Parts List and Assembly Diagram

Parts List

Part Description
1 Switch (Hy18)
2 Panel
3 Ø4 Flat Washer
4 ST4.2x14 Screw
5 Overload Protector
6 Gasket
7 Switch Box
8 Control Label
9 Feet
10 M6x25 Bolt
11 Ø6 Washer
12 Housing
13 Push Stick Clamp
14 Push Stick Block
15 Dust Cover
16 Power Cord
17 Cable Sleeve
18 Cable Clamp
19 M4x10 Bolt
20 Ø4 Spring Washer
21 Plug Clamp
22 Plug Block
23 M4 Nut
24 M4x12 Bolt
25 Plate
26 M4 Nut
27 Rack
28 M8x65 Bolt
29 Height Handle
30 M8 Nut
31 Label
32 Height Wheel
33 Spring
34 Ø2.5X22 Pin
35 Height Bar
36 Ø12 Spring Washer
37 M6 Nut
38 Bracket Base
39 Plate Stop
40 Slot Cover
41 M5x12 Bolt
42 Ø5 Spring Washer
43 Ø5 Flat Washer
44 M6x85 Bolt
45 Ø6 Flat Washer
46 Bushing
47 M6 Lock Nut
48 M5x14 Bolt
49 Magnifier
50 M8 Nut
51 Connecting Hook
52 M8x16 Bolt
53 Lock Knob
54 Ø6 Washer
55 Lock Sleeve
Page 20
Qty Part Description
1 56 M6 Nut
1 57 M6x30 Bolt
15 58 Rotary Board
16 59 M6 T-Screw
1 60 Height Bar
1 61 Bracket Base
1 62 M8 T-Screw
1 63 Ø8 Flat Washer
4 64 Bracket
4 65 M6x16 Bolt
6 66 Ø6 Spring Washer
1 67 Ø4X10 Spring Pin
2 68 M6x22 Bolt
2 69 M6x12 Bolt
1 70 Bracket
1 71 Ø45 Retaining Ring
1 72 Inner Flange
1 73 Saw Blade
1 74 Outer Flange
1 75 Blade Nut
1 76 Spring
1 77 Ø10 Flat Washer
1 78 Extension Bar
9 79 Ø4X8 Spring Pin
1 80 M5x20 Screw
9 81 Connecting Block
1 82 Bar Clamp
1 83 M6x25 Screw
1 84 M5x12 Screw
4 85 M6x12 Screw
1 86 Connecting Bar
1 87 M6x25 Screw
1 88 Riving Knife
1 89 Cover Plate
1 90 Bracket Base
9 91 Work Table
2 92 Ruler
1 93 M6x25 Screw
1 94 Lock Screw
1 95 Adjusting Lever
1 96 Pawl Lock Pin
5 97 Small Spring
9 98 Ø12 Ext. Retaining Ring
2 99 Table Insert
12 100 Anti-Kickback Pawl
3 101 Pawl Socket
15 102 Pawl Plate Location Pin
1 103 Double Twist Spring
1 104 Anti-Kickback Pawl
2 105 Pawl Plate Guard Cap
1 106 Lid Lock
1 107 M4×10 Cross Screw
1 108 Table Insert Washer (Left)
1 109 Table Insert Washer (Right)
1 110 Fence Handle
For technical questions, please call 1-888-866-5797.
Qty Part Description
7 111 Cross Recess Head Screw
1 112 Fence Guide
2 113 Ø8 Round Pin
2 114 Ø6 Round Pin
1 115 M6 Lock Handle
1 116 Fence Sliding Seat
2 117 Cam
3 118 Fence Lock
1 119 Forward Washer Plate
3 120 M6×10 Hex Bolt
9 121 Fence
2 122 Draw Bar (Fence)
4 123 Back Washer Plate
1 124 Press Spring 2
1 125 Fence Rear Plate
1 126 M6x16 Knob
1 127 Plastic Washer
1 128 Miter Gauge
1 129 6×11 Round Pin
1 130 Square Nut
1 131 Backer Cover (First)
1 132 M6×18 Handle
1 133 Miter Gauge Guide
2 134 Backer Cover (Second)
2 135 Aluminum Profile
1 136 3×20 Hollow Pin
3 137 Blade Guard
6 138 M6×10 Hex Bolt
1 139 Push Stick
2 140 Open-end Wrench
1 141 Open-end Wrench
3 146 M5×15 Cross Screw
1 147 Bearing Cover
1 148 6003 Bearing
1 149 Ø35 Retaining Ring
1 150 Output Shaft
1 151 Half-Circle Key
2 152 Gear
1 153 Ø6 Retaining Ring
1 154 Hk1210 Roller Bearing
1 155 M5x30 Screw
1 156 Middle Frame
1 157 6202 Bearing
1 158 Fan Shroud
1 159 Connecting Wire
1 160 Brush Holder Cap
2 161 Carbon Brush
1 162 Brush Holder
1 163 St4.8x65 Screw
1 164 Stator
1 165 Rotor
1 166 629 Bearing
1 167 Motor Cover
1
1
Qty
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
2
1
1
1
3
1
1
1
1
1
1
1
1
4
1
1
1
1
2
2
2
2
1
1
1
1
