button after entering the 6-digit hexadecimal number printed on the ezTCP main body in
the MAC ADDRESS box. It is useful when there are too many ezTCPs attached to the
network to search for one from the LIST box.
This button is used to save the changed value in ezTCP after modifying
the configuration. Make sure not to press this button during operating ezTCP since
ezTCP will automatically be reset right after its environment setup value is saved.
Otherwise, it may cause malfunction.
This button is used to close ezConfig. You can also close it by pressing
ESC key on the keyboard.
ezTCP provides User Authentication function to prevent an unwanted
person from modifying the configuration. The authentication process is performed
through the password string verification. When entering or changing the password
strings, you can use this button. Changing the ezTCP configuration details if a password
has been entered requires the proper password to be entered in the PASSWORD field.
√ If you forget the password, erase or reenter in Console Mode.
This button is used to read a dynamic status during operating ezTCP.
Pressing this button will display a new window, where the time-elapsed after the power
is on, the current IP address, and the data throughput of the serial port are indicated.
Double-clicking each item on the [Search List] will carry out the same function.

4.2.2. Example configuration of ezConfig

ezConfig can be used to change the IP address related items, the serial port setup value,
the serial port operation mode, and how to setup ezTCP. This section describes these
functions briefly. For more information, see the following sections.
The following example shows how to read and change ezTCP‟s basic functions. Try
changing ezTCP setup value according to the following sequence:
You can see only the ezTCP configuration values if you press this
