2003 Explorer/Mountaineer Workshop Manual
SECTION 501-00: Body System — Exterior
DIAGNOSIS AND TESTING
Glass, Frames and Mechanisms
Refer to Wiring Diagrams Cell
56
for schematic and connector information.
Refer to Wiring Diagrams Cell
100
for schematic and connector information.
Special Tool(s)
73III Automotive Meter
105-R0057 or equivalent
Inspection and Verification
1. Verify the customer concern by operating the power window/defrost system.
2. Visually inspect for obvious signs of mechanical and electrical damage. Refer to the following chart:
Visual Inspection Chart
Mechanical
Window regulator assembly
Window motor
Window glass
Window control switch
3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
4. If the concern is not visually evident, determine the symptom. GO to
Symptom Chart
Symptom Chart — Glass, Frames and Mechanisms
Condition
All power windows are inoperative
Single power window is inoperative — driver front window
Single power window is inoperative — passenger front
window
Single power window is inoperative — driver rear window
Single power window is inoperative — passenger rear window
The one touch down feature is inoperative — driver window
still operates in proportional mode
The back window will not defrost
The back window defroster will not shut off automatically
http://www.fordtechservice.dealerconnection.com/pubs/content/~WS3N/~MUS~LEN/19/S...
Printable View (356 KB)
Electrical
Fuse(s)
Circuitry
Window control switch
Relay(s)
Symptom Chart - Glass, Frames And
Possible Sources
Fuse(s).
Circuitry.
Instrument cluster module
(ICM).
Accessory delay relay.
Driver window control
switch.
Circuitry.
Driver window control
switch.
Driver window motor.
Circuitry.
Driver window control
switch.
Passenger window
control switch.
Passenger window motor.
Circuitry.
Driver window control
switch.
Driver rear window
control switch.
Driver rear window motor.
Circuitry.
Driver window control
switch.
Passenger rear window
control switch.
Passenger rear window
motor.
Driver window control
switch.
ICM.
Circuitry.
Heated back window
relay.
Heated back window grid.
Heated back window
relay.
Circuitry.
ICM.
Heated back window grid.
2003 Explorer/Mountaineer Workshop Manual
Procedure revision date: 08/04/2004
Mechanisms.
Action
GO to Pinpoint Test
H.
GO to Pinpoint Test
I.
GO to Pinpoint Test
J.
GO to Pinpoint Test
K.
GO to Pinpoint Test
L.
INSTALL a new driver window control switch. REFER to
Window Control Switch
in this section.
GO to Pinpoint Test
M.
GO to Pinpoint Test
N.
17
1/17/2011
Advertisement
Related Manuals for Ford Explorer 2003
Summary of Contents for Ford Explorer 2003
- Page 1 2003 Explorer/Mountaineer Workshop Manual SECTION 501-00: Body System — Exterior 2003 Explorer/Mountaineer Workshop Manual DIAGNOSIS AND TESTING Procedure revision date: 08/04/2004 Glass, Frames and Mechanisms Printable View (356 KB) Refer to Wiring Diagrams Cell for schematic and connector information. Refer to Wiring Diagrams Cell for schematic and connector information.
- Page 2 2003 Explorer/Mountaineer Workshop Manual The defrost system will not shut off automatically — can be ICM. INSTALL a new ICM. REFER to Section 413-00. turned ON and OFF with the defrost switch Connector Circuit Reference Instrument Cluster Module (ICM) C220a Pin Number(s) Circuit Designation/Description Normal Condition/Measurement...
- Page 3 2003 Explorer/Mountaineer Workshop Manual Pin Number(s) Circuit Designation/Description Normal Condition/Measurement CKT 1205 (BK) driver window control switch ground Less than 5 ohms to chassis ground. CKT 314 (TN/LB) passenger front window down Greater than 10,000 ohms to chassis ground and 0 volts. CKT 313 (WH/YE) passenger front window up Greater than 10,000 ohms to chassis ground and 0 volts.
- Page 4 2003 Explorer/Mountaineer Workshop Manual Pin Number Circuit Designation/Description Normal Condition/Measurement CKT 333 (YE/RD) passenger front window Less than 5 ohms to chassis ground. Greater than 10 volts when passenger front window control switch is depressed in the UP position with the key ON. CKT 334 (RD/YE) passenger front window Less than 5 ohms to chassis ground.
- Page 5 2003 Explorer/Mountaineer Workshop Manual Normal Operation Under normal operation the instrument cluster module grounds the accessory delay relay through circuit 1004 (LB/RD). Power is sent to the driver window control switch through circuit 400 (LB/BK) from the accessory delay relay. The driver window control switch is grounded through circuit 1205 (BK). Possible Causes Fuses.
