Savage Cub
Flight Manual
Aircraft Type & Model: Savage Cub 912 100hp
Aircraft Registration Number: 24-5360
Aircraft Serial Number: 08-0123
Zlin Aviation S.R.O. 2. Kvetna N.685 763 61 Napajedla Czech Republic
www.zlinaero.com
+420 5779 41250
savage.ulm@tiscalinet.It
Savage Cub Australian Flight Manual
© X-Air Australia 2008
Release 1.2
Page 1 of 40
Advertisement
Table of Contents
Related Manuals for Zlin Aviation Savage Cub 912 100 hp
Summary of Contents for Zlin Aviation Savage Cub 912 100 hp
-
Page 1: Flight Manual
Savage Cub Flight Manual Aircraft Type & Model: Savage Cub 912 100hp Aircraft Registration Number: 24-5360 Aircraft Serial Number: 08-0123 Zlin Aviation S.R.O. 2. Kvetna N.685 763 61 Napajedla Czech Republic www.zlinaero.com +420 5779 41250 savage.ulm@tiscalinet.It Savage Cub Australian Flight Manual ©... - Page 2 Savage Cub Australian Flight Manual © X-Air Australia 2008 Release 1.2 Page 2 of 40...
-
Page 3: Table Of Contents
Table of contents Table of contents........................3 Amendment Record Sheet .......................4 Aircraft Identification and Specifications...................5 Introduction ..........................7 Revisions..........................7 Definitions ..........................8 Speeds ..........................8 Meteorological Terminology....................8 Engine Power Terminology....................9 Airplane Performance and Flight Planning Terminology............9 Weight and Balance Terminology..................9 Three View Drawing.......................10 Performance (Max take-of weight) ..................11 Dimensions.........................11 Weights..........................11 Speeds ..........................11... -
Page 4: Amendment Record Sheet
Take Off with Obstacles......................22 Take Off with Cross Wind ....................22 After Take Off ........................22 Climb ..........................22 Cruising Flight........................22 Takeoff..........................22 Landing..........................23 Normal Landing ........................23 Short Landing ........................23 Landing with Cross Wind ....................23 Aborted Landing .........................24 Stall.............................24 Balancing the Stall......................24 After Landing ........................24 Enroute Climb ........................24 Cruise ..........................25 Before Landing ........................25... -
Page 5: Aircraft Identification And Specifications
Aircraft Identification and Specifications Aircraft Registration Number 24-5360 Aircraft Manufacturer Zlin Aviation Aircraft Model Savage Cub LSA Aircraft Serial Number 07-0123 Manufactured Date December 2007 First Registration Date February 2008 Aircraft Colour Yellow with black stripe on side Aircraft MTOW... - Page 6 · XCOM VHF Radio · VHF Aerial 83730069 · Garmin 327 Digital · UHF Aerial · Transponder Aerial Transponder · GME 3220 UHF · GPS Aerial Radio · AirGizmo GPS Mount System Savage Cub Australian Flight Manual © X-Air Australia 2008 Release 1.2 Page 6 of 40...
-
Page 7: Introduction
Flight Manual for the aircraft. Amendments shall be issued by ZLIN Aviation s. r. o. as necessary and will take the form of replacement pages, with the changes to the text indicated by a vertical line in the margin together with the amendment date at the bottom of the page. -
Page 8: Definitions
Definitions Speeds Standard Atmosphere Standard Atmosphere is the pressure at sea level at 15°C. The standard lapse rate is approx. 2°C per 1000ft increase in altitude. Airfield Pressure Altitude The Airfield Pressure Altitude is that altitude registered at the surface of the aerodrome by an altimeter with the pressure subscale set to 1013 millibars Density Altitude The Pressure Altitude corrected for non standard... -
Page 9: Engine Power Terminology
Engine Power Terminology BHP Brake Horsepower The power developed by the engine. RPM Revolutions Per Minute Engine speed. Static RPM The engine speed attained during a full-throttle engine run-up when the airplane is on the ground and stationary. Airplane Performance and Flight Planning Terminology Maximum Crosswind Velocity The velocity of the crosswind component for which adequate control of the airplane during takeoff and... -
Page 10: Three View Drawing
Three View Drawing Savage Cub Australian Flight Manual © X-Air Australia 2008 Release 1.2 Page 10 of 40... -
Page 11: Performance (Max Take-Of Weight)
Performance (Max take-of weight) Dimensions Wing span 93l cm Length 639 cm Height 203 cm Wing surface area 14.2 m2 Wing chord 156 cm Cabin width 69 cm Undercarriage gauge 170 cm LSA Registration RAA Registration Weights Max take-of weight 560 Kg 544 Kg Empty weight... -
Page 12: Fuselage
Fuselage Consists of a reticular structure made up of TIG-welded 4130 aeronautical steel tubing. Access to the cockpit is gained via a single canopy on the right hand side of the fuselage which opens upwards. The fully adjustable seating frame, ample space for the pilots, good all-round visibility and ergonomic controls make flying comfortable and safe even over long distances. -
