Contents Before driving Introduction Instrumentation Controls and features Seating and safety restraints Starting and driving Starting Driving Roadside emergencies Servicing Maintenance and care Capacities and specifications Customer assistance Reporting safety defects Index All rights reserved. Reproduction by any means, electronic or mechanical including photocopying, recording or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from Ford Motor Company.
Page 3: Introduction
Introduction The following warning may be required by California law: CALIFORNIA Proposition 65 Warning Engine exhaust, some if its constituents, and certain vehicle components contain or emit chemicals known to the State of California to cause cancer, or birth defects or other reproductive harm. ICONS Indicates a safety alert.
Page 4 Introduction BREAKING-IN YOUR VEHICLE There are no particular breaking-in rules for your vehicle. During the first 1 600 km (1 000 miles) of driving, vary speeds frequently. This is necessary to give the moving parts a chance to break in. INFORMATION ABOUT THIS GUIDE The information found in this guide was in effect at the time of printing.
Page 5 Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert See Owner’s Guide Fasten Safety Belt Air Bag-Front Air Bag-Side Child Seat Child Seat Installation Child Seat Tether Warning Anchorage Brake System Anti-Lock Brake System Brake Fluid - Traction Control...
Page 6 Introduction Vehicle Symbol Glossary Interior Luggage Child Safety Door Compartment Release Lock/Unlock Symbol Panic Alarm Engine Oil Engine Coolant Engine Coolant Temperature Do Not Open When Hot Battery Avoid Smoking, Flames, Battery Acid or Sparks Explosive Gas Fan Warning Maintain Correct Fluid Power Steering Fluid Level Emission System...
Page 7: Instrumentation
Instrumentation Instrument cluster (pg. 8) Headlamp control (pg. 21) Speed control (pg. 77) Instrument panel dimmer switch Reverse sensing (pg. 22) system* (pg. 33) DOOR AJAR CHECK 60 70 GAGE 0 0 0 RPMx1000 SPEED 0 0 0 0 0 0 CHECK CONT ENGINE...
Page 8 Instrumentation Rear wiper/washer Electronic sound system control Gearshift (includes (pg. 35) (pg. 82) overdrive button) (pg. 150) Rear window defroster control (pg. 33) R. WIPE VOL - PUSH ON PUSH BASS TREB FADE TAPE SEEK SIDE 1 - 2 SCAN TUNE Fog lamp control* Climate control system...
Page 9 Instrumentation WARNING LIGHTS AND CHIMES DOOR AJAR CHECK 60 70 GAGE 0 0 0 RPMx1000 SPEED 0 0 0 0 0 0 CHECK CONT ENGINE HIGH CHECK km/h FUEL CAP R N D 2 1 THEFT CHECK SUSP BRAKE Check engine Your vehicle is equipped with a computer that monitors the engine’s CHECK...
Page 10 Instrumentation 3. The fuel cap may not have been properly installed and securely tightened. These temporary malfunctions can be corrected by filling the fuel tank with high quality fuel of the recommended octane and/or properly installing and securely tightening the gas cap. After three driving cycles without these or any other temporary malfunctions present, the Check Engine light should turn off.
Page 11 Instrumentation Safety belt Momentarily illuminates when the ignition is turned to the ON position to remind you to fasten your safety belts. For more information, refer to the Seating and safety restraints chapter. Brake system warning Momentarily illuminates when the ignition is turned to the ON position.
Page 12 Instrumentation High beams Illuminates when the high beam headlamps are turned on. Anti-theft system (if equipped) Refer to SecuriLock passive anti-theft system in the Controls THEFT and features chapter. Charging system Illuminates when the ignition is turned to the ON position and the engine is off.
Page 13: Controls And Features
Instrumentation Four wheel drive high (if equipped) Momentarily illuminates when the ignition is turned to the START HIGH position. Illuminates when four-wheel drive high is engaged. If the light continues to flash have the system serviced. Door ajar Illuminates when the ignition is in the ON or START position and any DOOR door is open.
