Page 1 Table of Contents MULTIMEDIA PROJECTOR Safety Instructions Before Use Projecting an Image User’s Manual Useful Functions Available During a Presentation Setting Functions from Menus Installation Connecting to a Network Maintenance Networked Multi-Projection Overview Operation in Each Mode Functions in All Modes Other Information Index...
Page 2: How To Use This Manual
How to Use This Manual Thank you for purchasing a Canon projector. The WUX450 / WX520 Multimedia Projector (hereinafter referred to as “the projector”) is a high-performance projector that is capable of projecting a high-resolution computer screen and high-quality digital image on a large screen.
Page 3: Copyright Notice
How to Use This Manual Copyright Notice Please note that enlarging or reducing the size of an image for commercial purposes or public presentation may infringe on the legally protected copyright or the copyright holder of the original material. About Trademarks •...
Page 4: Projector Highlights
Compact 337 x 134 x 370 mm / 13.3 x 5.3 x 14.6 in (W x H x D) body can be installed with minimal space requirements. (P292) High-Resolution LCOS Projection Projection at 1920x1200 (WUXGA) for the WUX450 or 1440x900 (WXGA+) for the WX520, thanks to high-resolution reflective liquid crystal (LCOS) panels. Split-Screen Display Side-by-side projection of two input images from devices connected to the projector.
Page 5: Quick Reference Guide
Quick Reference Guide This Quick Reference Guide will help you find functions that make full use of the projector and are useful for producing an attractive presentation, etc. Changing the Remote Control Connecting the Projector Channel (P112) Connecting to the Computer (P134 - P136) Connecting to AV Equipment...
Page 6: Table Of Contents
Table of Contents How to Use This Manual................. 2 Projector Highlights................4 Quick Reference Guide ................5 Safety Instructions................16 Safety Precautions....................17 CAUTION ON HANGING FROM THE CEILING ............17 ■ READ AND KEEP THIS OWNER’S MANUAL FOR LATER USE......18 AC Power Cord Requirement...................20 Federal Communication Commission Notice............21 Canadian Radio Interference Regulations..............21...
Page 7 Table of Contents Operation..............47 Projecting an Image.................49 Step 1 Turn the Projector On ............... 50 Step 2 Select an Input Signal............... 51 Types of Input Signals....................51 Selecting an Input Signal ..................52 Step 3 Adjust the Image ............... 53 Setting the Display Resolution of the Computer ...........53 ■...
Page 8 Table of Contents Useful Functions Available During a Presentation ......73 Useful Presentation Functions ............74 Temporarily Blacking Out an Image................74 Freezing the Picture....................74 Adjusting the Volume ....................75 Muting the Sound......................75 Zooming an Image ....................76 Projecting Images on a USB Flash Drive..........77 Split-Screen Display ................
Page 9 Table of Contents Correcting Gamma....................98 Adjusting Colors .......................99 Adjusting to the Ambient Light (Ambient Light) ..........100 Reducing Image Noise (Noise reduction) .............101 Dynamic Gamma Adjustment ................101 Correcting Memory Color..................102 Fine-Tuning Colors (6-axis Color Adjustment) ............102 Fine-Tuning Gamma ....................103 Controlling Contrast (Iris) ..................104 Specifying the Lamp Mode..................105 Resetting Image Adjustment Settings ..............105 Customizing System Operation (System Settings) ......
Page 10 Table of Contents Installation and Maintenance........121 Installation..................123 Before Installation................124 Precautions When Carrying/Shipping the Projector ...........124 Precautions for Installation..................124 ■ When using mounted on the ceiling ..............126 ■ Install facing in the correct direction..............127 Installation Procedure ................ 128 Setting Up the Projector ..................128 ■...
Page 11 Table of Contents Installation-Related Menu Settings ........... 143 Locking Installation Settings .................143 Flipping Image Display ...................143 Specifying the Screen Aspect................145 Specifying Keystone Correction................146 Specifying Digital Image Shift................146 Specifying Micro Digital Image Shift ..............147 Adjusting Image Registration ................147 Specifying the Fan Mode..................148 Specifying Vertical Projection ................148 Selecting the Audio In Terminal ................149 Adjusting Colors to Suit the Screen Color ............149...
Page 12 Table of Contents Enabling/Disabling DHCP..................170 Specifying TCP/IP Settings ..................170 Initializing Network Settings ..................171 Specifying PJLink Settings ..................171 Specifying Use of AMX Device Discovery ............172 Specifying Use of Crestron RoomView..............173 Completing Computer Settings ............174 Specifying an IP Address ..................174 ■ Windows 7......................174 ■...
Page 13 Table of Contents Networked Multi-Projection (NMPJ)......201 Networked Multi-Projection Overview .........203 Introduction to Networked Multi-Projection ........204 ■ Projection Over a Network ................204 ■ Split-Screen Projection of Multiple Images ............204 ■ Projection of an Image from Multiple Projectors at Once........204 ■ Selecting the Projection Monitor ...............205 Installing the NMPJ Application ............
Page 14 Table of Contents Using the Projector Selection Menu ..........254 Projector Selection Menu ..................254 ■ Finding Projectors .....................256 ■ Selecting Password-Protected Projectors............257 ■ Using the Favorites Function ................258 ■ Resorting the Projector List................259 ■ Turning Projectors On ..................259 Using Layout Functions ..............260 ■...
Page 15 Table of Contents Appendix ..............273 Appendix ..................275 Troubleshooting.................. 276 LED Indicator Meanings ..................276 Symptoms and Solutions ..................277 ■ You Cannot Turn on the Projector ..............277 ■ You Cannot Project an Image from the Projector ..........278 ■ There is no Sound.....................279 ■...
Page 16: Safety Instructions
If your projector does not seem to be operating properly, read this manual again, check operations and cable connections, and try the solutions in the “Troubleshooting” section in the back of this manual. If the problem still persists, contact the Canon Customer Support Center. CAUTION RISK OF ELECTRIC SHOCK...
Page 17: Safety Precautions
Safety Instructions Safety Precautions WARNING: • THIS APPARATUS MUST BE GROUNDED. • TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. • This projector produces intense light from the projection lens. Do not stare directly into the lens, otherwise eye damage could result.
Page 18: Read And Keep This Owner's Manual For Later Use
Safety Instructions ■ READ AND KEEP THIS OWNER’S MANUAL FOR LATER USE. All the safety and operating instructions should be read before beginning to operate the product. Read all of the instructions given here and retain them for later use. Unplug this projector from the AC power supply before cleaning.
Page 19 If you are not sure of the type of power supplied, contact the Canon Customer Support Center or local power company. Do not overload wall outlets and extension cords as this can result in fire or electric shock.
Page 20: Ac Power Cord Requirement
EEE. Your cooperation in the correct disposal of this product will contribute to the effective usage of natural resources. For more information about the recycling of this product, please contact your local city office, waste authority, approved scheme or your household waste disposal service or visit www.canon-europe.com/weee, or www.canon-europe.com/battery.
Page 21: Federal Communication Commission Notice
If such changes or modifications should be made, you could be required to stop operation of the equipment. Canon U.S.A. Inc. One Canon Park, Melville, New York 11747, U.S.A. Tel No. (631) 330-5000 Canadian Radio Interference Regulations...
Page 22 Safety Instructions Safety Symbols in this Manual This section describes the safety symbols used in this manual. Important projector safety information is identified by the following symbols. Always observe the safety information by these symbols. Denotes the risk of death or serious injury from improper handling if the information is not observed.
Page 23: Precautions For Use
If the following situations occur, turn the power off, remove the power plug from the power outlet and contact the Canon Customer Support Center. Failure to do so could cause a fire or result in an electric shock.
Page 24: Precautions For Installation
Safety Instructions Pay attention to the following points regarding the power source, power plug and handling of the connector. Failure to do so may cause a fire, electric shock or personal injury. • Do not use any power source with a voltage other than the voltage indicated (AC 100–240 V).
Page 25 These could cause an electric shock or burn. If inspection, maintenance or repair is required, contact the Canon Customer Support Center. • Do not disassemble or modify the projector (including consumable parts) or the remote control.
Page 26: Precautions On The Lamp
If the illumination suddenly stops when the projector is in use or after you turn it on, the lamp may be broken. In this case, never attempt to replace the lamp by yourself. Always request service from the Canon Customer Support Center. Additionally, with ceiling-mounted projectors, the lamp may fall out when you open the lamp cover or while you are attempting to replace it.
Page 27: Precautions For The Batteries Of The Remote Control
Safety Instructions When handling the lamp, pay attention to the following points. • Be sure not to handle the lamp immediately after it has been used. Be sure to switch off the power and wait for approximately 1 hour for the lamp and the projector to cool down sufficiently.
Page 28: For Safe Use
For Safe Use Pay attention to the following points when carrying or transporting the projector. • This projector is a precision instrument. Do not knock it over or subject it to impacts. Doing so may cause a malfunction. • Do not reuse any packaging or shock-absorbent materials that were supplied with the projector at the time of purchase for transporting or shipping the projector.
Page 29 For Safe Use Pay attention to the following points when installing or using the projector. • Do not touch the lens with bare hands. Doing so may result in deterioration of image quality. • If the projector is suddenly moved from a location where the temperature is low to a location where the temperature is high, or if the temperature in the location where the projector is installed increases suddenly, moisture in the air could cause condensation to form on the projector lens or mirror.
Page 31: Before Use
Table of Contents Safety Instructions Before Use Before Use Projecting an Image Useful Functions Available During a Presentation Setting Functions from Menus Installation Connecting to a Network Maintenance Networked Multi-Projection Overview Operation in Each Mode Functions in All Modes Other Information Index...
Page 32: Supplied Accessories
Supplied Accessories Check that the following accessories have been supplied with the projector. • Remote control • Batteries for the remote control (AAA size x2) (part No.: RS-RC06) • Lens cap Optional remote controls are also available (RS-RC04, RS- RC05). However, some buttons are not supported with this projector.
Page 33: Preparing The Remote Control
Preparing the Remote Control ■ Installing Remote Control Batteries Open the battery Insert batteries. Close the compartment lid. Insert 2 new AAA compartment lid. Slide the lid while batteries in the Slide the lid until you pressing it down. compartment with the hear a click to + and –...
Page 34: Remote Control Operating Range
Preparing the Remote Control ■ Remote Control Operating Range The remote control is an infrared type. Point it at the infrared remote receiver on the front or rear of the projector to operate it. 25° 8 m (26.3') 25° 8 m (26.3') 25°...
Page 35: Using An Optional Wired Remote (Rs-Rc05)
Preparing the Remote Control ■ Using an Optional Wired Remote (RS-RC05) To use a wired remote control with the projector, use the RS-RC05, sold separately. Use a cable with a ø3.5 mm stereo mini jack (not included). Remote control (RS-RC05) Terminal for wired remote control ø3.5 mm stereo mini jack...
Page 36: Part Names
Part Names Projector ■ Front Side Hole caps (P129) Attach option feet (sold separately). For instructions on removing the hole caps, refer to “Attaching Option Feet (RS-FT01, Sold Side control Separately)”. (P40) Projection lens (P43) Infrared remote receiver (P34) Terminals and Air intake vent connectors (P42) Air filter (P195)
Page 37: Bottom Side
Depending on the installation environment, an extension pipe (part No.: RS-CL08 or RS-CL09) may also be required. Contact the Canon Customer Support Center for more detailed information. • Make sure to use the optional ceiling attachment.
