10-1-6 F Tuning function operation setting

Use this setting to specify the frequency range used to scan signals de-
tected by the F Tuning function. When "3" is selected, the scanning range
is set to be wide to allow accurate tuning; however, extra time is required.
Selecting "1" fi nishes scanning faster; however, the receiver may not tune
to the target signal properly. The DJ-X11 provides a variable range be-
cause the required accuracy varies depending on the conditions such as
the strength of the target signal.
Rotate the upper dial to select
1
"Tune setting".
Rotate the lower dial to select
2
from "1" through "3".

10-1-7 IQ signal output function

The DJ-X11 can output IQ signals from the earphone jack. By connecting
the earphone jack and the PC's MIC/LINE IN input port with a commer-
cially-available cable with ø3.5 mm stereo mini-plugs on both ends (the
specifi cation is the same as the cable used for the Cable-clone function
described on P. 98), you can use SDR (Software Defined Radio) pro-
grams to enjoy reception on the PC using software available on the Inter-
net. Since some of these programs offer functions which are unavailable
with the DJ-X11 such as DSP (Digital Signal Processor), this function will
expand the fun of "watching".
• Although Alinco has confi rmed operation by testing several software
programs developed by third-parties, some programs may not be us-
CAUTION
able due to various conditions such as the compatibility of your pro-
gram and PC, PC properties setting, and the signal receiving environ-
ment (noise or suppression). Note that Alinco does not offer any sup-
port other than testing "Weather or not your DJ-X11 meets our factory-
standard specifi cations." for this reason. Moreover, we cannot answer
questions about the operating procedure of specific software or the
type or environment settings of PCs.
10. Set Mode Confi gurations
145.000
VFO
Tune setting
2
B S
F M
10
77
