VHF FM Transceiver
VX-160V/-180V
Service Manual
©2002 VERTEX STANDARD CO., LTD. Printed in Japan.
Introduction
This manual provides technical information necessary for servicing the VX-160V and VX-180V FM Transceiver.
Servicing this equipment requires expertise in handling surface-mount chip components. Attempts by non-qualified
persons to service this equipment may result in permanent damage not covered by the warranty, and may be illegal in
some countries.
Two PCB layout diagrams are provided for each double-sided circuit board in the transceiver. Each side of is referred
to by the type of the majority of components installed on that side ("leaded" or "chip-only"). In most cases one side has
only chip components, and the other has either a mixture of both chip and leaded components (trimmers, coils, electrolyt-
ic capacitors, ICs, etc.), or leaded components only.
While we believe the technical information in this manual to be correct, VERTEX STANDARD assumes no liability
for damage that may occur as a result of typographical or other errors that may be present. Your cooperation in pointing
out any inconsistencies in the technical information would be appreciated.
Operating Manual Reprint ........................... 2
Cloning ............................................................. 6
Specifications ................................................... 7
Exploded View & Miscellaneous Parts ...... 8
VX-160V
Contents
VERTEX STANDARD CO., LTD.
4-8-8 Nakameguro, Meguro-Ku, Tokyo 153-8644, Japan
VERTEX STANDARD
US Headquarters
10900 Walker Street, Cypress, CA 90630, U.S.A.
International Division
8350 N.W. 52nd Terrace, Suite 201, Miami, FL 33166, U.S.A.
YAESU EUROPE B.V.
P.O. Box 75525, 1118 ZN Schiphol, The Netherlands
YAESU UK LTD.
Unit 12, Sun Valley Business Park, Winnall Close
Winchester, Hampshire, SO23 0LB, U.K.
VERTEX STANDARD HK LTD.
Unit 5, 20/F., Seaview Centre, 139-141 Hoi Bun Road,
Kwun Tong, Kowloon, Hong Kong
VX-180V
Block Diagram .................................................9
Circuit Description ................................ 10
Alignment ................................................ 12
Board Unit (Schematics, Layouts & Parts)
MAIN Unit ............................................................... 17
1
Advertisement
Table of Contents
Related Manuals for Vertex Standard VX-160V
Summary of Contents for Vertex Standard VX-160V
-
Page 1: Table Of Contents
ICs, etc.), or leaded components only. While we believe the technical information in this manual to be correct, VERTEX STANDARD assumes no liability for damage that may occur as a result of typographical or other errors that may be present. Your cooperation in pointing out any inconsistencies in the technical information would be appreciated. -
Page 2: Operating Manual Reprint
Operating Manual Reprint Controls & Connectors Before You Begin Battery Pack Installation and Removal LED Indicator r To install the battery, hold the transceiver with your Glows Green Monitor on Blinking Green Busy Channel (or SQL off) left hand, so your palm is over the speaker and your Glows Red Transmitting thumb is on the top of the belt clip. -
Page 3: Key Functions
MONITOR keys. These “Soft” keys func- Monitor tions can be customized (set to other functions), via pro- Low Power Lock* gramming by your VERTEX STANDARD dealer, to meet Lamp* your communications/network requirements. Some fea- Channel Up* tures may require the purchase and installation of optional Channel Down* internal accessories. -
Page 4: Description Of Operating Functions
Operating Manual Reprint Description of Operating Functions Monitor Follow-Me Scan Press the assigned Soft key momentarily to override (dis- “Follow-Me” Scan feature checks a User-assigned Prior- able) the Tone squelch. ity Channel regularly as you scan the other channels. Thus, Background noise or incoming signals will now be heard if only Channels 1, 3, and 5 (of the 8 available channels) whether or not a matching tone is present on the signal). - Page 5 Operating Manual Reprint Description of Operating Functions Call/Reset TX Save Off Press the assigned Soft key to disable the Transmit Bat- When the 2-tone selective calling unit is installed, press the assigned Soft key to silence the receiver and reset for tery Saver, if you are operating in a location where high another call, when a communication is finished.
