  • Page 1 SiBE81 - 623A Photocatalytic Air Purifiers...

  • Page 2: Table Of Contents

    SiBE81-623A Air Purifiers MC707VM-S MC707VM-W 1.Introduction ......................2 2.Precautions for Use..................8 2.1 Required Conditions ................8 2.2 Applicable Room Area .................8 3.Specifications ....................9 3.1 Specifications ..................9 3.2 Dimensions ..................10 3.3 Wiring Diagram ..................11 3.4 Packaging Drawing ................12 4.Operation Manual...................13 4.1 Safety Precautions ................13 4.2 Names and Operation of each Part ...........14...

  • Page 3: Introduction

    Introduction SiBE81-623A 1. Introduction 06CJG-2 Daikin's original electro-discharge streamer technology is used for powerful decomposition and removal efficiency in the flash streamer air purifiers we are marketing globally. Totally differentiated from the competition, our technology and performance are available nowhere else.
  • Page 4 SiBE81-623A Introduction Daikin original Flash streamer Streamer space discharge unit Electrostatic Titanium Prefilter Streamer Bio-antibody Plasma dust Apatite (with deodorizing filter ionizer collection Photocatalytic catechin) catalyst filter Filter 06CJG-5 Decomposition is continuous When formaldehyde’s concentration of 0.2* ppm is continually emanated...
  • Page 5 Introduction SiBE81-623A Adjuvants are substances included in air pollutants such as exhaust gas that, when inhaled along with allergens, make one's allergy symptoms worsen. Allergy symptoms Allergy symptoms worsen. worsen. Adjuvant Allergens Adjuvant Diesel exhaust(DPE) Diesel exhaust(DPE) Diesel exhaust Mites particles Exhaust gas Pollen...
  • Page 6 SiBE81-623A Introduction Bio-Antibody Filter The Bio-Antibody filter works in the same way as the influenza vaccination. It removes viruses in about 1 minute. • The Bio-Antibody filter is usable for one year after opening. • Replacement for subsequent years will be available. •...
  • Page 7 A mere 31 dB even in M mode (standard mode) Designed to be quiet It's as quiet as a whisper. Top-ranking silent operation is achieved by Daikin's original shroud fan and a low-pressure-loss filter. Operation sound and air flow Operation sound (dB)
  • Page 8 SiBE81-623A Introduction Flat panel blends with interiors and is easy to clean. Quick-wipe panel Designed for easy maintenance, a single wipe with a wet cloth is all it takes to keep it clean. 06CJG-17 Photocatalytic Air Purifiers...

  • Page 9: Precautions For Use

    • This product is for indoor use only. Do not use in bathroom or outdoors as it is not water/condensation proof. • Do not modify this product. Applicable Room Area MC707VM-S MC707VM-W House less than 48m JEM1467 Photocatalytic Air Purifiers...

  • Page 10: Specifications

    SiBE81-623A Specifications 3. Specifications Specifications Model MC707VM-S MC707VM-W Type Photocatalytic air purifier φ Power supply 220-240 / 220-230V 50 / 60Hz Sparkling silver White Color + metallic ocean blue + Sparkling silver Rated power consumption 55 / 23 / 14 / 10 / 8...

  • Page 11: Dimensions

    Specifications SiBE81-623A Dimensions MC707VM-S, MC707VM-W • Required installation space Air outlet grille Signal Transmitter 500. or more 500. or more • Dimension of remote controller Air inlet grille ( ARC437A3 ) Handles Air inlet grille Manufacturer’s Label Power supply cord Approx.

  • Page 12: Wiring Diagram

    SiBE81-623A Specifications Wiring Diagram MC707VM-S, MC707VM-W IONIZATION PART /STREAMER PART Note : 1.S,CN SHOWS A CONNECTOR. NEGATIVE ION 2.BS SHOWS A SWITCH. GENERATION PART 3.SYMBOLS SHOWS AS FOLLOWS RED:RED BLK:BLACK WHT:WHITE YLW:YELLOW GRN:GREEN BLU:BLUE PNK:PINK BRN:BROWN ORG:ORANGE S401 DC340V AC IN...

  • Page 13: Packaging Drawing

    Specifications SiBE81-623A Packaging Drawing Packed Filter (Bio-Antibody) Filter (Pleated) Accessory kit Warranty C: 3P165820A Photocatalytic Air Purifiers...

  • Page 14: Operation Manual

    SiBE81-623A Operation Manual 4. Operation Manual Safety Precautions Safety Precautions • • Keep this manual where the operator can easily find them. Do not use outdoors or where exposed to direct sunlight. • Direct sunlight can weaken remote controller signal reception Read this manual attentively before starting up the unit.

