VL4000 Spot Luminaire
User's Manual

Advertisement

Table of Contents
loading

Related Manuals for Philips VARI-Lite VL4000

Summary of Contents for Philips VARI-Lite VL4000

  • Page 1 VL4000 Spot Luminaire User’s Manual...
  • Page 2 All other brand or product names which may be mentioned in this manual are trademarks or registered trademarks of their respective companies or organizations. Philips Vari-Lite reserves the right to change details of design, materials and finishes. Information, graphics, drawings, specifications, etc. are subject to ❋...
  • Page 3 To obtain warranty service, please contact customer service at 1-877-VARI-LITE (1-877-827-4548), +1-214-647-7880, or entertainment.service@philips.com and request a Return Material Authorization (RMA) for warranty service. You will need to provide the model and serial number of the item being returned, a description of the problem or failure and the name of the registered user or organization. If available, you should have your sales invoice to establish the date of sale as the beginning of the warranty period.
  • Page 4 EC Declaration of Conformity We, Philips Lighting B.V., 10911 Petal Street, Dallas, Texas 75238, declare under our responsibility for the products contained herein are in conformity with the essential requirements of the following...

  • Page 5: Safety Notice

    OREWORD Safety Notice It is extremely important to read ALL safety information and instructions provided in this manual and any accompanying documentation before installing and operating the products described herein. Heed all cautions and warnings during installation and use of this product. Safety symbols used throughout this manual are as follows: CAUTION advising of potential damage to product.
  • Page 6 ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL WARNING: INSTRUCTIONS FOR CONTINUED PROTECTION AGAINST EXCESSIVE EXPOSURE TO UV RADIATION 1. Many VARI❋LITE luminaires use a lamp that produces UV radiation. DO NOT look directly at lamp. 2. It is hazardous to operate luminaires without lens or shield. Shields, lenses, or ultraviolet screens shall be changed if they have become visibly damaged to such an extent that their effectiveness is impaired.
  • Page 7 OREWORD Sicherheitshinweise Es ist äußerst wichtig, ALLE Sicherheitsinformationen und -hinweise in diesem Handbuch und dem beiliegenden Informationsmaterial zu lesen, bevor Sie die hierin beschriebenen Produkte installieren bzw. bedienen. Halten Sie bei der Installation und dem Einsatz dieses Produkts alle Warnhinweise und Vorsichtsmaßnahmen ein.
  • Page 8 ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL WARNUNG: HINWEISE ZUM SCHUTZ GEGEN ÜBERHÖHTE UV-STRAHLUNG 1. Viele VARI❋LITE-Scheinwerfer verwenden die Lampentyp, der UV-Strahlen abgibt. SCHAUEN SIE NICHT direkt in die Lampe. 2. Es ist gefährlich, Leuchten ohne Linsen oder Blenden zu bedienen. Blenden, Linsen oder Ultraviolettschirme müssen ausgetauscht werden, sofern deren Schutzwirkung durch sichtbare Beschädigung (z.
  • Page 9 OREWORD Notes de sécurité Avant de procéder à l’installation des produits décrits dans ce guide et de les mettre en marche, il est extrêmement important de lire TOUS les renseignements et TOUTES les directives de sécurité contenues dans ce guide ainsi que toute documentation jointe. Tenir compte de tous les avertissements et suivre toutes les précautions pendant l’installation et l’utilisation de cet appareil.
  • Page 10 ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL AVERTISSEMENT: DIRECTIVES POUR SE PROTÉGER CONTRE UNE EXPOSITION EXCESSIVE AUX RAYONS UV 1. Plusieurs luminaires VARI❋LITE utilisent une lampe qui produit des rayons UV. NE PAS fixer son regard sur la lampe. 2.
  • Page 11 OREWORD Aviso sobre Seguridad Es muy importante leer TODA la información e instrucciones sobre seguridad que se indica en este manual así como en los documentos adjuntos antes de instalar y operar los productos descritos. Se debe prestar atención a todos los avisos y advertencias durante la instalación y uso de este producto. Los símbolos de seguridad usados en este manual son los siguientes: CUIDADO, indica posibles daños al producto.
  • Page 12 ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL ADVERTENCIA: INSTRUCCIONES PARA PROTECCIÓN CONTINUA CONTRA LA EXPOSICIÓN EXCESIVA DE RADIACIÓN ULTRA VIOLETA 1. Muchas luminarias VARI❋LITE usan un tipo de lámpara que produce radiación UV. NO mire directamente a la lámpara. 2.
  • Page 13 OREWORD 02.97 04.000 1 D 03 Feb ru ary 201 5...
  • Page 14 ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL 03 Feb ru ary 201 5 02 .9 704 .00 01 D...

