Page 1 NEC Express Server Express5800 Series Express5800/T110f-S EXP285A User’s Guide Model Number: N8100-1983F/1984F Chapter 1 General Description Chapter 2 Preparations Chapter 3 Setup Chapter 4 Appendix 10.101.01-101.01 July 2013, First Edition © NEC Corporation 2013...
Page 2: Documents Provided With This Product
Chapter 2: Convenient Features Useful features and the detail of system BIOS settings, RAID Configuration Utility, and EXPRESSBUILDER Chapter 3: Appendix Error messages and Windows Event Logs Other documents Provides the detail of NEC ESMPRO, Universal RAID Utility, and the other features. Express5800/T110f-S User’s Guide...
Page 3: Table Of Contents
Contents Contents Documents Provided with This Product ......................... 2 Contents ................................3 Notations Used in this Document .......................... 7 Notations used in the text..........................7 Optical disk drives ............................7 Hard disk drives ............................7 Removable media ............................7 Abbreviations of Operating Systems ......................8 Trademarks ................................
Page 4 Contents Names and Functions of Parts ........................34 Front of the server ........................... 34 Rear view............................36 Internal view............................. 37 Motherboard ............................ 39 Status Indicators ..........................40 4.5.1 POWER LED ( ) ......................41 4.5.2 STATUS LED ( )......................41 4.5.3 Disk Access LED ( ) .....................
Page 5 Contents 1.11 PCI Card ............................69 1.11.1 Notes ..........................70 1.11.2 List of optional devices and installation slots ..............71 1.11.3 Installation.......................... 73 1.11.4 Configuration after installing ....................75 1.11.5 Removal ..........................75 1.11.6 Installing the N8117-01A extra RS-232C connector kit ............76 1.12 HDD Cages............................
Page 6 Contents Chapter 3 Setup ............................. 113 Turning on the Server..........................114 POST ............................. 115 1.1.1 POST sequence ......................115 1.1.2 POST Error Messages..................... 117 System BIOS Setup ..........................118 Overview............................118 Starting SETUP Utility ........................118 Description on On-Screen Items and Key Usage ................119 Cases that Require Setting Changes.....................
Page 7: Notations Used In This Document
Notations Used in this Document Notations Used in this Document Notations used in the text In addition to safety-related symbols urging caution, 3 other types of notations are used in this document. These notations have the following meanings. Important Indicates critical items that must be followed when handling the server or operating software. If the procedures described are not followed, server failure, data loss, and other serious malfunctions could occur.
Page 8: Abbreviations Of Operating Systems
Notations Used in this Document Abbreviations of Operating Systems Windows Operating Systems are referred to as follows. Refer to Chapter 1 (1.2 Supported Windows OS) in Installation Guide (Windows) for detailed information. Notations in this document Official names of Windows Widnows Server 2012 Standard Windows Server 2012 Widnows Server 2012 Datacenter...
Page 9: Trademarks
Trademarks Trademarks EXPRESSSCOPE are registered trademarks of NEC Corporation. Microsoft, Windows, Windows Server, Windows Vista, and MS-DOS are registered trademarks or trademarks of Microsoft Corporation in the United States and other countries. Intel, Pentium, and Xeon are registered trademarks of Intel Corporation of the United States.
Page 10: Regulatory Notices
Regulatory Notices Regulatory Notices FCC Statement This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
Page 11 Regulatory Notices Turkish RoHS information relevant for Turkish market EEE Yönetmeliğine Uygundur CCC声明有毒有害物质或元素部件名称铅汞镉六价铬多溴联苯多溴二苯醚 (Pb) (Hg) (Cd) (Cr(Ⅵ)) (PBB) (PBDE) 印刷线路板 × ○ ○ ○ ○ ○ HDD、DVD等 × ○ ○ ○ ○ ○...
Page 12 Regulatory Notices Декларація про Відповідність Вимогам Технічного Регламенту Обмеження Використання деяких Небезпечних Речовин в електричному та електронному обладнанні (затвердженого Постановою №1057 Кабінету Міністрів України) Виріб відповідає вимогам Технічного Регламенту Обмеження Використання деяких Небезпечних Речовин в електричному та електронному обладнанні (ТР ОВНР). Вміст...
Page 13: Warnings And Additions To This Document
The contents of this document may change without prior notice. Do not make copies or alter the document content without permission from NEC Corporation. Every effort has been made to ensure the completeness of this document. However, if you have any concerns, or discover errors or omissions, please contact your retailer.
Page 14: Precautions For Use (Be Sure To Read)
Names and Functions of Parts in this document. Safety precautions Follow the instructions in this document for the safe use of the NEC Express server. This User’s Guide describes hazardous parts of the server, possible hazards, and how to avoid them. Server components with possible danger are indicated with a warning label placed on or around them (or, in some cases, by printing the warnings on the server).
Page 15: Symbols Used In This Document And On Warning Labels
Precautions for Use (Be Sure to Read) (A label example used in this User’s Guide) Symbol to draw Description of a warning Term indicating a degree of danger attention WARNING Use only the specified outlet Use a grounded outlet with the specified voltage. Use of an improper power source may cause a fire or a power leak.
Page 16: Safety Notes
Precautions for Use (Be Sure to Read) Safety notes This section provides notes on using the server safely. Read this section carefully to ensure proper and safe use of the server. For symbols, refer to Safety precautions. General WARNING Do not use the server for services where human life may be at stake or high reliability is required. This server is not intended for use in medical, nuclear, aerospace, mass transit or other applications where human life may be at stake or high reliability is required, nor is it intended for use in controlling such applications.
Page 17: Power Supply And Power Cord Use
Precautions for Use (Be Sure to Read) Power supply and power cord use WARNING Do not hold the power plug with a wet hand. Do not disconnect/connect the plug while your hands are wet. Failure to follow this warning may cause an electric shock.
