CYLINDER ADJUSTER & BEARING HOUSINGS
ITEM RANSOMES
PART NO
1 LMSE057
* A199302
1A MBE2229C
2 MBC9180C
2A MBG4936
3 A299316
4 A219324
5 MBC8191B
5A* MBF1785
6 A163401
7 A159991
8 MBE0359
9 A292122
10 450380
11 450392
12 MBE1185
12* MBE2231
13 A230021
13* A230013
14 A205902
14* A209044
15 A229987
15* A230019
DESCRIPTION
GB
BEARING HOUSING
• HELICOIL INSERT
BEARING HOUSING
BEARING HOUSING
BEARING HOUSING
LUBRICATOR
BUSH
PIVOT PIN
PIVOT PIN
WOODRUFF KEY
WASHER
COLLAR
DISC SPRING
STIFFNUT M12
WASHER 12MM
RING CARRIER
RING CARRIER
SEAL RING
SEAL RING
BEARING
BEARING
SEAL
SEAL
* NOT ILLUSTRATED
QTY REMARKS
1 (DRIVE SIDE) 220 M28 /
PARKWAY 225 /
MOTOR 350D MK5
4
1 (DRIVE SIDE) PARKWAY 2250 /
COMMANDER 3500DX / TG 3400
& 4650
1 (NON DRIVE SIDE)
1 COMMANDER 3520
2
4
4
2 COMMANDER 3520 (NON
STANDARD DRIVE SIDE -
CENTRE UNIT)
4
6
2
6
4
4
2 220 M28 / MOTOR 350D MK5 /
PARKWAY 225
2 COMMANDER 3500DX / 3510 /3520
TG 3400 & 4650 / PARKWAY 2250
PARKWAY 2250 + / HIGHWAY 2130
2 220 M28 / PARKWAY 225 /
MOTOR 350D MK5
2 COMMANDER 3500DX / 3510 /3520
TG 3400 & 4650 / PARKWAY 2250
PARKWAY 2250 + / HIGHWAY 2130
2 220 M28 / PARKWAY 225 /
MOTOR 350D MK5
2 COMMANDER 3500DX / 3510 /3520
TG 3400 & 4650 / PARKWAY 2250
PARKWAY 2250 + / HIGHWAY 2130
1 220 M28 / PARKWAY 225 /
MOTOR 350D MK5
1 COMMANDER 3500DX / 3510 /3520
TG 3400 & 4650 / PARKWAY 2250
PARKWAY 2250 + / HIGHWAY 2130
LIST OF PARTS
Parts-13