  • Page 15: Table Of Contents

    ABLE OF ONTENTS Table of Contents Introduction About This Manual ...................... 1 Additional Documentation................... 2 Text Conventions ......................2 Customer Service ......................3 Chapter 1. Description Features Overview........................6 Components Included Items......................8 Replacement Items/Accessories................... 8 Luminaire Components....................9 Major Components ....................9 Chapter 2.
  • Page 16 ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Fixed Color Wheel 1 ................... 30 Fixed Color Wheel 2 ................... 31 Gobos ......................... 31 Rotating Gobo Wheel 1 ..................32 Rotating Gobo Wheel 2 ..................33 Animation Wheels...................... 34 Animation Wheel 1 - Dichro*Fusion ..............34 Animation Wheel 2 - Wicked Waves..............
  • Page 17 ABLE OF ONTENTS Test Descriptions ....................75 Service Menu Items Set Tilt Cal ......................... 76 Gobo Offset........................ 77 USB Logging ......................77 Appendix A. Maintenance Equipment Handling Locations/Use......................80 Lamps......................... 80 Servicing......................80 Heat........................80 Lamp Life ......................80 Solid State Electronics ....................81 Electrostatic Discharge (ESD)................
  • Page 18 ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL 03 Feb ru ary 201 5 02 .9 704 .00 01 D...

  • Page 19: Introduction

    This manual covers the following models: Model Part Number Lamp Type VL4000 Spot 20.9704.0001 1200W Short Arc, Philips MSR Gold FastFit Notes: • For complete product description, features, and specifications, refer to “Technical Specifications” on page •...

  • Page 20: Additional Documentation

    ❋ VARI LITE® - VL4000 S ’ UMINAIRE ANUAL Additional Documentation Note: Performing maintenance procedures may void the product warranty. Refer to the Vari-Lite Limited Warranty card included in the product shipping package for more information. For more information on installing DMX512 control systems, the following publication is available for purchase from the United States Institute for Theatre Technology (USITT), "Recommended Practice for DMX512: A Guide for Users and Installers, 2nd edition"...

  • Page 21: Customer Service

    Contact an Authorized Service Center or Contact the Vari-Lite Customer Service Department, 7am - 6pm CST Monday through Friday, at the following: phone: 1-877-VARI-LITE (1-877-827-4548) or +1-214-647-7880 e-mail: entertainment.service@philips.com Additional Resources For additional resources and documentation, please visit our website at www.vari-lite.com and follow the Support link.
  • Page 22 ❋ VARI LITE® - VL4000 S ’ UMINAIRE ANUAL Notes 03 Feb ru ary 201 5 02 .9 704 .00 01 D...

  • Page 23: Chapter 1. Description

    HAPTER Description This chapter contains descriptions of luminaire features and components, along with a list of accessories which are available. • Features • Components 02.97 04.000 1 D 03 Fe bru ary 201 5...

  • Page 24: Features

    ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Features Overview VL4000 Spot Luminaire feature highlights: Color System A three filter CYM cross fading system capable of extremely smooth movements at both slow and fast speeds, and a variable CTO color temperature correction system.
  • Page 25 ESCRIPTION EATURES Strobe High-performance dual blade strobe system capable of ultra-fast operation. Pan and Tilt Smooth, time-controlled continuous motion by way of three-phase stepper motor systems. • Range: Pan - 540°, Tilt - 270°. • Accuracy: 0.3° resolution. Weights Unit weighs (luminaire only, without accessories) 90 lbs (40.9 kg). Spacing Unit hangs on 25 inch (635 mm) centers.

  • Page 26: Components

    Truss Hook, Mega-Claw for 2” Round Tube 71.9704.1200 1200W Short Arc Lamp, Philips MSR Gold Fast-Fit* *F or app ro ved lamp typ es, se e the latest v e rsio n o f Vari-Lite te chn i cal n otice T N-248 in t he p r od u ct d ow nl o ads s ect i on o n t h e V a r i -L i t e w eb s it e , www.va ri-lite.com...

  • Page 27: Luminaire Components

    ESCRIPTION OMPONENTS Luminaire Components Below is a brief description of the major components and sub assemblies of the VL4000 Spot Luminaires. Major Components Note, truss hooks shown are sold separately. Truss and pipe by others. Mounting Brackets - For hanging the fixture. Hooks are sold separately and pipe shown by others Enclosure Assembly -...
  • Page 28 CAUTION: *Pan and tilt locks must be disengaged before powering and operating luminaire. NOTE: ** 1200W Philips MSR Gold FastFit lamp (rated for 800-1400W operation) running at 1400W in Standard mode or 1200W in Studio mode. Figure 1-3: Sub Assemblies 03 Feb ru ary 201 5 02 .9 704 .00 01 D...

