Service Manual E6i RM-227
Page
CONFIDENTIAL
SERVICE MANUAL
Level &2
RM-227
Copyright © 2007 NOKIA Corporation. All rights reserved.

(30)
Transceiver characteristics:
Dual Mode:
-GSM Band: Quad-band phone for EGSM 850/900/1800/1900MHz
-WCDMA Band: 2100
Camera: 2.0 Megapixel camera
Display: 7.112cm (2.8") QVGA display with 16M colors,
resolution 320 x 240 pixel; active area 56.9x42.7mm
Operating System: Symbian OS 9.1 Series 60 3rd edition
Bluetooth
WLAN
Connector: Pop-Port™ Connector
Memory Card: microSD™
Transceiver with BP-4L Li-Ion battery pack
Talk time
2.2h up to 9.5h
Environmental characteristics:
•
Approved .0
23.Feb.2007
Standby
Depends on network
8 up to 19days
parameters
Lead-free soldered
MGR
Note

Advertisement

Table of Contents
loading

Related Manuals for Nokia E61i

Summary of Contents for Nokia E61i

  • Page 1 Memory Card: microSD™ Transceiver with BP-4L Li-Ion battery pack Talk time Standby Note Depends on network 2.2h up to 9.5h 8 up to 19days parameters Environmental characteristics: • Lead-free soldered Service Manual E6i RM-227 Copyright © 2007 NOKIA Corporation. All rights reserved.

  • Page 2: Table Of Contents

    QUICK TROUBLE SHOOTER - SIDE KEYS QUICK TROUBLE SHOOTER - CARD READER QUICK TROUBLE SHOOTER - CAMERA CHANGE HISTORY Status Version No. Date Comments Draft 23.Jan.2007 Initial draft Approved 23.Feb.2007 Approval Service Manual E6i RM-227 Copyright © 2007 NOKIA Corporation. All rights reserved.

  • Page 3: Introduction

    INTRODUCTION The purpose of this document is to help NOKIA service levels 1 and 2 workshop technicians to carry out service to NOKIA products. This Service Manual is to be used only by authorized NOKIA service suppliers, and the content of it is confidential.

  • Page 4: General Repair Information

    Common Software Service Bulletins etc,… Use General SB-217 as a reference or overview. Please also check NOKIA Online (NOL) for latest news and files on a regular basis. Service Manual E6i RM-227 Copyright © 2007 NOKIA Corporation. All rights reserved.

  • Page 5: Pathfinder For Workshop Staff

    Videos – Disassembly/Assembly NOKIA Online Care Services Training Phone Models Level 1&2 e-learning courses offer a quick overview of the NOKIA phone and support for how to repair and use the phone: Overview & Guides Disassembly & Assembly Troubleshooting Basic information about the phone,...

  • Page 6: Exploded View

    CMO Operations & Logistics Training and Vendor Development 23.Feb.2007 Multimedia Creation & Support CONFIDENTIAL EXPLODED VIEW See corresponding ITEM/CIRCUIT REF in the Spare Parts Service Bulletins on NOL. Service Manual E6i RM-227 Copyright © 2007 NOKIA Corporation. All rights reserved.

  • Page 7: Spare Parts Overview

    Page (30) Approved .0 CMO Operations & Logistics Training and Vendor Development 23.Feb.2007 Multimedia Creation & Support CONFIDENTIAL SPARE PARTS OVERVIEW Service Manual E6i RM-227 Copyright © 2007 NOKIA Corporation. All rights reserved.

  • Page 8: General Recycling Recommendation

    Page (30) Approved .0 CMO Operations & Logistics Training and Vendor Development 23.Feb.2007 Multimedia Creation & Support CONFIDENTIAL GENERAL RECYCLING RECOMMENDATION Service Manual E6i RM-227 Copyright © 2007 NOKIA Corporation. All rights reserved.

