SUPER PROJECTOR MANUEL D’INSTRUCTIONS : SUPER PROJECTEUR DLA-M5000LE DLA-M5000SCE INSTRUCTIONS QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK RGB/COMPUTER SHIFT ZOOM FOCUS – LENS RM-M4100G REMOTE CONTROL UNIT LCT0979-002B...
Thank you for purchasing this projector. Before using it, read and follow all instructions carefully to take full advantage of the projector’s capabilities. SAFETY PRECAUTIONS IMPORTANT INFORMATION WARNING : TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
Page 4
– Xenon gas is enclosed with high pressure inside the light- source lamp (lamp unit) of this projector. If you drop or impart a shock to the lamp, or discard it as is, there is the possibility of explosion, leading to personal injury.
Information on the power cord plug The power cord of this projector does not have a wall outlet plug attached. We recommend you to select and attach a plug which matches your wall outlet.
For Operating Other Functions ...26 Operating the Setting Menu... 29 Making Basic Settings...29 Accessories he following accessories are included with this projector. Check for them; if any item is missing, please contact your dealer. Remote control unit AA/R6-size dry cell battery (...
Air is taken in through this area to cool the light-source lamp. If this area is blocked or if something that obstructs taking in or exhausting air is placed around the projector, heat may build up inside and could cause a fire. For details, refer to “Precautions for Installation”...
When operating with the remote control, aim it toward this sensor. An additional remote sensor is provided on the front of the projector. The effective operating distance of the remote control is 10 m from each of the sensors. The effective operating range of angles is 50°...
When the projector is in the stand-by mode, press this button for one or more seconds, and the main power switch is turned on, causing the OPERATE indicator to light. Press it again, and the projector goes into the cool- down mode, then stand-by mode. Memo...
Page 10
OPERATE STAND BY 7 AV button Use this button to select a device such as a video deck connected to the EXT. IN terminal of the projector. Each time you press the button, the device selected changes as follows: VIDEO*...
1080i) compatible with this unit, refer to 65. 4 REMOTE terminal (mini jack) This terminal is used to directly connect the remote control to the projector. Use the remote control cable supplied. An infrared remote control extension unit can also be connected to the jack.
For how to operate the buttons, see page 12. 5 RGB/COMPUTER button Use this button to select the devices connected to the projector’s RGB IN (RGB input) -1 and -2 input terminals. Each time you press the button, the selection changes as follows:...
Page 13
Remote Control Unit (Cont.) p AV button Use this button to select the devices such as a video connected to the projector’s AV IN (EXT. input) terminal. Each time you press the button, the selection changes as follows: Y/C* VIDEO* * Y/C and VIDEO can be used only when a video board separately sold has been installed.
MENU/ENTER (Menu Operation) Button The remote control supplied with this projector has only one button to navigate through the menus. Pressing the menu operation button too strongly may cause an incorrect operation. So, before you use the button in an actual situation, have some practice to make yourself familiar with using the button.
Precautions for Installation CAUTION • Since the projector weighs approx. 70 kg (154 lbs.), be sure to use four or more people when lifting or moving it; otherwise, the projector could possibly drop, causing personal injury and/or damage to the projector.
Page 16
• To prevent falling or overturning, it is recommended that the projector be fixed to its stand with bolts. • When mounting the projector to the ceiling, first install a special shelf and then set the projector on it securely. For safety and maintenance purposes, a suitable facility is necessary to easily lift and lower the projector from the shelf for maintenance access.
CAUTION • To prevent damage to the projector during shipment, a shift center lock pin was used to fix the lens mechanism when the projector was shipped out the factory. If you implement “SHIFT LENS” on the setting menu and the lens does not either move up or down, the shift center lock pin may not have been removed.
Page 18
Installing the Projector Lens Shift Function (Cont.) Maximum amount of shift The maximum amount of vertical shift is restricted by the amount of horizontal shift made. The amount of shift is defined as follows: With the screen width taken as 1, horizontal shift is defined...
Lenses that can be used are a 3 : 1 ~ 7 : 1 zoom lens and a 1.5 : 1 fixed-focus lens. With a zoom lens used, you have a wider latitude in selecting projection distance and installation space than with a fixed lens. For how to install the lens, consult the dealer who installed and adjusted your projector or service center. Relationship of screen size vs. projection distance Fixed-Focus Lens 1.5 : 1...
Connecting to Various Devices * Before connection, be sure to turn off the projector and connected devices. * Read the manual which comes with each device thoroughly. Signals that Can Be Input to the Projector The following signals can be input to the projector:...
Example of a basic system • By connecting an RGB switcher, a variety of input sources can be input to the projector as RGB signals. Using the remote control supplied, you can select the channel for an input source and project an image optimal to the source.