Page 38: Remote Control
Part Names Remote control The projector can be operated using buttons on the remote control or the side control on the projector. The remote control allows you to operate all functions of the projector. POWER button (P50, P71) Turns the projector on or off. BLANK button (P74) Toggles between display / non-display of image.
Page 39 Part Names INPUT button (P52) Switches the input signal. AUTO PC button (P55) Adjusts tracking etc. automatically in accordance with the signal from a computer when the analog PC input is selected. MENU button (P82) Displays a menu on the screen. Also used to assign a channel to the remote control.
Page 40: Side Control
Part Names Side Control (1) POWER button (P50, P71) (5) Pointer / VOL buttons (P75, P83) Turns the projector on or off. Adjust the sound volume. [ ] VOL+ button: Increases the (2) INPUT button (P52) volume. Switches the input signal. [ ] VOL–...
Page 41: Led Indicator Displays
Part Names • POWER ON (green) : Lights up or flashes under normal conditions when the power is on. • WARNING (red) : Lights up or flashes when an error occurs. • LAMP (orange) : Flashes when the time for replacing the lamp is near. When a lamp cover error occurs, the [WARNING] indicator will also flash.
Page 42: Input Terminal
Part Names Input Terminal (1) AUDIO OUT terminal (AUDIO OUT) (P136, P139) Outputs the audio to external AV equipment. This outputs the audio signal that corresponds to the projected image signal. (2) AUDIO IN terminal (AUDIO IN) (P134, P135, P138) Receives the audio signal input for 2 kinds of image input other than HDMI.
Page 43: Lens Shift Control
Part Names Lens Shift Control (1) Vertical lens shift dial Slides the lens up or down for vertical image adjustment. (2) Horizontal lens shift dial Slides the lens left or right for horizontal image adjustment. For details on lens shift, refer to “Lens Shift Function” (P131). Projection Lens (1) Zoom adjustment Move the lever to resize the image.
Page 44: Open Source Software
Open Source Software The product contains Open Source Software modules. For details, see “ThirdPartySoftware.pdf” (Third-Party Software License) in the OpenSourceSoftware folder in the LICENSE folder on the Setup CD-ROM. Each module’s license conditions are also available in the same folder. ■...
Page 45 Open Source Software NO SUPPORT Canon Inc., and all its subsidiaries or its dealers do not make any support service regarding the source code. Canon Inc., and all its subsidiaries or its dealers shall not respond to any questions or enquiries, from you or any other customers,...
Page 47: Operation
MULTIMEDIA PROJECTOR Operation...
Page 49: Projecting An Image
Table of Contents Safety Instructions Projecting an Before Use Image Projecting an Image Useful Functions Available During a Presentation Setting Functions from Menus Installation Connecting to a Network Maintenance Networked Multi-Projection Overview Operation in Each Mode Functions in All Modes Other Information Index...
Page 50: Step 1 Turn The Projector On
Turn the Projector On Step 1 Check the connection between the projector and the computer or AV equipment. (P134 - P137) For instructions on connecting the power cord, refer to “Plugging the Projector In” (P140). Press the POWER button. The [POWER ON] indicator initially flashes green, after which it remains lit. Remote control Projector The countdown window is displayed for approximately 20 seconds, and then...
Page 51: Step 2 Select An Input Signal
Select an Input Signal Step 2 Select the input signal in the [Input] menu when you want to project a digital PC or AV equipment signal, or to switch between inputs when multiple computers or multiple sets of AV equipment are connected. Skip this step if you have not changed the input signal since the last projection.
Page 52: Selecting An Input Signal
Step 2 Select an Input Signal Selecting an Input Signal Press the INPUT button to display the window shown below. Remote control Projector The currently active input signal is marked with a green circle and enclosed by a orange border. An input signal that is ready for projection is displayed in white.
Page 53: Step 3 Adjust The Image
Based on the maximum resolution of the projector, set the display resolution of the computer to the resolution closest to the output signal resolution of the projector. (P288) Maximum resolution WUX450 : 1920 X 1200 dots WX520 : 1440 X 900 dots ■ Windows 8 Move the cursor toward the upper or lower right corner to access the menu.
Page 54: Windows Vista
Step 3 Adjust the Image ■ Windows Vista ■ Windows XP Open the [Control Panel] from Right-click on the desktop the start menu, then select background and select [Appearance and [Properties] to open the [Display Personalization] - [Adjust screen Properties]. resolution] in the [Control Panel Click the [Settings] tab, and Home].
Page 55: Auto Pc Adjustment
Step 3 Adjust the Image Auto PC Adjustment If the image display is shifted or there is flickering of the screen when [Analog PC-1] or [Analog PC-2] is selected, press the AUTO PC button to adjust the projector to the optimal condition. The adjustment results will be stored.
Page 56: Adjusting The Image Position
Step 3 Adjust the Image Adjusting the Image Position Turn the lens shift dials to adjust the projected image vertically or horizontally. Called “lens shift,” this adjusts the projected image into position by moving the lens up, down, left, or right. •...
Page 57: Step 4 Select An Aspect Ratio (Screen Aspect) Matching The Screen
Select an Aspect Ratio (Screen Aspect) Matching the Screen Step 4 Select an optimum aspect ratio of the projected image (screen aspect) or an optimum screen mode (aspect) according to the aspect ratio of the screen, type of input image signal and so on for the projection to make best use of the screen size. [Screen aspect] Select the same screen aspect ratio as the screen you are using.
Page 58 Step 4 Select an Aspect Ratio (Screen Aspect) Matching the Screen Select [Screen aspect] with the [ ] / [ ] buttons, and then press the OK button. Remote control Projector Use the [ ] / [ ] buttons to select the desired contents. Remote control Projector 16:10...
Page 59 Step 4 Select an Aspect Ratio (Screen Aspect) Matching the Screen 16:9 D. image shift Select this when you use a screen with an aspect ratio of 16:9. Keystone correction cannot be performed in this mode. However, it is possible to move the image up / down when projecting level.
Page 60: Moving Image With 16:9 D. Image Shift
Step 4 Select an Aspect Ratio (Screen Aspect) Matching the Screen Moving Image with 16:9 D. Image Shift This option applies image processing to reposition the image. For this reason, it is called digital image shift. When the screen aspect is [16:9 D. image shift], press the MENU button to display the menu.
Page 61: Moving Image With 4:3 D. Image Shift
Step 4 Select an Aspect Ratio (Screen Aspect) Matching the Screen Use the [ ] / [ ] buttons to move the image up or down. Remote control Projector [ ] button [ ] button Moves the image up. Moves the image down. Screen When the image fits the screen, press the OK button.
Page 62: Resetting The Image Shift
Step 4 Select an Aspect Ratio (Screen Aspect) Matching the Screen Use the [ ] / [ ] buttons to select [Digital image shift], then press the OK button. Remote control Projector Use the [ ] / [ ] buttons to move the image. Remote control Projector [ ] button...
Page 63: Selecting The Aspect
Step 4 Select an Aspect Ratio (Screen Aspect) Matching the Screen Selecting the Aspect Select [Aspect] based on the input signal type, aspect ratio of the screen and resolution. For more details about aspect ratios, refer to “Relationship between Aspect and Screen Aspect”...
Page 64: Selecting An Aspect Ratio
Step 4 Select an Aspect Ratio (Screen Aspect) Matching the Screen Selecting an Aspect Ratio Press the ASPECT button on the remote control and select an appropriate aspect ratio. Press the ASPECT button to change the aspect ratio type. For more details about aspect ratios, refer to “Relationship between Aspect and Screen Aspect”...
Page 65: Step 5 Correct The Image Distortion
Correct the Image Distortion Step 5 Adjusting Keystone Distortion To correct keystone distortion, press the KEYSTONE button. Two types of correction are available: horizontal/vertical correction and corner correction. Horizontal/vertical keystone correction adjusts image width and height, and corner correction adjusts the image relative to each corner. For instructions on switching between the two types of keystone correction, refer to “Specifying Keystone Correction”...
Page 66: Corner Adjustment
Step 5 Correct the Image Distortion Press the pointer buttons to adjust the dimensions. Remote control Projector [ ] button [ ] button Reduces the dimensions of the Reduces the dimensions lower edge. of the upper edge. Screen [ ] button [ ] button Reduces the dimension Reduces the dimension...
Page 67: Resetting The Keystone Adjustment
Step 5 Correct the Image Distortion Press the pointer button of the corner for correction, and then press the OK button. Remote control Projector Press the pointer buttons to adjust the corner. Remote control Projector When you have finished correcting, press the OK button. ■...
Page 68: Step 6 Select The Image Quality (Image Mode)
Select the Image Quality (Image Mode) Step 6 You can select an image mode to suit the projected image. In each image mode, you can further adjust the brightness, contrast, sharpness, gamma, color adjustment, advanced adjustment, and lamp mode. (P95) Image Modes The image modes which can be selected vary somewhat depending on the selected input signal.
Page 69: Selecting An Image Mode
Step 6 Select the Image Quality (Image Mode) ■ Selecting an Image Mode Press the IMAGE button on the remote control to select. The image mode changes each time the IMAGE button is pressed. (The displayed image modes vary depending on the selected input signal.) Remote control You can also select any image mode from the [Image mode] menu.
Page 70: Step 7 Set Power-Saving Settings
Set Power-Saving Settings Step 7 Press the ECO button on the remote control to complete power-saving settings. The following three settings are available. • Lamp Settings For changing lamp and fan power consumption in the current image mode. • Auto Power-Off A function for automatically turning the power off after a certain period if the projector is not used and there is no input signal.
Page 71: Step 8 Turn The Projector Off
Turn the Projector Off Step 8 Press the POWER button to display the window shown below. Remote control Projector When this window is displayed, press the POWER button again to turn off the power. After you turn the power off, the projector will enter standby mode once it cools down.
Page 73: Useful Functions Available During A Presentation
Table of Contents Safety Instructions Useful Functions Before Use Available During a Projecting an Image Presentation Useful Functions Available During a Presentation Setting Functions from Menus Installation Connecting to a Network Maintenance Networked Multi-Projection Overview Operation in Each Mode Functions in All Modes Other Information Index...
Page 74: Useful Presentation Functions
Useful Presentation Functions Temporarily Blacking Freezing the Picture Out an Image Useful when: • You want to perform a computer Useful when: operation which is irrelevant to the • You have finished the presentation. proceedings of the presentation. • You want to divert attendees’ •...
Page 75: Adjusting The Volume
Useful Presentation Functions Adjusting the Volume Muting the Sound Useful when: Useful when: • You want to adjust the volume level of • You want to temporality mute the projector or external speakers. unnecessary sound. • You want to immediately mute the sound.
Page 76: Zooming An Image
Useful Presentation Functions Zooming an Image You can move the enlarged area by using the [ ] / [ ] / [ ] / [ ] buttons. Remote control Projector Useful when: • Zooming in on an object such as a small graph during a presentation (up to 12x).
Page 77: Projecting Images On A Usb Flash Drive
Projecting Images on a USB Flash Drive Images stored on a USB flash drive in the projector can be projected as follows. You can select the images to project, or you can project images automatically, one after another. JPEG images up to 7000x7000 can be projected. •...
