FILE NO. SERVICE MANUAL Multimedia Projector Model No. PLC-EF60A U.S.A., Canada, Europe, Asia, Africa Original Version Chassis No. KJ6-EF60A00 * Projection lens is optional. NOTE: Match the Chassis No. on the unit’s back cover with the Chassis No. in the Service Manual.
Page 2: Table Of Contents
Contents SERVICE MANUAL ........... 1 Control Port Functions..........87 Contents ................ 2 Cleaning ..............98 Safety Instructions ............3 IC Block Diagrams ............99 Safety Precautions............3 Electrical Parts List ............ 105 Product Safety Notice ..........3 Electrical Parts Location ......... 106 Service Personnel Warning ........
Page 3: Safety Instructions
Safety Instructions Safety Precautions WARNING: The chassis of this projector is isolated (COLD) from AC line by using the converter transformer. Primary side of the converter and lamp power supply unit circuit is connected to the AC line and it is hot, which hot circuit is identi- ﬁed with the line ( ) in the schematic diagram.
Page 4: Speciﬁcations
Speciﬁcations Mechanical Information Projector Type Multi-media Projector Dimensions (W x H x D) 20.39" x 9.92" x 23.86" (518mm x 252mm x 606mm) (Not including adjustable feet) Net Weight 52.9 lbs (24.0 kg) Feet Adjustment 0˚ to 3.65˚ Panel Resolution LCD Panel System 1.4"...
Page 5: Safety Protections
Safety Protections This projector provides the following safety protections to operate in safety. If the abnormality occurs inside the projec- tor, it will automatically turn off by operating one of the following protection circuits. 1. Fuse The fuse is located inside of the projector. When both of FUSE PART NO.
Page 6: Lamp Cover Switches
Safety Protections 3. Lamp cover switches There are mechanical switches SW902 and SW905 inside of the projector to detect that the covers are mounted cor- rectly. When one of them detects an error (open), the projector cannot turn on. - Lamp1 cover switch (SW902) - Lamp2 cover switch (SW905) SW902 SW905...
Page 7: Temp. And Airﬂow Sensors
Safety Protections 4. Temp. and airﬂow sensors The projector provides 2 temperature sensor ICs and an airﬂow sensor. The temperature sensor ICs monitor internal temperature and external temperature (around the intake duct ) respectively. The airﬂow sensor monitors intake air- ﬂow through the airﬁlter to detect the airﬁlter clogged.
Page 8: Air Filter Replacement
Air Filter Replacement Air ﬁlters prevent dust from accumulating on the surface of the optical elements inside the projector. Should the air ﬁlters become clogged with dust particles, it will reduce cooling fans’ effectiveness and may result in internal heat build up and adversely affect the life of the projector.
Page 9: Lamp Replacement
Lamp Replacement When the life of the projection lamp of this projector draws Top Control to an end, the LAMP1/2 REPLACE indicator lights yellow. If this indicator lights yellow, replace the lamp with a new one promptly. CAUTION For continued safety, replace with a lamp of the same type.
Page 10: How To Reset The Lamp Or Filter Timer
How to Reset the Lamp or Filter Timer How to reset the Lamp Time Special Menu (Lamp) Press the MENU button to display On-Screen Menu. Spin the menu icons with control buttons 7 8, and press the SELECT button when the SPECIAL icon comes right in front.
Page 11: Mechanical Disassemblies
Mechanical Disassemblies Mechanical disassemblies should be made following to the SEQ No. indicated Screws Expression on the right of each item. Following steps show the basic procedures, there- (Type ) mm x pcs Diameter x Length fore unnecessary step may be ignored. T type M Type Caution:...
Page 12: Cabinet Top Removal
Mechanical Disassemblies x Cabinet Top removal SEQ No. A : (M4 x 8) x 8 on cabinet top B : (M4 x 8) x 2 on holder Cabinet Top Fig.2 c Controls removal SEQ No. A : (T3 x 10) x 5 on holder B : (T3 x 10) x 2 on control board C : (T2 x 4) x 8 on control board Control Board...
Page 13 Mechanical Disassemblies v Main and LCD Drver Boards removal SEQ No. A : (M3 x 6) x 6 on main board B : (M3 x 6) x 6 on LCD drive board Main Board LCD Drive Board Fig.4 b Cabinet Front and RF Reciver removal SEQ No.
Page 14 Mechanical Disassemblies n Airﬁlter and Filter Cover removal SEQ No. A : (T3 x 8) x 7 on ﬁlter frame B : (T3 x 8) x 4 on ﬂter frame C : (T3 x 8) x 1 on senser duct D : (4 x 15) x 2 (pin) on filter cover Airfilter Filter Cover...