  • Page 9: Level 2 Solder Components

    Page (30) Approved .0 CMO Operations & Logistics Training and Vendor Development 23.Feb.2007 Multimedia Creation & Support CONFIDENTIAL LEVEL 2 SOLDER COMPONENTS Service Manual E6i RM-227 Copyright © 2007 NOKIA Corporation. All rights reserved.

  • Page 10: Nokia Online (Nol) 0

    Bulletins (spare parts, SWAP units and service tools). This will ensure, that you are using up-to-date order codes only. Therefore Service Bulletins have to be checked from NOL on daily basis. Service Manual E6i RM-227 Copyright © 2007 NOKIA Corporation. All rights reserved.

  • Page 11: Service Tools

    Inserted under the back cover, this Li-Ion battery provides power in a lightweight package. SS-02 Camera removal tool. CA-53 Service Cable to connect the PC with the Pop-Port™ connector. Service Manual E6i RM-227 Copyright © 2007 NOKIA Corporation. All rights reserved.
  • Page 12 For more informations refer to the Service Bulletin (SB-011) on NOKIA Online. Supplier or manufacturer contacts for tool re-order can be found in “Recommended service equipment” document on NOKIA Online. Service Manual E6i RM-227 Copyright © 2007 NOKIA Corporation. All rights reserved.

  • Page 13: Sw-Update 3

    To use FLS-5 Flash Dongle you have to follow the user guide inside the sales package. Please check always for the latest version of flash software, which is available on NOKIA Online. Service Manual E6i RM-227 Copyright © 2007 NOKIA Corporation. All rights reserved.

  • Page 14: Disassembly Instruction 4

    5. Then Gently, lift the CAMERA LID with the SS-93 and remove 6. Unscrew the four Torx Plus® size 6 screws in the order shown and discard them. Service Manual E6i RM-227 Copyright © 2007 NOKIA Corporation. All rights reserved.
  • Page 15 11. Gently, open the LCD connector with the SS-93 and remove 12. Separate the LCD SHIELD ASSY from the LCD MODULE. the LCD MODULE and the LCD SHIELD ASSY. Service Manual E6i RM-227 Copyright © 2007 NOKIA Corporation. All rights reserved.
  • Page 16 15. Remove the CAMERA with SS-102. 16. Unlock the SIDE BUTTON MODULE ASSY and remove it from its socket. 17. Remove the MICROPHONE. 18. Use the DC-PLUG to remove the DC-JACK. Service Manual E6i RM-227 Copyright © 2007 NOKIA Corporation. All rights reserved.
  • Page 17 19. Unlock both snaps of the CONNECTOR HOUSING ASSEMBLY 20. Remove the BATTERY RELEASE BUTTON and the BATTERY and remove it. RELEASE SPRING. 21. The disassembly procedure is now complete. Service Manual E6i RM-227 Copyright © 2007 NOKIA Corporation. All rights reserved.

  • Page 18: Assembly Hints

    Torx Plus ® size 6 screw to the torque of 20 Ncm. Always use a new screws 2 and 3. Tighten the Torx Plus ® size 4 screw to the torque of 17 Ncm. Service Manual E6i RM-227 Copyright © 2007 NOKIA Corporation. All rights reserved.

  • Page 19: Legend For Quick Trouble Shooter 9

    Page (30) Approved .0 CMO Operations & Logistics Training and Vendor Development 23.Feb.2007 Multimedia Creation & Support CONFIDENTIAL LEGEND FOR QUICK TROUBLE SHOOTER Service Manual E6i RM-227 Copyright © 2007 NOKIA Corporation. All rights reserved.

  • Page 20: Quick Trouble Shooter - Power On

    Page (30) Approved .0 CMO Operations & Logistics Training and Vendor Development 23.Feb.2007 Multimedia Creation & Support CONFIDENTIAL QUICK TROUBLE SHOOTER - POWER ON Service Manual E6i RM-227 Copyright © 2007 NOKIA Corporation. All rights reserved.