Page 78 Projecting Images on a USB Flash Drive Use the pointer buttons to select a file, and then press the OK button to project the image. Press the [ ] / [ ] buttons to select a file. To view another page, press the [ ] / [ ] buttons (if other pages are available). To navigate to a higher or lower folder, select a folder and press the OK button.
Page 79: Split-Screen Display
Split-Screen Display Two input images can be projected side by side. This is split-screen display. When you activate split-screen display, the current image is shown on the left side, and the new image is shown at right. You can change the source of images shown on each side by pressing the INPUT button.
Page 80 Split-Screen Display Press the INPUT button to select the input signal for the side with control rights. The [Input] menu is displayed. To determine which side is currently under control, check the screen ID in orange in the upper right of the menu. The side without control rights is labeled with a white circle.
Page 81: Setting Functions From Menus
Table of Contents Safety Instructions Setting Functions Before Use from Menus Projecting an Image Useful Functions Available During a Presentation Setting Functions from Menus Installation Connecting to a Network Maintenance Networked Multi-Projection Overview Operation in Each Mode Functions in All Modes Other Information Index...
Page 82: Using Menus
Using Menus Use the menus to set the operation of the projector in detail. Menu Configuration The menu screen is divided into 6 tabs as shown below. [Install settings] tab [System settings] tab This setting is used when installing You can set the operation of the projector.
Page 83: Basic Menu Operations
Using Menus Basic Menu Operations Press the MENU button to display the menu window. Remote control Projector Press the [ ] / [ ] buttons to select a tab. Remote control Projector • If the tab position is not highlighted in orange, press the [ ] / [ ] buttons to move the current selection to the top.
Page 84 Using Menus Adjusting with the [ ] / [ ] buttons Example: Contrast (P97) 1. Select [Contrast]. 2. Use the [ ] / [ ] buttons to adjust the setting. Selecting from a different screen (1) Example: Menu position (P150) 1.
Page 85: Setting Display Status (Input Settings)
Select this for clear projection of computer screens at up to WUXGA (WUX450) or WXGA+ (WX520) resolution. • There may be some cases when this cannot be selected, depending on the input signal and/or resolution.
Page 86: Setup Using Auto Pc
Setting Display Status (Input Settings) Setup Using Auto PC Selecting an Input Signal [Auto PC] > [Input settings] > [Input signal HDMI Component > [Input settings] > select] Digital PC Analog PC HDMI Component Automatically adjusts display Digital PC Analog PC position misalignment and screen flickering.
Page 87: Adjusting The Input Signal (Total Dots)
Setting Display Status (Input Settings) Adjusting the Input Adjusting the Input Signal Signal (Total dots) (Tracking) > [Input settings] > [Input signal > [Input settings] > [Input signal [Total dots] [Tracking] settings] > settings] > HDMI Component HDMI Component Digital PC Analog PC Digital PC Analog PC...
Page 88: Adjusting The Input Signal (Horizontal Position)
Setting Display Status (Input Settings) Adjusting the Input Adjusting the Input Signal Signal (Horizontal position) (Vertical Position) > [Input settings] > [Input signal > [Input settings] > [Input signal [Horizontal position] [Vertical position] settings] > settings] > HDMI Component HDMI Component Digital PC Analog PC...
Page 89: Adjusting The Input Signal (Horizontal Pixels)
Setting Display Status (Input Settings) Adjusting the Input Adjusting the Input Signal Signal (Horizontal pixels) (Vertical pixels) > [Input settings] > [Input signal > [Input settings] > [Input signal [Horizontal pixels] [Vertical pixels] settings] > settings] > HDMI Component HDMI Component Digital PC Analog PC...
Page 90: Adjusting Hdmi Input Level
Setting Display Status (Input Settings) Adjusting HDMI Input Setting the HDMI Level Color Format [HDMI input level] [HDMI color > [Input settings] > > [Input settings] > space] HDMI Component HDMI Component Digital PC Analog PC Digital PC Analog PC You can select this as required when Select the color space for the HDMI you project visual software using an...
Page 91: Specifying Hdmi Overscan
Setting Display Status (Input Settings) Specifying HDMI Specifying Progressive Overscan Processing [HDMI over scan] [Progressive] > [Input settings] > > [Input settings] > HDMI Component HDMI Component Digital PC Analog PC Digital PC Analog PC When projecting images in videos Performs progressive processing via HDMI, select this setting to trim optimized for still images in...
Page 92: Specifying The Slideshow Interval
Setting Display Status (Input Settings) Specifying the • [Film/auto] is the factory default. • Select [Off] when flickers and horizontal Slideshow Interval lines are noticeable in media that has a lot of fast-moving action. • Not available during split-screen display. [Slideshow >...
Page 93: Specifying Split-Screen Display
Setting Display Status (Input Settings) Specifying Split- • [Off] is the factory default. • The SPLIT button on the remote control can Screen Display also be used to select the [Split screen] settings. • If is displayed in the center of the [Split screen] >...
Page 94: Adjusting Image Quality (Image Adjustment)
Adjusting Image Quality (Image Adjustment) Specifying Image Can be independently configured Brightness (P97), Contrast (P97), Priority in Split-Screen Gamma (P98), Color adjustment (P99), Mode Fine-Tune Gamma (P103) [Primary] setting also applies to [Image > [Image adjustment] > [Secondary] priority] Image Mode (P95), Advanced adjustment HDMI Component (except Fine-Tune Gamma) (P100-P104),...
Page 95: Specifying The Image Mode
Adjusting Image Quality (Image Adjustment) Specifying the Image • [Standard] is the factory default for Analog PC-1 or 2, Digital PC, or HDMI (when Mode [HDMI In] is [Computer]), LAN or USB, and [Photo/sRGB] is the default for HDMI (when [HDMI In] is [Auto]) or Component.
Page 96: Creating/Saving A User Profile
Adjusting Image Quality (Image Adjustment) Creating/Saving a • The number of displayed user memories is 5, however it is possible to save different User Profile settings for when the connected equipment is a computer (ANALOG PC, DIGITAL PC or HDMI (when [HDMI In] (P113) is [Create >...
Page 97: Adjusting Brightness
Adjusting Image Quality (Image Adjustment) Adjusting Brightness Adjusting Contrast [Brightness] [Contrast] > [Image adjustment] > > [Image adjustment] > HDMI Component HDMI Component Digital PC Analog PC Digital PC Analog PC You can adjust the brightness of You can adjust the contrast of images.
Page 98: Adjusting Sharpness
Adjusting Image Quality (Image Adjustment) Adjusting Sharpness Correcting Gamma [Sharpness] [Gamma] > [Image adjustment] > > [Image adjustment] > HDMI Component HDMI Component Digital PC Analog PC Digital PC Analog PC You can adjust the sharpness of You can correct portions of an image images.
Page 99: Adjusting Colors
Adjusting Image Quality (Image Adjustment) Adjusting Colors When you have completed the adjustment, press the MENU or EXIT button. [Color > [Image adjustment] > adjustment] • The adjustments you have made are stored HDMI Component as adjusted values for the input signals and Digital PC Analog PC image mode of the current projection.
Page 100: Adjusting To The Ambient Light (Ambient Light)
Adjusting Image Quality (Image Adjustment) Adjusting to the Examples of Ambient Light Level Settings Ambient Light Level Example Location (Ambient Light) Projection room, sports bar, etc. Conference room, lecture room > [Image adjustment] > [Advanced [Ambient light] adjustment] > Press the OK button to accept your HDMI Component setting and then press the MENU...
Page 101: Reducing Image Noise (Noise Reduction)
Adjusting Image Quality (Image Adjustment) Reducing Image Dynamic Gamma Noise Adjustment (Noise reduction) > [Image adjustment] > [Advanced [Dynamic gamma] adjustment] > > [Image adjustment] > [Advanced [Noise reduction] adjustment] > HDMI Component Digital PC Analog PC HDMI Component Digital PC Analog PC You can adjust the gradation representation of light and dark...
Page 102: Correcting Memory Color
Adjusting Image Quality (Image Adjustment) Correcting Memory Fine-Tuning Colors Color (6-axis Color Adjustment) > [Image adjustment] > [Advanced > [Image adjustment] > [Advanced [Mem. color correct] [6-axis color adjust] adjustment] > adjustment] > HDMI Component HDMI Component Digital PC Analog PC Digital PC Analog PC Enhances skin tones, blue skies, and...
Page 103: Fine-Tuning Gamma
Adjusting Image Quality (Image Adjustment) Fine-Tuning Gamma • [Off] is the factory default. • The adjustments you have made are stored as adjusted values for the input signals and > [Image adjustment] > [Advanced image mode of the current projection. [Fine-Tune Gamma] adjustment] >...
Page 104: Controlling Contrast (Iris)
Adjusting Image Quality (Image Adjustment) Controlling Contrast • The adjustments you have made are stored as adjusted values for the input signals and (Iris) image mode of the current projection. • For details of gamma correction, refer to page > [Image adjustment] > [Advanced •...
Page 105: Specifying The Lamp Mode
Adjusting Image Quality (Image Adjustment) Specifying the Lamp Resetting Image Mode Adjustment Settings [Lamp mode] [Reset] > [Image adjustment] > > [Image adjustment] > HDMI Component HDMI Component Digital PC Analog PC Digital PC Analog PC Reducing the lamp brightness You can reset the current image reduces power consumption and adjustment settings to the default...
Page 106: Customizing System Operation (System Settings)
Customizing System Operation (System Settings) Registering User Logos Positioning User Logos > [System settings] > [User screen [Logo capture] settings] > > [System settings] > [User screen [Logo position] HDMI Component settings] > Digital PC Analog PC HDMI Component Digital PC Analog PC Registers the current image as a user logo.
Page 107: No Signal Screen
Customizing System Operation (System Settings) No Signal Screen Screen When Blank > [System settings] > [User screen > [System settings] > [User screen [No signal screen] [Screen when blank] settings] > settings] > HDMI Component HDMI Component Digital PC Analog PC Digital PC Analog PC As the image projected when there is...
Page 108: Selecting A Logo At Startup
Disable auto power-off. setting and then press the MENU button or EXIT button. • [Canon logo] is the factory default. • Only images with an aspect of 16:10 can be registered as user logos. Press the OK button to accept your setting and then press the MENU button or EXIT button.
Page 109: Specifying Direct Power-On
Customizing System Operation (System Settings) Specifying Direct Specifying Silence or Power-On Operating Tones [Direct power [Beep] > [System settings] > > [System settings] > HDMI Component HDMI Component Digital PC Analog PC Digital PC Analog PC You can select whether a beep You can turn on the projector by sounds or not when you operate the connecting the power cable without...
Page 110: Specifying Key Repeat Operation
Customizing System Operation (System Settings) Specifying Key Repeat Locking Projector or Operation Remote Buttons [Key repeat] [Key lock] > [System settings] > > [System settings] > HDMI Component HDMI Component Digital PC Analog PC Digital PC Analog PC By pressing and holding the button You can lock the projector to prevent on the projector or the remote its operation from either the main...
Page 111: Assigning A Channel For Remote Control
Customizing System Operation (System Settings) Assigning a Channel To Unlock Key Lock Function for Remote Control Turn off the projector and unplug the power plug. Hold down the OK button on [Remote the main unit and plug in the power cord, >...