Page 14: Seating And Safety Restraints
Instrumentation Speed control This light comes on when either the SPEED SET/ACCEL or RESUME controls CONT are pressed. It turns off when the speed control OFF control is pressed, the brake is applied or the ignition is turned to the OFF position.
Page 15: Engine Coolant Temperature Gauge
Instrumentation GAUGES DOOR AJAR CHECK 60 70 GAGE 0 0 0 RPMx1000 SPEED 0 0 0 0 0 0 CHECK CONT ENGINE HIGH CHECK FUEL km/h R N D 2 1 THEFT CHECK BRAKE SUSP Speedometer Indicates the current vehicle speed. 60 70 0 0 0 0 0 0 0 0 0...
Page 16 Instrumentation Never remove the coolant reservoir cap while the engine is running or hot. This gauge indicates the temperature of the engine coolant, not the coolant level. If the coolant is not at its proper level the gauge indication will not be accurate. Odometer Registers the total kilometers 60 70...
Page 17 Instrumentation Battery voltage gauge This shows the battery voltage when the ignition is in the ON position. If the pointer moves and stays outside the normal operating range (as indicated), have the vehicle’s electrical system checked as soon as possible. Engine oil pressure gauge This shows the engine oil pressure in the system.
Page 18 Instrumentation The FUEL DOOR icon and arrow indicates which side of the vehicle the fuel filler door is located. MESSAGE CENTER (IF EQUIPPED) With the ignition in the ON position, the message center displays important vehicle information through a constant monitor of vehicle systems.
Page 19 Instrumentation fueling. The display FUEL LEVEL ERROR indicates a problem with the fuel indication system. See your dealer or qualified service technician for system maintenance. Fuel status Press once to display the approximate amount of fuel remaining in the fuel tank. FUEL Press again to display the approximate amount of fuel used...
Page 20 Instrumentation System check Press the system check control to display the status of the following systems: FUEL • engine oil life left • engine oil level • voltage level • engine coolant temperature • washer fluid level • fuel level The engine oil life left has two phases.
Page 21 Instrumentation Oil change reset Press the OIL CHANGE RESET control to reset the oil life feature to 100% (or your personalized oil reset FUEL percentage) (at optimal driving conditions, 100% oil life is equivalent to a maximum of 12 000 kilometers [7 500 miles]).
Page 22: Controls And Features
Controls and features HEADLAMP CONTROL Rotate the headlamp control to the first position to turn on the parking lamps. Rotate to the second position to also turn on the headlamps. Foglamp control (if equipped) Turn on the low-beam headlamps and press the foglamp control to activate the foglamps.
Page 23 Controls and features Flash to pass Pull toward you to activate and release to deactivate. PANEL DIMMER CONTROL Use to adjust the brightness of the instrument panel during headlamp and parklamp operation. • Rotate up to brighten. • Rotate down to dim. •...
Page 24 Controls and features Temperature control knob Controls the temperature of the airflow inside the vehicle. Mode selector control Controls the direction of the airflow to the inside of the vehicle. The air conditioning compressor will operate in all modes except .
Page 25 Controls and features hot and full cold positions, the air distributed through the floor ducts will be slightly warmer than the air sent to the instrument panel registers. • (Floor)-Allows for maximum heating by distributing outside air through the floor ducts. However, the air will not be cooled below the outside temperature because the air conditioning does not operate in this mode.
Page 26 Controls and features • To prevent humidity buildup inside the vehicle, do not drive with the climate control system in the OFF or MAX A/C position. • Do not put objects under the front seat that will interfere with the airflow to the rear seats.
Page 27 Controls and features Turning the EATC on Press AUTOMATIC, any of the ˚ override controls or the fan speed AUTO control. The EATC will only operate REAR FAN OFF AUTOMATIC when the vehicle is running. MAX A/C VENT PNL • FLR FLOOR FLR •...