Page 15 Mechanical Disassemblies , AV Panel Box and FN913 and SS901 removal zxvb, SEQ No. A : (M4 x 6) x 4 on AV panel box B : (M4 x 8) x 2 on the chassis frame C : (T4 x 10) x 4 on air duct D : (T4 x 28) x 2 on fan (FN913) E : (T3 x 8) x 2 F : (M3 x 12) x 1 on airflow sensor (SS901)
Page 16 Mechanical Disassemblies ⁄0 AC Unit removal SEQ No. zxvb,⁄0 A : (M4 x 10) x 3 on AC unit B : (M4 x 6) x 3 on AC unit AC Unit Fig.10 ⁄1 AC Unit Disassemblies SEQ No. zxvb,⁄0 ⁄ 1 A : (M4 x 6) x 5 on holder K901(AC Socket) LF901(Noise Filter)
Page 17: Optical Unit Assy Removal
Mechanical Disassemblies ⁄2 Optical Unit Assy removal SEQ No. zxvb⁄2 A : (M4 x 10) x 4 on lens mount B : (T4 x 12) x 5 on optical unit C : (T4 x 12) x 2 on optical base lamp D : (M3 x 12) x 4 on lamp socket E : (T4 x 10) x 2 on holder Lamp 1...
Page 18 Mechanical Disassemblies ⁄4 Lamp Unit Disassemblies zxvb⁄2 ⁄ 3 ⁄ 4 SEQ No. A : (T3 x 14) x 4 on duct B : (M4 x 35) x 3 on fan (FN908) C : (M3 x 30) x 4 on fan (FN909) D : (M3 x 6) x 3 on fan guard E : (M3 x 6) x 1 on holder F : (M3 x 8) x 1 each on switch (SW911 &...
Page 19 Mechanical Disassemblies ⁄5 Lens Mount Disassemblies zxb⁄5 SEQ No. A : (M1.6 x 3) x 3 on socket terminal x 2 sets B : (M3 x 4) x 2 on motors x 2 sets C : (M2 x 8) x 2, (M2 x 8) x 3 on switches D : (M2 x 8) x 2 on cover x 2 sets E : (M2 x 2) x 1 on cover x 2 sets Lens Shift Motor...
Page 20 Mechanical Disassemblies ⁄7 Power Box and Fans removal SEQ No. zxv⁄6 ⁄ 7 A : (T4 x 10) x 6 on power box B : (M4 x 8) x 1 on power box Isolation C : (M3 x 30) x 4 on fan (FN905) sheet D : (M3 x 20) x 4 on fan (FN907) Power 2(AC)
Page 21 Mechanical Disassemblies ⁄9 Cabint Bottom Cover removal ⁄9 SEQ No. A : (M4 x 8) x 9 on cabinet bottom Fig.19 ¤0 Lamp Ballast Unit Assy removal ⁄9 ¤ 0 SEQ No. A : (T3 x 8) x 4 on duct ballast Ballast duct B : (T3 x 8) x 3 on ballast unit x 2 sets C : (M3 x 6) x 3 on ballast unit x 2 sets...
Page 22 Mechanical Disassemblies ¤1 Fans(FN904,FN911) removal SEQ No. ⁄9 ¤ 1 A : (T3 x 8) x 1 on Temp. Sens. board B : (T3 x 8) x 2 on Bottom net board C : (T4 x 28) x 2 on fan(FN904) FN904 D : (T3 x 8) x 4 on duct E : (T3 x 8) x 1 on duct Splitter...
Page 23: Optical Parts Disassemblies
Optical Parts Disassemblies This chapter describes disassemblies procedure of the optical parts. Disasemblies should be made following to the SEQ No. indicated on the right of each item. Caution: The parts and screws should be placed exactly the same position as the original otherwise it may cause loss of per- formance and product safety.
Page 24 Optical Parts Disassemblies x LCD/Prism Assy Disassemblies SEQ No. A : (M2.5 x 6) x 4 on LCD/Prism ass’y LCD/Prism Ass’y Fig.2 Optical Filter (Spacer Glass) Polarized Glass(R) Optical Filter- WV-Out(R) Polarized Glass(B) Pre-Polarized Glass(B) Polarized Glass(G) Pre-Polarized Glass(G) Optical Filter- WV-Out(B) Optical Filter-WV-Out(G) After re-installing the LCD/Prism assy, the some adjustments are required to maintain the best performance.
Page 25 Optical Parts Disassemblies c Polarized & Pre-polarized Glass removal SEQ No. (M2.5 x 5)x 2 Polarized Glass Ass’y Thermistor (SW913) B-Panel only Pre-Polar- (M3 x 8) ized Glass Film Polarized Glass Film Fig.3 v Optical Filter-WV removal SEQ No. (M3 x 6)x 2 Optical Filter-WV Ass’y Optical Filter-WV Film...
Page 26 Optical Parts Disassemblies b Integrator-In, Shutter removal SEQ No. (M2.5 x 8)x 2 Shutter Ass’y (M3 x 8)x 2 Integrator-In Ass’y (M3 x 3)x 4 Integrator-In Marker (behind) Fig.5 n Integrator-Out & PBS removal SEQ No. Integrator-Out Ass’y & PBS (M2.5 x 5)x 2 Shield (M3 x3)x4...
Page 27 Optical Parts Disassemblies m Mirror-R removal zxvm SEQ No. (M2.5 x 5)x 2 Mirror-R Ass’y (M2.5 x 5)x 2 Mirror-R (M2.5 x 3)x 2 Marker (Behind) Fig.7 , Relay Lens-Out removal zxv, SEQ No. (M3 x 6)x 2 Relay Lens-Out Ass'y (M2 x 2)x 2 Relay Lens-Out Fig.8...