  • Page 29: Chapter 2. Installation

    HAPTER Installation This chapter contains instructions for installation of the luminaire. It includes connecting power and data, along with instructions for powering up the luminaire for the first time and addressing it within your system. • Power and Data Cabling Requirements •...

  • Page 30: Power And Data Cabling Requirements

    ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Power and Data Cabling Requirements Power The luminaire requires standard AC power distribution from 200-240 VAC, 50/60 Hz. Current required depends on the AC supply voltage and product model. Refer to “Current vs.
  • Page 31 NSTALLATION OWER AND ABLING EQUIREMENTS WARNING: DO NOT connect to three-phase service in countries with 240 volt power. For single-phase power at 208 to 240 volts RMS: Connection AC Neutral AC Line Ground (Earth) For three-phase power at 208 volts RMS: Connection Phase 1 Phase 2...

  • Page 32: Current Vs. Voltage

    240V 9.2A Note: *1200W Philips MSR Gold FastFit lamp (rated for 800-1400W operation) running at 1400W in Standard mode or 1200W in Studio mode. WARNING: It is not recommended to power any VARI❋LITE luminaire from a dimmer - even in 'NONDIM' mode.

  • Page 33: Data Cables

    NSTALLATION OWER AND ABLING EQUIREMENTS Data Cables The luminaire is equipped with two, 5-pin XLR connectors for DATA IN and DATA THRU (out) applications. DATA IN requires a 5-pin, female XLR connector and DATA THRU requires a 5-pin, male XLR connector. When purchasing or constructing data cables, it is important that not only the correct cable type be used, but also quality cable to ensure a reliable DMX512 system.

  • Page 34: Recommended Cable Types/Manufacturers

    ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Recommended Cable Types/Manufacturers These are only a few of the suitable cable types. Any quality EIA485, twisted pair, 120 ohm, shielded cable will also work. ∗ Type Pairs Jacket Temp (F) ZΩ...

  • Page 35: Installation Procedures

    NSTALLATION NSTALLATION ROCEDURES Installation Procedures Installing Lamp In the event the lamp was packed separately during shipment, follow the procedure in this section. For lamp removal and replacement, refer to “Lamp Removal and Installation” on page WARNING: Disconnect fixture before relamping. Déconnectez le projecteur avant que le changement de lampe.
  • Page 36 ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Step 6. As shown in Figure 2-3, align lamp tabs with lamp socket. Align tabs of lamp with socket when installing Lamp* NOTE: * "Bow" of lamp must be oriented with "Slot" in reflector. Lamp Socket Cover Figure 2-3: Lamp Installation Step 7.

  • Page 37: Align Lamp For Maximum Beam Irradiance

    NSTALLATION NSTALLATION ROCEDURES Align Lamp For Maximum Beam Irradiance After a new lamp is installed in the luminaire, it will be necessary to align the lamp to optimize the beam. WARNING: Backcap and alignment screws will be HOT during lamp operation. Wear gloves and/or use tools to prevent burns.

  • Page 38: Hanging The Luminaire

    ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Hanging the Luminaire The VL4000 Spot Luminaire can be hung horizontally or vertically from any structure designed to work with the type of load created by this moving luminaire. Two mounting truss hooks or other mounting hardware are required.
  • Page 39 NSTALLATION NSTALLATION ROCEDURES thicknesses and any of the following thicknesses (0.035-inch, 0.043-inch, 0.050-inch, 0.073-inch) are acceptable for the application described herein. The washer serves two purposes: • To spread out the load. When a washer IS NOT used, the bolt head (without a washer) concentrates the load in a smaller area, creating focused stress on the steel bracket, making premature failure possible.
  • Page 40 ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL WARNING: Ensure that the bracket locking mechanism is fully seated after the bracket is installed on the luminaire. AVERTISSEMENT: Assurez-vous que le mécanisme de support de verrouillage est complètement inséré après le support est installé sur l'appareil. Example Truss Hook and Mounting Hardware (not included, sold separately) Mount Bracket* Raised Mounting Buttons (8 each)
  • Page 41 NSTALLATION NSTALLATION ROCEDURES Safety Cable: Recommended for hanging installations. May be required by local codes. Safety cable is sold separately. Câble de sécurité: Recommandé pour les installations pendaison. Peut être exigé par les codes locaux. Câble de sécurité est vendu séparément. Safety Cable Anchor Point 25.00 in.

  • Page 42: Floor Mounting The Luminaire

    ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Floor Mounting the Luminaire All luminaires included in this manual are designed to sit directly on its base in a floor installation application. When used in this type of application, be sure to leave enough space around the luminaire to allow proper, uninterrupted airflow for cooling and movement.