Page 18 Precautions for Use (Be Sure to Read) CAUTION Do not use any unauthorized interface cable. Use only the interface cables provided with the server. Electric current that exceeds the amount allowed could cause fire. Also, observe the following precautions to prevent electrical shock or fire caused by a damaged power cord.
Page 19: Installation, Relocation, Storage, And Connection
Use only the specified interface cable. Use only interface cables provided by NEC and locate a proper device and connector before connecting a cable. Using an authorized cable or connecting a cable to an improper destination may cause a short circuit, resulting in a fire.
Page 20: Cleaning And Working With Internal Devices
Precautions for Use (Be Sure to Read) Cleaning and working with internal devices WARNING Do not disassemble, repair, or alter the server. Never attempt to disassemble, repair, or alter the server on any occasion except as described in this document. Failure to follow this warning may cause not only malfunction of the server but also an electric shock or fire.
Page 21: During Operation
Precautions for Use (Be Sure to Read) During operation CAUTION Avoid contact with the server during thunderstorms. Do not touch any part of the server including the cables when a thunderstorm is approaching. Also, do not connect or disconnect any devices. There may be a risk of electric shock from lightning strike. Keep animals away from the server.
Page 22: Warning Labels
Precautions for Use (Be Sure to Read) Warning labels Warning label are attached on or near the components with potential hazards (This label is either attached or printed on the component.) to draw attention from users to potential hazards involved in handling the server. (Do not remove or black out this label and keep it clean).
Page 23: Handling Precautions (For Proper Operations)
Precautions for Use (Be Sure to Read) Handling precautions for proper operations Be sure to observe the following precautions for the proper functioning of the server. Ignoring the precautions may cause server malfunction or failure. • Do not use any cell phone or PHS and switch off them near the server. Electric waves from such devices can cause server to malfunction.
Page 24 Tape media: Approximately 1 day • For optional devices, we recommend you use our NEC products. Some memory or Hard Disk Drive manufactured by other companies are supported for use with this server, however, you will be charged to repair failure or damage caused by use of such products even within warranty period.
Page 25: Anti-Static Measures
Precautions for Use (Be Sure to Read) Anti-Static Measures This product contains static-sensitive electronic components. Follow the measures below to avoid a failure caused by static electricity when installing or uninstalling any optional device. • Wearing Anti-static Wrist Strap or Anti-static Gloves Wear a wrist strap on your wrist and connect the wire to the chassis.
Page 26 Precautions for Use (Be Sure to Read) Tips for your health and safety Using a computer extensively may affect different parts of your body. Here are tips you should follow while working on a computer to minimize strain on your body. Keep proper posture The basic body position for using a computer is sitting straight with your hands on the keyboard parallel with the floor, and your eyes...
Page 27: Chapter 1 General Description
NEC Express5800 Series Express5800/T110f-S General Description This chapter introduces the features of this server and the name of each part. 1. Introduction 2. Accessories Verify the condition of your server's accessories. 3. Standard Features Check and maintain the server system by using the functions explained in this section.
Page 28: Introduction
The server is designed with consideration of not only reliability but also expandability, which enables you to use it as a network server. Read this document before using the server thoroughly to fully understand handling of the NEC Express server and appreciate its functions to the maximum extent.
Page 29: Accessories
Chapter 1 General Description 2. Accessories Accessories The carton box contains various accessories which are required for setup or maintenance. Make sure you have them all for future use. • Keyboard × 1 • Mouse × 1 • Rubber foot × 4 •...
Page 30: Standard Features
Internal voltage monitoring feature • RAID System (Disk Array) (also available as an option) • BIOS password feature Management utilities • NEC ESMPRO • ExpressUpdate • Remote controlling feature (EXPRESSSCOPE Engine 3) • RAID System management utility (Universal RAID Utility) •...
Page 31 Chapter 1 General Description 3. Standard Features Many built-in features • El Torito Bootable CD-ROM (no emulation mode) format supported • Software power-off • Remote power-on feature • AC-Link feature • Remote console feature • Baseboard Management Controller (BMC) conforming to IPMI v2.0 Self-diagnosis •...
Page 32: Management Features
The hardware components of the server provide operation control/reliability features as shown below. Additionally, NEC ESMPRO Agent, which is provided in EXPRESSBUILDER, enables you to collectively manage the state of your systems. You can also monitor the server states from a PC to manage the network where NEC ESMPRO Manager provided in EXPRESSBUILDER is installed.
Page 33: Firmware And Software Version Management
3. Standard Features Firmware and Software Version Management By using NEC ESMPRO Manager and ExpressUpdate Agent, you can manage firmware or software on the server and update them by applying an update package. This function automatically updates multiple modules without stopping the system just by specifying the application of an update package from NEC ESMPRO Manager.
Page 34: Names And Functions Of Parts
Chapter 1 General Description 4. Names and Functions of Parts Names and Functions of Parts Names and functions of parts are as follows. Front of the server Air Cooling model (10) (11) (12) (1) POWER Switch (6) Front Bezel The switch to turn the server on and off. Press once to turn This cover protects the front part of the server.
Page 35 Chapter 1 General Description 4. Names and Functions of Parts Liquid Cooling model (10) (11) (1) POWER Switch (6) Front Bezel The switch to turn the server on and off. Press once to turn This cover protects the front part of the server. on the server.
Page 36: Rear View
Chapter 1 General Description 4. Names and Functions of Parts Rear view Air Cooling model, liquid Cooling model (5) (4) (11) (12) (10) (13) (11) (1) AC Inlet (8) USB connectors This socket is used to connect the power cord. These connectors are used to connect devices that support (2) PCI slots the USB interface.
Page 37: Internal View
