Southland S-CV-43 Operator's Manual

Gasoline powered cultivator 43cc, 2 cycle
Hide thumbs

Advertisement

Table of Contents

Look inside for:
Safety Definitions
Important Safety Information
Product Specifications
Parts & Features
Assembly
Operation
Maintenance
Storage
Troubleshooting
Technical Service
Warranty
IMPORTANT:
Thank you for purchasing this Southland™ Cultivator.
Read and understand all warnings and instructions in this manual before using this tool. Improper use of this tool can cause
severe injury or death. Keep this manual for future reference.
Record the following for future reference:
Mfg. Date Code : _________________
Date of Purchase: Attach a copy of your sales receipt.
Consumer Toll Free Number: 1-800-737-2112
Refer to the website for electronic manual and parts book.
If you have a question or problem...
CALL TOLL FREE: 1-800-737-2112
KEEP THIS MANUAL FOR FUTURE REFERENCE
10/30/09
Operator's Manual
GASOLINE POWERED CULTIVATOR
43cc, 2 Cycle
Page
1
2-3
4
4
5-6
7-8
9
9
10
10
11-16
www.gardnerinc.com
Printed in China
S-CV-43
MODEL No.
For Occasional Use Only
A200485

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S-CV-43 and is the answer not in the manual?

Questions and answers

Related Manuals for Southland S-CV-43

Summary of Contents for Southland S-CV-43

  • Page 1 11-16 IMPORTANT: Thank you for purchasing this Southland™ Cultivator. Read and understand all warnings and instructions in this manual before using this tool. Improper use of this tool can cause severe injury or death. Keep this manual for future reference.

  • Page 2: Safety Definitions

    Safety Definitions • Save all instructions Safety Warning Symbols: Indicates WARNING, DANGER, or This equipment can throw small objects CAUTION. at high speed causing personal injury. Inspect area where used and remove all foreign objects. Read operator’s manual before Engine exhaust contains carbon operating this machine.

  • Page 3: Important Safety Information

    Important Safety Information • Save all instructions Before Operating Cultivator 1. READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE OPERATING CULTIVATOR. Be thoroughly familiar with the controls and the proper use of the equipment. Know how to stop the unit and disengage the controls quickly. WARNING Read and follow all warnings and safety instructions.
  • Page 4 5. A guard or other part that is damaged should be properly repaired or replaced by a qualified service center. 6. Use only genuine Southland™ replacement parts and accessories. Use of any non-Southland™ parts or accessories could lead to injury, damage the unit, and void your warranty.

  • Page 5: Product Specifications

    Product Specifications • Save all instructions Engine ....43 cc, 2 cycle, Full-Crank 2-Cycle Oil Type ..2-Cycle Oil that meets or exceeds Idle Speed .

  • Page 6: Assembly

    Assembly If you need assistance or find any parts • Save all instructions missing, CALL TOLL FREE: 1-800–737-2112 Parts Included with Cultivator • Middle Handle (1) • Cable Ties (3) • Upper Handles (2) • Operator’s Manual (1) • Wing nuts and bolts (4 ea.) •...
  • Page 7 Assembly (Continued) • Save all instructions How to Assemble the Tines Fig. 4a Fig. 3 Fig. 4b Fig. 5 To Remove Tines 1. Remove the pins from each end of the tine shaft. Refer to Figure 3. 2. Slide the four tines off the tine shaft. To Install Tines The 4 different tines are labeled “A”, “B”, “C”, and “D”.

  • Page 8: Operation

    Operation • Save all instructions Before Starting Engine: Mixing Fuel / 2-Cycle Oil CAUTION WARNING Do not smoke or allow smoking near fuel or the cultivator. Use of incorrect gasoline such as diesel fuel or gasoline Mix and pour fuel outdoors WHERE THERE ARE NO containing more than 10% ethanol or methanol will damage SPARKS OR FLAMES.
  • Page 9 Operation (Continued) • Save all instructions Starting Engine (Continued): Starting a Flooded Engine 1. Place the cultivator on a flat surface. 2. Move the ignition switch to the ON position. 3. Move the choke lever to the ‘run/ warm start’ position. (see Figure 7) 4.

  • Page 10: Maintenance

    Maintenance • Save all instructions WARNING Turn off ignition switch, and disconnect the spark plug before performing maintenance except for carburetor adjustments. Reconnect the spark plug wire after the service is done. Air Filter Your cultivator has been equipped with two (2) foam air filters inside the air filter housing to prevent dirt and debris from entering the engine.

  • Page 11: Troubleshooting

    Troubleshooting • Save all instructions PROBLEM POSSIBLE CAUSE(S) SOLLUTION(S) Engine will not start. 1. Ignition Switch in the “OFF” position. 1. Move ignition switch to the ON position. 2. Engine flooded. 2. See Starting a Flooded Engine in OPERATION section. 3.

  • Page 12: Warranty

    Warranty • Save all instructions Southland™ CULTIVATOR Limited Warranty Always specify model number when contacting the factory. We reserve the right to amend these specifications at any time without notice. The only warranty applicable is our standard written warranty. We make no other warranty, expressed or implied. MAT Engine Technologies, LLC warrants this Cultivator...
  • Page 13 Warranty (Continued) • Save all instructions Other U.S States / Territories: In other areas of the Unites States, your outdoor power equipment engine must be designed, built and equipped so as to conform at the time of sale to U.S. EPA emissions standards for small off-road spark ignition engines at or below 19 kilowatts.
  • Page 14 Warranty (Continued) • Save all instructions Defects Warranty Coverage: METL warrants to the original purchaser and each subsequent purchaser that the small off-road engine (SORE) (1) has been designed, built and equipped so as to conform with all applicable regulations; and (2) is free from defects in materials and workmanship that cause the failure of a warranted part to conform with those regulations as may be applicable to the terms and conditions stated below.
  • Page 15 Warranty (Continued) • Save all instructions Emission Warranty Parts List: The repair or replacement of any warranted part otherwise eligible for warranty coverage may be excluded from such warranty coverage if METL demonstrates that the engine has been abused, neglected, or improperly maintained, and that such abuse, neglect, or improper maintenance was the direct cause of the need for repair or replacement of the part.
  • Page 16 Warranty (Continued) • Save all instructions California Evaporative Emission Control Warranty Statement YOUR WARRANTY RIGHTS AND OBLIGATIONS The California Air Resources Board and METL are pleased to explain the evaporative emission control system’s warranty on your 2009 model year small off-road engine (SORE). In California, new SOREs must be designed, built and equipped to meet the State’s stringent anti-smog standards.
  • Page 17 Warranty (Continued) • Save all instructions Defects Warranty Coverage: (a) The warranty period begins on the date the engine is purchased. (b) General Evaporative Emissions Warranty Coverage. The engine must be warranted to the ultimate purchaser and any subsequent owner that the evaporative emission control system when installed was: (1) Designed, built, and equipped so as to conform with all applicable regulations;...