  • Page 43: Powering Up

    NSTALLATION OWERING Powering Up Power-Up Procedure When the luminaire is powered up for the first time, the default setting is enabled and the lamp will remain off. When AC power is applied, the luminaire will immediately begin a calibration sequence that steps it through full pan and tilt movements.

  • Page 44: Addressing

    ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Addressing Program Starting Address The address setting for DMX console controlled systems is entered using the Menu Display (refer to “Menu Operation” on page 64). The luminaire retains the DMX address even if power is removed. Note: Refer to your console operating instructions for specific information regarding its addressing requirements.

  • Page 45: Transporting

    NSTALLATION RANSPORTING Transporting Overview When shipping or transporting VARI❋LITE Luminaires, Vari-Lite recommends that the luminaire(s) be sufficiently protected against any (including, but not limited to) shock, vibration, drops, jarring, exposure to the environment, etc. Failure to sufficiently protect any VARI❋LITE luminaire during shipping or transportation will result in damage and void the luminaire’s warranty.
  • Page 46 ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Notes 03 Feb ru ary 201 5 02 .9 704 .00 01 D...

  • Page 47: Chapter 3. Operation

    HAPTER Operation This chapter contains instructions for operating the luminaire using DMX control and for updating the internal software. • Color Control & Gobos • DMX Operation • Luminaire Timing • RDM Parameter IDs • Updating Software 02.97 04.000 1 D 03 Fe bru ary 201 5...

  • Page 48: Color Control & Gobos

    ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Color Control & Gobos The following is a brief description of each color control and gobo projection capabilities. Color Mixing The VL4000 Spot Luminaire provides full CYM color cross-fading and two fixed color wheels. •...

  • Page 49: Fixed Color Wheel 2

    Note: For all available patterns and their associated numbers, refer to VARI❋IMAGE System page on the Philips Vari-Lite web site or contact your local regional sales manager or Authorized VARI❋LITE Dealer.

  • Page 50: Rotating Gobo Wheel 1

    ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Rotating Gobo Wheel 1 Standard load rotating gobos for Rotating Gobo Wheel 1 are shown in Figure 3-3 and described in Table 1, “Rotating Gobo Wheel 1 - Standard Effects and Positions”.

  • Page 51: Rotating Gobo Wheel 2

    & G PERATION OLOR ONTROL OBOS Rotating Gobo Wheel 2 Standard load rotating gobos for Rotating Gobo Wheel 2 are shown in Figure 3-4 and described in Table 2, “Rotating Gobo Wheel 2 - Standard Effects and Positions,” on page Table 2: Rotating Gobo Wheel 2 - Standard Effects and Positions Position Gobo...

  • Page 52: Animation Wheels

    ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Animation Wheels The VL4000 spot luminaire has two animation wheels. Each offers unique rotatable, indexable patterns with variable motion control from horizontal to vertical. Animation Wheel 1 - Dichro*Fusion Figure 3-5 shows Animation Wheel 1.

  • Page 53: Dmx Operation

    : DMX O PERATION PERATION DMX Operation VL4000 Spot Channel Mapping These tables assume a DMX start address of 1. When a different starting address is used, this address becomes channel 1 function and other functions follow in sequence.This section contains the DMX channel maps for the VL4000 Spot Luminaire.
  • Page 54 ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Table 3: VL4000 Spot Enhanced 16-Bit DMX Channel Mapping Range Range Default Parameters Description / Operation Channel (DMX) Value* Used as a control channel for different movement options of Color Wheel 1. 0 - 5 = Linear Movement using shortest (quickest) path.
  • Page 55 : DMX O PERATION PERATION Table 3: VL4000 Spot Enhanced 16-Bit DMX Channel Mapping Range Range Default Parameters Description / Operation Channel (DMX) Value* Used as a control channel for different movement options for Rotating Gobo Wheel 1 (Channel 19). 0 - 5 = Gobo Selection using shortest (quickest) path.
  • Page 56 ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Table 3: VL4000 Spot Enhanced 16-Bit DMX Channel Mapping Range Range Default Parameters Description / Operation Channel (DMX) Value* Animation Wheel 1 (Dichro*Fusion) 16 bit control of the Animation Wheel 1 index and rotation. Index / Rotate - High Byte 0 - 65535...
  • Page 57 : DMX O PERATION PERATION Table 3: VL4000 Spot Enhanced 16-Bit DMX Channel Mapping Range Range Default Parameters Description / Operation Channel (DMX) Value* Controls spread of prism image from small (DMX 0) to wide (DMX 255). Prism Diverge 0 - 255 0 - 100% Note : there are some diverge positions that will not be available due to various lensing positions.