Chapter 1 General Description 4. Names and Functions of Parts Internal view <Air Cooling model> (10) Power supply unit 3.5-inch Expansion Bay 1 Cooling fan (CPU) A bay that can accommodate an extra 2.5-inch HDD cage DIMM slots (N8154-56F) Hard Disk Drive Bay 3.5-inch Expansion Bay 2 Can be equipped with 3.5-inch or 2.5-inch hard disk drives.
Page 38 Chapter 1 General Description 4. Names and Functions of Parts <Liquid Cooling model> (2) (3) (11) (10) (10) Power supply unit Motherboard Liquid cooling unit (for cooling CPU) Cooling fan (radiator) DIMM slots Radiator Hard disk drive bay (10) PCI slots Can be equipped with 3.5-inch or 2.5-inch hard disk drives.
Page 39: Motherboard
Chapter 1 General Description 4. Names and Functions of Parts Motherboard (12) (22) (21) (1)-2 (1)-4 (1)-1 (19) (1)-3 (20) (25) (23) (18)-1 (6)-4 (18)-2 (6)-5 (18)-3 (18)-4 (17) (16) (13)(15) (10) (11) (24) (14) DIMM slots (the number after hyphen indicates DIMM (16) Serial port (COM B) connector (for N8117-01A) number) (17) SPI Flash Mezzanine connector...
Page 40: Status Indicators
Chapter 1 General Description 4. Names and Functions of Parts Status Indicators This section explains the indication and meanings of the server LEDs. LINK/ACT POWER LED DISK Access LED STATUS LED Optical disk access LED SPEED LED Rear view Front view Express5800/T110f-S User’s Guide...
Page 41: Power Led ( )
The following table lists STATUS LED patterns, their explanation and solution. Tips Refer to the system event log (SEL) by using NEC ESMPRO or the offline maintenance utility to view the cause of failure. STATUS LED pattern...
Page 42: Disk Access Led ( )
Chapter 1 General Description 4. Names and Functions of Parts STATUS LED pattern Explanation Solution Failure of the power supply unit is detected Contact your sales representative. Flashing (amber) A fan alarm was detected. Check if the internal fan cable is properly connected. If the LED indication does not change when the fans are normal, contact your sales representative.
Page 43: Speed Led ( 1, 2, M)
Chapter 1 General Description 4. Names and Functions of Parts 4.5.7 SPEED LED ( 1, This LED indicates which network interface is used. − The two LAN connectors for data transmission support 1000BASE-T, 100BASE-TX, and 10BASE-T and the LED indicates which network interface is being used. •...
Page 44: Chapter 2 Preparations
NEC Express5800 Series Express5800/T110f-S Preparations This chapter describes preparations for using this server. 1. Installing Internal Optional Devices You can skip this section if you did not purchase any optional devices. 2. Installation and Connection You must place the server in an ideal location and connect some cables following this section.
Page 45: Installing Internal Optional Devices
• Use only the devices and cables specified by NEC. You will be charged to repair damages, malfunctions, and failures caused by the use of any devices or cables not specified for use with this server even within the warranty period.
Page 46: Anti-Static Measures
Chapter 2 Preparations 1. Installing Internal Optional Devices Anti-static Measures This product contains static-sensitive electronic components. Follow the measures below to avoid a failure caused by static electricity when installing or uninstalling any optional device. • Wearing Anti-static Wrist Strap or Anti-static Gloves Wear a wrist strap on your wrist and connect the wire to the chassis.
Page 47: Overview Of Installation And Removal
Chapter 2 Preparations 1. Installing Internal Optional Devices Overview of Installation and Removal Install/remove components by using the following procedure. If the server is ON, turn it off. Refer to Chapter 3 (6. Turning off the Server). Disconnect the power cord from the outlet and the server. Disconnect all cables connected to the connector at the rear.
Page 48: Removing The Side Cover
Chapter 2 Preparations 1. Installing Internal Optional Devices Removing the Side Cover Remove the side cover by using the following procedure. Refer to steps 1 to 3 in Chapter 2 (1.3 Overview of Installation and Removal) for preparations. Unlock the padlock attached to the chassis if applicable.
Page 49: Removing The Front Bezel
Chapter 2 Preparations 1. Installing Internal Optional Devices Removing the Front Bezel Remove the front bezel by using the following procedure. Refer to steps 1 to 3 in Chapter 2 (1.3 Overview of Installation and Removal) for preparations. Remove the screw. Place the server in the direction shown in the figure, and then pull the front bezel slightly toward the front until the tab can be released from the frame.
Page 50: Internal Flash Memory
Chapter 2 Preparations 1. Installing Internal Optional Devices Internal Flash Memory This section describes the procedure for installing the Internal Flash Memory. Internal Flash Memory connector 1.6.1 Installation Install the Internal Flash Memory in the following procedure. Refer to steps 1 to 5 in Chapter 2 (1.3 Overview of Installation and Removal) for preparations. Attach the Internal Flash Memory and fix it with the screw that comes with this product.
Page 51: Tpm Kit
Chapter 2 Preparations 1. Installing Internal Optional Devices TPM Kit This section describes the procedure for installing optional TPM Kit. TPM kit connector 1.7.1 Installation Install the TPM Kit in accordance with the following procedure. Note The TPM kit once installed cannot be removed. Refer to steps 1 to 5 in Chapter 2 (1.3 Overview of Installation and Removal) for preparations.
Page 52: Dimm
DIMMs. Up to 32 GB (8 GB × 4) of memory can be installed. • Use only the DIMMs specified by NEC. Installing a DIMM from a third party Important may cause the server to fail. (You will be charged to repair failures or damages caused by the use of such products even within the warranty period.)
Page 53: Maximum Supported Memory Size
Chapter 2 Preparations 1. Installing Internal Optional Devices 1.8.1 Maximum supported memory size The maximum available memory size on the server depends on the architecture (x86 architecture) and OS specs. A list of maximum memory sizes The maximum memory size The maximum memory size supported on each OS supported on the server...
Page 54: Installation
Chapter 2 Preparations 1. Installing Internal Optional Devices 1.8.3 Installation Install a DIMM by using the following procedure. Refer to steps 1 to 5 in Chapter 2 (1.3 Overview of Installation and Removal) for preparations. Hold the server with both hands and slowly and gently lay it so that the left side faces upward Rotate both levers of the target DIMM slot outward.
Page 55: Removal
• When removing a defective DIMM, check error messages displayed at POST or Note NEC ESMPRO and check the DIMM slot where the defective DIMM is installed. • At least one DIMM needs to be installed for the server to operate.
Page 56: Use Of Internal Hard Disk Drives In The Raid System
