8
WIRING DIAGRAM
Label all wires prior to disconnection when servicing controls. Wiring
!
errors can cause improper and dangrous operation. Verify proper
operation after servicing.
ELECTRIC DRYER WIRING DIAGRAM
Apply Model : 796.8219#900 / 7096.8102#900
GAS DRYER WIRING DIAGRAM
Apply Model : 796.9219#900 / 7096.9102#900
15