Page 112: Reducing Motion Blur
Customizing System Operation (System Settings) Reducing Motion Selecting a Channel on the Remote control Blur You can change the channel on the remote control as follows. [Motion blur > [System settings] > reduction] Press and hold the OK button and [ ] button at the HDMI Component same time for 3 seconds.
Page 113: Specifying Hdmi Input
Customizing System Operation (System Settings) Specifying HDMI Input Selecting a Display Language [HDMI In] > [System settings] > [Language] HDMI Component > [System settings] > Digital PC Analog PC HDMI Component Digital PC Analog PC Set the type of equipment which is connected to the HDMI port.
Page 114: Requiring A Password For Operation
Customizing System Operation (System Settings) Requiring a Password When the setting is completed, press the OK button to accept your setting for Operation and then press the MENU button or EXIT button. > [System settings] > [Other settings] > [Password settings] HDMI Component Digital PC...
Page 115: Setting A Password
Customizing System Operation (System Settings) Setting a Password To Cancel the Password Turn off the projector and unplug the > [System settings] > [Other settings] > power plug. [Register password] Hold down the MENU button on the side control and connect the power plug. HDMI Component Make sure to keep holding down the...
Page 116: Restoring Original Gamma Settings
Customizing System Operation (System Settings) Restoring Original If Gamma restore is performed, the Gamma Settings tone characteristics and achromatic color will be restored as close as possible to the condition when the > [System settings] > [Other settings] > projector was purchased, however it is [Gamma restore] not possible to restore it completely to the original condition.
Page 117: Resetting The Lamp Counter
Customizing System Operation (System Settings) Resetting the Lamp ■ About the Display of the Lamp Counter Counter The lamp counter displays the hours of use of the lamp in the following way. > [System settings] > [Other settings] > [Lamp counter] Less than 2,700 hours HDMI Component...
Page 118: Resetting The Air Filter Counter
Download firmware updates from the For details about how to replace or Canon website and store them at the clean the filter, refer to page 195. root directory on the USB flash drive.
Page 119: Resetting To The Default Setting
Customizing System Operation (System Settings) Resetting to the Default Setting > [System settings] > [Other settings] > [Factory defaults] HDMI Component Digital PC Analog PC You can reset the menu item settings and restore the system settings to the factory defaults. Select [Factory defaults] and press the OK button.
Page 120: Checking Projector Information
Information shown Item Explanation Model name WUX450 / WX520 Input signal Details of the input signal currently selected Information such as the type, resolution, and frequency of the signal is displayed. Firmware Current firmware version Serial no.
Page 121: Installation And Maintenance
MULTIMEDIA PROJECTOR Installation and Maintenance Request projector installation from a qualified technician, if possible, or contact the Canon Customer Support Center. For ceiling installation in particular, always request installation from a qualified technician or contact the Canon Customer Support Center.
Page 123: Installation
Table of Contents Safety Instructions Installation Before Use Projecting an Image Useful Functions Available During a Presentation Setting Functions from Menus Installation Connecting to a Network Maintenance Networked Multi-Projection Overview Operation in Each Mode Functions in All Modes Other Information Index...
Page 124: Before Installation
Before Installation Precautions When Carrying/Shipping the Projector Prepare the projector as described below before carrying it. • Disconnect the cables connected to the projector. Carrying the projector with the cables attached may cause an accident. • Retract the adjustable feet. •...
Page 125 Before Installation ■ Do Not Use in the Following Environments • Do not install the projector in a location that is damp, or where there is a lot of dust, oily smoke or tobacco smoke. Optical parts such as the lens and mirror may be stained, resulting in poor picture quality.
Page 126: When Using Mounted On The Ceiling
Before Installation ■ Be Careful of Condensation If the temperature of the room rises suddenly, moisture in the air may condense on the projector lens and mirror, causing the image to become blurred. Wait until the condensation has evaporated for the image projected to return to normal. ■...
Page 127: Install Facing In The Correct Direction
Before Installation ■ Install facing in the correct direction The projector can be installed facing any direction* , as shown below. However, projection upward ( ) or downward ( ) may shorten the useful life of the lamp. Installation in these orientations also requires projector settings adjustment.
Page 128: Installation Procedure
Installation Procedure Setting Up the Projector ■ Positioning the Projector in Front of the Screen Place the projector in front of the screen. • To avoid keystone distortion, install the Screen projector so that it is at right angles to the screen.
Page 129: Projection From High Surfaces
Installation Procedure ■ Projection from High Surfaces For projection from a shelf or other high surface, the projector can be installed upside-down and the projected image inverted. In this case, attach the option feet on top of the projector. When setting the projector on a high surface for projection, be sure the surface is flat and stable.
Page 130: Ceiling Mounting Or Rear Projection
Installation Procedure Removing hole caps labeled (2) Open the lamp cover and use a screwdriver or similar tool to push off the caps from below. Hole cap • Keep the caps in a safe place to avoid losing them. • The option feet can be used in conjunction with the adjustable feet. When changing the projection position with adjustable feet, you can make the projector more stable by attaching option feet to the two holes toward the back of the bottom surface.
Page 131: Relationship Of Image Size To Projection Distance
(projection distance) as well as the zoom. Refer to the following table and decide the distance between the projector and screen. 16:9 / 16:10 Image Size (diagonal) Width Width Projection distance [m (feet)] Image WUX450 WX520 Size 16:10 16:9 16:10 16:9 (Dia.) Wide...
Page 132 In this case, adjust lens shift to within the recommended range. Recommended lens shift range Projection range without using lens shift Lens shift range Maximum upward (A) and horizontal (B) movement using lens shift (reference values, in cm) Image WUX450 WX520 Size 16:10 16:9 16:10 16:9 (Dia.) •...
Page 133: Connection Procedure
Connection Procedure Connectable Equipment and Input Terminals HDMI Use this name to select the image Direction of signal and data flow input. HDMI The name of the terminal to which (Pxxx) indicates the page(s) to refer to. Terminal to connect equipment Analog PC-1 Analog PC-2 HDMI...
Page 134: Connecting A Computer
Connection Procedure Connecting a Computer Connect the projector to the computer. A digital connection (P135) is recommended when projecting an image in high quality. When using a computer with an HDMI output terminal, a digital connection (P136) can be made using an HDMI cable. Before connecting the cables, turn off both the projector and computer.
Page 135: Connecting To Dvi Monitor Output Terminal (Digital Connection)
Connection Procedure • Use a VGA-DVI-I cable in which all pins are connected. If the cable is a type in which all pins are not connected, the image may not be correctly displayed. • Use an audio cable without a built-in resistor. Using an audio cable with a built-in resistor will reduce the audio volume.
Page 136: Connecting With An Hdmi Cable (Input Signal Type: [Hdmi])
Connection Procedure • Use an audio cable without a built-in resistor. Using an audio cable with a built-in resistor will reduce the audio volume. • The AUDIO IN terminal can be changed in the Audio in terminal select screen (P149). ■...
Page 137: Connecting Av Equipment
Connection Procedure Connecting AV Equipment Connect the projector and AV equipment. The description provided here is one example. For more detailed information, refer to the manual for the connected AV equipment. Before connecting the cables, turn off both the projector and AV equipment. ■...
Page 138: Connecting To Analog Video Output Terminal (Analog Connection)
Connection Procedure ■ Connecting to Analog Video Output Terminal (Analog Connection) Connecting with a component cable (Input signal type: [Component] P51) Component video signals from AV equipment can be supplied to the projector by connecting the component cable to the projector’s COMPONENT terminal. Use a commercially available component cable (not included) that fits the terminal type of the AV equipment to create a relay connection.
Page 139: Outputting Audio To Speakers
Connection Procedure ■ Outputting Audio to Speakers It is possible to output audio from the projected images to AV equipment or amplified speakers. Projector Speaker To AUDIO OUT terminal RCA terminal Audio cable (not included) Mini jack AUDIO IN terminal (AUDIO IN) Use an audio cable without a built-in resistor.
Page 140: Plugging The Projector In
Connection Procedure Plugging the Projector In Connect the power cord to the projector and plug it in. Connect the ground terminal on the power plug to ground. Not doing so could result in an electric shock. Additionally, it may cause computers to be affected by electromagnetic interference and impair TV and radio reception.
Page 141: Starting Projection
Starting Projection Starting and Stopping Projection ■ Starting Projection Press the POWER button on the remote control or on the projector. The [POWER ON] indicator initially flashes green, after which it remains lit. Remote control Projector ■ Stopping Projection Press the POWER button on the remote control or on the projector twice. Remote control Projector ■...
Page 142: When "No Signal" Appears
Starting Projection ■ When “No signal” Appears With a notebook computer, the user must turn on the external monitor output. (P142) Press the INPUT button to select the input signal. (P52) ■ When Notebook Computer Screen Does Not Appear Set your notebook computer to output signals to an external monitor. For more details, refer to “Changing Notebook Computer Screen Output”...
Page 143: Installation-Related Menu Settings
Installation-Related Menu Settings Locking Installation Flipping Image Settings Display [Positional lock] [Image flip H/V] > [Install settings] > > [Install settings] > HDMI Component HDMI Component Digital PC Analog PC Digital PC Analog PC Operation of installation related Select this setting if you want to functions can be prohibited.
Page 144: Ceiling Mounting
Ceiling Mounting Rear projection Rear, Ceiling Mounting • To hang the projector from the ceiling, use the optional bracket. Contact the Canon Customer Support Center for more detailed information. • If you flip the image, the keystone distortion adjustment will be reset.
Page 145: Specifying The Screen Aspect
Installation-Related Menu Settings Specifying the Screen Press the OK button to accept your setting and then press the MENU Aspect button or EXIT button. [Screen aspect] > [Install settings] > • [16:10] is the factory default. • Changing the screen aspect will reset any HDMI Component keystone or digital image shift setting.
Page 146: Specifying Keystone Correction
Installation-Related Menu Settings Specifying Keystone Specifying Digital Correction Image Shift [Keystone] [Digital image > [Install settings] > > [Install settings] > shift] HDMI Component HDMI Component Digital PC Analog PC Digital PC Analog PC Two types of keystone correction are Moves the position of the projected available: horizontal-vertical image.
Page 147: Specifying Micro Digital Image Shift
Installation-Related Menu Settings Specifying Micro Adjusting Image Digital Image Shift Registration > [Install settings] > [Professional > [Install settings] > [Professional settings] > [Micro-digital image settings] > [Registration] shift] HDMI Component HDMI Component Digital PC Analog PC Digital PC Analog PC Adjusts colors that are out of Use this setting to fine-tune digital alignment.
Page 148: Specifying The Fan Mode
Installation-Related Menu Settings Specifying the Fan Specifying Vertical Mode Projection > [Install settings] > [Professional > [Install settings] > [Professional settings] > [Fan mode] settings] > [Vertical projection] HDMI Component HDMI Component Digital PC Analog PC Digital PC Analog PC Enable suitable cooling by switching You can ensure adequate cooling by the fan mode to the setting for low-...
Page 149: Selecting The Audio In Terminal
Installation-Related Menu Settings Selecting the Audio In Adjusting Colors to Terminal Suit the Screen Color [Audio in [Screen color] > [Install settings] > > [Install settings] > terminal select] HDMI Component HDMI Component Digital PC Analog PC Digital PC Analog PC You can adjust the color quality of You can select the audio in terminal the images projected according to...
