GENUINE Parking Sensor

INSTALLATION INSTRUCTIONS

Thank you for purchasing a genuine Mazda accessory.
Before removal and installation, be sure to thoroughly read these instructions.
Please read the contents of this booklet in order to properly install and use the Parking sensor.
Your safety depends on it.
Keep these instructions with your vehicle records for future reference.
There are several
installing or removing the Parking sensor. Always read and follow them in order to prevent injuries,
accidents, and possible damage to the vehicle.
WARNING:
Indicates a situation in which serious injury or death could result if the warning
is ignored.
CAUTION:
Indicates a situation in which bodily injury or damage to the vehicle could result if the
caution is ignored.
For areas indicating the tightening torque in this instruction manual, tighten to the specified torque using
a torque wrench.
Do not modify the Parking sensor.
Do not install the Parking sensor in any way other than described in the following instructions.
If in any doubt, please ask your Mazda dealer to install the accessory in order to prevent errors in
installation.
If you have any questions about the use of the accessory, ask your Mazda dealer for proper advice
before using it.
Mazda and its suppliers are not responsible for injuries, accidents, and damage to persons and property
that arise from the failure of the dealer or installer to follow these instructions.
To ensure safety and reliability of the work, installation, removal and disposal work must carried out by
an Authorized Mazda Dealership.
Be careful not to lose removed parts, and be sure that they are kept free from scratches, grease or
other dirt.
PART NAME:
VEHICLE:
PART NUMBER:
NOTE
To the dealer
Please turn over these instructions to the customer after installation.
To the customer
Keep these instructions after installation. The instructions may be necessary
for installing other optional parts or removal of this accessory.
Should the vehicle or this accessory be resold, always leave these instructions
with it for the next owner.
WARNING
WARNING and
CAUTION sections in this booklet concerning safely when
Parking sensor
MAZDA CX-5
KD33 V7 282 (Optional ON-OFF switch)
1
201206MA-00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CX-5 and is the answer not in the manual?

Questions and answers

Related Manuals for Mazda CX-5

Summary of Contents for Mazda CX-5

  • Page 1: Installation Instructions

    Do not modify the Parking sensor. Do not install the Parking sensor in any way other than described in the following instructions. If in any doubt, please ask your Mazda dealer to install the accessory in order to prevent errors in installation.
  • Page 2 1. PARTS Installation view Buzzer Back signal Control unit Sensor Back-up sensor ON-OFF switch (Label) Optional ON-OFF switch Trunk side trim LH...

  • Page 3: Parts List

    Parts list Note Verify that the kit includes all the following parts and that the parts are not dirty, scratched, or damaged. C851 V7 290 (Parking sensor kit) Part Part name Qty. Part Part name Qty. Part Part name Qty. Control unit Buzzer Main harness...
  • Page 4 2 BEFORE INSTALLATION REQUIRED TOOLS Screwdriver (Flathead) Screwdriver (Phillips) Socket wrench Fastener remover Nipper Pliers Masking tape Electrical vinyl tape IPA (Isopropyl alcohol) Drill ( 2 mm) Punch Holesaw( 20 mm) File Utility knife WARNING When the negative battery When connecting/dis- Do not pull the harness with Secure the harness with the cable is connected during...
  • Page 5 3 CONNECTION DIAGRAM...
  • Page 6 4. BEFORE INSTALLATION Sensor installation position marking (rear bumper) CAUTION Mark the drilling position for the rear bumper before removing the vehicle parts. 1. Open the liftgate. 2. Set the selector lever to P range. 3. Disconnect the negative battery cable. (Refer to 8 page.) 4.
  • Page 7 Optional ON-OFF switch installation position marking (trunk side trim (LH)) CAUTION Mark the drilling position for the trunk side trim (LH) before removing the vehicle parts. 1. Open the liftgate. 2. Set the selector lever to P range. 3. Disconnect the negative battery cable. (Refer to 8 page.) 4.
  • Page 8 5 VEHICLE PART REMOVAL CAUTION Be careful not to damage or lose any parts removed from the vehicle since they will be reused. Negative battery cable disconnection 1. Set the selector lever to P range. Negative battery cable (AT vehicles only) WARNING When removing/installing the parts, park the vehicle on level ground and apply the side brake securely.
  • Page 9 Trunk covering removal Fasteners 1. Remove fasteners. 2. Remove the trunk covering. Trunk covering Trunk board removal Trunk board No.1 1. Set the trunk covering aside. 2. Remove the trunk board No.1 in the direction of the arrow (1) shown in the figure. 3.
  • Page 10 3. Take the shaded area shown in the figure, detach tabs A while Tab D pulling the trunk end trim in the direction of the arrow (1) shown in the figure, then detach clips B, pins C while pulling in the direction of the arrow (2).

