Vehicle Specifications

MODEL OVERALL
LENGTH
Excel 590 5.88m
Excel 600 5.99m
Excel 640 6.40m
Excel 670 6.72m
MODEL TYRE SIZE
COLD (BARS)
EXCEL 590 EK 215/70R15CP
EXCEL 600B 215/70R15CP
EXCEL 640G 215/70R15CP
EXCEL 670B 215/70R15CP
Please Note: The Mass in Running Order includes a 75kg allowance for the driver and 90% full fuel tank, gas bottles and water tank. Please take care to ensure that you have allowed for the
masses of all items you intend to carry in the motorcaravan. e.g: Passengers, optional equipment and personal effects such as clothing, food, pets, bicycles etc.
WARNING: Under no circumstances should the maximum gross weight of the vehicle be exceeded.
MAX.GARAGE DIMENSIONS: Length: 2170mm, Width: 1265mm, Height: 1185mm.
GARAGE DOOR APERTURE: Width: 745mm, Height: 1094mm
MAX. ALLOWABLE WEIGHTS IN GARAGE: Excel 640: 150kg
HEATING GRADE
All Auto-Trail vehicles have a minimum heating classification of grade 2. This means that your vehicle can maintain an average temperature of at least 20 degrees centigrade when the
outside temperature is zero.
GAS INPUT OF APPLIANCES Fire = 3.9kw. Water Heater = 1.7kw. Cooker (3 gas burners) = 8.3kw. Fridge = 0.19kw.
54
T A K E Y O U R S O N
OVERALL OVERALL WHEELBASE
WIDTH HEIGHT
(Mirrors Folded)
2.23m 2.79m 3000
2.23m 2.79m 3450
2.23m 2.79m 3450
2.23m 2.79m 3800
TYRE PRESSURES – COLD (BARS)
FRONT
AXLE
5.0
5.0
5.0
5.0
A N A D V E N T U R E
MAX. MASS IN MAX.
GROSS RUNNING TOWABLE
WEIGHT ORDER WEIGHT
3300kg 2760kg 1240kg
3300kg 2790kg 1240kg
3300kg 2880kg 1240kg
3300kg 2925kg 1240kg
REAR
AXLE
5.5
5.5
5.5
5.5
GROSS PASSENGER
TRAIN SEATS
WEIGHT
(Std. Vehicles)
4540kg 1
4540kg 1
4540kg 1
4540kg 1