  • Page 21: Quick Trouble Shooter - Charging

    Page (30) Approved .0 CMO Operations & Logistics Training and Vendor Development 23.Feb.2007 Multimedia Creation & Support CONFIDENTIAL QUICK TROUBLE SHOOTER - CHARGING Service Manual E6i RM-227 Copyright © 2007 NOKIA Corporation. All rights reserved.

  • Page 22: Quick Trouble Shooter - No Service

    Page (30) Approved .0 CMO Operations & Logistics Training and Vendor Development 23.Feb.2007 Multimedia Creation & Support CONFIDENTIAL QUICK TROUBLE SHOOTER - NO SERVICE Service Manual E6i RM-227 Copyright © 2007 NOKIA Corporation. All rights reserved.

  • Page 23: Quick Trouble Shooter - Earpiece

    Page (30) Approved .0 CMO Operations & Logistics Training and Vendor Development 23.Feb.2007 Multimedia Creation & Support CONFIDENTIAL QUICK TROUBLE SHOOTER - EARPIECE Service Manual E6i RM-227 Copyright © 2007 NOKIA Corporation. All rights reserved.

  • Page 24: Quick Trouble Shooter - Ihf Speaker

    Page (30) Approved .0 CMO Operations & Logistics Training and Vendor Development 23.Feb.2007 Multimedia Creation & Support CONFIDENTIAL QUICK TROUBLE SHOOTER - IHF SPEAKER Service Manual E6i RM-227 Copyright © 2007 NOKIA Corporation. All rights reserved.

  • Page 25: Quick Trouble Shooter - Display

    Page (30) Approved .0 CMO Operations & Logistics Training and Vendor Development 23.Feb.2007 Multimedia Creation & Support CONFIDENTIAL QUICK TROUBLE SHOOTER - DISPLAY Service Manual E6i RM-227 Copyright © 2007 NOKIA Corporation. All rights reserved.

  • Page 26: Quick Trouble Shooter - Microphone

    Page (30) Approved .0 CMO Operations & Logistics Training and Vendor Development 23.Feb.2007 Multimedia Creation & Support CONFIDENTIAL QUICK TROUBLE SHOOTER - MICROPHONE Service Manual E6i RM-227 Copyright © 2007 NOKIA Corporation. All rights reserved.

  • Page 27: Quick Trouble Shooter - Keymat

    Page (30) Approved .0 CMO Operations & Logistics Training and Vendor Development 23.Feb.2007 Multimedia Creation & Support CONFIDENTIAL QUICK TROUBLE SHOOTER - KEYMAT Service Manual E6i RM-227 Copyright © 2007 NOKIA Corporation. All rights reserved.

  • Page 28: Quick Trouble Shooter - Side Keys

    Page (30) Approved .0 CMO Operations & Logistics Training and Vendor Development 23.Feb.2007 Multimedia Creation & Support CONFIDENTIAL QUICK TROUBLE SHOOTER - SIDE KEYS Service Manual E6i RM-227 Copyright © 2007 NOKIA Corporation. All rights reserved.

  • Page 29: Quick Trouble Shooter - Card Reader

    Page (30) Approved .0 CMO Operations & Logistics Training and Vendor Development 23.Feb.2007 Multimedia Creation & Support CONFIDENTIAL QUICK TROUBLE SHOOTER - CARD READER Service Manual E6i RM-227 Copyright © 2007 NOKIA Corporation. All rights reserved.

  • Page 30: Quick Trouble Shooter - Camera

    Page (30) Approved .0 CMO Operations & Logistics Training and Vendor Development 23.Feb.2007 Multimedia Creation & Support CONFIDENTIAL QUICK TROUBLE SHOOTER - CAMERA Service Manual E6i RM-227 Copyright © 2007 NOKIA Corporation. All rights reserved.
