Summary of Contents for EisSound 426A2

  • Page 1 426A2 CONTROL UNIT AENOR Empresa Registrada ER-0634/1998 USER'S AND INSTALLATION MANUAL...

  • Page 3: Table Of Contents

    Important Safety Instructions Table of contents Before installing the unit, please read and follow the instructions provided in the Installation Manual included . Before operating the unit, please read and follow the instuctions provided in the User´s Manual thoroughly and save it for future experience. WARNING - To reduce the risk of fire or electric shock: install in accordance with the manufacturer’s instructions 1.

  • Page 4: Quick Reference Guide

    1. Quick Reference Guide NORMAL PROGRAMMING off/on exit programming menu audio adjustment mode (volume-bass-treble - loudness - balance) audio channel selection (FM - DAB - discman input) FM/DAB tuner access to program / settings / installation menus store acoustic timer enabled (flashing) start acoustic timer stop acoustic timer numeric keypad...
  • Page 5 PROGRAM MENU QUICK ACCESS FUNCTIONS CLOCKS Alarm 1 (ON/OFF status - Hour, minutes - Days of week - Type - Volume) Alarm 1 status on/off Alarm 2 (ON/OFF status - Hour, minutes - Days of week - Type - Volume) Alarm 2 status on/off Auto Standby (ON/OFF status - Hour, minutes - Days of week) Autostandby status on/off...

  • Page 6: Features & Technical Characteristics

    - Different colours available (accessory) - Clock & calendar - IR remote control available (accessory) - 2 alarms - Autostandby - Sleep timer DAB (Band-III) frequency table 426A2 NORMAL COMMENTS Measurements 135,5x70,5x44 exterior (width x height x depth) CHANNEL MHz CHANNEL...
  • Page 7 How to use this manual The 426A2 Control Unit has three program menus of settings at different access levels. « Installation Menu: Discusses the settings related to the proper operation of the system. These settings should be programmed by a professional.

  • Page 8: Installation

    3. Installation Installation involves four elements: a power supply, a control unit, an antenna and loudspeakers. • If the room is monophonic, connect any of the speakers and set the control unit to MONO. (See 5.1. Mono/Stereo Installation) • • Ω...

  • Page 9: Operating

    Control Units start up in their “ideal” state. See 4.7. “Ideal” mode 4.2. Selection of Music Channels The 426A2 Control Unit has 3 CH fm ic channels FM tuner, DAB...
  • Page 10 4.4. Operation of the FM tuner Key Sequence Display 426A2 Control Unit is equipped with an internal FM tuner. When the FM tuner is selected as sound source, stations can be tuned in several different ways: frequency selection mode FM station tuned...
  • Page 11 Key Sequence Display frequency selection mode FM station tuned automatic station search sensitivity To enter the frequency selection mode, press FM again. level (1...4) frequency stereo frequency selection mode automatic station When pressed with a short key press, the search sensitivity level (1...4) + and - keys tune the frequency in frequency...
  • Page 12 Key Sequence Display 4.5. Operation of the DAB tuner 426A2 Control Unit is equipped with an internal DAB tuner. When the DAB tuner is memory pre-set number DAB service tuned selected as sound source, services can be tuned in several different ways:...
  • Page 13 To confirm it has been stored, press FM/DAB again. 4.7. “Ideal” Settings Mode The 426A2 Control Unit has the feature to store “ideal” audio settings, which are pre-programmed settings that can be activated quickly and immediately. These settings consist of an audio channel Vol 72 and pre-set levels of volume, balance, bass, treble and loudness.
  • Page 14 Key Sequence Display Visual 4.8. Autostandby The 426A2 Control Unit will go into standby mode (background music off) at the time and days of the week programmed. Access the program menu. Select the on/off status, time auto-standby and days of the week to execute the function.
  • Page 15 4.11. Acoustic Timer The 426A2 is equipped with a programmable timer which sounds a specific acoustic signal when the 121:00 programmed waiting time has elapsed (between 1 and 240 minutes). Key in the time desired for the timer, for example 121 minutes, followed by the timer starter key.

  • Page 16: Installation Menu

    5. Installation Menu Key Sequence Display Visual 5.1 Mono/Stereo Defines whether the control unit's audio output (terminals 04, 05, 06) is connected in stereo/mono mono or stereo mode. In a control unit in stereo, outputs 05 and 06 respond to the left 2’’...

  • Page 17: Settingsmenu

    6. SettingsMenu Key Sequence Display Visual 6.1 Language idioma españl To select the language of all display text. 2’’ To select a different language (for example, English). englsh Store 6.2 Greeting greeting 2’’ Allows you to personalize the message that appears on the display when the control unit is hello powered on (a maximum of 18 characters).

  • Page 18: Programming Menu

    7. Programming Menu 7.1 Clock Key Sequence Display Visual Key Sequence Display Visual 7.1.1 Alarm 1 and 2 The Control Unit is equipped alarm 1 Change SA OFF with two programmable alrm1 alarms with two operation Scroll through days SU ON modes, as described in section 4.10.
  • Page 19 7.1.2 Auto standby 7.1.3 Sleep Display Visual Key Sequence Key Sequence Display Visual Option to program a time for the Sleep time can be adjusted to the autostandby sleep minutes control unit to automatically go user's needs by using the min 20 into stand-by mode (background following programming option...
  • Page 20 7. Programming Menu 7.2 FM tuner Key Sequence Display Visual 7.2.1. FM Seek Sensitivity The option to adjust the automatic station seek sensitivity for the control unit's internal FM tuner fm sensitivity sens 4 To adjust the new sensitivity; sens 2 4=max, 1=min.
  • Page 21 7. Programming Menu 7.3 DAB tuner Key Sequence Display Visual 7.3.1. Initialize DAB The first time DAB is required, or after resetting, or if you change the unit's location, or want to add INIT DAB a new service after the initial setting, the unit must re-scan and create a list of receivable broadcasts.
  • Page 22 7. Programming Menu 7.4 Adjustments 7.4.1. Saving “Ideal” Settings To store the current audio Key Sequence Display Visual settings (volume, balance, bass, treble, loudness and selected ideal channel) as the “ideal settings” Select ON/OFF Store 7.4.2. Off/On Dimmer Display Visual Key Sequence Window brightness for on/off light off...
  • Page 24 6446 0036 CENTRAL Polígono Malpica Calle F Oeste Grupo de Naves Gregorio Quejido, 87-88 50016 Zaragoza (España) Electrónica Integral de Sonido Tel.: 34 976 465550 Fax: 34 976 465559 comercial@eissa.com MADRID Paseo de Europa 13, 2ºB 28700 San Sebastián de los Reyes Madrid (España) Tel.: 34 91 6593678 Fax: 34 91 6239525...
  • Page 25 Denominación Modificación Denomination Modification MANUAL DE USO E INSTALACION MANDO CONTROL 426A2 Código Pieza Part Code 64460036 Material Material SOPORTE: Fecha Date Nombre Name TINTA: BLANCO Y NEGRO Proyectado 17/04/2008 L.ABOS Projected Código Documento Edición Escala Dibujado Document Code Edition 17/04/2008 L.ABOS...
