1) Product Description
beep&park
®
is a parking assistance system that simplifies reversing
manoeuvres by alerting the driver to the presence of obstacles to the
front or rear of the vehicle.
6 kits in the Range
Kit n°1 :
•
4 rear sensors
•
1 loudspeaker
Kit n°2 :
•
4 rear sensors
•
1 small mirror top display with integrated loudspeaker
Kit n°3 :
•
4 rear sensors
•
1 dashboard screen with integrated loudspeaker
•
Tow Bar compatible
Kit n°4 :
•
4 front sensors
•
1 loudspeaker
Kit n°5 :
•
8 sensors (4 front+ 4 rear)
•
1 dashboard screen with integrated loudspeaker
•
Tow Bar compatible
Kit n°6 :
•
4 rear sensors
•
1 dashboard screen with integrated loudspeaker
•
Specific Kit for long vehicle (10 m cable)
•
Tow Bar compatible
User Guide
1/9
Advertisement
Related Manuals for Valeo parking assistance
Summary of Contents for Valeo parking assistance
- Page 1 User Guide 1) Product Description beep&park ® is a parking assistance system that simplifies reversing manoeuvres by alerting the driver to the presence of obstacles to the front or rear of the vehicle. 6 kits in the Range Kit n°1 : •...
- Page 2 User Guide 2) beep&park Utilisation ® • Each time you select the reverse gear, the 4 rear sensors are activated to detect the presence of obstacles at the rear of the vehicle ® • beep&park will send you an audible alert (beeps), which intensifies as much as you get closer to the obstacle, providing you with assistance during your parking manoeuvres.
- Page 3 User Guide 3) beep&park Utilisation (Continued) ® KIT N°1 : 1) Alerts Activation: 2) Sensor Diagnostic Function : • If the loudspeaker emits a beep even if no obstacle is present, this means that one or several sensor(s) is (are) not properly connected or damaged.
- Page 4 User Guide 3) beep&park Utilisation (Continued) ® KIT N°2 : 1) Alerts Activation: 2) Sensor Diagnostic Function : • You will find information about faulty sensor position on the screen. E1= 1 faulty sensor, E2= 2 faulty sensors, E3= 3 faulty sensors, E4= 4 faulty sensors.
- Page 5 User Guide 3) beep&park Utilisation (Continued) ® KIT N°3 : 1) Alerts Activation: 2) Sensor Diagnostic Function : • You will find information about faulty sensor position on the screen. E1= 1 faulty sensor, E2= 2 faulty sensors, E3= 3 faulty sensors, E4= 4 faulty sensors.
- Page 6 User Guide 3) beep&park Utilisation (Continued) ® KIT N°4 : 1) Alerts Activation: 2) Sensor Diagnostic Function : • If the loudspeaker emits a beep even if no obstacle is present, this means that one or several sensor(s) is (are) not properly connected or damaged.
- Page 7 User Guide 3) beep&park Utilisation (Continued) ® KIT N°5 : 1) Alerts Activation: 2) Sensor Diagnostic Function : • You will find information about faulty sensor position on the screen. E1= 1 faulty sensor, E2= 2 faulty sensors, E3= 3 faulty sensors, E4= 4 faulty sensors.
- Page 8 User Guide 3) beep&park Utilisation (Continued) ® KIT N°6 : 1) Alerts Activation: 2) Sensor Diagnostic Function : • You will find information about faulty sensor position on the screen. E1= 1 faulty sensor, E2= 2 faulty sensors, E3= 3 faulty sensors, E4= 4 faulty sensors.
- Page 9 User Guide Recomendations for Use: • beep&park® helps drivers in their parking manœuvres but does not replace drivers’ vigilance. • Obstructed sensor may avoid system to function properly. Make sure that the sensors are clean and not covered with mud, snow or ice. •...
Need help?
Do you have a question about the parking assistance and is the answer not in the manual?
Questions and answers
Hello, I have a problem with the rear sensors, I changed them and the cable also turns on the reverse gear light, but there is a beeping sound and the control light is on and the sensors are not working. Please help me to solve my problem. Thank you for your understanding
The beeping sound and control light activation in the Valeo parking assistance system after changing the rear sensors and cable could be caused by improperly connected or damaged sensors. The system emits a beep even if no obstacle is present when one or more sensors are not properly connected or are faulty. To resolve this issue, check the connections of the sensors and ensure they are correctly installed. If the problem persists, consult an approved auto technician for further diagnosis.
This answer is automatically generated