  • Page 58: 16-Bit Channel Mapping

    ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL 16-Bit Channel Mapping Table 4 provides DMX channel mapping of the DMX512 control values when the VL4000 Spot Luminaire is in 16-Bit DMX mode (as set by the luminaire’s menu system). Table 4: VL4000 Spot 16-Bit Channel Mapping Range Range...
  • Page 59 : DMX O PERATION PERATION Table 4: VL4000 Spot 16-Bit Channel Mapping Range Range Default Parameters Description / Operation Channel (DMX) Value* Used as a control channel for different movement options of Color Wheel 2. 0 - 5 = Linear Movement using shortest (quickest) path. 6 - 10 = Linear Movement using normal (longest) path.
  • Page 60 ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Table 4: VL4000 Spot 16-Bit Channel Mapping Range Range Default Parameters Description / Operation Channel (DMX) Value* 8-bit control of Rotating Gobo Wheel 2. See Channel 26 for control options. 0 - 5 = Open - No Gobo 6 - 10 = Gobo 1 (Circle of Eights) Index 11 - 15 = Gobo 2 (Punch Card) Index 16 - 20 = Gobo 3 (Vertical Bars) Index...
  • Page 61 : DMX O PERATION PERATION Table 4: VL4000 Spot 16-Bit Channel Mapping Range Range Default Parameters Description / Operation Channel (DMX) Value* Used as a control channel for Animation Wheel 1. 0 - 5 = Index using shortest (quickest) path. 6 - 10 = Index using normal (longest) path.

  • Page 62: Fixture Shutdown

    ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Table 4: VL4000 Spot 16-Bit Channel Mapping Range Range Default Parameters Description / Operation Channel (DMX) Value* Control Channel for strobing functions. 0 - 5 = Open 6 - 10 = Closed Strobe Control 0 - 255 0 - 100%...

  • Page 63: Luminaire Timing

    PERATION UMINAIRE IMING Luminaire Timing Luminaire Timing Channel Information Timing channel control improves the timed moves of certain groups of parameters. Four timing channels are provided, one for Pan and Tilt, one for color parameters, one for beam parameters and one for gobo/index parameters.
  • Page 64 ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Note: Some parameters have been excluded from the timing channels. Wheel spin and gobo rotation rate changes are not affected by timing channels. To use luminaire timing channels, you must: Step 1. Create the cue, including color, beam, gobo and position as required. Step 2.
  • Page 65 PERATION UMINAIRE IMING Table 6: Timing Channels Map (Continued) % Value = Seconds 10.2 10.4 10.6 02.97 04.000 1 D 03 Feb ru ary 201 5...
  • Page 66 ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Table 6: Timing Channels Map (Continued) % Value = Seconds 03 Feb ru ary 201 5 02 .9 704 .00 01 D...
  • Page 67 PERATION UMINAIRE IMING Table 6: Timing Channels Map (Continued) % Value = Seconds 02.97 04.000 1 D 03 Feb ru ary 201 5...
  • Page 68 ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Table 6: Timing Channels Map (Continued) % Value = Seconds 03 Feb ru ary 201 5 02 .9 704 .00 01 D...
  • Page 69 PERATION UMINAIRE IMING Table 6: Timing Channels Map (Continued) % Value = Seconds 02.97 04.000 1 D 03 Feb ru ary 201 5...
  • Page 70 ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Table 6: Timing Channels Map (Continued) % Value = Seconds Follows Cue Data 03 Feb ru ary 201 5 02 .9 704 .00 01 D...

  • Page 71: Rdm Parameter Ids

    • Table 9, "VL4000 Spot Luminaire RDM Parameters IDs Table 7: VL4000 Spot Luminaire RDM Product Parameters IDs Model ID Manufacturer Model Description Product Category 0x002F Philips Vari-Lite VL4000 Spot 0x0100 Table 8: VL4000 Spot Luminaire RDM UID MSB of ESTA LSB of ESTA Second Byte...
  • Page 72 ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Table 9: VL4000 Spot Luminaire RDM Parameters IDs RDM Parameter IDs Value Comment Implemented Allowed Allowed Category - Product Information ■ ■ DEVICE_INFO 0x0060 PRODUCT_DETAIL_ID_LIST 0x0070 ■ ■ DEVICE_MODEL_DESCRIPTION 0x0080 ■ ■...
  • Page 73 : RDM P PERATION ARAMETER Table 9: VL4000 Spot Luminaire RDM Parameters IDs RDM Parameter IDs Value Comment Implemented Allowed Allowed ■ ■ IDENTIFY_DEVICE 0x1000 ■ ■ RESET_DEVICE 0x1001 POWER_STATE 0x1010 PERFORM_SELFTEST 0x1020 SELF_TEST_DESCRIPTION 0x1021 02.97 04.000 1 D 03 Feb ru ary 201 5...