  • Page 15: Names And Operation Of Each Part

    Operation Manual SiBE81-623A Names and Operation of each Part Names and Operation of each Part Main unit Front Shock-absorbing material (cardboard) Be sure to remove the shock-absorbing material before operating. (page 5.) Pleated filter Rear 1 Front panel 14 Air inlet 2 Main unit display 15 Remote controller storage slot (page 4.)

  • Page 16: Main Unit Display

    SiBE81-623A Operation Manual Main unit display 1 Air intake for dust sensor 4 Automatic operation indicator (yellow) Air is taken in from here and the dust sensor detects the dirty state Lit during automatic operation. of the air. 5 Airflow rate indicator (green) (page 7.) 2 Clean monitor (Dust) Lit by the set airflow rate setting.

  • Page 17: Preparation Before Operation

    Operation Manual SiBE81-623A Preparation before Operation Preparation Before Operation Remote controller setup Remote controller • Do not drop or place the remote controller in water. 1. Remote controller (Damage may occur.) preparations • Do not press the remote controller buttons with sharp objects. •...
  • Page 18 SiBE81-623A Operation Manual 3. Attach the pleated filter. Attaching the bio-antibody filter • Remove the pleated filter from the bag. 1. Remove the pre-filter. Pleated filter The side with the three • Remove by pulling out in front while holding the tabs on top of the holes goes up.

  • Page 19: How To Operate

    Operation Manual SiBE81-623A 4 When you want to quickly clean the air Preparation Before Press the “ ” [TURBO] button. • A high airflow rate will quickly remove any dirtiness in the air. Operation • This is convenient to use when cleaning. 5 When you want to remove pollen Installation of main unit Press the “...

  • Page 20: Care And Cleaning

    SiBE81-623A Operation Manual Care and Cleaning Care and Cleaning Cleaning chart Cleaning the air inlet for the dust/odor sensor For cleaning, remove each part in the number order. • Clean dusts clogged in For restoring each part, follow the opposite order. the air inlet for the dust/ CAUTION odor sensor.
  • Page 21 Operation Manual SiBE81-623A Care and Cleaning Cleaning the pre-filter NOTE It is recommended to clean the pre-filter every two weeks. • Securely close the panel. Failing to do so may cause activation of 1. Remove the front panel. the safety switch and out of unit operation. •...
  • Page 22 SiBE81-623A Operation Manual Replace a pleated filter 5) Insert the pleated filter into the left and right hooks. (Replace the pleated filter when the “replace indicator” on the main unit display turns on or blinks.) 6) Secure the pleated filter with the tape.
  • Page 23 Operation Manual SiBE81-623A Care and Cleaning 3. Remove the bio-antibody filter. Clean the plasma ionizer • Remove the bio-antibody filter from hooks (2 locations) at top of (If “cleaning sign” on the main unit display blinks) the plasma ionizer. Top hooks (2 locations) Blink CAUTION •...
  • Page 24 SiBE81-623A Operation Manual Contents 1) Ionizing frame 2) Ionized wire 3) Streamer discharger 4) Opposing pole plate Remove each part. (page 11.) (page 11.) (page 11.) Vacuum dusts on the surface with a cleaner. Vacuum Caution • Do not remove the screws on the ionizer or streamer discharger. Breakdown may result. Soak in water or warm water with liquid mild detergent.
  • Page 25 Operation Manual SiBE81-623A Care and Cleaning 3) Ionizing frame CAUTION • Clean off the resin part with a soft cloth. • Use a cotton bud to wipe off dirt of odd-shaped area where • When cleaning the unit, be careful not to cut your hands with the your finger does not reach.
  • Page 26 SiBE81-623A Operation Manual Assembling the plasma ionizer 1. Attach the opposing pole plates. 2. Attach the streamer discharger. 1) Securely insert the opposing pole plate into the hooks (2 locations 1) Insert bottom of the streamer discharger to the ionizer frame. in the middle) of the plasma ionizer.

  • Page 27: Sensitivity Settings Of The Dust Sensor

    ” H (High) lamps blinks for 5 seconds, Disposal requirements and then the lamp corresponding to the set sensitivity turns on. Your Daikin product is marked with this symbol. This 2. Change the settings using the “ ” [Operation switch/ means that electrical and electronic products shall not Stop] button of the main unit.

  • Page 28: Troubleshooting

    SiBE81-623A Operation Manual Troubleshooting Frequently asked questions Question Answer 1. The dust sensor does not This is due to dusts built up in the dust sensor. change from the red (green) Vacuum dusts from the air inlet with a crevice nozzle of a cleaner and then manually operate the unit for lamp.

  • Page 29: Optional Accessories

    Optional Accessories SiBE81-623A 5. Optional Accessories Dimensions 5.1.1 Pleated Photocatalytic Filter KAC972A4E Specifications Model KAC972A4E Item Non-woven fabric (electrostatic) Material (Antibacterial and antiviral agent impregnated) No. of packages Notes: 1. Replacement guideline: Every year (for about 7 years in total) 2.