Chapter 2 Preparations 1. Installing Internal Optional Devices Use of Internal Hard Disk Drives in the RAID System This section describes how to use the Hard Disk Drives installed in the HDD cage at the front of the server in the RAID System.
Page 57 Chapter 2 Preparations 1. Installing Internal Optional Devices J7 jumper On-board SATA Optional RAID Controller Controller 3 2 1 3 2 1 Backplane for 2.5-inch Hard Disk Drives (when a 2.5-inch HDD cage is installed) When using on-board RAID Controllers (LSI Embedded MegaRAID Change jumper switch setting as shown below.
Page 58 Chapter 2 Preparations 1. Installing Internal Optional Devices If an optional RAID Controller is used Jumper pins on motherboard (SWRAID) Change jumper setting to 1-2 (Disabled). Backplane for 2.5-inch Hard Disk Drive (provided with 2.5-inch models) (J7) Change jumper setting to 2-3 (Optional RAID Controller) Note When installing an optional RAID Controller, start the BIOS Setup utility, select PCI Configuration from the Advanced menu, and then make sure that the...
Page 59: Notes On Setting Up A Raid System
Chapter 2 Preparations 1. Installing Internal Optional Devices 1.9.1 Notes on setting up a RAID System Note the following points when setting up a RAID System. • The number of Hard Disk Drives required varies in each RAID level. • If an on-board RAID Controller or optional RAID Controller (N8103-128/149) is used, the RAID System cannot be built in RAID5/RAID6.
Page 60 Chapter 2 Preparations 1. Installing Internal Optional Devices The insert position number displayed on the server <3.5-inch HDD cage> <2.5-inch HDD cage> N8154-65F 3.5-inch HDD cage N8154-59F 2.5-inch HDD cage <3.5-inch HDD cage and extra 2.5-inch HDD cage> <2.5-inch HDD cage and extra 2.5-inch HDD cage> N8154-56F extra 2.5-inch HDD cage N8154-65F...
Page 61: Extra Battery For Raid Controller
Chapter 2 Preparations 1. Installing Internal Optional Devices 1.10 Extra Battery for RAID Controller If a RAID Controller (N8103-149/150/151/167) is installed, use the optional extra battery to avoid data loss caused by accidents including temporary blackout during a write-back operation. The model of the extra battery to be used depends on RAID Controller.
Page 62 Chapter 2 Preparations 1. Installing Internal Optional Devices Connecting the battery control cable Referring to the image below, connect the battery control cable into the battery pack. Check the orientation of the connector and connect the cable straight into the connector. The upper portion is wider than that of lower portion.
Page 63 Chapter 2 Preparations 1. Installing Internal Optional Devices Installing the battery pack Remove one screw from the front panel bracket. Slide the front panel bracket slightly toward the right, and then pull the bracket toward the front to remove it. Important Be careful so that the cable does not come out from the connector when pulling the front panel bracket.
Page 64 Chapter 2 Preparations 1. Installing Internal Optional Devices Draw the cable into the chassis and mount the front panel bracket on the server chassis in the reverse order of the removal procedure. Connecting to a RAID Controller Connect another connector of the flash backup unit control cable to the connector on the RAID Controller.
Page 65: Removal
Chapter 2 Preparations 1. Installing Internal Optional Devices Install the RAID Controller into the PCI slot #4 and fix it in place. Be careful not to disconnect the battery control cable. RAID Controller Connect the cables and components that you removed earlier. 1.10.3 Removal To remove the extra battery for the RAID Controller, reverse the installation procedure.
Page 66 Chapter 2 Preparations 1. Installing Internal Optional Devices Installing the flash backup unit in the server This section describes how to install this product in the server. Start Preparation for installation Installing the flash backup unit Connecting to RAID Controller Finish Getting ready to install the battery Refer to Chapter 2 (1.3 Overview of Installation and Removal) for preparations.
Page 67 Chapter 2 Preparations 1. Installing Internal Optional Devices Mount the flash backup unit on the RAID Controller by using the anchoring bracket that comes with the RAID Controller and secure it by using a single screw. Screw Insert the two hooks of the anchoring bracket into the holes on the front...
Page 68: Removal
Chapter 2 Preparations 1. Installing Internal Optional Devices Connecting to a RAID Controller Connect another connector of the flash backup unit control cable to the connector on the RAID Controller. Check the orientation of the connector and connect the cable straight into the connector.
Page 69: Pci Card
Chapter 2 Preparations 1. Installing Internal Optional Devices 1.11 PCI Card This server provides four slots where PCI cards can be installed. • You must avoid static electricity to work with the procedure below. For Important details, refer to Chapter 2 (1.2 Anti-static Measures). •...
Page 70: Notes
Chapter 2 Preparations 1. Installing Internal Optional Devices 1.11.1 Notes Read the following notes when installing or removing a PCI card. • Do not touch the terminals of cards and the leads of electronic components with your bare hand. Fingerprints and dust left on them cause the server to malfunction due to a connection failure or damage to the leads.
Page 71: List Of Optional Devices And Installation Slots
Chapter 2 Preparations 1. Installing Internal Optional Devices 1.11.2 List of optional devices and installation slots PCI EXPRESS PCI#1 PCI#2 PCI#3 PCI#4 Product PCI slot performance Model name Remark lane lane lane lane name PCI slot size Low Profile PCI board socket type Size of mountable 168 mm or less board...
Page 72 Chapter 2 Preparations 1. Installing Internal Optional Devices About the standard network You can use functional equivalents of AFT/SFT/ALB teaming and bonding with the standard network and the following LAN cards: N8104-132 and N8104-138 Express5800/T110f-S User’s Guide...
Page 73: Installation
Chapter 2 Preparations 1. Installing Internal Optional Devices 1.11.3 Installation Install a PCI card to connect to a PCI slot by using the following procedure. Before installation, make sure the switch or jumper settings on the card are properly set according to the instruction manual supplied with the card if necessary.
Page 74 Chapter 2 Preparations 1. Installing Internal Optional Devices Orient the component side of the card toward the bottom of the server. When the rear panel of the card is firmly engaged with the spring, firmly press the card into the slot so that the component parts of the card securely connect to the slot.
Page 75: Configuration After Installing
