Philips PerfectCare Aqua GC8635 Service Manual

Hide thumbs Also See for PerfectCare Aqua GC8635:

Advertisement

Table of Contents

Philips Consumer Lifestyle
Service Manual

PRODUCT INFORMATION

Fast & powerful crease removal
• Soleplate: SteamGlide
• OptimalTemp
• Continuous steam output
• Continuous steam output: 120 g/min
• Steam boost: 220 g
• Vertical steam
• Steam pressure: Up to 5 bar
• Steam tip
• Power: 2400 W
Easy to use
• Water tank capacity: 2200 ml
• Filling and emptying water: Extra large filling hole
• Refill any time
• Heat-up time: 2 min
• Safety auto off
• Storage solution: Carry lock
• Hose storage: Hose storage compartment
• Power cord length: 1.8 m
• Hose length: 1.6 m
• Safe for all fabrics: Even for delicates like silks
• Low water alarm
Published by Philips Consumer Lifestyle
12/07
Calc management
• Suitable for tap water
• Calc clean solution: Easy De-calc
• Calc clean reminder
Safety Information
• This product meets the requirements regarding
interference suppression on radio and TV.
• After the product has been repaired, it should function
properly and has to meet the safety requirements and
legal regulations as officially laid down at this moment.
Printed in the Netherlands
PerfectCare Aqua
© Copyright reserved
GC8635
Subject to modification

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PerfectCare Aqua GC8635 and is the answer not in the manual?

Questions and answers

Related Manuals for Philips PerfectCare Aqua GC8635

Summary of Contents for Philips PerfectCare Aqua GC8635

  • Page 1 • Power cord length: 1.8 m • Hose length: 1.6 m • Safe for all fabrics: Even for delicates like silks • Low water alarm Published by Philips Consumer Lifestyle Printed in the Netherlands © Copyright reserved Subject to modification...
  • Page 2 Soleplate: Steam Glide New SteamGlide soleplate is the best Philips soleplate. It has great scratch resistancy, glides excellent and is easy to clean. OptimalTemp Technology...
  • Page 3 GC8635 DISASSEMBLY ADVICE - IRON LIGHT STRIP CAP ASSY 1 Remove Screw B Disassemble INLAY AND LIGHT STRIP ASSY 2 INLAY AND LIGHT STRIP ASSY 2 Disassemble REFLECTOR MOLDED 3 Remove Screw C REFLECTOR MOLDED 3 Disassemble LED MICROSWITCH HOLDER LED MICROSWITCH HOLDER ASSY 4 ASSY 4 Disassemble...
  • Page 4 GC8635 PARTS LIST - IRON Service code Description 4239 021 70734 Light strip cap assy 4239 021 70841 Inlay and light strip assy 4239 026 49561 Refl ector molded 4239 021 71942 LED microswitch holder assy 4239 014 54961 Trigger spring 4239 026 50372 Trigger molded 4239 010 12911...

  • Page 5: Exploded View - Iron

    GC8635 EXPLODED VIEW - IRON Rubber pad Rubber bung E1 E2 5-13...
  • Page 6 GC8635 DISASSEMBLY ADVICE - STAND FILLING DOOR MOLDED 17 RINSE CAP ASSY 24 REAR LOCK RUBBER 18 SAFETY CAP 25 TRAY RUBBER CAP 19 INOX CLAMP 26 TRAY CAP MOLDED 20 BRAIDED RUBBER HOSE BOILER 27 TRAY PRINTED 21 ELECTROVALVE 28 FRONT LOCK ASSY 22 SPACER TOP 29 WATER TANK ASSY 23...
  • Page 7 GC8635 DISASSEMBLY ADVICE - STAND POWER BUTTON PRINTED 37 BUTTON FRAME PRINTED 38 POWER BOARD PCB-PUMP SERVICE KIT 39 POWER CORD EU 40 STAND BOTTOM MOLDED 41 Remove Screw N1, N2, N3, N4, N5 Disassemble WATER TANK ASSY 23 Remove Screw S1, S2, S3 Disassemble POWER BUTTON PRINTED 37...
  • Page 8 GC8635 PARTS LIST - STAND Service code Description 4239 026 50134 Filling door molded 4239 015 59741 Rear lock rubber 4239 015 59731 Tray rubber cap 4239 026 51841 Tray cap molded 4239 021 71512 Tray printed 4239 021 71493 Front lock assy 4239 021 71523 Water tank assy...
  • Page 9 GC8635 EXPLODED VIEW - STAND 9-13...
  • Page 10 GC8635 EXPLODED VIEW - STAND 10-13...
  • Page 11 GC8635 WIRING DIAGRAM STAND Earth Inter- Pump connection Boiler Earth WA20 : HE (N) Thermistor - Fuse (N) Point WA19 : HE (L) - Fuse (L) WA7 - PCB to EV-Ctrl Thermal Fuse E-valve Thermal Fuse WA5 : Fuse (L) - PCB Boiler Heater WA3 : Earth WA6 : Fuse...
  • Page 12 GC8635 WIRING DIAGRAM IRON Trigger micro-switch Iron Thermistor Iron Heater JST eSL 3-way Iron Earth wite-to-wire connector Point Thermal Fuse IRON Mid-air crimp connection Hosecord (to Stand) 12-13...
  • Page 13 GC8635 REPAIR INSTRUCTIONS • Due to the high wattage of the iron, only the specified cord set must be used. • Should damage be observed on the HOSE-CORD ASSY 14 or CORDSET 40, they must be replaced. Continued usage is not allowed. •...