-
Page 6: Cloning
Cloning The VX-160/-180 includes a convenient “Cloning” feature, which allows the programming data from one transceiver to be transferred to another VX-160/-180. Here is the procedure for Cloning one radio's data to another. 6. Press the PTT switch on the source transceiver; “SEND- 1. -
Page 7: Specifications
Specifications GENERAL Specifications Frequency Range (MHz): 134 - 160 (A) 148 - 174 (C) Number of Channels: 16 channels Channel Spacing: 12.5 / 25 kHz (15 / 30 kHz) PLL Steps 2.5 / 6.25 kHz Power Supply voltage: 7.5 VDC ± 20% Operating Temperature Range: –22°F to +140°F (–30°C to +60°C) Frequency Stability: ±2.5 ppm... -
Page 8: Exploded View & Miscellaneous Parts
Exploded View & Miscellaneous Parts RA029600A (Lot. 17~) RA0296000 (Lot. 1~) REF. VXSTD P/N Description Qty. FRONT CASE ASSY (VX-160) À U44104002 TAPTITE SCREW M2X4NI RA0173500 U44104002 Â Á TAPTITE SCREW M2X4NI (VX-180U) Â Â U20206007 BINDING HEAD SCREW M2.6X6B Ã... -
Page 9: Block Diagram
Block Diagram... -
Page 10: Circuit Description
Circuit Description Receive Signal Path Squelch Control Incoming RF from the antenna jack is delivered to the The squelch circuitry consists of a noise amplifier and RF Unit and passes through a low-pass filter consisting band-pass filter within Q1037, and noise detector D1018 of coils L1001, L1002, and L1031, capacitors C1004, (1SS355 TE-17). -
Page 11: Transmit Inhibit
Circuit Description Automatic Transmit Power Control The data latch section of Q1005 also receives serial Current from the final amplifier is sampled by R1108, dividing data from the microprocessor, Q1014, which R1115, and R1125, and is rectified by Q1057 (IMZ2A causes the pre-divided VCO signal to be further divided T108). -
Page 12: Alignment
Also, Vertex Standard must re- 20° and 30°C (68°~ 86°F). When the transceiver is brought serve the right to change circuits and alignment proce-... - Page 13 Alignment The alignment tool outline Set up the test equipment as shown below for trans- ceiver alignment, and apply 7.5V DC power to the trans- Installation of the Alignment tool ceiver. The “alignment mode” is a software-based protocol, accessed by an “Alignment Mode” command from the computer while switching the transceiver on.It is oper- 50-ohm Dummy Load...
- Page 14 Alignment PLL VCV (Varactor Control Voltage) MIC Sensitivity r Connect the DC voltmeter between TP3 on the Main r Set the transceiver to CH 2 (band center). r Inject a 1 kHz tone at –37 dBm to the MIC jack. Unit and ground.
- Page 15 Alignment MAX Deviation RF Frequency r Set the transceiver to CH 2 (band center). r Set the transceiver to CH 2 (band center). r Inject a 1 kHz tone at –17 dBm to the MIC jack. r Open the “Adjust” window on CE44, then select the “RF Frequency”...
- Page 16 Alignment Note:...
