Summary of Contents for Strymon Mobius

  • Page 1 USER MANUAL ®...

  • Page 2: Front Panel Controls

    Mobius - User Manual ® Front Panel Controls LEVEL: Adjusts the VALUE: Provides fi ne adjustment of LFO speed when SPEED: Provides DEPTH: Sets the output level from -3dB to speed is displayed. Scrolls through presets when bank or coarse adjustment modulation depth +3dB.
  • Page 3 Mobius - User Manual ® REAR PANEL: POWER: NEVER plug into voltage STEREO IN/OUT higher than 9VDC. INPUTS: High Requires at least impedance 300mA of available inputs. Use PRE / POST current. LEFT input INPUT 2 OUTPUT 2 for mono.
  • Page 4 Mobius - User Manual ® In Depth: PARAM 1 & 2 controls The PARAM 1 & PARAM 2 knobs allow you to continuously control any desired parameter of the currently active mod machine. This can be very convenient in allowing continuous control over the various mod machines. For example, REGEN in a fl anger can be assigned to one of the parameter knobs to allow for continuous control over the fl anger feedback.
  • Page 5 Mobius - User Manual ® EXP Connections STEREO IN/OUT PRE / POST INPUT 2 OUTPUT 2 Connect an external TAP switch to tap tempo remotely. Use a standard TRS cable to connect the external switch. Set the EXP MD global setting to TAP to use external tap.
  • Page 6 ® Banks and Patches Mobius has 100 banks with A & B patches in each bank. Banks are numbered 0 to 99 on the display. The patches in banks 0-49 are duplicated in banks 50-99 at the factory. Saving Patches...