Page 150: Specifying A Menu Position
Installation-Related Menu Settings Specifying a Menu Showing/Hiding the Position Guide Screen > [Install settings] > [On screen] > > [Install settings] > [On screen] > [Menu position] [Guide] HDMI Component HDMI Component Digital PC Analog PC Digital PC Analog PC You can change the position of You can select whether to show or menus displayed.
Page 151: Showing/Hiding Input Status
Installation-Related Menu Settings Showing/Hiding Input Showing/Hiding Status Overheat Warnings > [Install settings] > [On screen] > > [Install settings] > [On screen] > [Show input status] [Overheat warning display] HDMI Component HDMI Component Digital PC Analog PC Digital PC Analog PC You can select whether the signal You can select whether or not to status is displayed on the screen...
Page 152: Specifying The Menu Display Time
Installation-Related Menu Settings Specifying the Menu Showing/Hiding Lamp Display Time Replacement Warnings > [Install settings] > [On screen] > [Menu display time] > [Install settings] > [On screen] > [Lamp warning display] HDMI Component Digital PC Analog PC HDMI Component Digital PC Analog PC The setting for the menu display...
Page 153: Showing/Hiding Filter Cleaning Warnings
Installation-Related Menu Settings Showing/Hiding Filter Showing/Hiding Split- Cleaning Warnings Screen ID > [Install settings] > [On screen] > > [Install settings] > [On screen] > [Air filter warning display] [Split screen ID display] HDMI Component HDMI Component Digital PC Analog PC Digital PC Analog PC A message advising you to perform...
Page 154: Showing/Hiding The Test Pattern
Installation-Related Menu Settings Showing/Hiding the Test Pattern [Test pattern] > [Install settings] > HDMI Component Digital PC Analog PC You can project a test pattern (P287) to check resolution, color, and other details even without supplying an input signal. The test pattern is not displayed. Displays the test pattern.
Page 155: Projecting From Multiple Projectors At Once (Edge Blending)
Installation-Related Menu Settings Projecting from Multiple Projectors at Once (Edge Blending) > [Install settings] > [Professional [Edge blending] settings] > HDMI Component Digital PC Analog PC Overlapping edges of images from multiple projectors used together can be blended to make the overall image more seamless.
Page 156 Installation-Related Menu Settings Here, you can use the following settings in the edge blending menu. Does not blend overlapping areas. Adjust Displays the menu for blending overlapping areas. Left, Right, Top, Bottom Projects an image with no correction. Adjust Marker Hides the markers.
Page 157 Installation-Related Menu Settings Select [Start position] and use the remote’s [ ] [ ] buttons to move the markers to the right edge where the images overlap. Select [Width], and use the remote’s [ ] [ ] buttons to move the markers to the overlapping area.
Page 158: Advanced Instructions: Black Level Adjustment
Installation-Related Menu Settings ■ Advanced Instructions: Black Level Adjustment In overlapping projection, dark colors are projected with less intensity than other colors in the overlapping area. For this reason, overlapping image areas might be more noticeable when the images themselves are dark. You can make this overlapping area less distracting by adjusting the black level of non-overlapping image areas.
Page 159 Installation-Related Menu Settings Here, you can use the following settings in the edge blending menu. Black level Adjust the black level of non-overlapping image areas. adjustment Adjust Adjustment Black type level D-area base Adjust the area D black level. D-area red Adjust the red component of the area D black level.
Page 160: Advanced Instructions: Smoother Overlapping Areas
Installation-Related Menu Settings ■ Advanced Instructions: Smoother Overlapping Areas Adjustments to areas A, B, and C may make the black level along the right edge of area D (that is, the edge bordering the blending area) more noticeable than that of surrounding areas.
Page 161 Installation-Related Menu Settings Select [B-width], and use the remote’s [ ] [ ] buttons to specify the width of area B. This will make the width of area D narrower. Adjust the width of area B to roughly match the area where the black level is noticeable, and then use the following edge-blending settings to adjust the black level of area B.
Page 163: Connecting To A Network
Table of Contents Safety Instructions Connecting to a Before Use Network Projecting an Image Useful Functions Available During a Presentation Setting Functions from Menus Installation Connecting to a Network Maintenance Networked Multi-Projection Overview Operation in Each Mode Functions in All Modes Other Information Index...
Page 164: Network Connection Overview
Network Connection Overview Connecting the projector to a network enables you to control the projector from a computer and receive notification of projector errors via email. Settings related to the network connection can be made from either the projector side (P165) or computer side (P174).
Page 165: Completing Projector Settings
Completing Projector Settings Locking/Unlocking From the projector menus screen, network settings can be configured in Network Settings the [Network Setting] tab. For instructions on menu operations, refer > [Network Settings] > to “Using Menus” (P82). [Network settings lock] You can lock/unlock the network settings so that they cannot be changed.
Page 166: Enabling/Disabling The Network Password
Completing Projector Settings Enabling/Disabling Forcibly canceling the the Network Password network lock On the Network password input [Network > [Network settings] > screen, press the buttons in the password setting] following order to unlock the settings: [ ] [OK] [ ] [OK] [ ] You can set whether or not a [OK].
Page 167: Registering A Network Password
Completing Projector Settings Registering a Network Enabling/Disabling Password Wired Network Functions [Register > [Network settings] > network password] [Network > [Network settings] > Register the projector network function (wired)] password. You can turn the projector network function on or off. Power can be saved by turning the function [Off].
Page 168: Specifying Standby Power Consumption
Completing Projector Settings Specifying Standby Viewing the IP Power Consumption Address [Network > [Network settings] > > [Network settings] > [Detailed settings standby settings] (wired)] > [IP address] Specify network function operating View the projector’s IP address as status in standby mode as follows. follows.
Page 169: Viewing The Gateway Address
Completing Projector Settings Viewing the Gateway Viewing the MAC Address Address > [Network settings] > [Detailed settings > [Network settings] > [Detailed settings (wired)] > [Gateway address] (wired)] > [MAC address] View the projector’s gateway View the projecto’s MAC address as address as follows.
Page 170: Enabling/Disabling Dhcp
Completing Projector Settings Enabling/Disabling Specifying TCP/IP DHCP Settings > [Network settings] > [Detailed settings > [Network settings] > [Detailed settings (wired)] > [DHCP] (wired) ] > [TCP/IP setting] You can turn the projector DHCP Configure the projector TCP/IP function on or off. settings.
Page 171: Initializing Network Settings
Completing Projector Settings Initializing Network Specifying PJLink Settings Settings [PJLink] > [Network settings] > [Detailed settings > [Network settings] > (wired)] > [Network setting You can turn the PJLink network initialization] function on or off. When the function You can initialize the projector is turned on, control is possible via network settings.
Page 172: Specifying Use Of Amx Device Discovery
Completing Projector Settings Specifying Use of What is PJLink? AMX Device In September 2003, the PJLink Discovery Working Group was established under the Data Projector Committee. During the first year, this PJLink [AMX Device > [Network settings] > Working Group standardized PJLink Discovery] as a new interface specification for In a network environment, AMX...
Page 173: Specifying Use Of Crestron Roomview
Completing Projector Settings Specifying Use of Crestron RoomView [Crestron > [Network settings] > RoomView] Crestron RoomView enables centralized management of multiple projectors over a network. For example, projectors can be remotely controlled to troubleshoot issues, check the useful life of lamps, or turn the projectors on or off.
Page 174: Completing Computer Settings
Completing Computer Settings Specifying an IP Address Following is an explanation of how to set the PC IP address for each operating system. ■ Windows 7 From the PC [Start] menu, select [Control Panel]. Click on [Network and Internet], then click on [View network status and tasks].
Page 175: Windows Vista
Completing Computer Settings ■ Windows Vista From the PC [Start] menu, select [Control Panel]. Click on [View network status and tasks]. From the menu on the left side of the window, click on [Manage network connections]. Right-click [Local Area Connection], and open [Properties]. Select [Internet Protocol Version 4 (TCP/IPv4)] and click the [Properties] button.
Page 176: Windows Xp
Completing Computer Settings ■ Windows XP From the PC [Start] menu, select [Control Panel]. Select [Network and Internet Connections] and open [Network Connections]. Right-click [Local Area Connection], and open [Properties]. Select [Internet Protocol (TCP/IP)] and click the [Properties] button. Make a note of the original network settings (IP address, subnet mask, default gateway, etc.).
Page 177: Resetting The Ip Address Setting Of The Computer
Completing Computer Settings Create a new network environment and set the IP address and subnet mask. The factory default IP address for the projector is “192.168.254.254”. Set an IP address which is different from this. Example IP address: 192.168.254.1 Subnet mask: 255.255.255.0 Click [Apply] to close the network preference window.
Page 178 Completing Computer Settings The following information is displayed. Network Multiple Projection For downloading the Networked Multi-Projection Download (NMPJ) program. (P207) Projector control Displays the projector control screen. Settings Shows the settings screen. Projector name The name of the projector on the network Location The location of projector installation MAC address...
Page 179: Network Setting
Completing Computer Settings The projector settings screen is displayed in the web browser. To operate the projector from the computer, click [Projector control] (P191). ■ Network setting To access the settings screen, click [Settings] on the web screen in step 3 of “Displaying the Network Configuration Screen”...
Page 180 Completing Computer Settings A confirmation window appears. Check the contents and if they are correct, click [Apply]. The settings are applied to the projector. When you select [Network] in the menu, this message is displayed: “Save completed. Please change setting and reconnect.” If you select functions other than [Network], “Save completed”...
Page 181 Completing Computer Settings Item Explanation Factory default setting Password User name When logging into the web root screen, enter the user name in 1-byte alphanumeric characters and symbols (4 - 15 characters). New password When logging into the web system screen, enter the password in 1-byte alphanumeric characters and symbols (4 -...
Page 182 Completing Computer Settings Specifying Networked Multi-Projection Settings: [NMPJ Password] From [NMPJ Password] in the settings screen, you can specify the items needed for NMPJ authentication. For the setting procedure, refer to “Displaying the Network Configuration Screen” (P177). Item Explanation Factory default setting Password Enter the password for <Blank>...
Page 183 <Blank> mails in 1-byte alphanumeric characters and symbols (1 - 63 characters). From: Enter the sender address for Projector@canon.co.jp error mails in 1-byte alphanumeric characters and symbols (1 - 63 characters). SMTP server IP address Enter the SMTP server IP 0.0.0.0...
Page 184 Completing Computer Settings Mail Authentication Settings [Mail auth] From [Mail auth] in the settings screen, you can configure the settings for authentication of mail that is sent when an error occurs. For the setting procedure, refer to “Displaying the Network Configuration Screen” (P177). Item Explanation Factory default setting...
Page 185 The sender address which was set from [Mail] in the settings screen (P182) is displayed. Subject: The predetermined mail title “Canon Projector test” is displayed. SNMP Settings [SNMP] From [SNMP] in the settings screen, you can configure the settings related to control of projectors which use SNMP (Simple Network Management Protocol).
Page 186 For the setting procedure, refer to “Displaying the Network Configuration Screen” (P177). Item Explanation Factory default setting Projector name Enter the projector name in 1-byte Canon Projector001 alphanumeric characters and symbols (1 - 63 characters). Location Enter the projector installation location <Blank> in 1-byte alphanumeric characters and symbols (0 - 63 characters).