-
Page 17: Main Unit
Circuit Diagram MAIN Unit SQL Open:2.78V SQL Close:2.78V SQL Open:0.73V SQL Close:0.74V SQL Open:0.0V SQL Open:1.97V SQL Close:0.0V SQL Close:1.97V SQL Open:0.73V SQL Open:0.0V SQL Close:0.73V SQL Close:0.0V <2.07V> {0.74V} <5.04V> {5.04V} 3.91V 5.08V 2.76V (3.91V) Wide:0.0V (0.0V) <2.04V> Narrow:0.0V (2.80V) 0.0V {0.72V}... - Page 18 MAIN Unit Parts Layout Side A LC75834W NJM2070M FMW1 (W1) CPH6102 (AB) 2SC4154E (LE) RT1N441U (N3) MC2850 (A7) 12-22SURSYGC/S530-A2/TR8 (Q1054) (Q1039) (Q1032) (Q1051) (Q1025, 1038 (Q1042, 1053) (D1030) (D1026) 1050, 1061) NJM2902V IMZ2 (Z2) RT1P441U (P3) 2SA1586Y (SY) PDTC114TE (24) FA1101F (VX-180) NJM12903R (Q1017, 1030)
- Page 19 MAIN Unit Side B M37516E6HP TA31136FN M62364FP 2SK2596 (BX) RT1N441U (N3) FMW1 (W1) DTB123EK (F12) 2SC4154E (LE) S-80735SN (DZ) DAN235E (M) (Q1014) (Q1037) (Q1052) (Q1016) (Q1034, 1045 (Q1027, 1028) (Q1036) (Q1008, 1055) (Q1041) (D1014) 1063) 2SC5005 (73) (Q1007) 2SC5006 (24) (Q1012) 2SC4215Y (QY) (Q1033)
- Page 20 Circuit Diagram MAIN Unit (Lot. 3~)
- Page 21 MC2850 (A7) 12-22SURSYGC/S530-A2/TR8 (Q1054) (Q1039) (Q1032) (Q1051) (Q1025, 1038 (Q1042, 1053) (D1030) (D1026) 1050, 1061) NJM2902V IMZ2 (Z2) RT1P441U (P3) 2SA1586Y (SY) PDTC114TE (24) FA1101F (VX-180) NJM12903R (Q1017, 1030) (Q1057) (Q1060) (Q1011, 1043) (Q1058) (D1035, 1038) (Q1049) VX-160V/-180V Service Manual...
- Page 22 (Q1012) 2SC4215Y (QY) (Q1033) 2SC5227 (LN) (Q1015) MB15A02PFV1 BR93LC66FV 2SK2974 TK11250BMCL SGM2016AM (MA) RT1P441U (P3) 2SA1586Y (SY) CPH6102 (AB) MC2850 (A7) (Q1005) (Q1010) (Q1024) (Q1040) (Q1026) (Q1013, 1020 (Q1056, 1062) (Q1029, 1031) (D1015, 1033 1059) 1034, 1036) VX-160V/-180V Service Manual...
- Page 23 Circuit Diagram MAIN Unit (Lot. 18~)
- Page 24 MC2850 (A7) 12-22SURSYGC/S530-A2/TR8 (Q1054) (Q1039) (Q1032) (Q1051) (Q1025, 1038 (Q1042, 1053) (D1030) (D1026) 1050, 1061) NJM2902V IMZ2 (Z2) RT1P441U (P3) 2SA1586Y (SY) PDTC114TE (24) FA1101F (VX-180) NJM12903R (Q1017, 1030) (Q1057) (Q1060) (Q1011, 1043) (Q1058) (D1035, 1038) (Q1049) VX-160V/-180V Service Manual...
- Page 25 (Q1012) 2SC4215Y (QY) (Q1033) 2SC5227 (LN) (Q1015) MB15A02PFV1 BR93LC66FV 2SK2974 TK11250BMCL SGM2016AM (MA) RT1P441U (P3) 2SA1586Y (SY) CPH6102 (AB) MC2850 (A7) (Q1005) (Q1010) (Q1024) (Q1040) (Q1026) (Q1013, 1020 (Q1056, 1062) (Q1029, 1031) (D1015, 1033 1059) 1034, 1036) VX-160V/-180V Service Manual...
-
Page 26: Parts List
MAIN Unit Parts List REF. DESCRIPTION VALUE TOL. MFR’S DESIG VXSTD P/N VERS. LOT. SIDE LAY ADR *** MAIN UNIT *** PCB with Components CB1390001 VX-160 PCB with Components CB1390002 VX-180 Printed Circuit Board FR006370E Printed Circuit Board FR006370G Printed Circuit Board FR006370H C 1001 CHIP CAP. - Page 27 MAIN Unit REF. DESCRIPTION VALUE TOL. MFR’S DESIG VXSTD P/N VERS. LOT. SIDE LAY ADR C 1065 CHIP CAP. 15pF GRM39CH150J50PT K22174215 C 1066 CHIP CAP. 0.0033uF GRM39B332K50PT K22174831 C 1067 CHIP CAP. 0.1uF GRM39B104K16PT K22124805 C 1068 CHIP CAP. 27pF GRM39CH270J50PT K22174221...