  • Page 74: Updating Software

    (downloaded from our web site), you can connect any USB 2.0 compatible port on a computer to a chain of up to 32 Philips Entertainment luminaires in order to update the luminaire software. Figure 3-7: USB Upload Cable (sold separately) Note: PEGASUS Software is compatible with previous versions of the VARI❋LITE USB Upload...

  • Page 75: Troubleshooting

    PERATION PDATING OFTWARE Step 3. Double click on pegausinstall.msi icon. Step 4. Follow all prompts in program’s installation wizard. Step 5. Insert USB Upload Cable (sold separately) into a USB 2.0 compatible port on your computer. WARNING: Do not use a USB hub, always connect directly to a USB port on your computer. Step 6.

  • Page 76: Upload Cable Warning (Error) Message

    If either of the these do not resolve the error message, you may have a Error Message defective Upload Cable. Contact customer service at 1.214.647.7880 entertainment.service@philips.com for assistance. Installing or Updating Luminaire Firmware Luminaire firmware, for the VL4000 spot luminaire can be loaded via PEGASUS or via the USB port.

  • Page 77: Important Notes & Warnings

    DMX signals. • You can upload multiple firmware files to a variety of luminaires that are data linked together. Each model of Philips Entertainment luminaire recognizes its own software and only downloads the appropriate file. • Do not use a USB hub, always connect directly to a USB port on your computer.

  • Page 78: Transferring Software From Luminaire To Luminaire

    ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Step 7. Click on bin file for luminaire to be updated (for example, SVL_080812.bin) as highlighted in Figure 3-11. NOTE: Select High Speed option when uploading to 16 or less luminaires. Progress Bar Figure 3-11: bin File Selection 3-11, click on Update Devices to start upload.
  • Page 79 PERATION PDATING OFTWARE A DMX termination connector is used in this process. Refer to page 16 for more information regarding the construction of this connector. Luminaire 2 Luminaire 1 AC In AC In AC In requiring update requiring update Data In Termination* Data Thru Master luminaire containing...
  • Page 80 ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Notes 03 Feb ru ary 201 5 02 .9 704 .00 01 D...

  • Page 81: Chapter 4. Menu System

    HAPTER Menu System This chapter contains instructions for operating the luminaire using the Menu Display feature. • Menu Operation • Self Tests • Service Menu Items 02.97 04.000 1 D 03 Fe bru ary 201 5...

  • Page 82: Menu Operation

    ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Menu Operation LCD Display and Menu System The VL4000 Spot Luminaire’s LCD Display and Menu System provides local control for accessing the following fixture’s settings: • Address – to set the DMX address •...

  • Page 83: Lcd Display And Menu System Operation

    YSTEM PERATION LCD Display and Menu System Operation The LCD Display Menu system consists of several categories. Use the Menu Buttons to access and make changes to the menu items. When the desired menu item is reached, press the desired Menu Button to display the menu options and to navigate and configure the menu options as required.

  • Page 84: Other Lcd Display Features

    ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Other LCD Display Features LCD Menu Battery Operation The LCD menu system utilizes a battery powered system for operation when the luminaire is not connected to power. The primary purpose of this mode is to allow basic setup and configuration of the luminaire.

  • Page 85: Menu Tree

    YSTEM PERATION Menu Tree Figure 4-3 Figure 4-4 page 68 are graphical representations of the menu system. Address - value (1 thru 512) Data** Ch 1 - Intensity XXX (Value) Ch 2 - Pan High Byte XXX (Value) Ch 3 - Pan Low Byte XXX (Value) Ch 4 - Tilt High Byte XXX (Value) Configure Lamp...
  • Page 86 ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Continued from previous page: Manual Intensity Value 0 - 255 Test ALL Test Running 'ALL TEST' Value 0 - 65535 Pan/Tilt Running 'PAN/TILT TEST' Tilt Value 0 - 65535 Running 'PAN TEST' Edge Value 0 - 65535 Tilt...

