Summary of Contents for Road Angel Halo

  • Page 1 User Guide...
  • Page 2 ROAD ANGEL Group Ltd has made every effort to ensure that all the information Your ROAD ANGEL Halo is guaranteed for one year from the date of purchase from contained in this manual is accurate and reliable. However, the information is all manufacturing defects that occur with normal use.
  • Page 3 ENVIRONMENTAL & COMPLIANCE SAFETY PRECAUTIONS Product Disposal Instructions • Do not disassemble or modify this product • Only use this product with the power cables supplied The symbol shown here and on the product means that it is classed as Electrical •...
  • Page 4 150°, a HD resolution of 1280p x 720p in the forward facing camera and 640p x 480p in the rear. ROAD ANGEL Halo is specifi cally designed to fi ght back against fraudulent claims as a simple, discreet accident camera suitable for use in any vehicle. Halo continuously records and saves footage as you drive, and in the event of an accident uses G-Force sensors to capture the footage in an event fi...

  • Page 5: Table Of Contents

    01. Before you start 03. Using Halo Player Product registration ................ 14 Preparing for use ................14 Installing Halo Player ............... 29 Anatomy of Halo ................15 Halo Player operation ..............30 Camera installation ................ 16 Halo device setup ................33 02.

  • Page 6: Halo Features

    Built-in back-up battery Front camera includes CMOS imaging sensor allowing high quality HD (1280 x 720) In the event of an incident, the Road Angel Halo will use its small internal battery to recording at 20 fps continue the event fi le recording*.

  • Page 7: Package Contents

    In-Car Power Cable 16GB Micro SD Card USB Micro SD Card Reader Preparing for use Anatomy of Halo Camera installation USB Stick Containing Rear Camera User Manual and Halo Quick-Start Guide 10 x Adhesive Wire Clips (with connection lead) Player Software...

  • Page 8: Preparing For Use

    BEFORE YOU START Product Registration Anatomy of Halo Before operating Halo please visit our website at www.roadangelgroup.com to register your product and activate your 12 month warranty. Preparing for use 1. Power connector Remember to check the camera position and angle before operation.

  • Page 9: Camera Installation

    fi eld of view Halo is affi xed to the windscreen using the sticky pad and to maintain a tidy interior. Alternatively cables can be supplied.

  • Page 10: Using Halo

    USING HALO Start-Up Sequence Apply power to Halo, a red LED will illuminate and an audible alarm will sound to denote that Halo is powering-up. The red LED will then change to blue, signifying that Halo has commenced Real time Recording mode.
  • Page 11 Pressing Control Button twice activates Manual Recording mode Pressing and holding the Control Button formats the Micro SD Halo will automatically revert back to Real time Recording after 15 seconds, signifi ed card. by the LED returning to constant a BLUE.
  • Page 12 When camera movement is detected, Parking Mode will save a 30 second video clip - combining 15 seconds from before mode activation with 15 seconds of footage Halo will automatically revert back to Real time Recording after 15 seconds, signifi ed from after mode activation. Halo’s LED indicator will fl ash during Parking Mode by the LED returning to constant a BLUE.
  • Page 13 End Parking Mode Recording Removing the Micro SD card during operation Should the Micro SD card be removed at any time during normal operation, Halo will Halo will automatically revert back to Real time Recording when the vehicle’s ignition is reset and then wait for another Micro SD to be inserted.
  • Page 14 USING HALO Removing power during operation (cont) If power is removed while Halo is in Event Mode, recording of the incident will continue until the end of the 15 second period before your device automatically powers down*. * Please note: If power is removed the length of the clip recorded will be determined...

  • Page 15: Using Halo Player

    Software for confi guration and video playback (known as “Halo Player”) is included on the USB stick supplied with Halo. Insert the USB stick into your computer and double click the “Halo Player” fi le to install the software in your preferred location. Please be aware Halo Player also installs a third party decoder called FFDshow.
  • Page 16 USING HALO PLAYER Halo Player Operation Halo Player Operation Video Playback Screens Front and rear video footage is played back in these areas On-Board Display Displays detailed real time information about the journey G-Sensor Graph Click here to view real time G-Sensor information...
  • Page 17 Halo Device Setup Tabs Toggle between confi guration, memory info & version info Time Manual time set (click padlock to access). Not required when using Halo with GPS Time Zone Set the time zone in which you are driving Daylight Saving...

  • Page 18: Other Information

    OTHER INFORMATION Control Button Overview Mode Press Button Once Press Button Twice Press and Hold Buton Real time recording Turn microphone on & off Start manual recording Format SD card Manual recording No action No action No action Event mode recording No action No action No action...

  • Page 19: Led Guide

    OTHER INFORMATION LED Guide Voice / Audible Alert Guide Front Camera Rear Camera Mode Voice Message / Sound Effect Remark Action Rear LED Front LED Boot Up Long Beep Sound Effect Boot Up RED ON Start Real time recording Short Beep Sound Effect Real time recording BLUE ON...
