S&G Biometric Keypad Programming And Operating Instructions

P
rogramming and
I
ntroductIon
The Sargent & Greenleaf Biometric Keypad can be added to S&G
®
electronic lock models 6120, 6123, and Z
represents models 2002-200 and 2002-300). The keypad enables
your lock to be opened using a fingerprint only, a code only, or a
fingerprint and code together.
• The silicon-based active capacitive fingerprint reader
represents superior biometric technology that combines high
reliability with the ability to reject devices and methods which
are sometimes used to fool optical-type readers.
• The Biometric Keypad is equipped with a backlit LCD readout,
offering two lines of text. The backlight feature can be turned
on or off at the keypad. Its use greatly increases readability
under marginal lighting conditions.
• The keypad houses two nine-volt alkaline batteries which
power both the keypad and the lock. Normal battery life is
approximately 1500 openings and closings of the lock, fewer if
the backlight feature is turned on. Batteries are easily replaced
from outside the safe. No data is lost during battery changing
or if power is lost for extended periods.
• When a Biometric Keypad is first connected to a lock
body, it is important that both components are set to
factory defaults. Both should be in single user mode, with
only a master code of 123456 installed. No other codes should
be present, and the time delay value should be zero.
• This Sargent & Greenleaf
the factory with a factory master code of 1 2 3 4 5 6 #. This
code can be used to open the lock and set or change codes.
You should set the lock to your own, unique master code.
• Your lock can be programmed with a management reset code
if one was not set at the factory. This code can be used to
regain control of the lock in the event the master code is lost.
The management reset code must be programmed into the
lock before the master code is changed for the first time.
Sargent & Greenleaf, Inc.
A Wholly Owned Subsidiary of Stanley Security Solutions, Inc.
PO Box 930, Nicholasville, Kentucky 40340-0930 USA
Phone (859) 885-9411
Phone (800) 826-7652
FAX (859) 887-2057
FAX (800) 634-4843
© Copyright 2005, Sargent & Greenleaf, Inc.
Biometric Keypad
(model designation Z
02
Biometric Keypad is shipped from
®
o
Perating
• Each time a button is pressed, the lock acknowledges it by
sounding a "beep," and the red LED on the keypad will light
momentarily as the "beep" sounds.
02
• All codes must contain six digits or six letters. Any digit or
letter can be used as many
times as you wish. All
codes end with #.
This signals the
lock that you have
finished entering
all digits of the
code.
• If you pause
more than 10
seconds between
button presses when
entering a code or
performing programming,
the lock will power down to
conserve battery life. You will have to begin the code entry
process again by pressing START.
• If you realize you have pressed an incorrect button when
entering a code, press ✽ to erase the last digit entry.
• Personal data which can be directly related to a code holder,
such as a birth date, should not be used in making up a lock
code. Avoid codes which can be easily guessed.
• After the lock is changed to a new code, lock function must
be checked by locking and unlocking it several times with the
container door open. Make sure it functions correctly before
closing the door.
• It is recommended the fingerprint sensor be cleaned
periodically with a clean, dry cloth. The keypad will operate
best with no debris or latent fingerprints on the sensor.
i
nstructions
Sargent & Greenleaf S.A.
9, chemin du Croset
1024 Ecublens, Switzerland
Phone +41-21 694 34 00
FAX +41-21 694 34 09
Document 630-713
Revised 1/5/09