Chapter 2 Preparations 1. Installing Internal Optional Devices 1.11.4 Configuration after installing Depending on the type of card installed, you might need to use a utility (the BIOS setup utility included with this server or a setup utility provided with the card) following installation to modify server settings. Follow the instructions in the manual provided with the card to specify the correct settings.
Page 76: Installing The N8117-01A Extra Rs-232C Connector Kit
Chapter 2 Preparations 1. Installing Internal Optional Devices 1.11.6 Installing the N8117-01A extra RS-232C connector kit Install a PCI card to connect to the PCI slot by using the following procedure. For details, refer to the instruction manual supplied with the connector kit. Important The N8117-01A extra RS-232C connector kit contains two types of cables.
Page 77 Chapter 2 Preparations 1. Installing Internal Optional Devices Remove the expansion blank cover aligned with the slot where you are going to install a card. Important Keep the removed blank cover for future use. Make sure that you are properly inserting the bracket edge into the frame guide, and attach it securely.
Page 78 Chapter 2 Preparations 1. Installing Internal Optional Devices Arrange the cable so as not to buffer other PCI cards, and connect to the COM connector used for internal connections in the motherboard. Refer to the following for the position of the COM connector for internal connections. •...
Page 79: Hdd Cages
Disk Drives can be installed. Important Use Hard Disk Drives specified by NEC. Installing a third-party Hard Disk Drive might cause a failure of the server and the Hard Disk Drive. You will be charged for maintenance for failures and damage caused by these products, even during the maintenance period.
Page 80: Installing A 3.5-Inch Hdd Cage And Hard Disk Drives
Chapter 2 Preparations 1. Installing Internal Optional Devices 1.12.1 Installing a 3.5-inch HDD cage and hard disk drives Install a 3.5-inch HDD cage in the server by using the following procedure. Refer to Chapter 2 (1.3 Overview of Installation and Removal) for preparations. Remove the side cover and front bezel by referring to Chapter 2 (1.4 Removing the Side Cover and 1.5 Removing the Front Bezel).
Page 81: Removing Hard Disk Drives
Chapter 2 Preparations 1. Installing Internal Optional Devices Insert the hard disk drive attached to the tray into the slot of the HDD cage. When it is pushed to the end, it locks with a click. Connect the signal cables and power cable to the hard disk drive. Use the signal cables that come with the HDD cage.
Page 82: Installing A 2.5-Inch Hdd Cage And Hard Disk Drives
N8154-56F 2.5-inch extra HDD cage can mount a SATA HDD, and vice versa. Important Use Hard Disk Drives specified by NEC. Installing a third-party Hard Disk Drive might cause a failure of the server and the Hard Disk Drive. You will be charged for maintenance for failures and damage caused by these products, even during the maintenance period.
Page 83 Chapter 2 Preparations 1. Installing Internal Optional Devices Install a 2.5-inch HDD cage in the server by using the following procedure. Refer to Chapter 2 (1.3 Overview of Installation and Removal) for preparations. While referring to Chapter 2 (1.4 Removing the Side Cover and 1.5 Removing the Front Bezel, remove the side cover and front bezel.
Page 84 Chapter 2 Preparations 1. Installing Internal Optional Devices Connect the interface cable and power cable to the HDD cage. Use the interface cable that comes with the HDD cage. Use the power cable connected to the motherboard in advance. For details of cable connection, refer to (2.2.1 Interface cables) described later.
Page 85: Installing An Extra 2.5-Inch Hdd Cage
Chapter 2 Preparations 1. Installing Internal Optional Devices 1.12.4 Installing an extra 2.5-inch HDD cage Two hard disks can be added by using an extra 2.5-inch HDD cage. Tips With a liquid-cooled server, an extra 2.5-inch HDD cage cannot be used at the same time as a backup device.
Page 86: How To Open The Extra 2.5-Inch Hdd Cage Door
Chapter 2 Preparations 1. Installing Internal Optional Devices Open the front door of the standard 2.5-inch HDD cage. Slide the tab on the bezel of the extra 2.5-inch HDD cage in the direction shown by the arrow, and then remove it from the bezel. Sliding this tab toward the outside of the bezel allows you to lock the bezel of the extra 2.5-inch HDD cage when the front door of the standard 2.5-inch HDD...
Page 87: Installing The Hard Disk Drive
When finished, close the lever to lock the hard disk drive (2). (You will hear a click.) Important Use only the hard disk drives recommended by NEC. Ask your sales agent or service representative for details. Note Make sure that the orientation of the hard disk drive (tray) before insertion (see the figure) is correct.
Page 88: Optical Disk Drive
Procedures for replacing the standard optical disk drive with the optional internal DVD SuperMULTI drive are described below. Important Do not install a drive other than those specified by NEC. 1.13.1 Replacing drives Follow the procedure below to replace your drive with the optional internal DVD SuperMULTI drive.
Page 89: Removal
Chapter 2 Preparations 1. Installing Internal Optional Devices Mount the bracket for the optical disk drive on the DVD SuperMULTI drive. Install the bracket with DVD SuperMULTI drive installed to the server. Connect the SATA cable and DC power cable you disconnected in step 3 to the server. This completes the installation procedures.
Page 90: Backup Devices
Chapter 2 Preparations 1. Installing Internal Optional Devices 1.14 Backup devices The 3.5-inch device bay of the server can contain a backup device such as a magnetic tape drive. In an air cooled server, install the backup device in 3.5-inch device bay 2. In a liquid-cooled server, install the backup device in 3.5-inch device bay 1.
Page 91: Installation
Chapter 2 Preparations 1. Installing Internal Optional Devices 1.14.1 Installation Install a backup device by using the following procedure. Refer to Chapter 2 (1.3 Overview of Installation and Removal) for preparations. Remove the side cover and front bezel while referring to Chapter 2 (1.4 Removing the Side Cover and 1.5 Removing the Front Bezel).
Page 92: Connecting Cables
Chapter 2 Preparations 1. Installing Internal Optional Devices 1.15 Connecting cables This section shows an example of internal device cable connection. 1.15.1 Internal interface cables This section describes the connection of internal interface cables. Tips The figure shown here primarily describes connections. For more information about the connectors on the motherboard, refer to Chapter 1 (5.4 Motherboard).
Page 93 Chapter 2 Preparations 1. Installing Internal Optional Devices • If a RAID Controller (N8103-171/149) has been added Connecting to a RAID Controller (N8103-171/149) requires a dedicated cable (K410-277(00)) for use with RAID Controllers. Install the Hard Disk Drives in order from the left side. Power supply unit Optical disk drive...