  • Page 30: Troubleshooting

    SiBE81-623A Troubleshooting 6. Troubleshooting Basic Inspection (1) Is the connector for the PCB plugged in? Or is there any poor connection? (2) Is the wire harness broken? It is not malfunction Red lamp is blinking. Red lamp is on or blinking. Time for cleaning the Replace the pleated filter and plasma ionizer.

  • Page 31: Troubleshooting

    Be sure to turn off power switch before connect or disconnect connector, Caution or parts damage may be occurred. Models Covered Troubleshooting Diagnosis Remedy MC707VM-S MC707VM-W Is AC cord plugged in? Plug in AC cord. Or is breaker "ON"? Set breaker to “ON”.
  • Page 32 Be sure to turn off power switch before connect or disconnect connector, Caution or parts damage may be occurred. Models Covered Troubleshooting Diagnosis Remedy MC707VM-S MC707VM-W *Release child lock. Is battery correct? Replace battery. (2.5V or more?) Check if infrared signal is Method of Mal- sent from remote control.
  • Page 33 Be sure to turn off power switch before connect or disconnect connector, Caution or parts damage may be occurred. Models Covered Troubleshooting Diagnosis Remedy MC707VM-S MC707VM-W <Dust sensor unit LED> Put the plug in a socket while pressing the ON/OFF switch. Does LED light out for It is not...
  • Page 34 Be sure to turn off power switch before connect or disconnect connector, Caution or parts damage may be occurred. Models Covered Troubleshooting Diagnosis Remedy MC707VM-S MC707VM-W Four airflow rate indicators blink simultaneously. Retry to operate with NOTE: If connector ON/OFF switch.
  • Page 35 Be sure to turn off power switch before connect or disconnect connector, Caution or parts damage may be occurred. Models Covered Troubleshooting Diagnosis Remedy MC707VM-S MC707VM-W *Entering demo LED may be in demo mode. mode Keep holding down Exit demo mode.

  • Page 36: Removal Procedure

    SiBE81-623A Removal Procedure 7. Removal Procedure Removal of the Front Panel / Filters Warning Be sure to wait 10 minutes or more after turning off all power supplies before disassembling work. Procedure Points 1. Appearance Rear topside ON/OFF button Dust sensor Odor sensor * The upper part of the 2.
  • Page 37 Removal Procedure SiBE81-623A Procedure Points * The projection at the (2) Lift the panel to undo back side of the front the hooks. Now panel operates the detach the panel. safety switch. Be careful not to trans- form the projection. Projection (backside) Knobs...
  • Page 38 SiBE81-623A Removal Procedure Procedure Points Hooks * When assembling, catch 4. Removing the Bio- the bottom hooks. Antibody Filter (Unless the hooks are caught, the pre-filter, (1) Bend the fixing part which uses the same slightly to undo upper hooks, cannot be assembled.) two hooks.
  • Page 39 Removal Procedure SiBE81-623A Procedure Points 5. Removing the plasma ionizer unit Plasma ionizer unit (1) Hold the grips of the plasma ionizer unit. Pull the unit toward yourself to release its bottom. (2) Lift the unit to undo the hooks. Now detach the unit.
  • Page 40 SiBE81-623A Removal Procedure Procedure Points 6. Removing the pleated filter (1) Undo the three hooks. Pleated filter (2) The filter is made of Hooks fiber. Undo the hook with stretching the filter. (3) Zoomed up view of the upper hooks. Photocatalytic Air Purifiers...
  • Page 41 Removal Procedure SiBE81-623A Procedure Points (4) Undo the two bottom hooks and remove the filter. Hooks * When assembling, stick (5) A piece of Velcro is at the Velcro. the bottom. Velcro (6) Zoomed up view of the bottom hooks. Photocatalytic Air Purifiers...
  • Page 42 SiBE81-623A Removal Procedure Procedure Points (7) Take out the spare filter from the holder. Pleated filter holder (8) Take out the filter from the bag and attach it. Photocatalytic Air Purifiers...
  • Page 43 Removal Procedure SiBE81-623A Procedure Points 7. Removing the deodorizing catalytic filter (1) Undo the right and left hooks. (2) Undo the bottom hook and remove the deodrizing catalytic unit. Deodrizing catalytic unit Photocatalytic Air Purifiers...
  • Page 44 SiBE81-623A Removal Procedure Procedure Points (3) Undo the two hooks at the bottom and remove the deodorizing catalytic filter. (4) When assembling, Deodorizing catalytic filter catch the bottom hooks, slightly bend the filter itself and fit it into position. Photocatalytic Air Purifiers...

