Stratus
ftServer
W Series 2300
®
®
Technical Reference Guide
Revision 1 – 10/28/04
1. Overview
The Stratus® ftServer® W Series 2300 system is based on Intel® IA32 architecture using Intel's
Xeon Prestonia processor in a dual modular redundancy (DMR) configuration.
Each W Series 2300 system has two CPU elements and two I/O elements combined on a 16X20-
inch motherboard in a 4U (7-inch) standard 19-inch rack-mountable unit (can be converted to a
pedestal system). The CPU element is configured to support a front side bus (FSB) of 533 MHz
with a CPU speed of 3.06 GHz.
Each I/O element has two user configurable 33-Mhz/64-bit PCI slots. Optional Virtual
Technician Modules (VTMs) may be installed in the system to enhance the system's remote
management functionality. This VTM is a PCI adapter that is installed in a 168-pin DIMM
connector. It uses a dedicated serial port.
The embedded features include a 10/100/1000 Mbit PCI Ethernet controller, a PCI Video
controller, and a PCI SATA controller.
The figures on the following page show the front and rear components of the W Series 2300
system.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ftServer W 2300Series and is the answer not in the manual?

Questions and answers

Related Manuals for Stratus ftServer W 2300Series

Summary of Contents for Stratus ftServer W 2300Series

  • Page 1 Revision 1 – 10/28/04 1. Overview The Stratus® ftServer® W Series 2300 system is based on Intel® IA32 architecture using Intel’s Xeon Prestonia processor in a dual modular redundancy (DMR) configuration. Each W Series 2300 system has two CPU elements and two I/O elements combined on a 16X20- inch motherboard in a 4U (7-inch) standard 19-inch rack-mountable unit (can be converted to a pedestal system).

  • Page 2: Front View

    FRONT VIEW Disk Drives CD-ROM Drive USB Port 3 LEDs Power Button Dump Button Cooling Fans REAR VIEW 10/100 Enet Port Gbit Enet Port USB Ports 1 & 2 PCI Slot 1 PCI Slot 2 10/100 Enet Port Serial Port 1 Gbit Enet Port Serial Port 2 Serial Port 3...

  • Page 3: Operating System Requirements

    2. Operating System Requirements The W Series 2300 system is currently supported by the following operating systems: • Microsoft Windows Server 2003 Standard Edition • ftServer System Software (ftSSS) Release 3.1 (minimum) 3. Hardware Components The main hardware components in the W Series 2300 system are the following: •...
  • Page 4 Total Memory Slot 1 Slot 2 Slot 3 Slot 4 in Each Element M228 DIMM M228 DIMM 1 GB 2 GB M228 DIMM M228 DIMM M228 DIMM M228 DIMM 2 GB M229 DIMM M229 DIMM 4 GB M229 DIMM M229 DIMM M229 DIMM M229 DIMM 3.1.2 I/O Element...

  • Page 5: Sata Backplane Board

    3.1.2.2 PCI Slot Assignments For consistency of manufacturing, the default is to configure adapters in the order shown in the following table unless otherwise specified within special instructions. Adapter PCI Slot 1 PCI Slot 2 U527 U525 U574 U575 Key: The corresponding PCI adapter has the option to be installed in this slot The corresponding PCI adapter is recommended to be installed in this slot 3.2 SATA Backplane Board...

  • Page 6: Tape Drives

    USB 1.1 Port. It’s connected to the motherboard via a 1X14-pin flat ribbon cable. 3.5 ASN Serial Modem The C719, a 56K Data/Fax MultiTech ZBA modem, is the external serial modem used for the Stratus Service Network (ASN). The C719 plugs into COMM 1 (COMM2 if no VTM is installed). 3.6 Optical Devices The CD-ROM used with the W Series 2300 can be either of the optical devices listed in the following table.

  • Page 7: External Usb Floppy Disk Drive

    Remote KVM, Remote CD/Floppy and access to the Stratus Service Network (ASN). The kit contains two RMP cards and requires an external modem.

  • Page 8: System Configuration

    4. System Configuration Marketing ID P3401R-1D Rack Mount Chassis Processor 1-way 3.06 GHz Processor speed 512 KB Cache size 533 MHz Front Side Bus Speed No. CPU Elements No. Physical Processors 8 (4 per CPU element) No. DIMM Slots No. I/O Elements No.

  • Page 9: System Specifications

    5. System Specifications 5.1 Rack-Mount System Power Output wattage A-side: 420W (AC) B-side: 420W (AC) Nominal input voltage 100-240 VAC +/- 10%; 50/60 Hz Physical Dimensions Height 6.5 in. (16.51 cm; 4U) Width 17.75 in. (45 cm) Depth 24 in. (60.96 cm) System weight 63.9 lb.

  • Page 10: Physical Dimensions

    5.2 Pedestal System Power Output wattage A-side: 420W (AC) B-side: 420W (AC) Nominal input voltage 100-240 VAC +/- 10%; 50/60 Hz Physical Dimensions Height 23.25 in. (59.05 cm.) Width 8.62 in. (21.89 cm); 12.88 in. (32.72 cm) with skirt Depth 31.38 in.

  • Page 11: Related Documentation

    • ftServer W Series 2300 Technical Service Guide 6.2 Customer Documentation • Stratus ftServer 2300: Site Planning Guide (R562) • Stratus ftServer 2300: Operation and Maintenance Guide (R563) • Stratus ftServer 2300: Installation Guide (R564) • Stratus ftServer Software Installation and Configuration Guide (R002W) •...