  • Page 7: Editing Parameters

    Allows confi guration per preset of the pre/post confi guration available via the rear panel toggle switch. When Mobius is used in pre/post confi guration, set to “PRE” to place the modulation effect in front of your amp and set to “POST” to place the modulation effect in your amp’s effect loop.
  • Page 8 (param) FILTER FORMANT hold (global) PHASER VINTAGE TREM VIBE PATTERN TREM Mobius - User Manual ® ROTARY AUTOSWELL FLANGER DESTROYER PARAM 1 PARAM 2 Mod Machines: Chorus CHORUS QUADRATURE ® TYPE push (bank/BPM) A full featured Chorus with 5 distinct modes. dBucket, Multi and Vibrato all utilize our dBucket variable clock technology for hold (save) classic analog bucket brigade style chorusing.
  • Page 9 VALUE DEPTH LEVEL SPEED push (param) FILTER FORMANT hold (global) PHASER VINTAGE TREM Mobius - User Manual VIBE PATTERN TREM ® ROTARY AUTOSWELL Mod Machines: Flanger FLANGER DESTROYER PARAM 1 PARAM 2 CHORUS QUADRATURE ® A deep and rich Flanger with a wide pallete of sonic possibilities. Six separate modes cover a variety of fl anger sounds. Each TYPE separate algorithm uses dBucket technology at its heart for authentic recreations of classic bucket brigade fl angers.
  • Page 10 VALUE SPEED DEPTH LEVEL push (param) FILTER FORMANT Mobius - User Manual hold (global) PHASER VINTAGE TREM ® VIBE PATTERN TREM Mod Machines: Rotary ROTARY AUTOSWELL FLANGER DESTROYER PARAM 1 PARAM 2 A realistic recreation of a rotary speaker cabinet commonly used with tonewheel organs and guitars. Just like an actual...
  • Page 11 Mobius VALUE SPEED DEPTH LEVEL - User Manual ® push (param) FILTER FORMANT hold (global) PHASER VINTAGE TREM Mod Machines: Vibe VIBE PATTERN TREM ROTARY AUTOSWELL A recreation of the late ‘60s “vibe” circuit which was one of the fi rst modulation effects of its time. A staple in classic rock...
  • Page 12 Mobius - User Manual ® VALUE DEPTH LEVEL SPEED push (param) FILTER FORMANT Mod Machines: Phaser hold (global) PHASER VINTAGE TREM VIBE PATTERN TREM From the thick and chewy 2, 4 and 6 stage modes, to the rich and swirly 8, 12 and 16 stage modes, the PHASER machine...
  • Page 13 Mobius - User Manual ® VALUE DEPTH LEVEL SPEED Mod Machines: Filter push (param) FILTER FORMANT hold (global) VINTAGE TREM PHASER An LFO synced fi lter with three fi lter types, eight LFO waveshapes and variable resonance. Envelope fi ltering and traditional...
  • Page 14 The SPEED knob controls how quickly the formants follow the envelope. Connect an expression pedal and select EXPR under the WAVSHP param, and Mobius will blend between the two vowels based on the position of the pedal giving you a vocal Wah experience.
  • Page 15 Mobius - User Manual ® VALUE DEPTH LEVEL SPEED push (param) FILTER FORMANT Mod Machines: Vintage Trem hold (global) PHASER VINTAGE TREM VIBE PATTERN TREM The Vinage Trem features three classic tremolo sounds from the ‘60s. The distinctly different tremolo circuits in vintage...
  • Page 16 Mobius VALUE DEPTH LEVEL SPEED - User Manual ® push (param) FILTER FORMANT hold (global) PHASER VINTAGE TREM Mod Machines: Pattern Trem VIBE PATTERN TREM ROTARY AUTOSWELL A pattern-sequenced tremolo with user defi nable patterns. Up to eight beats can be sequenced, with one to sixteen trem...
  • Page 17 VALUE SPEED DEPTH LEVEL push (param) FILTER FORMANT Mobius - User Manual hold (global) PHASER VINTAGE TREM ® VIBE PATTERN TREM Mod Machines: Autoswell ROTARY AUTOSWELL FLANGER DESTROYER PARAM 1 PARAM 2 An automatic volume swell effect triggered by the input signal. Various rise times and swell curves are available. A chorus...
  • Page 18 VALUE SPEED DEPTH LEVEL push (param) FILTER FORMANT hold (global) PHASER VINTAGE TREM Mobius - User Manual PATTERN TREM VIBE ® ROTARY AUTOSWELL Mod Machines: Destroyer FLANGER DESTROYER PARAM 1 PARAM 2 CHORUS QUADRATURE ® An intricate tool to mangle your audio. The speed knob controls rotational speed of the virtual record for the Vinyl effect.
  • Page 19 (param) FILTER FORMANT hold (global) PHASER VINTAGE TREM Mobius VIBE PATTERN TREM - User Manual ® ROTARY AUTOSWELL FLANGER DESTROYER Mod Machines: Quadrature PARAM 1 PARAM 2 CHORUS QUADRATURE ® TYPE push (bank/BPM) The Quadrature machine handles another spectrum of signal corruption featuring Quadrature oscillators. Choose from AM...
  • Page 20 Bypass Set-Up: Changes the bypass mode between True Bypass and Buffered Bypass. In True Bypass, electromechanical relays are used to bypass Mobius so that no components are touching the input signal. In Buffered Bypass the bypassed signal runs through a high quality analog buffer.
  • Page 21 Mobius - User Manual ® Globals Menu EXP input mode: Confi gures the EXP input to use an Expression Pedal or an external TAP footswitch. PEDAL Patch Names: Enables or disables the display of patch names when displaying the current bank.
  • Page 22 Mobius - User Manual ® PRE/POST Setup in an Amplifi er’s Effect Loop Set the PRE/POST switch to the down position to use Mobius in a pre/post type setup. STEREO IN/OUT PRE / POST INPUT 2 OUTPUT 2 Connect INPUT 2 and...
  • Page 23 Mobius - User Manual ® PRE/POST Setup in a Chain of Pedal Effects Set the PRE/POST switch to the down position to use Mobius in a pre/post type setup. STEREO IN/OUT PRE / POST INPUT 2 OUTPUT 2 Amp/Pedals Connect INPUT 2 to your other...
  • Page 24 PATTERN TREM - Beat 3 0-18 PATTERN TREM - Beat 4 0-18 Mobius will accept MIDI clock at the MIDI input and sync PATTERN TREM - Beat 5 0-18 modulation speed. A MIDI start clock message resets the modulation phase.
  • Page 25 • Numerous deep edit parameters on all mod machines • Stereo Input & Output • Pre-post mode for flexible routing, allowing you to place Mobius in two different places in your mono signal chain. • Expression pedal input with selectable simultaneous control over multiple knob parameters •...
  • Page 26 In no event will Strymon be liable for more than the amount of the purchase price, not to exceed the current retail price of the product. Strymon disclaims any other warranties, express or implied. By using the product, the user accepts all terms herein.
