Summary of Contents for Dolphin Supreme M4
- Page 1 English DOLPHIN SUPREME M4 User Instructions Guide d’utilisation Istruzioni per l’uso Instrucciones para el Usuario Bedienungsanweisungen...
- Page 2 English...
- Page 3 “S” clip Power supply unit Dolphin pool cleaner Dolphin pool cleaner Caddy kit Optional components available on request from your Dolphin distributor Power supply unit Section 1 - Description of Main Components 1. Filters Dual-level filtration system. Spring filter + base frame...
- Page 4 A. Assemble the Caddy kit – you will find the instructions in a separate document B. Adjusting the handle float angle The Handle angle must be adjusted to determine the speed that the Dolphin advances along the water-line. 1. Press the latch down and hold in position.
- Page 5 Part 2 - Into the water Inserting the Dolphin into the pool. Place your Dolphin into the pool and release it. Note: When using the combined brushes or Wonder brushes, gently squeeze the Wonder brush material until it is totally wet.
- Page 6 Part 3 - Taking the Dolphin out of the water Unplug power supply before any servicing activity. If the Dolphin has not finished its cycle, turn off the power supply unit and unplug the mains. Pull the floating cable gently until the Dolphin has risen to the surface, then lift by the handle.
- Page 7 English Section 3 - Routine Maintenance Part 1 - Extracting and cleaning the filter elements Unplug power supply before any servicing activity. Reassemble Insert the locating tabs at the bottom of the filter element into their groves on the base frame, then close the “S” clip. Locating tab Locating tab groove...
- Page 8 Part 3 - Storage instructions Coil the cable and store in dry cool area – preferably on the Caddy if available. Do NOT store the Dolphin exposed to direct sunlight. Do NOT store the Dolphin exposed to excessive heat. Do NOT store the Dolphin exposed to frost.
- Page 9 English Helpful hints for better scanning of your pool The floats can be moved side-ways along the handle groove housings. To Move the floats in their handle housing grooves Push float outwards. To move the floats back to their original position, while pressing the release button on the base of the float, push the float back.
-
Page 10: Troubleshooting Guide
Make sure filter cartridge is clean Straighten cable and lay it in the sun periodically Dolphin is moving in circles or does not reach all pool areas Check for foreign objects in moving parts Make sure filter cartridge is clean and well mounted and that the...