Connecting to Various Devices Connecting to Computer Devices Before connection, be sure to turn off both the projector and computer devices. • Read the manual which comes with each device thoroughly. • Use the separately available computer connection cable. Also, prepare cables required for connecting the devices connected.
• If you connect the cable terminal of the remote control and the REMOTE terminal of the projector with a remote control cable, you can use the remote control in a place or at an angle from which the infrared beam cannot reach the projector.
Connecting to Various Devices Connecting the Power Cord (Supplied) After all devices have finished being connected, connect the projector’s power cord. At this time, do not turn on the MAIN POWER switch yet. I Preparation Attach a plug which matches your wall outlet, to the power cord.
After the fans have stopped, turn off the MAIN POWER switch and pull out the power cord. After that, re-insert the power cord and try to operate the projector. If it goes into emergency again, after the fans have stopped, turn off the main power switch, pull out the power cord, and consult your authorized dealer or service center for repair.
(Or press the remote control’s OPERATE button for one second or more.) • The STAND BY indicator changes to blinking, and the projector goes into cool-down mode. Example of the projector’s button 2 Turn off the MAIN POWER switch after the cooling fans have stopped running.
ZOOM (T/W) buttons – LENS ATTENTIONS • DO NOT give any shock to this projector while operating it; otherwise, the light-source lamp goes off (the EMERGENCY indicator lights up). If the shock turns off the light-source lamp — Turn off the power by pressing the MAIN POWER switch, then turn it on again.
The quick alignment function is used to automatically adjust (set) the screen settings of “TRACKING, PHASE, H. POS. and V. POS.” of computer system input video. • Use either the remote control’s or projector’s button. When using the remote control unit: Press the QUICK ALIGN. button.
Page 29
The main menu appears on the screen. Remote control unit Note • To change the menu language displayed English is set when the projector is shipped from the factory. The language displayed can be selected from the following six languages: N DEUTSCH (German), ESPAÑOL (Spanish), ITALIANO (Italian), and FRANÇAIS (French).
Page 30
Basic Operations I Remote control unit AV HIDE button QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK PAGE BACK button PRESET button RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I To display “CHANNEL” on the screen While no menu is displayed, pressing the PAGE BACK button causes the channel now being used to appear.
(connection). Notes • The setting menu is displayed when you press the SETTING button on the projector. After the menu is displayed, you can make settings (adjustments). • If the projector’s position or connections have been...
When projecting high-vision video image, a ratio of 16 : 9 can be selected. Sets the length of sleep time. A set sleep time after input signal is depleted, the projector goes into a stand-by state. Sleep time can be selected from 10 minutes, 20 minutes, 30 minutes, 60 minutes and 0 minutes.
4 : 3. When projecting high-vision image, a ratio of 16 : 9 can be selected. Sets the length of sleep time. A set sleep time after input signal is depleted, the projector goes into a stand-by state. Sleep time can be selected from 10 minutes, 20 minutes, 30 minutes, 60 minutes and 0 minute.
E N G L I S H Decoder (color system) Language For projector’s menus, the setting menu and the main menu are available. Here, we explain about the operation of the main menu. For the setting menu, refer to “Making Basic Settings” on page 29.
When video signals from AV devices are input, the item for the color system can be set. AUTO is set for the color system when the projector is shipped from the factory. Normally, use it in AUTO. If operation in AUTO is unstable such as with color not being shown, set to a dedicated color system in accordance with the color system of the signal being input.
H D T V ( 1 0 8 0 i ) FRANÇAIS ... French Memo About language display English is selected when the projector is shipped from the factory. The languages in the menu display are the following six: (German), ESPAÑOL (Spanish), ITALIANO (Italian) and FRANÇAIS (French).
Adjusting the Pixel Clock I Remote control unit QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK PAGE BACK button MENU/ENTER button RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Main menu Y P B P R H D T V ( 1 0 8 0 i ) P I X E L C L O C K P O S I T I O N P I C T U R E...
Operating the Main Menu Adjusting the Screen Position I Remote control unit QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK PAGE BACK button MENU/ENTER button RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Main menu Y P B P R P I X E L C L O C K P O S I T I O N P I C T U R E O P T I O N S...
Adjusting Picture Quality I Remote control unit QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK PAGE BACK button MENU/ENTER button RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Main menu Y P B P R H D T V ( 1 0 8 0 i ) P I X E L C L O C K P O S I T I O N P I C T U R E...
Page 40
Operating the Main Menu Adjusting Picture Quality (Cont.) I Remote control unit QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK PAGE BACK button MENU/ENTER button RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Submenu items [PICTURE menu] P I C T U R E ( N T S C ( 4 8 0 i ) ) B R I G H T N E S S C O N T R A S T...