Page 94 Chapter 2 Preparations 1. Installing Internal Optional Devices • When a RAID Controller (N8103-149) is installed and an extra 2.5-inch HDD cage (N8154-56F) is connected: When a RAID Controller (N8103-149) is installed and an extra 2.5-inch HDD cage (N8154-56F) is connected, dedicated cables (K410-277(00) and K410-287(00)) are required.
Page 95 Chapter 2 Preparations 1. Installing Internal Optional Devices • About RAID LED cables Important The DISK access LED on the front of the equipment shows the access status of Hard Disk Drives that are connected to a RAID Controller. To display this status, connect the LED cable that comes with the optional K cord cable K410-277(00).
Page 96 Chapter 2 Preparations 1. Installing Internal Optional Devices In case of 3.5-inch Hard Disk Drive installed When adding 3.5-inch Hard Disk Drives, connect the cables as in the following figure. Install the Hard Disk Drives in order from slot 0. •...
Page 97 Chapter 2 Preparations 1. Installing Internal Optional Devices • If a RAID Controller (N8103-171/149/150/151/167) has been added If SAS or SATA Hard Disk Drives are installed and used in a RAID System with a RAID Controller (N8103-128/149/150/151), the dedicated cable K410-180(00) is required. Install Hard Disk Drives from Slot 0 in ascending order.
Page 98 Chapter 2 Preparations 1. Installing Internal Optional Devices Power Extra 2.5-inch HDD cage supply unit (N8154-56F) Slot 4: Fifth Hard Disk Drive Slot 5: Sixth Hard Disk Drive I-SAS5 I-SAS4 BP IF1 Optical disk drive Motherboard Extra battery (N8103-155 or SATA4 flash backup unit included with M8103-167) (0 to 3)
Page 99 Chapter 2 Preparations 1. Installing Internal Optional Devices Connecting backup devices The 3.5-inch device bay of the server can mount USB devices (for internal connection). If mounting an internal USB device (In case of Air Cooling model) Use the dedicated internal USB cable (for USB 3.0: K410-276(00), for USB 2.0: K410-286(00). Power supply unit Backup device 2...
Page 100: Power Cables
Chapter 2 Preparations 1. Installing Internal Optional Devices 1.15.2 Power cables The illustration below shows an example of connecting the power cables. Power cables other than those shown here are not used by the devices. When using 3.5-inch Hard Disk Drives in air cooling model and an extra 2.5-inch HDD cage and a backup device are installed Power supply unit...
Page 101 Chapter 2 Preparations 1. Installing Internal Optional Devices 3.5-inch Hard Disk Drives in liquid cooling model and a backup device is installed Power supply unit 3.5-inch backup device 2.5 x 2HDD PWR DET 1 3.5 Dev. Optical disk drive Motherboard 3.5 HDD 1 3.5-inch HDD cage (N8154-65F)
Page 102 Chapter 2 Preparations 1. Installing Internal Optional Devices When using 2.5-inch Hard Disk Drives in liquid cooling model and an extra 2.5-inch HDD cage is installed Power supply unit Extra 2.5-inch HDD cage (N8154-56F) 2.5 x 2HDD 3.5 Dev. PWR DET 1 Optical disk drive Motherboard 2.5-inch HDD cage...
Page 103: Attaching The Front Bezel
Chapter 2 Preparations 1. Installing Internal Optional Devices 1.16 Attaching the Front Bezel You can attach the front bezel by reversing the removal procedure. Insert the tab inside the front bezel into the hole on the front upper side of the server, push the left side of the front bezel toward the server, and then lock the bezel by using the tab on the upper side of the bezel.
Page 104: Installing The Side Cover
Chapter 2 Preparations 1. Installing Internal Optional Devices 1.17 Installing the Side Cover You can attach the side cover by reversing the removal procedure. Make sure that hooks at both the top and bottom of the side cover are securely inserted in the holes on the server frame.
Page 105: Installation And Connection
Chapter 2 Preparations 2. Installation and Connection Installation and Connection This section describes how to position the server and connect cables. Installation CAUTION Be sure to observe the following precautions to use of the server safely. Failure to observe the precautions may cause burns, injury, and property damage. For details, refer to Safety precautions in Precautions for Use.
Page 106 Chapter 2 Preparations 2. Installation and Connection Do not install the server in an environment in which any of the following conditions apply: Installing the server in any of the following conditions will cause the server to malfunction. Places where corrosive gas is present (environments where there is sulfur vapor in the atmosphere), or places Place of drastic temperature change...
Page 107: Preparation For Installation
Chapter 2 Preparations 2. Installation and Connection 2.1.1 Preparation for installation For vertical mounting For vertical use of the server, the stabilizer attached to the bottom of the server must be removed to change the orientation as instructed below. Also be sure to attach the vent holes cover for cooling on the top of the server. Removing/installing the stabilizer Removing the stabilizer Release the lock lever and slide it in the direction of the arrow to remove.
Page 108 Chapter 2 Preparations 2. Installation and Connection After attaching the stabilizers, set up the server as shown in the image. Tips When two or more servers are installed vertically side by side, installing the stabilizers in slots 1 and 2 alternately can remove the gap between servers. The server in which the The server in which the stabilizer is installed in slot 2...
Page 109: Connection
Chapter 2 Preparations 2. Installation and Connection Connection Connect peripheral devices to the server. Connectors that allow a variety of peripheral devices to be connected are provided at the front and rear of the server. Images on the following pages show the peripheral devices that can be connected in their standard state and their respective connector positions.
Page 110: Interface Cables
• The connectors that are not explained here are not used. Do not connect anything to the connectors. • Be sure to use the display unit specified by NEC. The operation is not guaranteed if you install a display unit not specified by NEC.
Page 111 Chapter 2 Preparations 2. Installation and Connection <Front view> USB devices (such as a FD drive) <Rear view> Finally, connect the provided power cord to an outlet. A device with serial interface (such as a modem) Display unit Hub/Switching hub USB devices (such as a terminal adapter) Express5800/T110f-S User’s Guide...
Page 112: Power Cord