- Page 6 2003 Explorer/Mountaineer Workshop Manual REPAIR the circuit. TEST the system for normal operation. Is the resistance less than 5 ohms? H6 CHECK CIRCUIT 1004 (LB/RD) FOR AN OPEN Disconnect: Instrument Cluster Module (ICM) C220a. Measure the resistance between accessory delay relay socket pin 85, and ICM C220a-5, circuit 1004 INSTALL a new ICM.
- Page 7 2003 Explorer/Mountaineer Workshop Manual Does the driver power window go up? I4 CHECK CIRCUIT 991 (TN/LB) FOR OPEN Disconnect: Driver Power Window Motor C524. Measure the resistance between driver power window motor C524-2, circuit 991 (TN/LB), and driver window GO to I4. control switch C504a-7, circuit 991 (TN/LB) harness side.
- Page 8 2003 Explorer/Mountaineer Workshop Manual Is the voltage greater than 10 volts? J2 CHECK THE GROUNDS TO THE PASSENGER FRONT WINDOW CONTROL SWITCH — CIRCUITS 313 (WH/YE) AND 314 (TN/LB) Ignition OFF. GO to J4. Measure the resistance between passenger front window control switch C604-6, circuit 313 (WH/YE) and C604-1, circuit 314 (TN/LB) harness side and ground.
- Page 9 2003 Explorer/Mountaineer Workshop Manual (TN/LB) and C604-2, circuit 334 (RD/YE) and a second jumper wire between C604-3, circuit 170 (RD/LB) and C604-5, circuit 333 (YE/RD) harness side. The window should operate in the up direction. Does the window operate correctly? J5 CHECK CIRCUITS 333 (YE/RD) AND 334 (RD/YE) FOR AN OPEN Ignition OFF.
- Page 10 2003 Explorer/Mountaineer Workshop Manual Is the voltage greater than 10 volts? K2 CHECK THE GROUNDS TO THE DRIVER REAR WINDOW CONTROL SWITCH — CIRCUITS 316 (YE/LB) AND 317 (GY/OG) Ignition OFF. GO to K4. Measure the resistance between driver rear window control switch C701-6, circuit 317 (GY/OG) and C701-1, circuit 316 (YE/LB) harness side and ground.
- Page 11 2003 Explorer/Mountaineer Workshop Manual Connect a jumper wire between driver rear window control switch C701-1, circuit 316 (YE/LB) and C701-2, circuit 885 (YE/LB) and a second jumper wire between C701-3, circuit 170 (RD/LB) and C701-5, circuit 884 (YE/BK) harness side. The window should operate in the upward direction.
- Page 12 2003 Explorer/Mountaineer Workshop Manual Test Step Result / Action to Take L1 CHECK THE VOLTAGE TO THE PASSENGER REAR WINDOW CONTROL SWITCH — CIRCUIT 170 (RD/LB) Disconnect: Passenger Rear Window Control Switch C801. GO to L2. Ignition ON. NOTE: Set the driver window control switch to the UNLOCK position. Measure the voltage between the passenger rear window control switch C801-3, circuit 170 (RD/LB) harness side and ground.
- Page 13 2003 Explorer/Mountaineer Workshop Manual Connect a jumper wire between passenger rear window control switch C801-1, circuit 320 (RD/BK) and C801-2, circuit 882 (BN/YE) and a second jumper wire between C801-3, circuit 170 (RD/LB) and C801-5, circuit 881 (BN) harness side. The window should operate in the up direction.
- Page 14 2003 Explorer/Mountaineer Workshop Manual Disconnect: Heated Backlight Relay. GO to M2. Ignition ON. Measure the voltage between rear window defrost relay socket pin 85 and pin 30 harness side and ground. REPAIR the circuit(s). TEST the system for normal operation. Is the voltage greater than 10 volts? M2 CHECK THE ICM OUTPUT Turn ON the rear window defrost.
- Page 15 2003 Explorer/Mountaineer Workshop Manual Disconnect: ICM C220a. If equipped with manual A/C, GO to M8. Disconnect: Function Selector Switch C294b (Manual A/C Only) or DATC Module C228a. If equipped with manual A/C, measure the resistance between function selector switch C294b-12, circuit 688 If equipped with DATC, INSTALL a new DATC climate (GY/LB) harness side and ICM C220a-15, circuit 688 (GY/LB) harness side.
- Page 16 2003 Explorer/Mountaineer Workshop Manual PINPOINT TEST N: THE DEFROST SYSTEM WILL NOT SHUT OFF AUTOMATICALLY — ON AT ALL TIMES Test Step Result / Action to Take N1 CHECK CIRCUIT 186 (BN/LB) FOR A SHORT TO VOLTAGE Disconnect: Heated Backlight Relay. REPAIR the circuit.