Page 28 Optical Parts Disassemblies . Optical Unit-Top and SW914 removal zxv. SEQ No. A : (M3 x 6) x 4 on integrator-out holder B : (M3 x 4) x 1 on SW914 C : (T3 x 12) x 5 on optical unit top D : (M3 x 8) x 2 on optical unit top E : (M3 x 8) x 1 on stopper SW914...
Page 29 Optical Parts Disassemblies ⁄0 Optical Parts in the Optical Unit zxv.⁄0 SEQ No. When the optical parts mounting or assembling in the optical unit, the parts must be mounted in the speciﬁed location and direction as shown in ﬁgure below. - The direction of the printed number on the lens is as shown in the ﬁgure.
Page 30: Lcd Panel Replacement
LCD Panel Replacement Procedure Remove the Cabinet Top following to chapter “Mechanical Disassemblies”. Remove the FPC cables on the LCD DRIVE board. Remove 4 screws then pull up the LCD/Prism assy uppward. Remove 3 screws to take off the LCD panel from the panel holder. After replacing the LCD panel, the some adjustments are required to maintain the best performance.
Page 31: Adjustments
Adjustments PIN Code Reset If the PIN code is set on the projector, you cannot control the projector. The PIN code can be reset to the factory de- fault setting (1234) according to the following procedure. When you reset the PIN code, the function PJ lock and key lock will be reset, as well. 1.
Page 32: Optical Adjustments
Optical Adjustments Before taking optical adjustments below, remove the Cabinet Top following to chapter “Mechanical disassemblies”. Adjustments require a 2.0mm hex wrench and a slot screwdriver. Note: Do not disconnect connectors on the Main or LCD Drive board, because the projector cannot turn on due to operate the power failure protection.
Page 33 Optical Adjustment z Integrator-in angle adjustment Condition: Lamp 2 Mode (Menu: Setting -> Lamp -> Mode -> 1-Lamp -> Lamp 2) Eddge becomes clear Remove a shutter assy from the optical unit and disconnect the FPC cables of the panels. Turn the projector on with Lamp 2 mode.
Page 34 Optical Adjustment x Mirror-R adjustment Move the Mirror-R to overlap the red projected image onto the green (white) projected image precisely. 1) To adjust the image vertically as shown in Fig.2-1, loosen 2 slot-B screws , and turn the by using a slot screwdriver. 2) To adjust the image horizontally as shown in Fig.2-2, loosen 2 slot-D screws...
Page 35 Optical Adjustment c Relay lens-B adjustment Same color-offset band width Move the Relay lens-B to make the same width of yellow and blue color-offset on the top/bottom and left/right of the screen. 1) To adjust the image vertically as shown in Fig.3-1, loosen 2 slot-B screws , and move the...
Page 36 Optical Adjustment v Integrator adjustment Move the Integrator-out and Integrator-in to remove the shadow area on the top/bottom or left/roght of the screen. 1) To adjust the image vertically as shown in Fig.4-1, loosen 2 screws , and move the slot by using a slot screwdriver.
Page 37 Optical Adjustment b Lamp center adjustment n Shutter adjustment Adjust the white uniformity of the screen by turning the Mount the shutter assy onto the optical unit correctly screw and put screws loosely. Switch the lamp mode to Lamp1 only and adjust the Set the Shutter mode to High-contrast mode and Lamp white uniformity of the screen by turning the screw mode to 2-Lamp mode by using the menu control.
Page 38: Contrast Adjustment
Optical Adjustment 2. Contrast adjustment Input a 100%-whole black signal. Loosen 1 screw on the optical ﬁlter(WV) mounting base and 1 screw on the polarized glass mounting base. (The opical ﬁlter for blue panel is not provided.) Turn the optical ﬁlter mounting base with lever to obtain the darkest brightness and proper black color uniformity on the screen.
Page 39: Convergence Service Adjustment
Optical Adjustment 3. Convergence service adjustment Preparation When adjusting the convergence of LCD panels, Convergence Adjustment Tool is required. This tool can be ordered as a service parts. Parts No. shown below. Mound Adjustment Tool on the LCD panel and adjust each panel convergence. Make sure each Red, Green and Blue LCD panel unit has been correctly installed before performing convergence adjustments.
Page 40 Optical Adjustment Adjustment For convergence adjustment, use Green as the reference standard. Align Red and Blue with Green by adjusting the position and angle of the Red and Blue LCD panel. Screws H1, H2, V1 and V2 are for convergence adjustment. When adjusting the Green reference LCD panel, both on Red and Blue LCD panel should be converged.
Page 41: Back Focus Adjustment
Optical Adjustment 4. Back focus adjustment Loosen 4 screws on the LCD Panel/Prism ass’y with 2.0 mm hex driver. Turn the projector on and project the test pattern (cross hatch pattern) provided with the projector. (Menu: Special -> Test pattern -> Crosshatch 1) Turn the zoom control to the wide position and adjust the focus control to obtain the best focus.