Page 41
Adjusting Picture Quality (Cont.) I Remote control unit QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK PAGE BACK button MENU/ENTER button RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Submenu items [PICTURE menu] P I C T U R E ( S X G A 2 ) B R I G H T N E S S C O N T R A S T R - G A I N...
Operating the Main Menu Setting and Adjusting Other Functions (OPTIONS) I Remote control unit QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK PAGE BACK button MENU/ENTER button RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Main menu Y P B P R P I X E L C L O C K P O S I T I O N P I C T U R E...
Page 43
Setting and Adjusting Other Functions (OPTIONS) (Cont.) I Remote control unit QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK PAGE BACK button MENU/ENTER button RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Submenu items [OPTIONS menu] O P T I O N S M E N U A U T O O F F L I N E D I S P L A Y R I G H T L E F T R E V .
Page 44
Note • When you view a conventional (normal) 4 : 3 video picture, which is not wide video picture, on the projector’s screen the aspect change function, the upper and lower parts of the video picture become partially invisible. View such an original video picture in 4 : 3 mode, respecting the producer’s intention.
Changing (Setting) the Source I Remote control unit QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK PAGE BACK button MENU/ENTER button RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Main menu Y P B P R H D T V ( 1 0 8 0 i ) P I X E L C L O C K P O S I T I O N P I C T U R E...
Page 46
Operating the Main Menu Changing (Setting) the Source (Cont.) I Remote control unit QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK PAGE BACK button MENU/ENTER button RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Submenu [SOURCE setup menu] S O U R C E ( H D T V ( 1 0 8 0 i ) ) S V G A 1 A U T O...
Page 47
Press MENU/ENTER down to set a source. • By having a source set, the source for the projector switches to the setting registered to the user source. I Pressing PAGE BACK twice will bring you back to the main menu. To finish the main menu, press PAGE BACK again.
Operating the Main Menu Setting Up Channels I Remote control unit QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK PAGE BACK button MENU/ENTER button RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Main menu Y P B P R P I X E L C L O C K P O S I T I O N P I C T U R E O P T I O N S...
Setting Up Channels (LINE setup) I Remote control unit QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK PAGE BACK button MENU/ENTER button RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I CHANNEL setup • selection menu C H A N N E L ( A U T O ) L I N E S O U R C E...
Operating the Main Menu Setting Up Channels (SOURCE setup) I Remote control unit QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK PAGE BACK button MENU/ENTER button RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I CHANNEL setup • selection menu C H A N N E L ( A U T O ) L I N E S O U R C E...
Page 51
Setting Up Channels (SOURCE setup) (Cont.) I Remote control unit QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK PAGE BACK button MENU/ENTER button RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I CHANNEL setup • selection menu C H A N N E L ( A U T O ) L I N E S O U R C E...
Note • You can automatically switch the channels of the projector by specifying a switcher number through an external controller. As an example, if switcher number 1 (SW No1) has been...
Changing Channels (CH Change) I Remote control unit QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK PAGE BACK button MENU/ENTER button RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Main menu Y P B P R H D T V ( 1 0 8 0 i ) P I X E L C L O C K P O S I T I O N P I C T U R E...
Page 54
Operating the Main Menu Changing Channels (CH Change) (Cont.) I Remote control unit QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK PAGE BACK button MENU/ENTER button RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Main menu Y P B P R P I X E L C L O C K P O S I T I O N P I C T U R E...
Setting Up (or Changing) User Sources I Remote control unit QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK PAGE BACK button MENU/ENTER button RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Main menu R G B 1 P I X E L C L O C K P O S I T I O N P I C T U R E O P T I O N S...
Page 56
Operating the Main Menu Setting Up (or Changing) User Sources (Cont.) I Remote control unit QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK PAGE BACK button MENU/ENTER button RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Main menu R G B 1 P I X E L C L O C K P O S I T I O N P I C T U R E...
Page 57
Setting Up (or Changing) User Sources (Cont.) I Remote control unit QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK PAGE BACK button MENU/ENTER button RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Main menu R G B 1 P I X E L C L O C K P O S I T I O N P I C T U R E O P T I O N S...
PC video boards, etc.) of an input signal (source) registered in the user source setup does not match the display size projected by this projector, this setup should be performed. In the user source setup, a display size most approximate to the standard setting of the projector is automatically assumed.
Setting Up (or Changing) the Display Size (Cont.) I Remote control unit QUICK QUICK ALIGN. button ALIGN. OPERATE AV HIDE PRESET PAGE BACK PAGE BACK button MENU/ENTER button RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Main menu R G B 1 P I X E L C L O C K P O S I T I O N P I C T U R E...