  • Page 11: Trunk Side Trim Lh Removal

    Trunk side trim LH removal 1. Remove bolts A, then remove the cargo net hook. Screw C Tightening torque : 0.9-1.3 N m 2. Remove the fastener B. 3. Remove the screw C. Screw D Cargo 4. Remove the cap, then remove the screw D. (4:2:4 split type) net hook Bolt A Fastener B...
  • Page 12 Rear combination light removal Service hole Fogging or condensation on the inside of the rear combination lights may occur due to a natural phenomenon occurring as a result of a temperature difference between the interior and exterior of the combination lights. However, it has no effect on the light performance because the temperature inside the rear combination lights rises after illuminating the brake/taillight bulbs or a period of time has...
  • Page 13 5. Disconnect the connectors. Rear turn Brake/taillight light connector connector 6. Remove the nuts. Tightening torque : 4.1-6.1 N m 7. To prevent scratches or damage, affix protective tape to the position shown in the figure. CAUTION When the rear combination light is removed from the body, perform the procedure after affixing protective tape to the body.
  • Page 14 Rear over fender removal 1. Remove fasteners A. 2. Pull the rear over fender in the direction of the arrow while Clip B removing clips B, C, D. Clip C CAUTION Do not pull over fender far from vehicle as it may cause stress damage around clip B area.
  • Page 15 Rear bumper removal 1. Affix the protective tape to the position (body side) shown in the figure. Protective tape 2. Remove fasteners A. Rear over fender 3. Pull the rear over fender in the direction of the arrow shown in the figure above, then peel it back while removing clips B.
  • Page 16 7. Pull the end of the rear bumper (A) in the direction of the arrow Rear bumper (1) shown in the figure, while removing tabs. CAUTION The rear bumper and rear bumper slider are engaged Rear bumper slider firmly. If they are disengaged forcibly the bumper could fall and be damaged.
  • Page 17 6. INSTALLATION OF SENSOR, ON-OFF SWITCH, BUZZER, AND UNIT Sensor installation 1. Wrap the drill bit with duct tape as shown in the figure. Duct tape 2. Set the drill rotation to low speed. Drill CAUTION Always use a drill with a rotation speed adjustment, otherwise the rear bumper may deform.
  • Page 18 Optional ON-OFF switch installation (KD33-V7-282) 1. Wrap the drill bit with duct tape as shown in the figure. Duct tape 2. Set the drill rotation to low speed. Drill CAUTION Always use a drill with a rotation speed adjustment, otherwise the trunk side trim may deform. Be careful when handling drills and other sharp objects.
  • Page 19 Control unit installation 1. Affix double-sided adhesive tape to the control unit. CAUTION Always remove dirt or oil because the adhesive strength of the double-sided adhesive tape weakens. Control unit 2. Peel off the double-sided adhesive tape backing and adhere the vehicle side) Ground wire ( control unit to the body panel of the lower part inside of the trunk...
  • Page 20 7 WIRING HARNESS Sensor wiring harness 1. Connect the sensor wiring harness connector to the No.1, No.2, No.3, No.4 sensor and install the rear bumper. Cover Cover Sensor Sensor wiring harness 2. Affix the mount bases to the rear bumper. (4 locations) CAUTION Clean the adhesion area with ISP alcohol.
  • Page 21 4. Remove the hole cover from the vehicle interior using needle-nos e pliers. Hole cover 5. Pull the sensor wiring harness into the vehicle cabin. Sensor wiring harness Sensor wiring harness 6. Enlarge the hole cover hole using a flathead screwdriver. Sensor wiring harness flathead CAUTION...
  • Page 22 7. Route the sensor wiring harness through the hole cover. Hole cover Sensor wiring harness 8. Connect the sensor wiring harness connector to the control unit. Control unit CAUTION Make sure the connector is securely pressed in until a click sound is heard.
  • Page 23 Main harness, Buzzer and ON-OFF switch wiring harness 1. Branch connect the wiring harness (R) for the BACK signal line branch of the main wiring harness to the RBCM (W/B) using an electro-tap. CAUTION Connect an electro-tap to the indicated signal line securely. Misconnection may cause a system or vehicle malfunction.
  • Page 24 2. Tighten the ground wire together with the ground bolt on the vehicle side. Ground bolt Vehicle wiring harness Ground wire 3. Cut the ground wire at the position approx. 120mm (0.39ft, 4.7 in) from the ground lug. 4. Electro-tap connect the cut ground wire with the ON-OFF switch wiring harness. Cut the ground wire (B).
  • Page 25 Branching connection using electro-tap (ON-OFF switch harness) CAUTION The terminal is embedded in the insulator. If it is not, insert the terminal as shown in the figure and press it in until it is securely fixed. Terminal Insulator 1. Put the vehicle harness to be branch-connected into the guide Vehicle harness groove.
  • Page 26 5. Connect the buzzer wiring and main harness connectors to the control unit. CAUTION Make sure the connector is securely pressed in until a click sound is heard. Buzzer Buzzer harness connector Control unit 6. Secure the main sensor wiring harness to the vehicle wiring harness at 2 locations using tie wraps. 7.
  • Page 27 Pull up the power window switch to close the window and continue to pull it up for about two seconds after it is fully closed. If the feature does not function even after the ignition switch is turned off, contact an Authorized Mazda Dealer. TPMS system If the battery is disconnected, the TPMS (Tire Pressure Monitoring System) initial setting is reset and the system may not operate normally.
  • Page 28 Operation check for parking sensor CAUTION While performing the inspection, always switch the ignition on (engine off) Always set the wheel blocks on level ground before performing the verification alone. Operate the shift lever while fully depressing the clutch pedal (MT vehicles only) or the brake pedal so that the vehicle does not move accidentally.
  • Page 29 Operation condition Is available when the ignition is switched ON. The sensor detects obstructions when the shift lever is in the R position. Alarm (beeper) sound The beeper operates (sounds) as follows while the system is operating. Rear sensor Approx. 2-1.5 ft (23.62-17.71 in) Approx.
  • Page 30 MAZDA INSTALLATION Parking distance sensor INSPECTION CX-5 SHEET C851 V7 290 (Parking sensor kit) KD33 V7 282 (Optional ON-OFF switch) A. Vehicle parts reinstallation Install removed vehicle parts in the reverse order of “VEHICLE PARTS REMOVAL”. Check CAUTION Make sure that the vehicle parts are clean before reinstalling. Clean any dirty parts.