  • Page 87: Menu System Functions

    YSTEM PERATION Menu System Functions Table 4-1: Menu System Chart 1st Level 2nd Level 3rd Level 4th Level 5thLevel Address DMX Address DMX Address value 1 to 512 Configure Lamp Lamp Options Power ON (default) System Configuration Power Up Lamp OFF (default) Lamp Power-up State Lamp Off Lamp ON Lamp On...
  • Page 88 ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Table 4-1: Menu System Chart (Continued) 1st Level 2nd Level 3rd Level 4th Level 5thLevel DATA Ch 1 - Intensity XXX (Value) DMX Data and Note: Channel and Dimmer Ch 2 - Pan High Byte XXX (Value) Pan/Tilt Mode information displayed Ch 3 - Pan Low Byte XXX (Value)
  • Page 89 YSTEM PERATION Table 4-1: Menu System Chart (Continued) 1st Level 2nd Level 3rd Level 4th Level 5thLevel Fixture Status Fixture OK Displays fixture Status/Error Display . . . Or displays a list of errors encountered information, during calibration process or operation. condition or ReCalibrate Fixture Are you sure?
  • Page 90 ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Table 4-1: Menu System Chart (Continued) 1st Level 2nd Level 3rd Level 4th Level 5thLevel Manual Intensity Value 0 - 255 Manual Value 0 - 65535 Commands Tilt Value 0 - 65535 Edge Value 0 - 65535...
  • Page 91 YSTEM PERATION Table 4-1: Menu System Chart (Continued) 1st Level 2nd Level 3rd Level 4th Level 5thLevel Test* ALL Test Running 'ALL TEST' Press [Menu] to System Test Pan/Tilt Running 'PAN/TILT TEST' stop tests Running 'PAN TEST' Note: Test is Tilt Running 'TILT TEST' Disabled if...

  • Page 92: Self Tests

    ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Self Tests Running Parameter Tests The luminaire is capable of running self tests by using the TEST menu functions. For complete details and values for each test refer to “Diagnostic Tests” on page When running tests on multiple luminaires, a DMX termination connector is required at the last luminaire in the link.

  • Page 93: Diagnostic Tests

    YSTEM ESTS To set movement option: Step 1. Press [ESC]. Step 2. Press [Up] / [Down] arrows until Config appears. Press [OK]. Step 3. Press [Up] / [Down] arrows until Pan/Tilt appears. Press [OK]. Step 4. Movement will be displayed. Press [OK]. Step 5.

  • Page 94: Service Menu Items

    ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Service Menu Items Refer to “Menu Tree” on page 67 for more information. The following menu items were added in VL4000 Spot Luminaire software release 01/16/15. CAUTION: Certain features described below are for Authorized Service Centers and Certified Vari- Lite Technicians use only.

  • Page 95: Gobo Offset

    YSTEM ERVICE TEMS Gobo Offset Gobo Offset (for each Gobo Wheel) menu under the Fixture -> Service menu - In luminaire software 01/16/15 or later, the ability to adjust the offset of each gobo wheel was implemented. Gobo Offset should only be adjusted if a wheel is not properly centering gobos in the aperture. CAUTION: This feature should only be performed by Authorized Service Centers and Certified Vari- Lite Technicians.
  • Page 96 ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Table 5: .csv Log File Information Parameter Example Information Meaning Model VL4000 Spot The fixture model Fixture Hours The total of number of hours the fixture has been operating DMX Address Current DMX address of the fixture as set by the user RDM UID 56:4c:2f:0:7:2a...

  • Page 97: Appendix A. Maintenance

    PPENDIX Maintenance This appendix provides instructions for performing routine maintenance which may be necessary during the life of the luminaire. • Equipment Handling • Troubleshooting • Routine Maintenance WARNING: All maintenance procedures are to be performed with power completely removed from the luminaire.

  • Page 98: Equipment Handling

    ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Equipment Handling Below are some basic tips and information on handling luminaires and their associated components. Locations/Use VARI❋LITE luminaires are designed for dry locations only. Exposure to rain or moisture (including, but not limited to, fog machines, misters, etc.,) may damage luminaire.

  • Page 99: Solid State Electronics

    ROUBLESHOOTING AND AINTENANCE • If the luminaire will be dimmed out for more than two hours, the lamp should be doused. Solid State Electronics Electrostatic Discharge (ESD) Electrostatic discharge (ESD) presents a significant danger to solid state electronic components (semiconductor devices and PC board assemblies). Static electricity can build on a variety of common objects (including people) simply by handling or moving.

  • Page 100: Troubleshooting

    ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Troubleshooting Error Messages If a problem occurs during luminaire calibration, at the end of the calibration sequence the Menu Display will cycle through any applicable error message(s), one at a time until the end of the list is reached.

  • Page 101: Troubleshooting Guide

    ROUBLESHOOTING AND AINTENANCE Troubleshooting Guide If a problem is suspected, first try recalibrating the luminaire to prompt an error message. The chart below provides possible causes and remedies for various error messages and/or symptoms. CAUTION: Some troubleshooting is included for reference only. Performing remedies may void product warranty.

