Using the Control Panel

The following information applies to both of the control panels shown above. Other instructions
specific to each panel follow this section. Gain a thorough knowledge of the following features
before starting up your spa.
Display Window
JETS Buttons
Dimension One Spas – Reflections Owner's Manual
The Display Window shows the current status of the hot tub, its
monitoring functions, self-diagnostics, or programming messages. By
default it shows the spa water temperature.
When you push the JETS 1 or JETS 2 Button (or the JETS Button on
one-pump models) :
• The corresponding jet pump activates.
• The Jet Indicator Light glows.
• A swirl icon appears in the upper left corner of the Display
Window. Its swirl speed indicates the pump's speed.
Pushing a JETS Button once starts the pump on LOW speed. Pushing
it a second time turns on HIGH speed. Pushing it a third time turns
the pump off.
A built-in timer will automatically shut the pump off after 30 minutes
(60 minutes on some models), unless you turn it off manually. (You
can reprogram this shut-off time if you like. See the Programming
section).
When the pump is turned on, after the pump speed appears in the
Display Window, a status bar appears indicating the time remaining
until shut-off. If your spa has multiple jet pumps, they are all
controlled by the same shut-off cycle.
The automatic shut-off not only protects your pumps from
running continuously, it also allows you to filter your hot
tub immediately after use. Just push the Jet button one
more time as you get out, for an additional cycle of
filtering.
Pushing a JETS Button will disable any concurrent filter cycle.