Page 42: Electrical Adjustments
Electrical Adjustments 1. Service Adjustment Menu Operation To enter the service mode To enter the “Service Mode”, press and hold the MENU and SELECT buttons on the projector at the same time for more than 3 seconds. The service menu appears on the screen as follows. To adjust service data Select the adjustment Group by pressing the MENU (increase) or SELECT (decrease) button, and select the item No.
Page 43: Circuit Adjustments
Electrical Adjustments 2. Circuit Adjustments CAUTION: The each circuit has been made by the ﬁne adjustment at factory. Do not attempt to adjust the following adjustments except requiring the readjustments in servicing otherwise it may cause loss of performance and product safety. [Adjustment Condition] 16 steps gray scale pattern ●...
Page 44 Electrical Adjustments c DC adjustment b Input adjustment Receive the 16-step grey scale computer signal with PC Input adjustment INPUT 2 [RGB] mode. Receive the 100% whole-white computer signal with Enter the service mode and select group no. “ ”. INPUT 2 [RGB] mode.
Page 45: Common Center Adjustment
Electrical Adjustments n Gain adjustment , PC white balance adjustment Set projector with 2-lamp mode. PC gain adjustment Receive the 50% whole-white computer signal with IN- Receive the 16-step grey scale computer signal with PUT 2 [RGB] mode. INPUT 2 [RGB] mode. Enter the service mode and select group no.
Page 46 Electrical Adjustments ⁄1 AV white balance adjustment-2 ⁄3 White balance adjustment (Lamp2) Set projector with 2-lamp mode. Set projector with 1-lamp and Lamp 2 mode. Receive the 50% whole-white component signal with INPUT 2 [Y/Cb/Cr] mode. White balance adjustment-1 (PC) Enter the service mode and select group no.
Page 47: Test Points And Locations
Electrical Adjustments 3. Test points and locations TPV2B TP_GVID1 TPV1G TPV2G TP3601 FAN_D2 POWER(DC) Board FAN_D1 TPFAN_C * TP3601 is located on the POWER(DC) Board behind the MAIN Board. POWER(DC) MAIN The side view from the arrow direction on the above figure. TP3601 - 47 -...
Page 48: Service Adjustment Data Table
Electrical Adjustments 4. Service Adjustment Data Table These initial values are the reference data written from the CPU ROM to memory IC when replaced new memory IC. The adjustment items indicated with “✻” are required to readjust following to the “Electrical adjustments”. Other items should be used with the initial data value.
Page 49 Electrical Adjustments Group Item Function Range Initial Value DIMMER CTRL LEVEL10 Bright level10 data: Bright level10 when less than the value 0~32767 DIMMER CTRL LEVEL11 Bright level11 data: Bright level11 when less than the value 0~32767 DIMMER CTRL LEVEL12 Bright level12 data: Bright level12 when less than the value 0~32767 DIMMER CTRL LEVEL13 Bright level13 data: Bright level13 when less than the value...
Page 50 Electrical Adjustments Group Item Function Range Initial Value Hi-Land SW 0:Normal Mode1: High-land Mode (Fan max speed continuously) 0 ~ 1 Not used Not used ANZEN FAN Control Fix SW 0:Normal 1:Normal Min2:Normal Max3:Eco Min4:Eco Max Fan Parameter Setting FAN_TEMP_A_WARNING Temperature A to judge Abnormal Temp.
Page 51 Electrical Adjustments Group Item Function Range Initial Value A02(IC571)V2R DAC Video Center R H (IC571 15pin) 0 ~ 255 144 [143] A06(IC571)V2B DAC Video Center B H (IC571 19pin) 0 ~ 255 144 [143] A11 (IC501)VREFH G DAC G Contrast H (IC571 8pin) 0 ~ 255 174 [220] A10 (IC501)VREFH R...
Page 52 Electrical Adjustments Group Item Function Range Initial Value (Not Used) (Not Used) (Not Used) (Not Used) (Not Used) (Not Used) (Not Used) (Not Used) (Not Used) (Not Used) (Not Used) (Not Used) (Not Used) (Not Used) (Not Used) (Not Used) (Not Used) (Not Used) (Not Used)
Page 53 Electrical Adjustments Group Item Function Range Initial Value B Gain Coefﬁcient AV B Gain Coefﬁceant adjustment [901h] 160~266 255 [255] G GAMMA SHIFT Differential AV White Balance AdjustmentG[503h] G, lnks with R,B -2048 ~ 2047 R GAMMA SHIFT Differential AV White Balance AdjustmentR[103h] -2048 ~ 2047 B GAMMA SHIFT Differential AV White Balance AdjustmentB[903h]...