- Page 28 MAIN Unit REF. DESCRIPTION VALUE TOL. MFR’S DESIG VXSTD P/N VERS. LOT. SIDE LAY ADR C 1137 CHIP CAP. 0.01uF GRM39B103K25PT K22144803 C 1138 CHIP TA.CAP. 10uF 6.3V TEMSVA0J106M-8R K78080027 C 1139 CHIP CAP. 0.01uF GRM39B103K25PT K22144803 C 1140 CHIP CAP. 2.2uF GRM42-6B225K10PT K22101801...
- Page 29 MAIN Unit REF. DESCRIPTION VALUE TOL. MFR’S DESIG VXSTD P/N VERS. LOT. SIDE LAY ADR C 1226 CHIP CAP. 0.1uF GRM39B104K16PT K22124805 C 1227 CHIP CAP. 0.001uF GRM39B102K50PT K22174821 C 1228 CHIP TA.CAP. 10uF 6.3V TEMSVA0J106M-8R K78080027 C 1229 CHIP CAP. 0.1uF GRM39B104K16PT K22124805...
- Page 30 MAIN Unit REF. DESCRIPTION VALUE TOL. MFR’S DESIG VXSTD P/N VERS. LOT. SIDE LAY ADR L 1013 M.RFC 0.047uH HK1608 47NJ-T L1690524 L 1014 M.RFC 0.1uH HK1608 R10J-T L1690528 L 1015 M.RFC 0.056uH HK1608 56NJ-T L1690525 L 1016 M.RFC 0.047uH HK1608 47NJ-T L1690524 L 1017...
- Page 31 MAIN Unit REF. DESCRIPTION VALUE TOL. MFR’S DESIG VXSTD P/N VERS. LOT. SIDE LAY ADR R 1001 CHIP RES. 1/16W 5% RMC1/16 000JATP J24185000 R 1002 CHIP RES. 1/16W 5% RMC1/16 103JATP J24185103 R 1003 CHIP RES. 1/16W 5% RMC1/16 563JATP J24185563 R 1004 CHIP RES.
- Page 32 MAIN Unit REF. DESCRIPTION VALUE TOL. MFR’S DESIG VXSTD P/N VERS. LOT. SIDE LAY ADR R 1074 CHIP RES. 1/16W 5% RMC1/16 101JATP J24185101 R 1075 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 R 1076 CHIP RES. 220k 1/16W 5% RMC1/16 224JATP J24185224 R 1077 CHIP RES.
- Page 33 MAIN Unit REF. DESCRIPTION VALUE TOL. MFR’S DESIG VXSTD P/N VERS. LOT. SIDE LAY ADR R 1151 CHIP RES. 2.7k 1/16W 5% RMC1/16 272JATP J24185272 R 1152 CHIP RES. 1/16W 5% RMC1/16 123JATP J24185123 R 1153 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 R 1154 CHIP RES.
- Page 34 MAIN Unit REF. DESCRIPTION VALUE TOL. MFR’S DESIG VXSTD P/N VERS. LOT. SIDE LAY ADR R 1224 CHIP RES. 1/16W 5% RMC1/16 103JATP J24185103 R 1225 CHIP RES. 1/16W 5% RMC1/16 103JATP J24185103 R 1226 CHIP RES. 1/16W 5% RMC1/16 223JATP J24185223 R 1227 CHIP RES.
- Page 35 MAIN Unit Note:...
- Page 36 Copyright 2002 VERTEX STANDARD CO., LTD. All rights reserved No portion of this manual may be reproduced without the permission of VERTEX STANDARD CO., LTD. Printed in Japan.
