IV.
ZENA Welder Specifications
Power Output @
100% Duty Cycle
Typical Voltage Output
@ Full Power
w/Arc Established
Typical Voltage Output
@ Full Power
w/NO Arc Established
Min. Power Generator
Shaft Speed for
Maximum Output
Power
DC Power Required
(When Welding)
DC Power Required
(When NOT Welding)
Control Circuit
Protection
Welding Controls
Accessory Controls
ZENA mobile welding system -- Operators Manual -- Series 150 & 200 Welders
150 amps.
20-24VDC w/High
Frequency Waveform
Modulation
58-78VDC w/High
Frequency Waveform
Modulation
approximately
6,500 RPM
11-14.5 volts @
7 amps. maximum
None
Internal Fuses (2)
Internal, Solid State
Internal (2)
SR150.12 welding power generator with WC12 control module
(Typically 700 modulation transitions per
second)
(Typically 700 modulation transitions per
second)
(Higher shaft speeds – up to 15,000 rpm -
have no detrimental effect on welding
performance, but welding at these speeds
requires larger drive pulley diameters)
(1 to 4 amps at average welding power
settings)
(2 amp. & 10 amp.)
(Built into electrode holder/welding cable
assembly)
7 7