Page 54 Electrical Adjustments Group Item Function Range Initial Value Built-in Device :SW-FPGA MANUAL_COAST_ED NTSC,480i,575i,1080i60,1035i,1080i60,720p,PAL,480p,575p 0 ~ 255 MANUAL_COAST_ST NTSC,480i,575i,1080i60,1035i,1080i60,720p,PAL,480p,575p 0 ~ 255 MANUAL_ON NTSC,480i,575i,1080i60,1035i,1080i60,720p,PAL,480p,575p 0 ~ 1 FB_HS_GATE_ON NTSC,480i,575i,1080i60,1035i,1080i60,720p,PAL,480p,575p 0 ~ 1 DAT_CNTDN_VON NTSC,480i,575i,1080i60,1035i,1080i60,720p,PAL,480p,575p 0 ~ 1 DAT_VGATE_WIDTH 0 ~ 255 DAT_VGATE_ADD_LINE 0 ~ 255 DAT_VGATE_RESET_CNT...
Page 55 Electrical Adjustments Group Item Function Range Initial Value Disp Dots 0 ~ 3000 1024 [1400] H Back Porch 0 ~ 3000 246 [335] V Back Porch 0 ~ 3000 54 [54] Disp Line 0 ~ 1500 556 [556] Clamp Position 0 ~ 3000 155 [155] Clamp Size...
Page 56 Electrical Adjustments Group Item Function Range Initial Value H Back Porch 0 ~ 3000 222 [298] V Back Porch 0 ~ 3000 42 [42] Disp Line 0 ~ 1500 466 [466] Clamp Position 0 ~ 3000 155 [155] Clamp Size 0 ~ 3000 20 [20] VSBEG...
Page 57 Electrical Adjustments Group Item Function Range Initial Value V Back Porch 0 ~ 3000 40 [40] Disp Line 0 ~ 1500 1080 [1080] Clamp Position 0 ~ 3000 100 [16] Clamp Size 0 ~ 3000 5 [0] VSBEG 0 ~ 15 2 [2] HDCP (480P) VSBEG...
Page 58 Electrical Adjustments Group Item Function Range Initial Value H Back Porch 0 ~ 3000 300 [302] V Back Porch 0 ~ 3000 40 [39] Disp Line 0 ~ 1500 464 [465] Clamp 0 ~ 3000 0 [0] Blank Top 0 ~ 255 0 [0] Blank Bottom 0 ~ 255...
Page 59 Electrical Adjustments Group Item Function Range Initial Value V Back Porch 0 ~ 3000 24 [25] Disp Line 0 ~ 1500 720 [720] Clamp Position 0 ~ 3000 150 [150] Clamp Size 0 ~ 3000 20 [20] VSBEG 0 ~ 15 2 [2] DVI Card - RGB Video (1080i-60) XGA[SXGA]...
Page 60 Electrical Adjustments Group Item Function Range Initial Value Right side Blending ON/OFF Right OSD ON/OFF for Blending 0 ~ 1 Blending (TopSide) Blending OSD width Blending (BottomSide) Blending OSD width Blending (LeftSide) Blending OSD width Blending (RightSide) Blending OSD width General IP Mode 0:not use IP Block 1:use IP Block and IP OFF...
Page 61 Electrical Adjustments Group Item Function Range Initial Value 0~8191 4096 0~8191 4096 0~8191 4096 Auto Gain Control PC XGA[SXGA] Auto Gain auto gain 0:Ready to set, 1:End of setting, -1: Error 0~8191 4096 0~8191 4096 0~8191 4096 PC Contrast PC 100% adjustment (Contrast) 2096/1976/2320 R Contrast PC/DIGITAL/FAROUJA White 100% adjustment (Contrast)R...
Page 62 Electrical Adjustments Group Item Function Range Initial Value For factory use DXOUT XGA[SXGA] 0~ 1023[0~511] 520 [237] 520 [237] 0~ 1023[0~511] 520 [237] 0~ 1023[0~511] Reference for Sample Hold 1 ~ 12 6 [3] 1 ~ 12 6 [3] 1 ~ 12 6 [3] Panel Variation Companzation (Not used)
Page 63 Electrical Adjustments Group Item Function Range Initial Value Video processing Ghost Correction XGA[SXGA] Reference position setting for gohst correction [R] 0 ~ 11 8 [1] Reference position setting for gohst correction [G] 0 ~ 11 8 [1] Reference position setting for gohst correction [B] 0 ~ 11 8 [1] Progressive ghost correction coefﬁcient [R]...
Page 64 Electrical Adjustments Group Item Function Range Initial Value R-Graduation MID 3 level [G-Graduation MIN level] 0 ~ 1023 652 [184] R-Graduation MID 2 level [G-Graduation MID2 level] 0 ~ 1023 688 [488] R-Graduation MID 1 level [G-Graduation MID1 level] 0 ~ 1023 732 [608] R-Graduation MAX level [G-Graduation MAX level] 0 ~ 1023...
Page 65: Chassis Description & Troubleshooting
Chassis Description & Troubleshooting 1. Chassis Overview K90B RGB/COMPONENT/VIDEO - 65 -...
Page 66: Signal Input And Decoding Stage
Chassis Description & Troubleshooting 2. Signal Input and Decoding Stage DVI Input DVI digital input signals are applied to IC8001<DVI/HDCP RECEIVER> and sent to IC6201<FPGA> through the latch ICs. The sync. signals for digital are applied to IC8181<SYNC I/F> and sent to IC6201<FPGA> as the signal "S_HIN" and "S_VIN".
