- Page 1 90 Day pet feeder Please read the manual carefully and keep the instructions for future reference.
-
Page 2: Table Of Contents
Contents Control Panel Page 3 Features Page 3 Assembly and Disassembly Page 4 Getting Started Page 5 General Operation Page 6 Reviewing the settings Page 8 Feed Times Page 9 Voice Recording Page 9 Feeding Alarm Page 10 Opening the feed cover Page 11 Cleaning and Care Page 11... -
Page 3: Control Panel
Control Panel Keys CLOCK –displays clock (current time). TIMER – switches between pre-set feeding times. VOL – sets the feeding volume/portion-size. SET – enters SET mode, and confirms any feeding times you enter and advances to the next setting. Also used with VOL key to perform manual feedings. START –... -
Page 4: Assembly And Disassembly
Assembly & Disassembly Assembly Open the food tank and unpack the feeder tray. On a flat surface, line up the pet feeder with the feeder tray. Push the feeder tray into the recess until it snaps in place. Disassembly Open the spring loaded locks on the sides of the feeder base, using both hands and your thumbs to push down the locks and release the food tank. -
Page 5: Getting Started
Getting started Open the battery door (under the unit). Insert four D-size alkaline batteries into the battery tray. DO NOT use old or cheap carbon batteries. Close the battery door and switch on the feeder. The ON switch is next to the battery door (under the unit). -
Page 6: General Operation
General operation Setting the Current Time All digits should now be flashing. Press the CLOCK key to set the HOUR. Press the TIMER key to set the MINUTE. Press the SET key once to confirm the time, now the display will show either 12 or 24 to indicate the display mode. -
Page 7: Setting The Volume/Portion-Size
Note: If all four feeding-times have been set, the process will terminate and the schedule will start automatically. The next feeding time will then be displayed. (If only 1 feeding-time has been set then the feeding-timer display will not change even if you press the TIMER key.) Feeding-times must be set in ascending order otherwise the remaining number of the feeds will not be served. -
Page 8: Reviewing The Settings
To review the settings Press the TIMER key to cycle through and view the feeding times. Only the feeding times per day that are set will be displayed. Digit-1 is the feeding number each day, Digit 3 & 4 are the feeding times (in hours). Example: (1 07)=(1st feeding at 7am). -
Page 9: Feed Times
Setting the Number of Days to Feed Press the DAY key and the left side of the LCD shows the number of days your Automatic Feeder will feed for until it stops. The default setting of (0) means the feeder will feed continuously and never stop. To change the number of days to feed, press the DAY key then press and hold the SET key (for 2 seconds) until the days flash on the LCD. -
Page 10: Feeding Alarm
Feeding Alarm Your Automatic Pet Feeder has an ALARM (a continuous beeping) to alert you to when your feeding schedule has ended and no more food will be dispensed. The Feeding Alarm will start at 6:00AM the next day to avoid disturbing anyone during the night. -
Page 11: Opening The Feed Cover
Opening and closing the food cover To open ( Unlock ) the food cover Automatic Pet Feeder, rotate the round dial so the ARROW points towards the Open Lock. To close ( Lock ) the food cover Automatic Pet Feeder, rotate the round dial so the ARROW points towards the Closed Lock. -
Page 12: Faqs
FAQ’S The clock can display in either 12 or 24-hour display format The ( PM ) icon will show in the afternoon under the 12-hour display mode. The feeding days can be changed at any time but the previous schedule will be replaced and will start from the 1 new feeding day set. -
Page 13: Guarantee
UK and EU Guarantee Your new Andrew James product comes with a 24 month guarantee and a 2 year fixed warranty, effective from receipt confirmation. Your receipt or order number is required as proof of purchase date so it is imperative that you keep it safe.
Need help?
Do you have a question about the 90 Day pet feeder and is the answer not in the manual?
Questions and answers
How do I set to feed once per day at 17.00 hours. I seem to get it in the morning and if I set to 24 hr clock if I set in the mornings I get the time as, say 22.45. Where **** I going wrong?
To set the Andrew James 90 Day Pet Feeder to feed once per day at 17:00 hours, follow these steps:
1. Set the Clock: Press the Clock button and adjust the time to the current time.
2. Set Feeding Time: Press the Timer button, then adjust the feeding time to 17:00.
3. Set Feeding Days: Press the Day button and select the number of days you want it to feed.
4. Set Food Volume: Press the Volume button and adjust the amount of food per feed.
5. Start Feeding Schedule: Press the Start button to activate the settings.
Your pet feeder is now programmed to feed once per day at 17:00 hours.
This answer is automatically generated
