HOLUX M-1200E Bluetooth GPS Logger User's Manual
Bluetooth GPS Logger
M-1200E
User's Guide
Rev. 1.0
Technology, Inc.
No.1-1, Innovation Road I, Science-based Industrial Park, HsinChu City 300, Taiwan
TEL: 886-3-6687000 FAX: 886-3-6687111
Website: www.holux.com
All Right Reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M-1200E and is the answer not in the manual?

Questions and answers

Related Manuals for Holux M-1200E

Summary of Contents for Holux M-1200E

  • Page 1 HOLUX M-1200E Bluetooth GPS Logger User’s Manual Bluetooth GPS Logger M-1200E User’s Guide Rev. 1.0 Technology, Inc. No.1-1, Innovation Road I, Science-based Industrial Park, HsinChu City 300, Taiwan TEL: 886-3-6687000 FAX: 886-3-6687111 Website: www.holux.com All Right Reserved...

  • Page 2: Table Of Contents

    HOLUX M-1200E Bluetooth GPS Logger User’s Manual Table of Contents OVERVIEW ..........................2 .......................... 3 AIN FEATURES TECHNICAL SPECIFICATION ....................4 ........................ 4 ASIC PECIFICATION )............. 4 CQUISITION REFER TO CHIP SPECIFICATION ........................ 4 ECEIVER CCURACY ......................... 4 IMITATION ........................... 4...

  • Page 3: Overview

    Overview (Fig.1) The HOLUX M-1200E Wireless GPS Logger allows users to store of up to 200,000 GPS coordinates of latitude, longitude, time, and elevation. The data can be analyzed by uploading to a computer through its USB/Bluetooth connection. Once the coordinates and the digital images are integrated, the tracking history and the location the images were taken can be shared through ezTour or Google Earth.

  • Page 4: Main Features

    HOLUX M-1200E Bluetooth GPS Logger Manual Main features Built in MTK MT3329 Low power consumption GPS chipset 66 parallel satellite-search channels for fast acquisition and reacquisition Superior sensitivity up to -165 dBm Built-in WAAS/EGNOS Demodulator without any additional hardware Compatible with Bluetooth Serial Port Profile (SPP) completely...

  • Page 5: Technical Specification

    , max Power Supply External Voltage: 5V DC +/-5% Batteries: Main Power: Built-in rechargeable Li-ion battery for system power. Working voltage: 30~40mA@ 3.7V (Normal mode). 28mA (Power Saving). Auto Power saving mode. Circuit protection on M-1200E when over-temperature 45°C occurs.

  • Page 6: Output And Interface

    HOLUX M-1200E Bluetooth GPS Logger Manual Output and Interface Output I. Output protocol Baud Rate: 38400 bps Data bit: 8 Parity: No Stop bit: 1 II. Format. NMEA0183 V3.01: GPGGA (1time/1 sec), GPGSA (1 time/5 sec.), GPGSV (1time /5 sec.), GPRMC (1time /1 sec.), GPVTG (1 time/1 sec), (GLL, or MTK NMEA Command for optional).

  • Page 7: Getting Started

    HOLUX M-1200E Bluetooth GPS Logger Manual Getting Started 1. Charge Battery Please charge battery till LED off for the first time. Power cable plug in Power cable connect to power socket ↓ Charge Battery Battery indicator light: Mini USB socket...

  • Page 8: Hardware Description

    Press M-1200E POI Button ↓ ↓ POI button Yellow LED on Yellow LED off POI status Hardware Description 1). M-1200E Body description see Fig. 2: LED of GPS (Orange) LED of Battery (Red / Green) Bluetooth LED (Blue) POI LED (Yellow) Power switch...
  • Page 9 HOLUX M-1200E Bluetooth GPS Logger Manual 2). LED status: SYMBOL COLOR STATUS DESCRIPTION 1 time / 1 sec Search Bluetooth Device Blue Blinking 1 time / 1 sec Standby Mode 1 time / 3 sec Transferring Data Record the POI data...

  • Page 10: M-1200E Logger Track Logging And Mode Setting

    HOLUX M-1200E Bluetooth GPS Logger Manual M-1200E Logger Track Logging and Mode Setting 5.2.1 Data Logging 1. When the power is turned on, the device will automatically search for satellite positioning (orange LED on), and then logging will begin. When the power is switched off, the logging will stop.
  • Page 11 HOLUX M-1200E Bluetooth GPS Logger Manual 3. From the Menu bar select [Setup GPS Logger] to bring up the settings window 4. Make sure that the M-1200E is connected to a PC or notebook, and select [reconnect] or [manual settings] 5.
  • Page 12 7. Press [Confirm] to start logging according to the new setting. 5.2.3 Data Read When the logger M-1200E is connected to a PC or notebook through USB or Bluetooth, the data can be extracted through ezTour. Please see ezTour instruction manual for details.

  • Page 13: Installation Of Mini Gps Viewer Program

    HOLUX M-1200E Bluetooth GPS Logger Manual Installation of Mini GPS Viewer program We provide a program “Mini GPS viewer.exe” for end user to watch the satellite signal receiving status on laptop or PDA device. For Windows 2000/XP OS, you can execute “Mini GPS viewer_PC” directly.

  • Page 14: Driver Installation

    I. Starts the driver installer from driver CD. II. Connect USB data cable to computer. System will search new hardware and install the driver automatically III. Connect M-1200E GPS Logger with USB data cable. Important Verify the COM port to start using your own navigation software.
  • Page 15 HOLUX M-1200E Bluetooth GPS Logger Manual Click <Start> menu, select → <Setting>, then enter→ <Controller> After entering <Controller>, and select <System>. III. Select <Device Manager>. IV. Find the < Connector (COM & LPT)> and check the Virtual COM Port, which was created by the USB driver.

  • Page 16: Appendix A. Troubleshooting

    HOLUX M-1200E Bluetooth GPS Logger Manual Appendix A. Troubleshooting Problems Possible Reasons Methods Using ezTour to Turn on the M-1200E power switch, and connect M-1200E power is not turned on. make sure GPS Orange LED is on. Please M-1200E is fail reference 7.3.

  • Page 17: Appendix B. Power Jack & Data Port

    HOLUX M-1200E Bluetooth GPS Logger Manual Appendix B. Power Jack & Data Port Jack type: Mating face of 5 pin Mini USB Type B female. Pin definition see table Table 1 Pin Name Signal and description Signal ground, Battery charging ground.

  • Page 18: Appendix C. Bluetooth Devices Connection

    HOLUX M-1200E Bluetooth GPS Logger Manual Appendix C. Bluetooth Devices Connection The following is the steps of software installation to setup on PDA, DELL AXIM x51v with Bluetooth Manager. For other PDA or laptop device, the steps might vary. 2. In Pocket PC setting system panel, enable “manage GPS automatically”.
  • Page 19 HOLUX M-1200E Bluetooth GPS Logger Manual 6. Connect to “Serial port” or “SPP Slave”, then tap “Finish” 7. Go to the “COM ports” panel to tap “New Outgoing Port”, choose “HOLUX_M-1200E” device and tap “Next”. 8. Select the COM port, then tap finish, it will show as right figure, and tap “OK”...

  • Page 20: Federal Communications Commission (Fcc) Statement

    HOLUX M-1200E Bluetooth GPS Logger Manual Federal Communications Commission (FCC) Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
