MODEL
SV 12SG
Hitachi
Power Tools
TECHNICAL DATA
ORBITAL SANDER
AND
SV 12SG
SERVICE MANUAL
S
LIST No. 0353
Jun. 2004
SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT

Advertisement

Table of Contents
loading

Related Manuals for Hitachi SV 12SG

Summary of Contents for Hitachi SV 12SG

  • Page 1 MODEL SV 12SG Hitachi Power Tools TECHNICAL DATA ORBITAL SANDER SV 12SG SERVICE MANUAL LIST No. 0353 Jun. 2004 SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT...
  • Page 2 REMARK: Throughout this TECHNICAL DATA AND SERVICE MANUAL, a symbol(s) is(are) used in the place of company name(s) and model name(s) of our competitor(s). The symbol(s) utilized here is(are) as follows: Competitors Symbols Utilized Company Name Model Name B04552/B04553 MAKITA...

  • Page 3: Table Of Contents

    CONTENTS Page 1. PRODUCT NAME ..........................1 2. MARKETING OBJECTIVE ........................ 1 3. APPLICATIONS ..........................1 4. SELLING POINTS ..........................1 4-1. Selling Point Descriptions ........................2 5. SPECIFICATIONS ..........................3 5-1. Specifications ............................3 6. COMPARISONS WITH SIMILAR PRODUCTS ................. 4 7.

  • Page 4: Product Name

    The Model SV 12SF orbital sander has been on the market for 9 years. To meet a demand for a remodeled, we now offer totally renewed design for increased competitiveness and expanded sale. The Model SV 12SG has been developed to upgrade and replace the current Models SV 8SA, SV 12SA and SV 12SF.

  • Page 5: Selling Point Descriptions

    (3) All new design. The large soft grip comfortably fits in the palm of a hand for ease of operation. The Model SV 12SG has a large soft grip that comfortably fits in the palm of a hand (double molded housing with elastomer).

  • Page 6: Specifications

    5. SPECIFICATIONS 5-1. Specifications Item Specifications Sanding paper size 114 mm x 140 mm (4-1/2" x 5-1/2") Sanding pad size 110 mm x 100 mm (4-3/8" x 4") Orbital diameter 1.5 mm (1/16") Power source AC single phase 50 Hz or 60 Hz Voltage, current and 110 V 120 V...

  • Page 7: Comparisons With Similar Products

    6. COMPARISONS WITH SIMILAR PRODUCTS HITACHI Maker Model • Item SV 12SG SV 12SF 114 x 140 115 x 140 114 x 140 Sanding paper size (4-1/2" x 5-1/2") (4-1/2" x 5-1/2") (4-1/2" x 5-1/2") 110 x 100 116 x 104...

  • Page 8: Precautions In Sales Promotion

    7. PRECAUTIONS IN SALES PROMOTION In the interest of promoting the safest and most efficient use of the Model SV 12SG Orbital Sander by all of our customers, it is very important that at the time of sale the salesperson carefully ensures that the buyer seriously recognizes the importance of the contents of the Handling Instructions, and fully understands the meaning of the precautions listed on the nameplate attached to each tool.

  • Page 9: Precautions In Disassembly And Reassembly

    8. PRECAUTIONS IN DISASSEMBLY AND REASSEMBLY The [Bold] numbers in the descriptions below correspond to the item numbers in the Parts List and exploded assembly diagram. 8-1. Disassembly (1) Removal of the Armature [25] and the Stator [22] Remove the four Machine Screws M4 x 10 [18], and remove the surrounding parts such as the Pad [17], Base [16] and Felt [34].

  • Page 10: Tightening Torques

    (2) Wiring the Stator [22] When wiring the Stator [22], be sure to insert each terminal in correct direction as shown in Fig. 2. At this time, securely insert each terminal as far as it will go. Viewed from the commutator Internal Wire (Blue) [24] Tab Terminal (Blue) [6] Internal Wire (Brown) [5]...

  • Page 11: Wiring Diagram

    8-4. Wiring Diagram Internal Wire (Blue) [24] Tab Terminal (Blue) [6] Pillar Terminal [19] Stator [22] White or blue Cord For NZL, AUS, EUROPE, CHN Noise Suppressor [4] Black or brown Stator [22] Slide Switch [20] Tab Terminal (Brown) [23] Internal Wire (Brown) [5] Fig.

  • Page 12: Standard Repair Time (Unit) Schedules

    9. STANDARD REPAIR TIME (UNIT) SCHEDULES Variable 60 min. MODEL Fixed SV 12SG Work Flow Slide Switch Cord Cord Armor General Assembly Housing (A).(B) Set Stator Ball Bearing Armature 626VV Ball Bearing 629VV Balance Fan Fan Guide Leg x 2...
  • Page 13 Hitachi Power Tools LIST NO. 0353 ELECTRIC TOOL PARTS LIST ORBITAL SANDER 2004 • • Model SV 12SG (E1)
  • Page 14 PARTS SV 12SG ITEM CODE NO. DESCRIPTION REMARKS USED NAME PLATE 301-653 TAPPING SCREW (W/FLANGE) D4X20 (BLACK) 322-766 HOUSING (A).(B) SET 930-039 NOISE SUPPRESSOR 1 FOR NZL, AUS, GBR, EUROPE, NOR, SUI, CHN 322-764 INTERNAL WIRE (BROWN) 322-761 TAB TERMINAL (BLUE)

  • Page 15: Standard Accessories

    STANDARD ACCESSORIES SV 12SG ITEM CODE NO. DESCRIPTION REMARKS USED 310-339 DUST BAG 323-004 DUST BAG 1 FOR USA, CAN 310-342 SANDING PAPERS 114X140 AA100 (10 PCS.) 1 FOR FELT PAD 310-345 SANDING PAPERS 110X100 AA100 (10 PCS.) 1 FOR PAD, PRESSURE SENSITIVE TYPE...
  • Page 16 SV 12SG ITEM CODE NO. DESCRIPTION REMARKS USED Printed in Japan - - - 4 - - - 3 -- 04 (040330N)