  • Page 102: Routine Maintenance

    ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Routine Maintenance Lamp Removal and Installation WARNING: Disconnect fixture before relamping. Déconnectez le projecteur avant que le changement de lampe. CAUTIONS & WARNINGS • Wear cotton gloves or other covering while installing lamp. Touching lamp glass with bare fingers will leave oil and may cause the lamp to explode or reduce lamp life.
  • Page 103 ROUBLESHOOTING AND AINTENANCE Step 6. Remove replacement lamp from shipping box. Step 7. As shown in Figure A-2, align replacement lamp tabs with lamp socket. Align tabs of lamp with socket when installing Lamp* NOTE: * "Bow" of lamp must be oriented with "Slot"...

  • Page 104: Fixed Color Wheel Filter Removal And Installation

    ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Fixed Color Wheel Filter Removal and Installation To remove and replace fixed color filters: Step 1. Before removing power from luminaire, move Edge towards front of luminaire with control console or via luminaire menu system. WARNING: Remove power from luminaire and allow luminaire to cool completely before performing this procedure.
  • Page 105 ROUBLESHOOTING AND AINTENANCE Step 4. At fixed color wheel, slowly rotate wheel by hand until filter to be removed is visible on assembly as shown in Figure A-5. Step 5. At filter to be removed, (1) press filter out of fixed color wheel with fingers and (2) guide filter up and away from fixed color wheel.

  • Page 106: Rotating Gobo Removal And Installation

    ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Rotating Gobo Removal and Installation CAUTION: VL4000 spot luminaires accept glass gobos only. Use of metal gobos in these luminaires may damage gobo assembly and will void the luminaire warranty. To remove and replace rotating gobos: Step 1.
  • Page 107 ROUBLESHOOTING AND AINTENANCE Note: For the standard load of rotating gobos, refer to “Rotating Gobo Wheel 1” on page 32 “Rotating Gobo Wheel 2” on page 33 Step 4. At rotating gobo wheel, slowly rotate wheel by hand until gobo to be removed is visible on assembly.
  • Page 108 ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Retaining Tabs Rotating Gobo Assembly (Retaining clips need to be (gear side towards front of seated in pins but are not luminaire) used to aid in removal) Do not touch glass with bare fingers. CAUTION: Handle by gobo carrier only.

  • Page 109: Animation Wheels Removal And Installation

    ROUBLESHOOTING AND AINTENANCE Animation Wheels Removal and Installation To remove and replace animation wheels: Step 1. Before removing power from luminaire, move Edge towards front of luminaire with control console or via luminaire menu system. WARNING: Remove power from luminaire and allow luminaire to cool completely before performing this procedure.
  • Page 110 ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Step 4. Loosen screw on bulkhead so animation arm can swing out Step 5. Remove one screw from animation frame. CAUTION: Be careful not to lose belt bearing, washer, screw or post. These will be required for reassembly and installation.

  • Page 111: Cleaning Optical Lenses And Filters

    ROUBLESHOOTING AND AINTENANCE Cleaning Optical Lenses and Filters WARNING: Remove power from luminaire before performing maintenance. WARNING: Acetone is a harsh cleaning agent and solvent. Acetone is very flammable. Please handle acetone according to manufacturer’s safety instructions and precautions. The front lens, optics/color filters, and reflector may require cleaning after extended use. •...
  • Page 112 ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Notes 03 Feb ru ary 201 5 02 .9 704 .00 01 D...

  • Page 113: Appendix B. Technical Specifications

    PPENDIX Technical Specifications Note: Philips Vari-Lite reserves the right to change details of design, materials and finishes. Specifications are subject to change without notice. Some features may be the result of future software updates. Philips VARI❋LITE automated lighting equipment is made in the U.S.A.
  • Page 114 ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Shutter Control A four-blade shutter mechanism that allows the blades to be operated independently or in unison on two planes for a clear and crisp image. The entire mechanism can rotate 50º in either direction.

  • Page 115: Optical

    ECHNICAL PECIFICATIONS Optical Source 1200W Philips MSR Gold FastFit lamp (rated for 800-1400W operation) running at 1400W in Standard mode or 1200W in Studio mode. Reflector Precision facetted, elliptical glass reflector system with dichroic cold mirror coating. Color Temperature 6000K...

  • Page 116: Operational

    ❋ VARI LITE - VL4000 S ’ UMINAIRE ANUAL Operational Power Requirements Standard AC power distribution from 200 - 240VAC, 50/60 Hz. The unit requires up to 11.0A depending on the AC supply voltage.* Note: *For a breakdown of total luminaire current draw at different voltages, see “Current vs.
  • Page 118 Vari-Lite 10911 Petal Street Dallas, Texas 75238 1.877.VARILITE 1.214.647.7880 www.vari-lite.com ©2015 Philips Group. All rights reserved. Printed in the U.S.A.

Table of Contents