Bring the projector into stand-by state, and turn off the MAIN POWER switch. Put the projector into stand-by, and make sure the STAND BY indicator is lit, then tun off the MAIN POWER switch. After that, disconnect the power cord from the wall outlet and the projector. For detailed procedures, refer to “Turning off the power”...
Wash the filter in water with neutral detergent, and dry it in the shade. Reinstall the filters. To reinstall the filters to the projector, reverse the procedure for removing. Finally, be sure to reinstall the filter covers. Notes • Install the filters correctly; otherwise the projector will not operate normally.
Troubleshooting Solutions to common problems related to your projector are described here. If none of the solutions presented here solves the problem, unplug the projector and consult a authorized dealer or service center. Symptom Power is not supplied. • Is the power cord disconnected? •...
Page 63
• Have the channel’s setup contents been position on the screen changed? has shifted. • Is sync signal being input correctly? • Has the projector been moved from its installed place? Video image suddenly • Aren’t video turned off by pressing the go out.
Page 64
Refer to the CAUTION and NOTES on page 23. * This projector is equipped with a microcomputer that may operate abnormally due to interference from external components. If this happens, turn off the main power and disconnect the power cord from the wall AC outlet. Then reconnect the power cord to AC outlet and turn on the main power again.
Page 66
Horizontal sync/composite sync signal (H/C Vertical sync signal (V) [CONTROL] 1-line, D-sub 9-pin × 1 • RS-232C: * RS-232C-interface specified control terminal for controlling this projector with a personal computer. 1-line, mini-jack × 1 • REMOTE I General • Power requirements •...
Outside dimensions I Top I Front φ 50 I DTV-format signals * The following are DTV-format signals that can be input. DTV-Formats 480i Signal Standard ITU-R BT. 601-4 Scanning Line / Frame Effective Samples 720 × 485 × Scanning Lines Field Frequency (Hz) 59.94 Line Frequency (Hz)
3 : 1~7 : 1 zoom lens GL-M4015S 1.5 : 1 fixed-focus lens • Video board PK-G1101D A board to be used for adding composite video signal input and Y/C (S-Video) function to the projector. Pin number Signal name GND (Y) GND (C) Pin number...
Merci d’avoir acheté ce projecteur. Avant de l’utiliser, lisez et respectez attentivement toutes les instructions pour profiter au maximum des capacités du projecteur. IMPORTANTES MESURES DE SÉCURITÉ INFORMATIONS IMPORTANTES AVERTISSEMENT : POUR ÉVITER TOUT RISQUE D’INCENDIE OU D’ÉLÉCTROCUTION, N’EXPOSEZ PAS CET APPAREIL À...
Page 70
– Cet appareil doit être alimenté uniquement avec le type d’alimentation indiqué sur l’étiquette. Si vous n’êtes pas sûr du type d’alimentation secteur de votre maison, consultez le revendeur de l’appareil ou votre compagnie d’électricité. – Cet appareil est équipé d’une fiche à trois broches. Elle ne peut être branchée que dans une prise secteur avec mise à...
Page 71
CONNEXION ELECTRIQUE (Royaume-Uni seulement) AVERTISSEMENT Ne débranchez pas la fiche principale de cet appareil. Si la fiche existante ne convient pas aux prises de courant de votre maison ou si le cordon est trop court pour atteindre une prise de courant, procurez-vous un cordon prolongateur ou un adapteur de sécurité...
Page 72
Table des matières IMPORTANTES MESURES DE SÉCURITÉ ... 1 Table des matières ... 4 Accessoires ... 4 Commandes et fonctions... 5 Face avant / Dessus / Côté droit...5 Côté gauche / Arrière ...6 Panneau de commande ...7 Panneau de connecteurs ...9 Télécommande ...10 Touche MENU/ENTER (Fonctionnement du menu) ...12...
Commandes et fonctions Face avant / Dessus / Côté droit 1 Pied réglable Il est réglé sur la position la plus basse en sortie d’usine. Tourner le pied pour mettre le projecteur de niveau. Le réglage peut être effectué sur une plage de ±4° à partir de la position verticale et ±5°...
Commandes et fonctions Côté gauche / Arrière 8 Évents de sortie d’air Orifices permettant l’évacuation de l’air chaud et le refroidissement des ventilateurs. 9 Panneau de commande Pour plus de détails, référez-vous à “Panneau de commande” à la page 7 et 8. p Capteur de télécommande Lors de l’utilisation de la télécommande, la diriger vers ce capteur.
Panneau de commande OPERATE STAND BY 1 Indicateur STAND BY ON : Quand l’appareil est en mode d’attente. Clignotant :Quand l’appareil est en mode de refroidissement. PRECAUTIONS • Le mode de refroidissement continue pendant environ 20 secondes, pendant lesquelles la projection ne peut pas être redémarrée.
