Loader Valve - Mahindra ML 120 3535 Operator's Manual

17
13
Reference Description
Seal Kit Complete (contains all of the following :) ..............................................0580-6347 ................................1
1 ..............................O-Ring (Spool/Casting Seal)....................................................SK.............................................4
2 ..............................O-Ring (Load Check Seal).......................................................SK.............................................1
Spool End Float Kit Complete (contains all of the following :)..........................0580-6351 ................................1
6 ..............................Spacer ......................................................................................NSS ..........................................1
7 ..............................Stop Cup ..................................................................................NSS ..........................................1
8 ..............................Spring .......................................................................................NSS ..........................................1
9 ..............................Washer .....................................................................................NSS ..........................................1
10 ............................Detent Retainer ........................................................................NSS ..........................................1
11 ............................Steel Ball ..................................................................................NSS ..........................................2
12 ............................Spring .......................................................................................NSS ..........................................1
13 ............................Poppet......................................................................................NSS ..........................................1
14 ............................Cap Screw................................................................................NSS ..........................................2
15 ............................End Cap ...................................................................................NSS ..........................................1
17 ............................Float Detent Sleeve..................................................................NSS ..........................................1
18 ............................Retainer....................................................................................NSS ..........................................1

29. LOADER VALVE

8
9
10
11
12
14 15
96
21
24
23
1
6
7
18
25
Part No.
35 Series 4WD, Model - 3535 & 4035 Loader June'08
2
22
19
20
Qty.