Page 187 Completing Computer Settings Setting PJLink [PJLink] From [PJLink] in the settings screen, you can set the PJLink functions which are the standard for projector management on a network. For the setting procedure, refer to “Displaying the Network Configuration Screen” (P177). For information about PJLink, refer to “What is PJLink?”...
Page 188: Setting Errors
Completing Computer Settings Factory default Item Explanation setting IP ID Specify the controller’s IP ID. IP address Specify the controller’s IP address. 127.0.0.1 Port number Specify the controller’s port number. 41794 Setting Errors When a setting-related error occurs, the error name is displayed on the screen, and a “!”...
Page 189 Completing Computer Settings Resetting Network Settings to the Default Settings Perform steps 1 - 3 on “Displaying the Network Configuration Screen” (P177) to display the settings screen. Click [Initialize]. A confirmation window appears. Click [OK].
Page 190: Error List
Completing Computer Settings ■ Error notification mails The messages shown in the following error list are sent when an error occurs in the projector. Error list Errors related to Error name Temperature abnormality temperature Text The temperature inside the projector is too high for some reason or the outside air temperature is higher than the specified one.
Page 191: Control Via The Web Screen
Completing Computer Settings Control via the Web Screen When the projector is connected to a network, it is possible to control the projector from a computer via the network. Turn on the computer and projector. Launch a web browser, enter “http://(projector IP address)” in the address bar, and press the Enter key.
Page 192 Completing Computer Settings Item Explanation Projector name The name of the connected projector is displayed. (P186) IP address The IP address of the connected projector is displayed. (P191) Refresh Refreshes the displayed contents with the most recent information. Power Turns projector power on or off. Input Select an input signal and click [Apply] to change to that input signal.
Page 193: Maintenance
Table of Contents Safety Instructions Maintenance Before Use Projecting an Image Useful Functions Available During a Presentation Setting Functions from Menus Installation Connecting to a Network Maintenance Networked Multi-Projection Overview Operation in Each Mode Functions in All Modes Other Information Index...
Page 194: Cleaning The Projector
Cleaning the Projector Clean the projector frequently to prevent dust from settling on the surface. A dirty lens may ruin the quality of the projected image. When cleaning the projector, make sure to turn off the projector, wait until the cooling fan stops, disconnect the power plug from the electrical outlet, and let the projector stand for at least 1 hour.
Page 195: Cleaning And Replacing The Air Filter
Cleaning and Replacing the Air Filter Replacing the Air Filter Follow the procedure below when replacing the air filter. Turn off the projector power and remove the power plug. As you press the top and bottom of the air filter cover to release the lock, remove the cover.
Page 196: Cleaning The Air Filter
• Handle the air filter carefully. If damaged, the air filter will not work properly. • When the lamp is replaced, it is recommend that you also clean or replace the air filter. • Contact the Canon Customer Support Center for further information. • Replacement air filter part number: RS-FL02 •...
Page 197: Replacing The Lamp
Replacing the Lamp When the usage time of the lamp exceeds a certain amount of time, the following message (two types) is displayed for 10 seconds every time the projector is turned 2,700 hours to less than 3,000 hours Prepare a new lamp when this screen is displayed. •...
Page 198: Replacement Lamp
If the illumination suddenly stops when the projector is in use or after you turn it on, the lamp may be broken. In this case, never attempt to replace the lamp by yourself. Always request service from the Canon Customer Support Center. Additionally, with ceiling-mounted projectors, the lamp may fall out when you open the lamp cover or while you are attempting to replace it.
Page 199 Replacing the Lamp As you hold down the lamp cover release button, slide the lamp cover toward the back, and then lift the cover to open it. Release button As you slide the lamp cover toward the back, be careful not to pinch your fingers between the lamp cover.
Page 200: If The Lamp Cover Comes Off
• We recommend cleaning or replacing the air filter (part no.: RS-FL02) when you replace the lamp. • Contact the Canon Customer Support Center for further information. ■ If the lamp cover comes off Align the point of attachment on the lamp cover with the groove on the projector...
Page 201: Networked Multi-Projection (Nmpj)
MULTIMEDIA PROJECTOR Networked Multi- Projection (NMPJ)
Page 203: Networked Multi-Projection Overview
Table of Contents Safety Instructions Networked Multi- Before Use Projection Projecting an Image Overview Useful Functions Available During a Presentation Setting Functions from Menus Installation Connecting to a Network Maintenance Networked Multi-Projection Overview Operation in Each Mode Functions in All Modes Other Information Index...
Page 204: Introduction To Networked Multi-Projection
Introduction to Networked Multi-Projection ■ Projection Over a Network Networked Multi-Projection (NMPJ) is a projector function enabling projection of computer screens over a local network. Multiple computers and multiple projectors can be connected, for a variety of projection scenarios. Links computers and projectors via a network connection. ■...
Page 205: Selecting The Projection Monitor
Introduction to Networked Multi-Projection ■ Selecting the Projection Monitor For multi-monitor computers, you can project either the primary or secondary monitor. Select the primary or secondary monitor for projection For each computer, you can select the monitor to project. Select the primary or secondary monitor of each computer •...
Page 206: Installing The Nmpj Application
Installing the NMPJ Application To use the NMPJ function, you must install the NMPJ application. Instructions in this manual are for installation in a Windows 7 environment. System Requirements Application system requirements are as follows. Core 2 Duo P8600, 2.4 GHz or higher (32- or 64-bit) Memory 1 GB or more 32 GB or more...
Page 207: Installation
Installing the NMPJ Application Installation The application is stored in the projector’s internal memory. To install it on a computer, use a web browser on the computer to access the projector and download the application. For instructions on connecting to the computer over a network, refer to “Connecting to a Network”...
Page 208 Installing the NMPJ Application If a [User Account Control] message is displayed, click [Yes]. Next, follow the instructions displayed to complete the installation process. • In Windows 7 and Windows Vista, confirmation or warning messages may be displayed during installation or uninstallation. These messages request administrator credentials from the current user.
Page 209: Uninstallation
Installing the NMPJ Application ■ Uninstallation Select [Start] > [All Programs] > [Canon NMPJ] > [Uninstall network multiple projection]. If a [User Account Control] message is displayed, click [Yes]. After the confirmation message is displayed, click [OK].
Page 210 Delete the following folder manually. Windows XP C:\Documents and Settings\<User Name>\Local Settings\Application Data\Canon\NMPJ Windows Vista C:\Users\<User Name>\AppData\Local\Canon\NMPJ Windows 7 C:\Users\<User Name>\AppData\Local\Canon\NMPJ These files are hidden. To view hidden files in Windows Explorer, select [Folder options] > [View] > [Show hidden files, folders, and drives].
Page 211: From Startup To Shutdown
If restarting is requested, always restart the computer. Reinstall the application and try again. (Do not attempt to install the application over an existing installation. Be sure to uninstall it first.) Select [Start] > [All Programs] > [Canon NMPJ] > [Network Multiple Projection]. Windows Firewall The following alert may be displayed the first time you start the application, depending on your Windows Firewall settings.
Page 212 From Startup to Shutdown If the computer is equipped with multiple network adapters, a selection window is displayed. Click [OK] next to the desired network adapter. The same three buttons are shown in the upper right of this window and subsequent windows.
Page 213 From Startup to Shutdown (3) Classroom Mode When multiple computers are connected to multiple projectors. Gives a single presenter control over the specific computer and projector used for projection. (P241) (4) Broadcast Mode When a single computer is connected to multiple projectors. Useful when multiple projectors are installed at various positions in an auditorium to project the same image.
Page 214 From Startup to Shutdown To return to the mode selection menu, click in the upper right. After a confirmation message is displayed, click [Return to menu]. To exit the application, click in the upper right of the mode selection menu.
Page 215: Projection Sessions
From Startup to Shutdown ■ Projection Sessions A session consists of all the computers and projectors used in projection. In Meeting and Classroom modes, the first user must create a session for the computers and projectors involved. Other users join the session by selecting it from a list of sessions.
Page 217: Operation In Each Mode
Table of Contents Safety Instructions Operation in Each Before Use Mode Projecting an Image Useful Functions Available During a Presentation Setting Functions from Menus Installation Connecting to a Network Maintenance Networked Multi-Projection Overview Operation in Each Mode Functions in All Modes Other Information Index...
Page 218: Using The Projector In Direct Mode
Using the Projector in Direct Mode In this mode, one computer is connected to one projector over the network. Procedure In the mode selection menu, select [Direct Mode]. The Direct Mode window is displayed. Click To connect to projectors in another subnet, enter the projector’s IP address in the [PJ IP address] field and click...
Page 219 Using the Projector in Direct Mode The projector selection menu is displayed. Click the projector to connect For details on the projector selection menu, refer to “Using the Projector Selection Menu” (P254). The Direct Mode window is displayed again. Click [Start projecting]. The computer screen is now projected.
Page 220: Direct Mode Window
Using the Projector in Direct Mode Direct Mode Window (1)(2)(3)(4)(5) (10) (11) (12) (13) (14) (15) (1) Help View application help. (2) Back to mode selection Return to the mode selection menu. (3) Compact display View the window at a compact size. (P270) (4) Minimize Minimize the window to the taskbar.
Page 221 Using the Projector in Direct Mode (7) IP address To connect to projectors in another subnet, enter the projector’s IP address here and click (8). (8) Find projectors Find the projector with the IP address entered in (7). Results of projector searching are shown in (9).
Page 222: Using The Projector In Meeting Mode
Using the Projector in Meeting Mode In meeting mode, multiple computers are connected to multiple projectors. This mode is intended for group meetings where multiple computers are used. Up to ten computers and six projectors can be connected. Creating a Session In the mode selection menu, select [Meeting Mode].
Page 223 Using the Projector in Meeting Mode The projector selection menu is displayed. In the list of projectors at left, click the projector to connect to. You can select up to 6 projectors. Selected projectors are listed at right. • If the [NMPJ Password] setting has been configured on the projector’s settings screen (P182), the password is now requested.
Page 224 Using the Projector in Meeting Mode A window for creating the session is displayed. Specify a session name, password, nickname, and desktop (primary or secondary monitor for projection), and then click [OK]. • If you choose to set a session password, other users must enter that password to join the session.
Page 225 Using the Projector in Meeting Mode In the list at right, select a computer to use with your designated projector. Drag the computer to a desired position in the layout area. You can arrange up to four computers as desired in the layout area. Drag the computers for use in projection in the layout area to rearrange them, as needed.
Page 226 Using the Projector in Meeting Mode Click [Start projecting]. Images are now projected from the computers in the layout area. • To stop projection, click [Stop projecting]. • To rearrange the layout during projection, click [Start projecting] again. Note that if you simply rearrange the layout, the new layout will not be applied to projection.
Page 227 Using the Projector in Meeting Mode The following confirmation message is displayed. To end the entire session, click [Close]. To leave the session, click [Exit]. Return to the mode selection menu. [Exit] is not shown unless other computers are connected.
Page 228: Joining A Session
Using the Projector in Meeting Mode Joining a Session In the mode selection menu, select [Meeting Mode]. The session selection menu is displayed. Click [Enter] next to the session to join. To join a session in another subnet, click and enter the projector’s IP address to locate the projector.