Page 76
Commandes et fonctions Panneau de commande (suite) OPERATE STAND BY 7 Touche AV Utilisez cette touche pour sélectionner un appareil comme un équipement vidéo raccordé à la prise EXT. IN du projecteur. À chaque pression sur cette touche, l’appareil sélectionné change comme suit : Y/C* VIDEO* * Y/C et VIDEO ne peuvent être utilisés que lorsqu’une...
Panneau de connecteurs 1 Prise d’entrée Y/C (S-vidéo) (Mini DIN 4 broches) Raccordez cette prise à la prise de sortie S-Vidéo d’un magnétoscope, etc. * Cette prise peut être utilisée si une carte vidéo (PK- G1101D) vendue séparément a été installée. La prise n’est pas fournie lors de l’expédition du projecteur depuis l’usine.
Commandes et fonctions Télécommande 1 Emetteur de signal pour la télécommande 2 Touche OPERATE Pour mettre l’appareil sous tension ou hors tension, appuyez sur cette touche pendant une seconde ou plus. * Environ 30 secondes après la mise sous tension, l’image vidéo apparaît à...
Page 79
Télécommande (suite) p Touche AV Utilisez cette touche pour sélectionner les appareils (par exemple vidéo) raccordés à la prise AV IN (entrée EXT.) du projecteur. À chaque pression sur cette touche, la sélection change comme suit : Y/C* VIDEO* * Y/C et VIDEO ne peuvent être utilisés que lorsqu’une carte vidéo vendue séparément a été...
Commandes et fonctions Touche MENU/ENTER (Fonctionnement du menu) La télécommande fournie avec ce projecteur ne possède qu’une seule touche pour naviguer dans les menus. Une pression trop forte sur la touche de fonctionnement de menu peut provoquer un fonctionnement incorrect. Par conséquent, avant d’utiliser cette touche en situation réelle, entraînez-vous afin de vous familiariser avec son utilisation.
Installation du projecteur Précautions pour l’installation PRECAUTION • Le projecteur pesant environ 70 kg, veillez à employer au moins quatre personnes pour le soulever ou le déplacer ; dans le cas contraire, vous risqueriez de le faire tomber et de provoquer des blessures corporelles et/ ou des dommages au projecteur.
Page 82
Installation du projecteur Précautions pour l’installation (suite) I Observez les points suivants lors de l’installation du projecteur au plafond : • Pour prévenir toute chute ou retournement de l’appareil, il est recommandé de fixer le projecteur à son support à l’aide de boulons.
Fonction de déplacement d’objectif Ecran 90° Les objectifs vendus séparément utilisés sur le projecteur bénéficient d’une fonction de déplacement d’objectif. Avec ces objectifs, vous pouvez ajuster l’image projetée verticalement à l’aide du menu de réglage ou de la touche SHIFT U ou D de la télécommande.
Page 84
Installation du projecteur Fonction de déplacement d’objectif (suite) Déplacement maximal Le déplacement vertical maximal est limité par le déplacement horizontal effectué. Le déplacement est défini comme suit : Avec une largeur d’écran de 1, le déplacement horizontal est défini comme le rapport (%) de la largeur d’écran, tandis qu’avec une hauteur d’écran de 1, le déplacement vertical shift est défini comme le rapport (%) de la hauteur d’écran.
Distances de projection et tailles d’écran Les objectifs utilisables sont un objectif zoom 3 : 1 ~ 7 : 1 et un objectif à mise au point fixe 1,5 : 1. Lorsque vous utilisez un objectif zoom, vous disposez d’une latitude plus importante dans la sélection de la distance de projection et de l’espace d’installation.
Raccordement avec différents appareils * Avant la connexion, assurez-vous que le projecteurs et autres appareils à raccorder sont éteints. * Bien lire le manuel fourni avec chaque appareil. Signaux pouvant être entrés dans le projecteur Les signaux suivants peuvent être entrés dans le projecteur : I Signaux vidéo (1) Réponse aux systèmes de couleur Système de...
Exemples de configuration système Avant tout raccordement, assurez-vous que le projecteur et l’équipement sont hors tension. • Consultez également les manuels fournis avec l’équipement. Exemple de système de base • En raccordant un commutateur RGB, différentes sources d’entrée peuvent être entrées dans le projecteur comme signaux RGB.
Raccordement avec différents appareils Raccordement aux ordinateurs Avant tout raccordement, assurez-vous que le projecteur et ordinateur sont hors tension. • Bien lire le manuel fourni avec chaque appareil. • Utilisez le câble de raccordement pour ordinateur vendu séparément. Préparez également les câbles nécessaires pour raccorder les appareils connectés.
