
similar function to Q Link from Panasonic.
For details, refer to your television's operating
instructions or consult your dealer.
Accessories
Remote Control
DVD
TV
DRIVE CH VOLUME
SELECT AV
PAGE
1 2 3
4 5 6 CH
7 8 9 VIDEO Plus+
EUR7659YG0 DELETE
0 SELECT INPUT
SKIP SLOW/SEARCH
STOP PAUSE PLAY/
PROG/CHECK
ENTER
OK
SUB MENU RETURN
CREATE
CHAPTER MANUAL SKIP
REC REC MODE EXT LINK DIRECT TV REC
TEXT STTL DISPLAY TIME SLIP
AC Mains Lead
RJA0044-3C or
K2CT3CA00004
For use with this unit only.
Do not use it with other equipment.
Also do not use the cords for other
equipment with this unit.
What kind of input terminal does your television have?
Scart
Component video
S Video
Audio/video
Please check and identify the supplied accessories.
Use numbers when asking for replacement parts.
(Product numbers correct as of March 2006.
These may be subject to change.)
Batteries for the
Remote Control
R6 size
Audio/video cabel
K2KA6BA00003
2x RF coaxial cables
(black)
(K1TWACC00001)
1x RF coaxial cable
(grey)
(K1TWACA00001)
Highly recommended connection.
You can enjoy high-quality RGB video from this unit
by connecting to an RGB compatible television.
If your television has the Q Link feature, you can use
a variety of useful functions.
These terminals provide a purer picture than the
S Video terminal.
If your television is compatible with progressive
scan, you can enjoy high-quality progressive video.
If you have a progressive compatible CRT television,
we cannot recommend this connection as some
flickering may occur.
This terminal achieves a more vivid picture than
the video terminal.
The most basic connection.
Q Link (registered trademark of Panasonic)
Easy Link (registered trademark of Philips)
SMARTLINK (registered trademark of Sony)
DATA LOGIC (registered trademark of Metz)
Megalogic (registered trademark of Grundig)
Insert the batteries
into the remote control
Required cable(s) Page No. for
connections
Fully wired 21-pin
Scart cable
3 Video cables
(Operating Instructions)
S Video cable
(Operating Instructions)
Audio/Video cable
(included)
(Operating Instructions)
R6/LR6, AA
Page No. for
TV settings
2, 3
4
60
4
62
62