Page 67 Chassis Description & Troubleshooting IC301 SCAN CONVERTER <PW388-10L> IC6201 FPGA <EP1C4F4000C8> IC8201 IC9201 A/D PC A/D AV <AD9888> <AD9881> 14,12,10 12,13,14 IC9036 RGB MATRIX <CXA2175Q> 22,23,24 31,32,33 RGB Y/PB/PR IC9033 SYNC SEP. <BA7078> IC3101 VIDEO DECODER <TB1274AF> IC9013 RGB/COMPONENT-SW IC131 <AD8185>...
Page 68: Lcd Drive Stage
Chassis Description & Troubleshooting 3. LCD Drive Stage The digital converted RGB signals are scan-converted in the IC301<SCAN CONVERTER> , and then applied to IC401<DIGITAL GAMMA & TIMING CONTROL> through IC9401<AI>. The signals clock for "SC_DCLK", H-Sync for "SC_DHSYNC", V-Sync for "SC_DVSYNC" are output from pins 237, 231 and 142 of IC301 and applied to IC401 through IC4481.
Page 69 Chassis Description & Troubleshooting IC5826 IC6721 K4402 IC301 SCAN CONVERTER <PW388-10L> - 69 -...
Page 70: Lamp Control
Chassis Description & Troubleshooting 4. Lamp Control Lamp Driving Circuit Lamps on and off are carried out by signal "BALAST1_SW" and "BALAST2_SW". IC801<CPU> sends IC4802<I/O EXPANDER> the lamp on/off signal through the parallel bus. IC4802 outputs the lamp drive signals from pins 34 and 35 and sends to the Lamp Ballast Unit via the IC5825<BUFFER>...
Page 71 Chassis Description & Troubleshooting BALLAST2_SW BALAST2_SW LAMP2_CONT LAMP2_TXD LAMP2_ERR LAMP2_RXD POWER_SW LAMP_COVER POWER POWER CONTROL CONTROL CIRCUIT CIRCUIT IC4713 I/O EXPANDER IC4751 IC5825 INVERTER BUFFER IC4801 IC4802 I/O EXPANDER I/O XPANDER - 71 -...
Page 72: Fan Control
Chassis Description & Troubleshooting 5. Fan Control The Fan drive power supplies "FAN_A", "FAN_B", "FAN_C", "FAN_D1", "FAN_D2", "FAN_E" and "16V_M" are gener- ated in the POWER(DC) board. Each power supply drives fans as follow; FAN_A....Fan FN901, FN902, FN903 for LCD panel cooling and fan FN904 for PBS cooling FAN_B....Fan FN907 for POWER 1,2(AC) board cooling and fan FN905 for main exhaust FAN_C ....Fan FN908 for Lamp2 cooling and fan FN909 for lamp exhaust FAN_D1 ....Fan FN910 for Lamp1 cooling...
Page 73 Chassis Description & Troubleshooting K36K FAN_B FN905 K60E K36A MAIN EXHAUST FAN_PF5 K36L FN907 MAIN POWER FAN_PF7 POWER 1(AC) POWER(DC) BOTTOM NET K36J K56A K56C FAN_A FN901 PANEL R FAN_PF1 K56D FN902 PANEL G FAN_PF2 K56E FN903 PANEL B FAN_PF3 K56F FN904 FAN_PF4...
Page 74: Motor Control
Chassis Description & Troubleshooting 6. Motor Control Zoom, Focus, Lens Shift Left/Right, Lens Shift Up/Down The motor drive signals for Zoom, Focus, Lens Shift Left/Right and Lens Shift Up/Down are output from IC4801<I/O EXPANDER> through the parallel bus lines of IC801<CPU>. IC4801 outputs zoom drive signal from pins 53 and 54, focus drive signal from pins 50 and 51, lens shift right/left drive signal from pins 14 and 13 and lens shift up/down drive signal from pins 10 and 11.
Page 75: Projection Lens
Chassis Description & Troubleshooting MAIN MOTOR ZOOM K16F K96J IC1601 53,54 14,13 ZOOM DRIVE ZOOM +,- <LB1641> FOCUS IC1611 50,51 12,11 FOCUS DRIVE FOCUS +,- <LB1641> LENS SHIFT K96G D[3] IC1621 14,13 15,16 D[7] LENS SHIFTDRIVE SHIFT_L,R <LB1641> IC1631 10,11 18,17 LENS SHIFTDRIVE SHIFT_U,D...
Page 76: System Control
Chassis Description & Troubleshooting 7. System Control The selection of the Dsub RGB signal and BNC or RCA RGB/Component signal is performed at IC9013<RGB/COM- PONENT-SW> by the signal "AV1/AV2_SW" applied on pin 22. The selection of horiz. and vert. sync signals of PC1 and PC2 is performed at IC9027<SYNC SELECTOR>...
Page 77 Chassis Description & Troubleshooting Lamp cover Switch When the lamp covers are not ﬁxed securely, the projector can not turn on because of one of the detection switches is turned off. - Lamp Cover Switch (SW902, SW905) SW902 SW905 Fig.7- LED controls The LED drive signals are output from pins 10 to 18 of IC4802<I/O EXPANDER>.
Page 78 Chassis Description & Troubleshooting REMOTE CONTROL RECEIVER K301 K6703 K4403 Q6851 POWER Q6852 READY Q6853 WARNING Q6854 LAMP REPLACE1 Q6856 SHUTTER Q6857 FILTER Q6858 LAMP REPLACE2 IC6755 IC6718 IC4801 BUFFER I/O EXPANDER IC4802 I/O EXPANDER IC3805 - 78 -...
Page 79: Power Supply And Failure Detection
Chassis Description & Troubleshooting 8. Power Supply and Failure Detection Detection of Power failure Projector provides a protection circuit to prevent the secondary failure when the power failure, fans failure or tempera- ture failure occurs on the projector. The power failure detection lines "PF_S16", "FAN_PF13", etc. are connected to the main power supplies and fans.
Page 80 Chassis Description & Troubleshooting IC4402 I/O EXPANDER K4404 FAN_PF13 FAN_PF5 FAN_C IC4714 I/O EXPANDER POWER_SW POWER_SW IC4713 I/O EXPANDER POWER_SW_CPU IC9017 IC9016 I/O EXPANDER I/O EXPANDER - 80 -...
Page 81: Diagnosis Of Failure With Led Indication
Chassis Description & Troubleshooting 9. Diagnosis of Failure with LED indication This projector provides a function which is to specify an abnormal place/part simply by indicating the LEDs on the cabinet. Connect the AC cord and turn on the projector with the mains switch, and then check the LED indication. No Power LAMP WARMING...
Page 82 Chassis Description & Troubleshooting The cause of the NO POWER is separated into 5 items as listed below. Check with the table on previous page and make a short list of failure. The below shows the error condition and detection parts/signals. Error Condition, Detection parts and signals ﬂow Temperature failure - IC8801 monitors temperature inside the projector and IC8841 moitors temperature arround the intake duct,...
Page 83: Diagnosis Of Power Failure With Rs-232C Port
Chassis Description & Troubleshooting 10. Diagnosis of Power Failure with RS-232C port This projector provides a function to get the error information of the projector by using the RS-232C serial port for the power failure diagnosis. The further error information of the power failure and fan failure can be found out by using this function. Diagnosis procedure Connect a RS-232C serial cross cable to SERIAL PORT IN on the projector and serial port on the PC.
Page 84 Chassis Description & Troubleshooting Power supply ﬂow chart and Error Information DETECTION LINE NAME ERROR INFO. MOTOR PF_MOTOR16V MOTOR,16V IC1621 IC1631 IC1611 IC1621 <LENS SHIFT> <LENS SHIFT> <FOCUS> <ZOOM> MAIN PF_-5V MAIN,-5V S3.3V Q1821 3.3V MAIN,3.3V PF_3.3V IC6202 1.5V IC6621 3.3VA LCD DRIVE 3.3V...
Page 85 Chassis Description & Troubleshooting Fans, Power supplies and Sensors ﬂow chart and Error Information DETECTION LINE NAME ERROR INFO. POWER(DC) FAN_A POW,FAN_A FAN_A FAN_B POW,FAN_B FAN_B FAN_C FAN_C POW,FAN_C FAN_D1 FAN_D1 & D2 POW,FAN_D1&2 FAN_E FAN_E POW,FAN_E FAN_D2 16V_M FN901 PANEL R FAN,FN901 FAN_PF1...
Page 86: Error Information
Chassis Description & Troubleshooting Power failure, Fan lock, Temp. Failure Detecting ICs IC (Board) Signal Name Target Error Information IC4713 (MAIN) PF_-5V 5V(MAIN) MAIN, IC4713 (MAIN) PF_3.3V 3.3V(MAIN) MAIN, 3.3V IC4713 MAIN PF_6V 6V(MAIN) MAIN, IC4713 (MAIN) PF_16V 16V(MAIN) MAIN, S16V IC4713 (MAIN) LAMP_COVER LAMP COVER...
Page 87: Control Port Functions
Control Port Functions Function Name Function Pol. Action CPU(SH7727) (IC801) 1 1.9V Power for RTC(1.9V) 2 (Not used) X’TAL for built-in RTC (Open) 3 1.9V X’TAL for built-in RTC (Vcc) 4 GND Power for RTC(0V) 5 MD1 Clock Mode Setting [Default:L] Switch 6 MD2 Clock Mode Setting [Default:L]...
Page 88 Control Port Functions Function Name Function Pol. Action 66 3.3V Power for Input/Output(3.3V) 67 A4 Address Bus 68 A5 Address Bus 69 A6 Address Bus 70 A7 Address Bus 71 A8 Address Bus 72 A9 Address Bus 73 A10 Address Bus 74 A11 Address Bus 75 GND...
Page 89 Control Port Functions Function Name Function Pol. Action 132 GND Power for Input/Output(0V) 133 CS_SDI_CPU Dual SDI Control(4 line Serial SOUT) 134 3.3V Power for Input/Output(3.3V) 135 SCLK_GAM_CPU Control for Digital Gamma IC (3 line Serial CLK) 136 SDATA_GAM_CPU Control for Digital Gamma IC (3 line Serial DATA) 137 GND Power (0V) 138 SCALER_RESET...