Page 13: Cabin
Cabin The cabin is tandem seating. Each pilot has a four point seatbelt. The pilot flies from the front seat when he flies solo. The baggage area can carry up to 20 Kg. Controls On the left side Two throttles One trim lever One flap lever On the floor:... -
Page 14: Limitations
Fuel capacity Total 2 x 34 litres Useable 2 x 32 litres Approved oil grades Motorcycle oil of a registered brand with gear additive Specification API classification SF or SG For temp above and below stated check engine manual Oil capacity Oil capacity is 3.5 litres Tyre inflation pressures... -
Page 15: Weights And Loading
Airspeed Indicator Markings and their operational significance are shown below. Marking Knots Significance White Arc 34 - 60 Full-flap operating range. Lower limit is max. weight Vso in landing configuration. Upper limit is max. speed permissible with flaps extended Green Arc 37 –... -
Page 16: Maximum Air Temperature For Operations
Maximum Air Temperature for Operations 50° C for takeoff at gross weight. Minimum Air Temperature for Operations -25° C for takeoff at gross weight. Maximum Permissible Number of Occupants Two (including Pilot). Flights with Door Open Fly with open door maximum 60 knots. Maximum Crosswind Velocity 15 knots Maximum Baggage Weight... -
Page 17: Checklist & Procedures
Then retract flap fully and continue to climb at or above Maximum Recommended Turbulent Air Penetration Speed Maximum Demonstrated Crosswind Velocity Checklist & Procedures Pre-flight Inspection Prior to flight, the aircraft should be inspected in accordance with the following checklists and in the sequence shown in the following diagram: NOTE Visually check airplane for general condition during walk-around inspection. -
Page 18: Pre-Flight Inspection Checklists
Pre-flight Inspection Checklists 1 Fuel Fuel Quantity Check level in tank through visual Water Check Before first flight of the day & after each refuelling, drain small quantity of fuel from fuel drain valve & check for water & sediment. Fuel Filler Cap Check secure on each wing 2 Empennage... -
Page 19: Before Starting Engine
Fuel Shutoff Valve Seatbelts and Shoulder Check condition and security Harnesses Aileron Cable Mountings Check for free rotation & excessive movement, bolts secure & anchors. Elevator Tube Mounting Check for free rotation & excessive movement, bolt secure & Rod Ends &... -
Page 20: Warm-Up And Functional Check
Warm-Up and Functional Check Warm-up the engine with a fast idle of 1500 - 2500 RPM until the oil temperature reaches 50 degrees C. During this phase, the cooling is insufficient due to reduced airflow. It is therefore advisable not to shorten the warm-up time by running the engine at higher RPM. The aircraft should be pointed into wind to allow additional cooling air. -
Page 21: Taxi Instructions
Taxi Instructions Normal taxi is provided with throttle, tail wheel and brakes. The right application and coordination makes taxing easy. Brakes and pedals are placed so they operate together. Let the speed of the airplane increase slowly and check the brakes operation. The tail wheel is used to control normal operations on the ground. -
Page 22: Take Off With Obstacles
Take Off with Obstacles Follow instructions as by the short take off after the T.O. rise up and increase the speed in ground effect to 56 – 60 knots, be sure that you will miss the obstacle. Take Off with Cross Wind Keep the flaps in the neutral position and follow the instructions for a normal takeoff (except for flaps) keep the runway direction with the rudder pedals. -
Page 23: Landing
Throttle FULL OPEN Brakes RELEASE Elevator Control LIFT THE TAIL Take off Speed 32 knots Landing Warning: In case of protracted descent with minimal engine speed, the engine can sometimes rapidly cool and ice can be formed in the carburettor. Therefore we remind you to be aware of carburettor icing. -
Page 24: Aborted Landing
Aborted Landing If it is necessary to abort the landing use full power. At the moment when sufficient speed or height is reached retract the flaps. (Speed 56-58 knots). Stall This airplane has good stability and the flight features. The features of the stall of this airplane are normal and gentle. -
Page 25: Cruise
Cruise Power Not above maximum continuous power of 5500 RPM. 4500 – 5000 Normal. Elevator Trim ADJUST. Before Landing Seatbelts & Harnesses ADJUST & LOCK Carburettor Head As required Fuel Boost Pump * ON – if present Landing Normal Landing Airspeed 43 knots Wing flaps... -
Page 26: Propeller Care
SAFETY WARNINGS Never prepare fuel in an area that is enclosed or where fumes could reach ignition point. DO NOT SMOKE or allow open flames or sparks in the vicinity. Never add fuel while the engine is running. Never refuel an aircraft if fuel could be spilled on hot engine components or lexan. (THE LEXAN WILL CRACK IMMEDIATELY IN THIS CASE) Use only approved fuel containers and never transport fuel in an unsafe manner. -
Page 27: Emergency Procedures