  • Page 45: Removal Of Streamer Electric Discharge Unit

    Removal Procedure SiBE81-623A Removal of Streamer Electric Discharge Unit Warning Be sure to wait 10 minutes or more after turning off all power supplies before disas- sembling work. Procedure Points Preparation (1) Catch the upper hole in advance with your finger and Streamer electric lift it up.
  • Page 46 SiBE81-623A Removal Procedure Procedure Points (4) Remove the screw. * When assembling, insert (5) Lift up and slide the the upper narrow sheet unit to remove it. metal. Photocatalytic Air Purifiers...

  • Page 47: Removal Of Lonizing Wire

    Removal Procedure SiBE81-623A Removal of lonizing Wire Warning Be sure to wait 10 minutes or more after turning off all power supplies before disassembling work. Procedure Points Part A 1. Removing the Counter grid counter grid Hook Hook (1) Undo the outer hook and lift the counter grid to detach.
  • Page 48 SiBE81-623A Removal Procedure Procedure Points Hook 2. Removing the CAUTION ionizing wires Be careful not to get your hands cut by the ionizing wires. (1) Pinch and detach the ionizing wires with * Once removed, the ion- izing wires cannot be pincers.

  • Page 49: Removal Of Fan Motor

    Removal Procedure SiBE81-623A Removal of Fan Motor Warning Be sure to wait 10 minutes or more after turning off all power supplies before disassembling work. Procedure Points 1. Removing the back cover * Point (1) Remove the 2 screws Note that the screws are from the front top.
  • Page 50 SiBE81-623A Removal Procedure Procedure Points 2. Removing the fan motor (1) The figure shows the wiring routes. * Once removed, the seal (2) Peel the seal material cannot be material. reused. Seal material (3) Disconnect the fan motor connectors. Photocatalytic Air Purifiers...
  • Page 51 Removal Procedure SiBE81-623A Procedure Points (4) Remove the nut and pull out the fan. * When assembling, align mark on the fan with the D cut on the motor shaft. D cut (5) Lift and detach the harness retainer. (6) When assembling, Part A put part A first in the groove, and then...
  • Page 52 SiBE81-623A Removal Procedure Procedure Points * The motor and the har- (7) Remove the 3 screws Lock plate ness are integrated from the lock plate together. and take out the fan * Make sure no washers are left behind the fan. motor.

  • Page 53: Removal Of Electrical Box / Pcb

    Removal Procedure SiBE81-623A Removal of Electrical Box / PCB Warning Be sure to wait 10 minutes or more after turning off all power supplies before disassembling work. Procedure Points * Remove the back cover. * Disconnect the fan motor connector. 1.
  • Page 54 SiBE81-623A Removal Procedure Procedure Points * When assembling, fit the (2) Pull out the electrical box in the groove. box to detach. 3. Removing the PCB (1) Undo the 2 hooks at the back and take out the flame-proof plate. * When fitting the flame- proof plate in position, Flame-proof plate...
  • Page 55 Removal Procedure SiBE81-623A Procedure Points (2) Disconnect the each S129 connector. (3) Disconnect the S127 connector S127 from the connector S128 of display PCB (A3P). Photocatalytic Air Purifiers...
  • Page 56 SiBE81-623A Removal Procedure Procedure Points * When connecting, con- (4) Disconnect the PCB nect firmly not to be connector. unfastened. (5) Undo the 2 hooks and remove the PCB. Photocatalytic Air Purifiers...
  • Page 57 Removal Procedure SiBE81-623A Procedure Points * Lead-free solder PbF is (6) The figure at right used. shows the power supply and control PCB. S129 S127 Fuse AC250V 3.15A (7) Undo the 4 hooks to remove the high voltage PCB (HVU). Photocatalytic Air Purifiers...
  • Page 58 SiBE81-623A Removal Procedure Procedure Points (8) Remove the tape. (9) Undo the 3 hooks from the back to remove the display PCB. Hooks Photocatalytic Air Purifiers...
  • Page 59 Removal Procedure SiBE81-623A Procedure Points (10) Undo the 2 hooks (1 each at right and left) from the top. (11) Undo the 3 hooks to remove the PCB. ON/OFF switch cover ON/OFF switch Filter reset switch Receiver Odor sensor Photocatalytic Air Purifiers...
  • Page 60 SiBE81-623A Removal Procedure Procedure Points (12) Undo the hook from the dust sensor and push out the sensor from front. Dust sensor (13) Pinch the bulge of the safety door switch from inside to push out the switch. Photocatalytic Air Purifiers...
  • Page 61 Use only those parts and accessories supplied or specified by Daikin. Read the User's Manual carefully before using this product. The User's Manual provides important safety instructions and warnings. Be sure to follow these instructions and warnings. Specifications, designs and other content appearing in this brochure are current as of August 2006 but subject to change without notice.