Chapter 2 Preparations 2. Installation and Connection 2.2.2 Power cord Connect the provided power cord to the server. • To connect the power cord to a UPS, connect it to the outlet provided at the rear Tips of the UPS. For details, refer to the instruction manual supplied with the UPS •...
Page 113: Chapter 3 Setup
NEC Express5800 Series Express5800/T110f-S Setup This chapter describes how to set up the server. 1. Turning on the Server POST (Power-On Self-Test) is explained in this section. 2. System BIOS Setup You can customize BIOS settings by following the instructions in this section.
Page 114: Turning On The Server
3. Press the POWER switch at the front of the server. The POWER LED is turned on green and after a while, the NEC logo appears on the display. While the NEC logo is being displayed, the self-diagnostic program (POST) runs and diagnoses the hardware. For details, refer to Chapter 3 (1.1 POST).
Page 115: Post
POST starts memory check. When the memory check is completed, some messages appear. As factory settings, the NEC logo appears on the screen during POST. 2. When Password On Boot is set to Enabled on the Security menu in the BIOS setup utility (SETUP), the logo is displayed, and then the password entry screen is displayed.
Page 116 Chapter 3 Setup 1. Turning on the Server 5. After a while, the following message is displayed on the screen. Press <F2> SETUP, <F3> Internal Flash Memory, <F4> ROM Utility, <F12> Network By pressing the designated function key following messages, you can call the functions below upon completion of POST.
Page 117: Post Error Messages
Chapter 3 Setup 1. Turning on the Server 1.1.2 POST Error Messages When POST detects an error, it displays an error message on the screen or beeps for some errors. For descriptions of error messages, causes, and countermeasures, refer to "Maintenance Guide". Note Take notes on the messages displayed before consulting with your maintenance service company.
Page 118: System Bios Setup
Press <F2> SETUP, <F3> Internal Flash Memory, <F4> ROM Utility, <F12> Network If you press the <F2> key at this time, SETUP runs and displays the Main menu upon completion of POST. (You can also press the <F2> key while the NEC logo appears to display the Main menu.) Important If a password is set, you will be prompted to enter the password at the next startup of the SETUP utility.
Page 119: Description On On-Screen Items And Key Usage
Chapter 3 Setup 2. System BIOS Setup Description on On-Screen Items and Key Usage This section shows display examples and how to control the key. Use the keyboard to work with the SETUP utility. Indicates the currently displayed menu Indicates the menu has submenus.
Page 120 Chapter 3 Setup 2. System BIOS Setup <F2> key If you press this key, the following window appears. If you select Yes, the previous parameter(s) are restored. Load Previous Values? [Yes] <F3> key If you press this key, the following window appears. If you select Yes, restore the parameters of the currently selected item to the default setting.
Page 121: Cases That Require Setting Changes
On/Off NumLock on power ON Boot → Quite Boot → Disabled On/Off the function to display By pressing the <Esc> key, the NEC logo during POST prevent the display of the logo. Advanced → PCI Configuration → PCI Optional When an optional board is...
Page 122 Chapter 3 Setup 2. System BIOS Setup Category Description To be changed Remark Server → Power Control When the server is supplied Configuration → AC-LINK → Power Powerlink with power from UPS, always turn on the power. Server → Power Control If it is turned off by using Configuration →...
Page 123: Expressscope Engine 3
Chapter 3 Setup 3. EXPRESSSCOPE ENGINE 3 EXPRESSSCOPE ENGINE 3 Overview EXPRESSSCOPE Engine 3 provides a variety of features using BMC (Baseboard Management Controller), which is a system management LSI. EXPRESSSCOPE Engine 3 monitors the power unit, fans, temperature, and voltage of the server. If you have the management LAN connector connected to the network, you can remotely perform the following over a web browser or SSH client: •...
Page 124: Expressscope Engine 3 Network Configuration
2. If you press the <F4> key at this time, ROM utility starts upon completion of POST. You can also press the <F4> key while the NEC logo is being displayed to open the Off-line TOOL MENU screen. 3. The keyboard selection screen appears. Select your keyboard type.
Page 125 Chapter 3 Setup 3. EXPRESSSCOPE ENGINE 3 5. If Property is selected, the following screen is displayed. On this screen, specify whether to use DHCP and if DHCP is not used, configure IP Address/Subnet Mask. Tips If Shared BMC LAN is enabled, Web feature, remote media/KVM feature, or command line interface feature may be interrupted.
Page 126: Expressbuilder
RAID configuration to installation of applications. To use this feature, (Windows reinstallation) select Os installation in the menu after boot. Storage of software* Stores various bundled software (such as NEC ESMPRO Agent). Maintenance Diagnoses your server system. To use this feature, select Tool menu in the menu after boot.
Page 127: Installing Software Components
Chapter 3 Setup 5. Installing Software Components Installing Software Components Continue to install software components such as OS. Refer to the instructions below. • Installation Guide (Windows) Express5800/T110f-S User’s Guide...
Page 128: Turning Off The Server
Chapter 3 Setup 6. Turning off the Server Turning off the Server Turn off the server by using the following procedure. If the power cord of the server is connected to a UPS, refer to the documentation supplied with the UPS or the documentation for the application controlling the UPS. 1.
Page 129: Chapter 4 Appendix
NEC Express5800 Series Express5800/T110f-S Appendix Specifications Interrupt Lines Express5800/T110f-S User’s Guide...
Page 130: Specifications
Chapter 4 Appendix 1. Specifications Specifications Air Cooling System Express5800/T110f-S, EXP285A Product name N8100-1983F ® ® ® ® ® ® Type Intel Xeon Intel Xeon Intel Xeon processor E3-1220 v3 processor E3-1230L v3 processor E3-1265L v3 Clock/cache 3.10 GHz/8 MB 1.80 GHz/8 MB 2.50 GHz/8 MB Standard /...
Page 131: Liquid Cooling System
Chapter 4 Appendix 1. Specifications Liquid Cooling System Express5800/T110f-S, EXP285A Product name N8100-1984F ® ® ® ® ® ® Type Intel Xeon Intel Xeon Intel Xeon processor E3-1220 v3 processor E3-1230L v3 processor E3-1265L v3 Clock/cache 3.10 GHz/8 MB 1.80 GHz/8 MB 2.50 GHz/8 MB Standard / Not pre-installed / (1)
Page 132: Interrupt Lines
Chapter 4 Appendix 2. Interrupt Lines Interrupt Lines Interrupt lines are assigned as factory settings as shown below. Use this table as a reference when you add optional devices. • Interrupt lines As factory settings, interrupt lines are assigned as follows. Peripheral Device (Controller) Peripheral Device (Controller) System timer...