Raccordement à des appareils qui contrôle le projecteur Avant tout raccordement, assurez-vous que le projecteur et les appareils à raccorder sont hors tension. • Bien lire la notice d’emploi accompagnant chaque appareil devant être raccordé. • En raccordant un ordinateur à la prise RS-232C, vous pouvez contrôler le projecteur. * Pour plus de détails, consultez votre revendeur ou un centre de service agréé.
Raccordement avec différents appareils Branchement du cordon d’alimentation (fourni) Une fois tous les appareils raccordés, branchez le cordon d’alimentation du projecteur. À ce stade, n’allumez pas encore l’interrupteur MAIN POWER. I Préparation Raccordez une prise (adaptée à la prise de courant) au cordon d’alimentation.
Lors de la mise en marche des périphériques raccordés au projecteur Allumez les interrupteurs du projecteur et des périphériques raccordés dans l’ordre suivant. Ignorez les périphériques non raccordés s’il y en a. Interrupteur d’alimentation du moniteur de l’ordinateur qui fournit les signaux d’entrée au projecteur Périphériques de l’ordinateur qui fournissent des signaux d’entrée au projecteur (Disque dur, disque magnéto-optique, scanner, etc.) Interrupteur d’alimentation des périphériques AV qui fournissent des signaux d’entrée au projecteur...
Fonctionnement de base I Touches du projecteur Indicateur STAND BY Indicateur OPERATE TEMP STAND BY OPERATE LAMP EMERGENCY Touche OPERATE Interrupteur MAIN POWER I Télécommande QUICK Touche OPERATE ALIGN. OPERATE AV HIDE PRESET PAGE BACK RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Avertissement relatif aux projections prolongées :...
Fonctionnement de base I Touches du projecteur EMERGENCY SETTING Touche QUICK ALIGN. I Télécommande Commutateur LENS LOCK j UNLOCK Touche QUICK ALIGN. QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK RGB/COMPUTER Touches FOCUS (+/–) SHIFT ZOOM FOCUS – LENS 4. Réglage de la mise au point I Réglez la mise au point à...
Page 95
I Touche du projecteur TEMP LAMP EMERGENCY SETTING Touche SETTING I Télécommande QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK Touche PRESET Touche MENU/ENTER RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Pour afficher le menu REGLAGE Le menu de réglage permet d’effectuer des réglages de base (TRACK, PHASE, POSITION H., POSITION V., FOCUS et ZOOM) sur l’image vidéo projetée après installation (raccordement) ou après basculement des...
Page 96
Fonctionnement de base I Télécommande Touche AV HIDE QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK Touche PAGE BACK Touche PRESET RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Pour afficher “CHANNEL” à l’écran Lorsqu’aucun menu n’est affiché, une pression sur la touche PAGE BACK provoque l’affichage du canal utilisé...
Utilisation du menu de réglage Réglages de base I Touches du projecteur Touche SETTING SETTING EMERGENCY Touche QUICK ALIGN. I Menu de réglage R E G L A G E T R A C K P H A S E P O S I T I O N H .
Utilisation du menu principal Configuration du menu principal (Entrée AV) page suivante. Vous pouvez ajuster la qualité vidéo (IMAGE), etc. à l’aide des menus. Les menus sont configurés comme suit : Menu principal (Entrées AV : Avec le signal d’entrée EXT. IN) Menu principal (Entrées AV : Avec le signal d’entrée EXT.
Configuration du menu principal (entrée d’ordinateur) Menu principal (Entrées d’ordinateur : Avec le signal d’entrée COMPUTER IN -1 ou -2) HORLOGE PIXCEL TRACK : PHASE : POSITION POSITION V. : POSITION H. : IMAGE LUMINOSITE : CONTRASTE : GAIN-R : GAIN-V : GAIN-B : MODE TEXTE :...
Utilisation du menu principal Utilisation du menu principal (Utilisation de base du menu principal) I Télécommande QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK Touche PAGE BACK Touche MENU/ENTER RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Menu principal Eléments de sous-menu Ligne d’entrée Source Y P B P R...
Changement du système de couleur I Télécommande QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK Touche PAGE BACK Touche MENU/ENTER RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Menu principal H D T V ( 1 0 8 0 i ) Y P B P R H O R L O G E P I X C E L P O S I T I O N...
Utilisation du menu principal Changement de l’affichage de la langue I Télécommande QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK Touche PAGE BACK Touche MENU/ENTER RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Menu principal Y P B P R H O R L O G E P I X C E L P O S I T I O N I M A G E O P T I O N S...
Ajustement de l’horloge de pixels I Télécommande QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK Touche PAGE BACK Touche MENU/ENTER RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Menu principal Y P B P R H D T V ( 1 0 8 0 i ) H O R L O G E P I X C E L P O S I T I O N I M A G E...