At altitudes under 2000 feet, avoid flying in close proximity to houses or over parks and recreational areas During approach to or departure from an airport, climb after takeoff and descent for landing should be made so as to avoid prolonged flight at low altitude near noise sensitive areas. -
Page 28: Operational Checklists
Maximum Glide Distance, Still Air 56 – 60 knots Precautionary Landing Approach with Engine Power 40 – 43 knots Landing Approach Without Engine Power landing Flaps Up 47 knots landing Flaps Down 43 knots Note: A slightly higher speed may give better distance over the ground if gliding into wind; a slightly lower speed if gliding downwind. -
Page 29: Fire
IMPORTANT DO NOT depress starter button while propeller is rotating. Ignition Switches Cabin Clear Increase angle off attack & reduce speed (up to & including a stall) until propeller stop rotation Establish Glide 56 – 60 knots Fuel Fuel Pump Master Ignition Switches Starter button... -
Page 30: Engine Fire In Flight
Engine Fire in Flight Throttle CLOSED Fuel Shutoff Valve Mag Switches Master Switch Fuel pump Switch Cabin Air Airspeed 56 – 60 knots (if fire is not extinguished, increase glide speed to find an airspeed which will provide an incombustible mixture). Forced Landing Execute (as described in Emergency Landing Without Engine Power). -
Page 31: Maximum Glide
Brakes as required Open Field Precautionary Landing with Engine Power Initial Airspeed 43 knots Wing Flaps Stage Fuel Pump Selected Field FLY OVER Note terrain and obstructions Radio and electrical Switches Wing Flaps FULL ( on final approach ) Touchdown Three point, as for airfield soft landing Ignition Switch Brakes... -
Page 32: Other Procedures
Just AFTER rudder reaches the stop, move the control stick FORWARD far enough to break the stall. HOLD these control inputs until rotation stops. Premature relaxation of control inputs may extend the recovery. As rotation stops, neutralise rudder and make a smooth recovery from the resulting dive Other Procedures Ignition Malfunction... -
Page 33: Weight And Balance Information
Flap Setting Zero Stage 1 Stage 2 Takeoff Landing 35 knots 33 knots 31 knots Nature of Stall Aircraft buffeting announce the stall. Takeoff & Landing Distances Takeoff 90 meters Landing ( Full Flap ) 70 meters Weight and Balance Information The flight envelope depends on airplane weight, and on the moment of CG according to the fixed point, which is determined by engineering contractor. - Page 34 2 main landing gear sx 154 cm. 3 pilot 170 cm. 4 fuel 193 cm. 5 passenger 253 cm. 6 baggage compartment 307 cm. 7 tail wheel 593 cm. METHOD Calculate the dead weights. These dead weights are multiplied with index and the result are the moments.
-
Page 35: Empty Weight
Savage Cub Weight and Balance Calculations Kgs Note: You can ONLY enter information into the Yellow highlighted boxes in this worksheet. If the GC range is OK it is highlighted GREEN, if it is outside CG range it is RED. If the plane is above the 560kgs MTOW the total weight is highlighted Black. -
Page 36: Load Factors Information For Pilots
Weight in Kg Arm in cm Moment 1 Left Landing Gear 20482 2 Right Landing Gear 132.5 20405 3 Pilot 20400 4 Fuel 8615.52 6 Baggage Compartment 3070 7 Tail Wheel 25.5 15121.5 Total Weight 465.64 88094.02 C.G. 189.2 Acceptable range of CG from 188 cm to 205cm Load Factors Information for Pilots It is necessary that every effort be made to determine in advance the worst loads likely to be... - Page 37 due to centrifugal forces acting on the object-forces which tend to pull the object away from the centre of the circle and keeps it moving in a straight line. You have increased the pull on the string to overcome these forces thus creating the centripetal forces noted above-forces which tend to push the object toward the centre of the circle and produce a curved path of travel.
- Page 38 An abrupt pull-up at high speed is very likely to cause structural failure. No matter how strong an airplane has been designed there is a speed above which it is possible to break the wings. Some military airplanes are so strong that the pilot "blacks out" before he can put enough load on the wings or reach a speed which would break the wings.
- Page 39 3. THOU SHALL EVER TAKE HEED UNTO AIR TRAFFIC RULES : Keep a constant lookout for other aircraft. Follow the rules so that pilots of other planes will know what you are going to do. 4. THOU SHALL NOT MAKE FLAT TURNS : This is particularly important when making power-off turns.
-
Page 40: Feedback Form
Feedback Form Zlin Aviation s.r.o. Customer Feedback Form Please return via mail to savage.ulm@tiscali.it Manual Title:_______________________________________________________________ Date of Issue: ______________________________________________________________ Section, Chapter, Paragraph Affected:___________________________________________ You’re Feedback: ___________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ Now Reads: _______________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ Should Read: ______________________________________________________________ _________________________________________________________________________...