This manual is also suitable for:

Express5800/t110f-s Exp285a

NEC Express5800/T110f-SEXP285A User Manual

Chapter 1 General Description

Introduction

Accessories

Standard Features

Management Features

Firmware and Software Version Management

Names and Functions of Parts

Front of the Server

Rear View

Internal View

Motherboard

Status Indicators

Chapter 2 Preparations

Installing Internal Optional Devices

Safety Precautions

Anti-Static Measures

Overview of Installation and Removal

Removing the Side Cover

Removing the Front Bezel

Internal Flash Memory

TPM Kit

DIMM

Use of Internal Hard Disk Drives in the RAID System

Extra Battery for RAID Controller

PCI Card

HDD Cages

Optical Disk Drive

Backup Devices

Connecting Cables

Attaching the Front Bezel

Installing the Side Cover

Installation and Connection

Installation

Connection

Chapter 3 Setup

Turning on the Server

Post

System BIOS Setup

Overview

Starting SETUP Utility

Description on On-Screen Items and Key Usage

Cases that Require Setting Changes

Expressscope Engine 3

Overview

EXPRESSSCOPE ENGINE 3 Network Configuration

Expressbuilder

Features of EXPRESSBUILDER

Starting EXPRESSBUILDER

Installing Software Components

Turning off the Server

Chapter 4 Appendix

Specifications

Air Cooling System

Liquid Cooling System

Interrupt Lines

Quick Links

Related Manuals for NEC Express5800/T110f-SEXP285A

Summary of Contents for NEC Express5800/T110f-SEXP285A

This manual is also suitable for:
