COMPACT COMPONENT SYSTEM
KOMPAKT-KOMPONENTEN-SYSTEM
SYSTEME DE COMPOSANTS COMPACT
KOMPACTO KOMPONENTEN-SYSTEEM
SISTEMAS DE COMPONENTES COMPACTOS
IMPIANTO A COMPONENTI COMPATTO
CA-MXJ150R
PROGRAM
/SET
CD
CD
STANDBY
COUNTER
CLOCK
ACTIVE
SOUND
RESET
/TIMER
BASS EX.
MODE
DEMO
DISPLAY
PTY
– SELECT +
MODE
/EON
PROGRAM/SET
TIMER
PHONES
ON/OFF SLEEP
REPEAT
REPEAT
ACTIVE
SOUND
COMPU
BASS EX.
MODE
PLAY
CONTROL
TAPE A/B TUNING MODE FM MODE
TAPE
FM/AM
AUX
EJECT
DISC SKIP
+
VOL.
FADE
MUTING
PLAY
–
VOL.
FULL-LOGIC CONTROL
RM–SMXJ100E
REMOTE CONTROL
INSTRUCTIONS
BEDIENUNGSANLEITUNG
MANUEL D'INSTRUCTIONS
GEBRUIKSAANWIJZING
MANUAL DE INSTRUCCIONES
ISTRUZIONI
OPEN / CLOSE
CD
1
CD
2
CD
3
DISC CHANGE
COMPACT
PLAY & EXCHANGER
DIGITAL AUDIO
VOLUME
+
–
AUX
FM/AM
CD
TAPE
CD REC
TAPE A/B
START
- TUNING
TUNING +
REC/PAUSE
A
B
DUBBING
–
+
PRESET
EJECT
REC/PLAY
CD SYNCHRO RECORDING
COMPACT
DIGITAL AUDIO
For Customer Use:
Enter below the Model No. and Serial
No. which are located either on the rear,
bottom or side of the cabinet. Retain this
information for future reference.
Model No.
Serial No.
LVT0473-001A
[ E ]