Page 90 Control Port Functions Function Name Function Pol. Action 198 RxD0 Receive Data0 [PAD Remote Control] 199 (Not used) SIOF Receive Data/IO Port for SCI (Pull-up) 200 GND Power (0V) 201 RxD2 Receive Data2 [External] 19200bps or 9600bps 202 1.9V Power (1.9V) 203 IRQ5 I/O Expander(No.1) Interrupt Active L...
Page 91 Control Port Functions Function Name Function Pol. Action 22 CPU_CHK_DPRAM INT Clear L:not INT Clear 23 S3.3V 24 X1 (Not used) H Fixed 25 GND 26 X2 (Not used) Open 27 A0 Address 0 28 A1 Address 1 29 A2 Address 2 30 A3 Address 3...
Page 92 Control Port Functions Function Name Function Pol. Action 6 TX_SLOT UART for Slot 7 RX_SLOT UART for Slot 8 TRM_1 D_SUB75 ohm terminate ON/OFF L:Off(Default)H:On 9 TRM_2 D_SUB75 ohm terminate ON/OFF L:Off(Default)H:On 10 LAMP2_REP_LED Lamp-2Replace LED On/Off L:LED on 11 C_ON PC Root C Filter ON/OFF L:Off(Default)H:On 12 GND...
Page 93 Control Port Functions Function Name Function Pol. Action 72 GND 73 S3.3V 74 D4 Data Bus 4 75 D5 Data Bus 5 76 D6 Data Bus 6 77 D7 Data Bus 7 Serial Port Wakeup (Open) 79 IRQ0 Interrupt Output(Level Output) Serial Port Invalid (Open) Parallel Output Expander1(74LVCX374) (IC6755)
Page 94 Control Port Functions Function Name Function Pol. Action (Not used) (Open) 13 RGB/YCbCr CXA2175 Input Switch L”:YCbCrH:RGB 14 SLOT_CTL Slot Control L:Slot Connection 15 STB_GAM_CPU Control for Digital Gamma IC(3-Line Serial Stlobe 16 DVI_PDO DVI Receiver Power Down Control (Output Only) L:Power Down (Not used) 18 STR2_SW...
Page 95 Control Port Functions Function Name Function Pol. Action 4 PFLCD_12V Power Fail Detection (12V) LCD Drive Error: L 5 PF_S16V Power Fail Detection (S16V) LCD Drive Error: L 6 PF_3.3V Power Fail Detection (3.3V) LCD Drive Error: L 7 PF_15.5V Power Fail Detection (15.5V) LCD Drive Error: L (Not used)
Page 96 Control Port Functions Function Name Function Pol. Action 8 GND 9 FAN_B_PF FAN_B Control Voltage Abnormal Detection Error: L 10 FAN_C_PF FAN_C Control Voltage Abnormal Detection Error: L 11 FAN_D_PF FAN_D Control Voltage Abnormal Detection Error: L 12 FAN_E_PF FAN_E Control Voltage Abnormal Detection Error: L 13 Power 5V 14 Slave Address 2 (GND)
Page 97 Control Port Functions Function Name Function Pol. Action IIC Bus 8Bits 12ch 12V-D/A Converter (M62398FP) (IC571) 1 Reset Input 2 IIC BUS SCL 3 IIC BUS SDA 4 VCOMR 5 VCOMG 6 VCOMB 7 VREFHR 8 VREFHG 9 VREFHB 10 DAC Lower Ref. Voltage 11 DAC Upper Ref.
Page 98: Cleaning
Cleaning After long periods of use, dust and other particles will accumulate on the LCD panel, prism, mirror, polarized glass, lens, etc., causing the picture to darken or color to blur. If this occurs, clean the inside of optical unit. Remove dust and other particles using air spray.
Page 99: Ic Block Diagrams
IC Block Diagrams ● AD9888KS Selector <IC8201> OUTA CLAMP OUTB OUTA CLAMP OUTB OUTA CLAMP OUTB HSYNC DATACK HSYNC HSOUT VSYNC VSOUT VSYNC SOGOUT SYNC SOGIN PROCESSING SOGIN CLOCK GENERATION COAST BYPASS CLAMP CKINV CKEXT FILT AD9888 SERIAL REGISTER POWER MANAGEMENT ●...
Page 100 IC Block Diagrams ● BA7078AF Sync Separator <IC9033> ● L3E01031F0A RGB-Level Shift <IC3501, IC3521, IC3541> - 100 -...
Page 101 IC Block Diagrams ● LB1641 Motor Driver <IC1601, IC1611, IC1621, IC1631> ● TB1274AF RGB Matrix <IC3101> - 101 -...
Page 102 IC Block Diagrams ● TC4052BFT Selector <IC9005> ● TC90A69F PAL-Y/C Separator <IC2101> - 102 -...
Page 103 IC Block Diagrams ● TE7780 I/O Expander <IC4801, IC4802> ● MAS1390 G-Sensor <IC5711> - 103 -...