Utilisation du menu principal Réglage de la position de l’écran I Télécommande QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK Touche PAGE BACK Touche MENU/ENTER RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Menu principal Y P B P R H O R L O G E P I X C E L P O S I T I O N I M A G E O P T I O N S...
Ajustement de la qualité de l’image I Télécommande QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK Touche PAGE BACK Touche MENU/ENTER RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Menu principal Y P B P R H D T V ( 1 0 8 0 i ) H O R L O G E P I X C E L P O S I T I O N I M A G E...
Page 106
Utilisation du menu principal Ajustement de la qualité de l’image (suite) I Télécommande QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK Touche PAGE BACK Touche MENU/ENTER RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Eléments de sous-menu [Menu IMAGE] I M A G E ( N T S C ( 4 8 0 i ) ) L U M I N O S I T E C O N T R A S T E...
Page 107
Ajustement de la qualité de l’image (suite) I Télécommande QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK Touche PAGE BACK Touche MENU/ENTER RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Eléments de sous-menu [Menu IMAGE] I M A G E ( S X G A 2 ) L U M I N O S I T E C O N T R A S T E G A I N - R...
Utilisation du menu principal Réglage et ajustement d’autres fonctions (OPTIONS) I Télécommande QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK Touche PAGE BACK Touche MENU/ENTER RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Menu principal Y P B P R H O R L O G E P I X C E L P O S I T I O N I M A G E O P T I O N S...
Page 109
Réglage et ajustement d’autres fonctions (OPTIONS) (suite) I Télécommande QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK Touche PAGE BACK Touche MENU/ENTER RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Eléments de sous-menu [Menu OPTIONS] O P T I O N S M E N U A R R E T A U T O N O N A F F S O U R C E...
Page 110
Utilisation du menu principal Réglage et ajustement d’autres fonctions (OPTIONS) (suite) I Télécommande QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK Touche PAGE BACK Touche MENU/ENTER RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Eléments de sous-menu [Menu OPTIONS] O P T I O N S M E N U A R R E T A U T O A F F S O U R C E I N V E R S D - G...
Modification (définition) de la source I Télécommande QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK Touche PAGE BACK Touche MENU/ENTER RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Menu principal Y P B P R H D T V ( 1 0 8 0 i ) H O R L O G E P I X C E L P O S I T I O N I M A G E...
Page 112
Utilisation du menu principal Modification (définition) de la source (suite) I Télécommande QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK Touche PAGE BACK Touche MENU/ENTER RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Sous-menu [Menu de configuration SOURCE] S O U R C E ( H D T V ( 1 0 8 0 i ) ) S V G A 1 A U T O...
Page 113
Modification (définition) de la source (suite) I Télécommande QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK Touche PAGE BACK Touche MENU/ENTER RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Sous-menu [Menu de configuration SOURCE] S O U R C E ( H D T V ( 1 0 8 0 i ) ) S V G A 1 A U T O S V G A 2...
Utilisation du menu principal Configuration des canaux I Télécommande QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK Touche PAGE BACK Touche MENU/ENTER RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Menu principal Y P B P R H O R L O G E P I X C E L P O S I T I O N I M A G E O P T I O N S...
Configuration des canaux (configuration de LINE) I Télécommande QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK Touche PAGE BACK Touche MENU/ENTER RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Menu configuration de CHANNEL • sélection C H A N N E L ( A U T O ) L I N E S O U R C E...
Page 116
Utilisation du menu principal Configuration des canaux (configuration de SOURCE) I Télécommande QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK Touche PAGE BACK Touche MENU/ENTER RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Menu configuration de CHANNEL • sélection C H A N N E L ( A U T O ) L I N E S O U R C E...
Page 117
Configuration des canaux (configuration de SOURCE) (suite) I Télécommande QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK Touche PAGE BACK Touche MENU/ENTER RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Menu configuration de CHANNEL • sélection C H A N N E L ( A U T O ) L I N E S O U R C E...
Utilisation du menu principal Configuration des canaux (configuration de SW No) I Télécommande QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK Touche PAGE BACK Touche MENU/ENTER RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Menu configuration de CHANNEL • sélection C H A N N E L ( A U T O ) L I N E S O U R C E...
Changement de canal (Changement de CH) I Télécommande QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK Touche PAGE BACK Touche MENU/ENTER RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Menu principal Y P B P R H D T V ( 1 0 8 0 i ) H O R L O G E P I X C E L P O S I T I O N I M A G E...
Page 120
Utilisation du menu principal Changement de canal (Changement de CH) (suite) I Télécommande QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK Touche PAGE BACK Touche MENU/ENTER RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Menu principal Y P B P R H O R L O G E P I X C E L P O S I T I O N I M A G E...