Page 229 Using the Projector in Meeting Mode A session login window is displayed. Specify the session password, your nickname, and desktop (primary or secondary monitor for display), and then click [OK]. Desktop selection is only available with computers that have dual monitor support. The Meeting Mode window is displayed.
Page 230: Meeting Mode Window
Using the Projector in Meeting Mode Meeting Mode Window (1) (2) (3) (4) (5) (10) (11) (12) (15) (16) (13) (14) (1) Help View application help. (2) Back to mode selection Return to the mode selection menu. (3) Compact display View the window at a compact size.
Page 231 Using the Projector in Meeting Mode (7) Projector pull-down list Lists connected projectors. Your actions on this screen apply to the projector selected here. (8) Computers Lists connected computers. To prepare computers for projection, drag them to the layout area. Your own computer is listed first. , the computer’s display position is indicated by a white square.
Page 232: Using The Projector In Classroom Mode
Using the Projector in Classroom Mode In classroom mode, multiple computers are connected to multiple projectors. A single presenter can control any computer or projector used for projection, whether their own or those of others in attendance. Up to ten computers and six projectors can be connected.
Page 233 Using the Projector in Classroom Mode The projector selection menu is displayed. In the list of projectors at left, click the projector to connect to. You can select up to 6 projectors. Selected projectors are listed at right. • If the [NMPJ Password] setting has been configured on the projector’s settings screen (P182), the password is now requested.
Page 234 Using the Projector in Classroom Mode A window for creating the session is displayed. Specify a session name, password, nickname, and desktop (primary or secondary monitor for projection), and then click [OK]. • If you choose to set a session password, other users must enter that password to join the session.
Page 235 Using the Projector in Classroom Mode In the list at right, select a computer to use with your designated projector. Drag the computer to a desired position in the layout area. You can arrange up to four computers as desired in the layout area. Drag the computers for use in projection in the layout area to rearrange them, as needed.
Page 236 Using the Projector in Classroom Mode Click [Start projecting]. Images are now projected from the computers in the layout area. • To stop projection, click [Stop projecting]. • To rearrange the layout during projection, click [Start projecting] again. Note that if you simply rearrange the layout, the new layout will not be applied to projection.
Page 237 Using the Projector in Classroom Mode The following confirmation message is displayed. Click [Close]. Return to the mode selection menu.
Page 238: Joining An Existing Session
Using the Projector in Classroom Mode Joining an Existing Session In the mode selection menu, select [Classroom Mode]. The session selection menu is displayed. Click [Enter] next to the session to join. To join a session in another subnet, click and enter the projector’s IP address to find the projector.
Page 239 Using the Projector in Classroom Mode A session login window is displayed. Specify the session password, your nickname, and desktop (primary or secondary monitor for display), and then click [OK]. Desktop selection is only available with computers that have dual monitor support. The Classroom Mode window (for joining a session) is displayed.
Page 240 Using the Projector in Classroom Mode To end the session, click in the upper right. The following confirmation message is displayed. Click [Exit]. Return to the mode selection menu.
Page 241: Classroom Mode Window (Starting A Session)
Using the Projector in Classroom Mode Classroom Mode Window (Starting a Session) (2) (3) (4) (5) (10) (11) (12) (15) (16) (13) (14) (1) Help View application help. (2) Back to mode selection Return to the mode selection menu. (3) Compact display View the window at a compact size.
Page 242 Using the Projector in Classroom Mode (7) Projector pull-down list Lists connected projectors. Your actions on this window apply to the projector selected here. (8) Computers Lists connected computers. To prepare computers for projection, drag them to the layout area. Your own computer is listed first. , the computer’s display position is indicated by a white square.
Page 243: Classroom Mode Window (Joining A Session)
Using the Projector in Classroom Mode Classroom Mode Window (Joining a Session) (1) (2) (3) (4) (5) (10) (11) (1) Help View application help. (2) Back to mode selection Return to the mode selection menu. (3) Compact display View the window at a compact size. (P270) (4) Minimize Minimize the window to the taskbar.
Page 244 Using the Projector in Classroom Mode (7) Layout area Lists computers selected for projection. (8) Projection status Indicates the projection status. (9) Computer A number is shown here only when secondary monitor connectivity is activated on the computer you are using. Clicking the number will switch between the primary and secondary monitor.
Page 245: Using The Projector In Broadcast Mode
Using the Projector in Broadcast Mode In Broadcast Mode, a single computer is connected to up to 12 projectors. Before projecting from projectors in other subnets in Broadcast Mode, you must configure the router’s multicast routing settings. For details, ask your network administrator. Procedure In the mode selection menu, select [Broadcast Mode].
Page 246 Using the Projector in Broadcast Mode • If the [NMPJ Password] setting has been configured on the projector’s settings screen (P182), the password is now requested. Enter the password. • To clear a selected projector, click in the upper right of that projector listing. •...
Page 247 Using the Projector in Broadcast Mode To end the session, click in the upper right. The following confirmation message is displayed. Click [Close]. Return to the mode selection menu.
Page 248: Broadcast Mode Window
Using the Projector in Broadcast Mode Broadcast Mode Window (1) (2) (3) (4) (5) (9) (10) (11) (1) Help View application help. (2) Back to mode selection Return to the mode selection menu. (3) Compact display View the window at a compact size. (P270) (4) Minimize Minimize the window to the taskbar.
Page 249 Using the Projector in Broadcast Mode (7) Projection status Shows the projected image status. (8) Switch primary/secondary monitor A number is shown here only when secondary monitor connectivity is activated on the computer you are using. Clicking the number will switch between the primary and secondary monitor.
Page 251: Functions In All Modes
Table of Contents Safety Instructions Functions in All Before Use Modes Projecting an Image Useful Functions Available During a Presentation Setting Functions from Menus Installation Connecting to a Network Maintenance Networked Multi-Projection Overview Operation in Each Mode Functions in All Modes Other Information Index...
Page 252: Using The Session Selection Menu
Using the Session Selection Menu Session Selection Menu (1) (2) (3) (4) (1) Help View application help. (2) Back to mode selection Return to the mode selection menu. (3) Minimize Minimize the window to the taskbar. To view the window again, click the taskbar icon.
Page 253: Finding Sessions
Using the Session Selection Menu (8) [Enter] Join the session. (P228) Finding Sessions You can find sessions from the session selection menu. In the session selection menu, click The search window is displayed. Enter the IP address of a projector in the session to join, and then click to find the projector.
Page 254: Using The Projector Selection Menu
Using the Projector Selection Menu Projector Selection Menu (3) (4) (5) (6) (1) Find projectors Find projectors in another subnet. (P256) (2) Sort Change the sort order of the projector list. (P259) (3) Help View application help. (4) Back to mode selection Return to the mode selection menu.
Page 255 Using the Projector Selection Menu (7) Projector list Projectors are listed here. The information shown includes the projector names, installation location, and IP address. Available projectors are indicated by white text. Gray text indicates that the projector is not available, whether it is off, in use by other computers, or unavailable for other reasons.
Page 256: Finding Projectors
Using the Projector Selection Menu ■ Finding Projectors To find projectors in other subnets, do the following in the projector selection menu. In the projector selection menu, click The search window is displayed. Enter the projector’s IP address, and then click...
Page 257: Selecting Password-Protected Projectors
Using the Projector Selection Menu Once the projector is found, click [OK]. The selected projector is now added to the projector list. ■ Selecting Password-Protected Projectors Selecting a password-protected projector will display a password input field. Enter the password.
Page 258: Using The Favorites Function
Using the Projector Selection Menu ■ Using the Favorites Function You can register commonly used projectors as favorites. Favorite projectors are listed first when you click the button (sort by favorites). Up to five projectors can be registered as favorites. To register a projector as a favorite, click the Favorites icon in the projector selection menu.
Page 259: Resorting The Projector List
Using the Projector Selection Menu ■ Resorting the Projector List You can change the sort order of projector information by clicking the sort buttons. List by projector name. List by installation location. List projectors that are currently on first. List favorite projectors first. ■...
Page 260: Using Layout Functions
Using Layout Functions ■ Switching Projectors Used for the Layout On the layout window, you can set up the projection layout. To choose a different projector for the layout, select it from the projector pull-down list. ■ Controlling all Projectors at Once To set up the projection layout for all projectors at once, select [ALL] in the projector pull-down menu.
Page 261: Projecting From Multiple Projectors (Multi-Projection)
Using Layout Functions ■ Projecting from Multiple Projectors (Multi-Projection) In Meeting and Classroom Modes, separate images from multiple projectors can be projected together. This is called “multi-projection.” On the layout window for Meeting or Classroom Modes, you can set up the projection layout for each projector used.
Page 262: Switching The Primary/Secondary Monitor
Using Layout Functions ■ Switching the Primary/Secondary Monitor Using the application, you can switch between projection from the primary or secondary monitor. If your computer has dual monitor support, the computer icons are labeled with numbers. The primary monitor is labeled “1,” and the secondary one, “2.” To switch the monitor used for projection, click the icon of computers shown with a number.
Page 263: Projecting Session Information
Using Layout Functions ■ Projecting Session Information You can project session information needed by other users to join a session, such as the session name and projector IP address. To project session information, click . To cancel display, click again. ■...
Page 264 Using Layout Functions Meeting Mode window Classroom Mode window (starting a session)
Page 265: Blanking Projection From Your Computer
Using Layout Functions Broadcast Mode window ■ Blanking Projection from Your Computer In Meeting and Classroom Modes, you can blank projection your computer alone. To blank projection from your computer, click in the computer list. To cancel blanking and return to normal projection, click again.
Page 266: Checking For Computers That Join Or Leave Sessions
Using Layout Functions Classroom Mode window (joining a session) ■ Checking for Computers That Join or Leave Sessions In Meeting and Classroom Modes, computer users can join or leave sessions as needed. Computers joining a session are added to the computers listed on the layout window.
Page 267 Using Layout Functions Similarly, computers leaving a session are removed from the list of computers.
Page 268: Completing Application Projection Settings
Completing Application Projection Settings Application settings can be configured to specify the image quality of computer projection, user nicknames, and other details. Click next to the computer icon. The settings window is displayed. Complete each setting as needed, and then click [OK]. Available settings are as follows.
Page 269 Completing Application Projection Settings Picture qual setting Select one of the following options, depending on your preferred image quality and frame rate. High : Projects at a lower frame rate while emphasizing image quality. Select this mode if lower image quality is not acceptable.
Page 270: Reducing Windows To A Compact Size
Reducing Windows to a Compact Size A compact version of windows in all modes is available, showing only the minimum buttons and information needed. Click The window is now reduced to a compact size. The title bar is no longer displayed when the cursor is away from the window, which makes the window even more compact.
Page 271: Tips For Better Networked Projection
Tips for Better Networked Projection ■ Avoid Exceeding Connection Limits The maximum number of computers and projectors that can be connected varies by mode. When this limit would be exceeded, it is not possible to add computers or projectors to a session. Thus, if the total number of computer users requesting to join a session at the same time would exceed the limit, their requests may be denied.
Page 272: Restrictions
Restrictions ■ Router Connections Although the application can also link computers and projectors over a network via a router, operation is only ensured over one router hop. Note that before projecting from projectors in other subnets in Broadcast Mode, you must configure the router’s multicast routing settings.
Page 273: Appendix
MULTIMEDIA PROJECTOR Appendix...
