Summary of Contents for Wicked lasers S3 Arctic Series

  • Page 2 User’s Manual and Laser Safety Guide www.wickedlasers.com...
  • Page 3 F O R E W O R D Absolute power. Unmatched performance. Exceptional stability. First and foremost, we are laser enthusiasts. We desire nothing more than to achieve perfection in our craft. For us, pushing the limits of technology is part of our daily routine. It’s only impossible if we don’t try. “Wicked”...

  • Page 4: Table Of Contents

    Table of Contents The S3 Spyder III Arctic We wanted to create the world’s most powerful handheld laser - we succeeded and inadvertently set a world record in doing so. We are Technical Specifications extremely proud to be included in the Guinness Book of World Records The Arctic Diagram for 2007.

  • Page 5: The S3 Spyder Iii Arctic

    W W W.W I CK E D LA SE RS. COM The S3 Arctic Series The S3 Spyder III Arctic is the most powerful handheld laser you can legally own. It’s got a cool-blue, but blazing-hot, 1W laser beam. ● Completely legal laser power. The <1000mW output power of the blue laser beam is able to burn through balloons, plastic, and much more.

  • Page 6: Technical Specifications

    WWW.W I CK E D L AS ER S. C OM Technical Specifications The Arctic Diagram Model Name: S3 Arctic Series Removable Lens Protector Laser Product Class: FDA Compliant Endcap Wavelength: 445nm nominal center λ Lasing Medium: Laser Type: Direct Diode Laser Power: <...

  • Page 7: Fda Compliant Endcap Diagram

    WWW.W I CK E D L AS ER S. C OM The Arctic Diagram FDA Compliant Endcap Diagram Removable Lens Protector FDA Compliant Endcap Screw Safety Interlock Contact Guard Screw SmartSwitch Button Contact Guard WIC KE D L ASE R S 2010 Pro S e r ies | 6 W I CK ED LAS ERS 2010 P ro Se r i e s | 7...

  • Page 8: How To Use The Smartswitch

    WWW.W I CK E D L AS ER S. C OM How To Use The SmartSwitch™ 2.0 How To Use The SmartSwitch™ 2.0 The S3 Series are the world’s first and only hand held lasers equipped with SmartSwitch™ Unlocking Your Laser: three short clicks This is the first code you should remember technology.
  • Page 9 WWW.W I CK E D L AS ER S. C OM How To Use The SmartSwitch™ 2.0 How To Use The SmartSwitch™ 2.0 SmartSwitch™ 2.0 Codes: After unlocking your laser, you can select among the active modes by using one of these following codes when pressing the button: FLASHING ▪...

  • Page 10: Using Your Laser

    WWW.W I CK E D L AS ER S. C OM How To Use The SmartSwitch™ 2.0 Using Your Laser Code sequences should be performed consecutively otherwise it will reset if you pause in between clicking or holding for too long. FLASHING FLASHING FLASHING...

  • Page 11: Using Your Fda Compliant Endcap

    WWW.W I CK E D L AS ER S. C OM Using Your FDA Compliant Endcap Safety and Maintenance CAUTION - Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. No scheduled maintenance necessary to keep the Do not take apart, modify or dismantle the laser or product in compliance.

  • Page 12: How Intensely The Human Eye Perceives Different Colors

    WWW.W I CK E D L AS ER S. C OM Class 4 Laser Safety Instructions DANGER CLASS 4 LASER : All visible lasers with beams over 500 milliwatts (1/2 watt) are classified as Class 4. EXTREME DANGER, MUST BE USED CAREFULLY ●...
  • Page 13 WWW.W I CK E D L AS ER S. C OM Class 4 Laser Safety Instructions Class 4 Laser Safety Instructions DO NOT LOOK OR STARE AT DIFFUSED REFLECTIONS DO NOT BURN OR DAMAGE MATERIALS Looking at the laser “dot” can cause eye damage. Danger is higher The beam can char, burn or ignite materials.
  • Page 14 WWW.W I CK E D L AS ER S. C OM Class 4 Laser Safety Instructions Class 4 Laser Safety Instructions OTHER IMPORTANT SAFETY AND USE CAUTIONS: AVOID EXPOSURE TO BLUE LIGHT Blue laser light can cause photochemical eye damage. Avoid prolonged exposure to blue light (light from 530nm green to 380 DO NOT USE AS A LASER POINTER.

  • Page 15: Lens Cleaning Procedure And Troubleshooting

    WWW.W I CK E D L AS ER S. C OM Lens Cleaning Procedure and Troubleshooting Types of Common Lens Problems What you need : Procedure : Dirty Lens Scratched Lens - The most common problem with your laser - A scratched lens may occur if you unit is a dirty lens.
  • Page 16 You will not be able to clean this as water has condensed inside the lens and/or crystal set. This condition can be repaired by Wicked Lasers, however, will not be covered in your warranty. A repair cost will apply.

  • Page 17: Limitation Of Liability

    All Spyder III Series lasers come with a standard 12 Month Manufacturer’s Warranty. In no event shall Wicked Lasers or any of its subsidiaries or affiliates be liable for any indirect, special, incidental or Our warranty guarantees your laser to be free from defects in manufacture and consequential injury to persons or damage to property caused by the use of any of our products.
  • Page 18 Manufacturer’s Warranty This warranty does not include defects or damages attributable to misuse, normal surface weathering, or damages caused by accidents or fire or other casualty or force majeure or any other causes or occurrences beyond the manufacturer’s control. To claim your warranty, please send this form or email support@wickedlasers.com with the following information: Full Name: Address:...
  • Page 19 1-877-952-7377 Unit 1010, Miramar Tower, 132 Nathan Road, Tsim Sha Tsui Kowloon, Hong Kong www.wickedlasers.com | support@wickedlasers.com...