Configuration (ou modification) des sources utilisateur I Télécommande QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK Touche PAGE BACK Touche MENU/ENTER RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Menu principal R G B 1 H O R L O G E P I X C E L P O S I T I O N I M A G E O P T I O N S...
Page 122
Utilisation du menu principal Configuration (ou modification) des sources utilisateur (suite) I Télécommande QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK Touche PAGE BACK Touche MENU/ENTER RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Menu principal R G B 1 H O R L O G E P I X C E L P O S I T I O N I M A G E O P T I O N S...
Page 123
Configuration (ou modification) des sources utilisateur (suite) I Télécommande QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK Touche PAGE BACK Touche MENU/ENTER RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Menu principal R G B 1 H O R L O G E P I X C E L P O S I T I O N I M A G E O P T I O N S...
Utilisation du menu principal Configuration (ou modification) de la taille d’affichage I Télécommande QUICK ALIGN. OPERATE AV HIDE PRESET PAGE BACK Touche PAGE BACK Touche MENU/ENTER RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Menu principal R G B 1 H O R L O G E P I X C E L P O S I T I O N I M A G E O P T I O N S...
Page 125
Configuration (ou modification) de la taille d’affichage (suite) I Télécommande QUICK Touche QUICK ALIGN. ALIGN. OPERATE AV HIDE PRESET PAGE BACK Touche PAGE BACK Touche MENU/ENTER RGB/COMPUTER SHIFT ZOOM FOCUS – LENS I Menu principal R G B 1 H O R L O G E P I X C E L P O S I T I O N I M A G E O P T I O N S...
Maintenance du filtre et remplacement de la lampe source de lumière Nettoyage et remplacement du filtre Les filtres doivent être nettoyés régulièrement. S’ils sont très sales, si vous ne parvenez pas à enlever les tâches ou s’ils sont endommagés, remplacez-les par de nouveaux filtres (Numéro de pièce : LC30505) ; de la poussière et de la saleté risquent de pénétrer à...
Nettoyage et remplacement du filtre (suite) Nettoyez les filtres. Lavez le filtre avec de l’eau et un détergent neutre, puis faites-le sécher à l’ombre. Remettez les filtres en place. Pour remettre les filtres dans le projecteur, suivez la même procédure mais en sens inverse. Pour finir, assurez-vous de bien remettre les couvercles des filtres en place.
Dépannage Les solutions aux problèmes communs avec le projecteur sont décrites ici. Si aucune des solutions présentées ici ne pouvait résoudre le problème, débranchez le projecteur et consultez un revendeur autorisé ou un centre de service. Symptôme Pas d’alimentation. • Le cordon d’alimentation est-il débranché...
Page 129
Symptôme Cause probable La couleur est pauvre • Les paramètres TRACK et PHASE sont- ou instable. ils ajustés correctement ? • La qualité de l’image (densité de couleur, etc.) est-elle ajustée correctement ? • Le CLAMP correct est-il sélectionné ? Durant la lecture •...
Page 130
Dépannage Symptôme L’image vidéo • La vidéo n’a-t-elle pas été arrêtée par disparaît une pression sur la touche AV HIDE de soudainement. la télécommande ? • Tous les signaux de couleur vidéo sont- ils entrés ? Le réglage du • La broche de verrouillage centrale mise déplacement en place pour l’expédition a-t-elle bien d’objectif est...
Spécifications I Système de mécanisme optique • Méthode de projection Appareil 3D-ILA, 1 objectif, méthode à obturateur optique 3 couleurs primaires 2,3 cm mesuré en diagonale (1365 pixels × 1024 pixels) × 3 • Appareil D-ILA (Nombre total de pixels : 4 193 280) •...
Page 132
Spécifications Signal de synchro horizontale/synchro de composante (H/C Signal de synchro verticale (V) * Certains périphériques raccordés peuvent ne pas correspondre à la synchro de composante ) ou au signal de G sur synchro. [RGB OUT (SORTIE RGB)] 1 ligne, D-sub 3 rangées 15 broches × 1 •...
Dimensions extérieures I Haut I Avant φ 50 I Signaux de format DTV * Les signaux de format DTV suivants peuvent être entrés. Formats DTV 480i Norme de signal ITU-R BT. 601-4 Trame / Ligne de balayage Echantillons effectifs × Lignes de 720 ×...
Spécifications Affectation des broches (Spécification pour les prises) I Prise Y/C I Prise RS-232C I Prise COMPUTER IN-1 (PC) / COMPUTER OUT Informations sur les articles vendus séparément • Objectif de projection GL-M4023SZ Objectif zoom 3 : 1~7 : 1 GL-M4015S Objectif à...