Page 275: Appendix
Table of Contents Safety Instructions Appendix Before Use Projecting an Image Useful Functions Available During a Presentation Setting Functions from Menus Installation Connecting to a Network Maintenance Networked Multi-Projection Overview Operation in Each Mode Functions in All Modes Other Information Index...
Page 276: Troubleshooting
(only) flashes 4 cooling fan another component. Unplug the projector from times the electrical outlet, then plug it back into the repeatedly. outlet and turn on the projector again. Contact the Canon Customer Support Center if the same warning occurs again.
Page 277: Symptoms And Solutions
Unplug the projector from the electrical repeatedly. outlet, then plug it back into the outlet and turn on the projector again. Contact the Canon Customer Support Center if the same warning occurs again. WARNING Filter error The air filter is not installed.
Page 278: You Cannot Project An Image From The Projector
Troubleshooting ■ You Cannot Project an Image from the Projector Cause Countermeasure A cable is not connected Check whether the projector is connected to the correctly. computer or AV equipment correctly. (P134, P137) 20 seconds have not When the projector is turned on, the opening window elapsed since the is displayed for approximately 20 seconds.
Page 279: There Is No Sound
Troubleshooting Cause Countermeasure Images on a USB flash Projection from USB flash drives requires JPEG drive cannot be images with a resolution not exceeding 7000x7000, projected. single-byte alphanumeric file names, and a FAT- formatted drive. Split-screen display is Split-screen display is not available when projecting not available.
Page 280: The Projected Image Is Blurred
Troubleshooting ■ The Projected Image Is Blurred Cause Countermeasure The image is out of Adjust the focus. (P56) focus. The distance to the Check whether the distance to the screen is screen is too short. appropriate. If the distance is shorter than approximately 1.3 m (4.3'), the projector cannot focus on the screen.
Page 281: You Cannot Project An Image Appropriately
(P27, P197, P198) The operating Check whether the operating temperature is between temperature is 0°C and 40°C. (P29) inappropriate. If you use the projector at 2,300 m (7,545.8') or higher above sea level, contact the Canon Customer Support Center.
Page 282: You Cannot Operate The Remote Control
Check the system requirements (P206). If the above causes cannot be identified, the projector may be damaged. Contact the Canon Customer Support Center as soon as possible. Administrator privileges are required when installing NMPJ from the universal installer. The following message is displayed when you are logged in as a regular user:...
Page 283: Relationship Between Aspect And Screen Aspect
Relationship between Aspect and Screen Aspect This section describes the relationship between screen aspect (P57) and aspect (P63). Select an optimum aspect ratio of the projected image (screen aspect) or an optimum screen mode (aspect) according to the aspect ratio of the screen, type of input image signal and so on for the projection to make best use of the screen size.
Page 284: When The Image Is Projected On A 16:9 Screen
Relationship between Aspect and Screen Aspect ■ When the image is projected on a 16:9 screen Aspect ratio of Screen aspect Aspect setting (P63) Screen image connected device setting (P57) (16:10) 1920 x 1200 [16:9] 1440 x 900 1280 x 800 (16:9) [16:9] [16:9]...
Page 285: When Projecting On A 16:10 Screen In The Aspect Ratio Of The Connected Device
Relationship between Aspect and Screen Aspect ■ When projecting on a 16:10 screen in the aspect ratio of the connected device Aspect ratio of Screen aspect Aspect setting (P63) Screen image connected device setting (P57) (16:10) 1920 x 1200 [16:10] 1440 x 900 [Auto] 1280 x 800...
Page 286: When Projecting On A 4:3 Screen In The Aspect Ratio Of The Connected Device
Relationship between Aspect and Screen Aspect ■ When projecting on a 4:3 screen in the aspect ratio of the connected device Aspect ratio of Screen aspect Aspect setting (P63) Screen image connected device setting (P57) (16:10) 1920 x 1200 [Auto] 1440 x 900 1280 x 800 (16:9)
Page 287: Displayed Test Patterns
Displayed Test Patterns The test pattern can be displayed by pressing the TEST PATTERN button. Use this when there is no image signal, etc. While the test pattern is displayed, you can use the [ ] / [ ] buttons to change to a different test pattern.
Page 288: Supported Signal Types
Supported Signal Types This projector supports the following signal types. If your computer or AV equipment is compatible with any one of these signal types, the projector’s Auto PC function selects the input signal type to project an image appropriately. Analog PC Horizontal frequency Resolution (dots)
Page 289 25.000 33.750 30.000 *1: WUX450, *2: WX520 * The specifications in the table above are subject to change without notice. * This projector does not support any computer output signal with a dot clock of higher than 162 MHz. * Use a computer cable in which all pins are connected. If the cable is a type in which all pins are not...
Page 290: Product Specifications
Product Specifications ■ Projector Model name WUX450 WX520 Display system RGB liquid crystal system Color separation by dichroic mirror / polarizing beam splitter Optical system and color composition by prism Type Reflective liquid crystal panel Size / Aspect ratio 0.71'' x 3 / 16:10 0.70'' x 3 / 16:10...
Page 291: Remote Control
Accessories PC connection cable, lens cap, User’s Manual (this manual), Important Information and Warranty Card WUX450 only Compliance with ISO21118-2012 * 99.99% or more of the LCD panel pixels are effective. During projection, 0.01% or less of pixels may stay lit or unlit due to the characteristics of the LCD panel.
Page 292: External View
Product Specifications ■ External View 91.5 mm 362 mm (14.3") (3.6") 337 mm (13.3") 370 mm (14.6") 33 mm (1.3") 301 mm (11.9") Bolt holes (M6 x 4) for installation of ceiling attachment...
Page 293: Communication Format
Product Specifications ■ ANALOG PC-2 / COMPONENT terminal This terminal is used as a computer ANALOG PC input or COMPONENT input terminal. Use a D-sub computer cable for connection. The terminal specifications for the ANALOG PC input and COMPONENT input are the same.
Page 294: Control Commands
Product Specifications Control commands Commands ASCII representation Binary representation Power on POWER=ON<CR> 50h 4Fh 57h 45h 52h 3Dh 4Fh 4Eh 0Dh Power supply 50h 4Fh 57h 45h 52h 3Dh 4Fh 46h 46h Power off POWER=OFF<CR> Power status 47h 45h 54h 3Dh 50h 4Fh 57h 45h 52h GET=POWER<CR>...
Page 295 Product Specifications Commands ASCII representation Binary representation Sharpness 47h 45h 54h 3Dh 53h 48h 41h 52h 50h GET=SHARP<CR> acquisition Contrast value 43h 4Fh 4Eh 54h 3Dh <numeric code> Contrast CONT=<value><CR> setting Contrast GET=CONT<CR> 47h 45h 54h 3Dh 43h 4Fh 4Eh 54h 0Dh acquisition 41h 53h 50h 45h 43h 54h 3Dh 41h 55h Auto...
Page 296: Index
Index Numerics 6-axis color adjust ......102 D. ZOOM ...........76 DHCP ..........170 Digital image shift ......60 Digital PC ........51, 135 Adjusting keystone distortion .... 65 Direct Mode........218 Adjusting the volume......75 Direct power on .......109 Air filter..........195 Display resolution (Preparing the Ambient light ........
Page 297 Index IMAGE ..........69 Network function .....166, 167, 168 Image adjustment menu ....82 Network password setting ....166 Image flip H/V (Ceiling mounted / Rear Network setting initialization ....171 projection)........143 Network settings........82 Image mode (Image quality) ..... 68 Network settings lock ......165 Information ........
Page 298 Index Split-screen display ......79 System settings menu....... 82 TCP/IP settings ....... 170 Test pattern ......154, 287 Total dots........... 87 Tracking ..........87 True size (Aspect) ......63 Turning on external monitor output (preparing the notebook computer) ............. 142 USB...........
Page 299: Option
Option • Lamp • Air filter Part No.: RS-LP08 Part No.: RS-FL02 • Ceiling attachment • Remote control Part No.: RS-CL12 Part No.: RS-RC06 • Ceiling-mount pipe RS-RC05 (400 - 600 mm / 15.7 - 23.6 in) • Option feet Part No.: RS-CL08* Part No.: RS-FT01 •...
Page 300: Menu Configuration
Menu Configuration Input Settings Menu *: Factory defaults (setting after reset) Digital PC / Analog PC-1/2 / HDMI (when [HDMI In] is Aspect [Computer]) Auto* 16:10 16:9 True size HDMI (when [HDMI In] is [Auto]) / Component Auto* 16:9 Zoom True size USB / LAN Auto...
Page 301: Image Adjustment Menu
Menu Configuration Slideshow interval [--:--] [60:00] Split screen Digital PC / Analog PC-1/2 / HDMI / Component Off* Settings Split screen Control rights Left screen Right screen Image Adjustment Menu Image priority (in split-screen COMMON mode) Primary Secondary Image mode COMMON Photo/sRGB* User 1 - 5...
Page 302 Menu Configuration Advanced adjustment Ambient light (when Photo/sRGB is P100 Off* selected) Adjust Type Tungsten Fluorescent Level Noise reduction*2 P101 Weak Middle Strong Dynamic gamma*3 P101 Weak Middle Strong Mem. color correct*4 Flesh Off* P102 Weak Green Middle Strong 6-axis color adjust Off* P102 Hue / Saturation /...
Page 303 Menu Configuration Install Settings Menu Positional lock Off* P143 Image flip H/V None* P143 Ceiling mounted Rear Rear, Ceiling mounted Screen aspect 16:10* P145 16:9 16:9 D. image shift 4:3 D. image shift Keystone Horizontal-vertical keystone* P146 Corner adjustment Reset Digital image shift D.image shift adjustment P146...
Page 304 Menu Configuration Digital PC P149 Audio in 1* Audio in 2 Analog PC-1 P149 Audio in 1* Audio in 2 Analog PC-2 P149 Audio in 1 Audio in 2* Component P149 Audio in 1 Audio in 2* Screen color Normal* P149 Greenboard Adjust...
Page 305: System Settings Menu
Black P107 Blue* User logo Screen when blank Black* P107 Blue User logo Projector on Skip P108 Canon logo* User logo Auto power-off 5 min. P108 10 min. 15 min.* 20 min. 30 min. 60 min. Disabled Direct power on...
Page 306: Network Settings Menu
Menu Configuration HDMI In Auto* P113 Computer Language English Turkish P113 German Polish French Hungarian Italian Czech Spanish Danish Portuguese Arabic Chinese Swedish (Simplified) Chinese Russian (Traditional) Dutch Korean Finnish Japanese Norwegian Other settings Password settings Off* P114 Register password Password input P115 Gamma restore...
Page 307 Menu Configuration Gateway address P169 MAC address P169 DHCP Off* P170 TCP/IP settings IP address P170 Subnet mask Gateway address Enter Network setting initialization P171 IP address (wired) Shows the IP address PJLink P171 AMX Device Discovery Off* P172 Crestron RoomView Off* P173 Information...
Page 308 CANON Belgium N.V. / S.A. U.S.A. Berkenlaan 3, 1831 Diegem (Mechelen), CANON U.S.A. INC. Belgium One Canon Park, Melville, New York 11747, CANON Netherland NV U.S.A. Neptunusstraat 1, 2132 JA Hoofddorp, The For all inquires concerning this product, call toll Netherlands free in the U.S.