Page 28 Controls and features Temperature selection The display window indicates the ˚ selected temperature, function AUTO (AUTO or one of the override controls) and manual control of fan speed ( ) if automatic fan speed is not desired. To control the temperature, select any temperature between 18°C (65°F) and 29°C (85°F) by pressing the blue (cooler) or red (warmer)
Page 29 Controls and features Fan speed ( When AUTOMATIC is pressed, fan speed is adjusted automatically for existing conditions. You can override fan speed at any time. To control fan speed manually, use the AUTOMATIC thumbwheel or steering wheel control to cancel automatic fan speed operation.
Page 30 Controls and features Since the air conditioner removes considerable moisture from the air during operation, it is normal if clear water drips on the ground under the air conditioner drain while the system is working and even after you have stopped the vehicle. •...
Page 31 Controls and features Rear fan off Press REAR FAN OFF to turn off the rear console fan. This overrides the rear console fan speed control. REAR FAN OFF MAX A/C VENT PNL • FLR The EATC display window will indicate REAR FAN OFF. The rear console fan will remain off until REAR FAN OFF is pressed again.
Page 32 Controls and features • Remove any snow, ice or leaves from the air intake area (at the bottom of the windshield). • If your vehicle has been parked with the windows closed during hot weather, the air conditioner will do a much faster job of cooling if you drive for two or three minutes with the windows open.
Page 33 Controls and features Turn the fan speed control to the - VOLUME + MODE desired position. SEEK MEMORY Select for air to flow through these vents: – VOLUME BAND SEEK MEMORY Select for air to flow through these vents: – VOLUME BAND SEEK...
Page 34 Controls and features REAR WINDOW DEFROSTER The rear defroster control is located on the instrument panel. Press the rear defroster control to clear the rear window of thin ice and fog. • A small LED will illuminate when the rear defroster is activated. The ignition must be in the ON position to operate the rear window defroster.
Page 35 Controls and features To help avoid personal injury, always use caution when in reverse and when using the reverse sensing system. This system is not designed to prevent contact with small or moving objects. The system is designed to provide a warning to assist the driver in detecting large stationary objects to avoid damaging the vehicle.
Page 36 Controls and features A reverse sensing control allows the driver to enable and disable the RSS when the ignition is ON. The reverse sensing control indicator momentarily illuminates when the ignition is turned ON. The OFF indicator remains illuminated when the system is disabled.
Page 37 Controls and features Volume/power control Press the control to turn the audio VOL - PUSH ON system on or off. Turn the control to raise or lower volume. VOL - PUSH ON If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal”...
Page 38 Controls and features Tune adjust The tune control works in radio mode. Tune adjust in radio mode • Press to move to the next SEEK frequency down the band (whether or not a listenable TUNE station is located there). Hold the control to move through the frequencies quickly.
Page 39 Controls and features Setting memory preset stations 1. Select the frequency band with the AM or the FM select control. 2. Select a station. Refer to Tune adjust or Seek function for more information on selecting a station. 3. Press and hold a memory preset control until the sound returns, indicating the station is held in memory on the control you selected.
Page 40 Controls and features Speaker balance adjust Speaker sound distribution can be adjusted between the right and left speakers. Speaker fade adjust Speaker sound can be adjusted between the front and rear speakers. FADE Tape select • To enter tape mode while in radio mode, press the TAPE AMS control.
Page 41 Controls and features selection). The tape deck stops and returns to play mode when the AMS circuit senses a blank section on the tape. In order to ensure proper operation of the AMS feature, the tape MUST have a blank section of at least four seconds duration between programs. Rewind The rewind control works in tape SIDE...
Page 42 Controls and features Setting the clock Press CLK to toggle between listening frequencies and clock mode while in radio mode. To set the hour, press and hold the CLK control and press the SEEK TAPE control: • to decrease hours and •...
Page 43 Controls and features When in clock mode, the media information will display for 10 seconds, when the radio is turned on, and then revert to clock information. Anytime that the media is changed, (new radio station, etc.), the media information will again display for 10 seconds before reverting back to the clock.
Page 44 Controls and features Turn control to raise or lower VOL - PUSH ON volume. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on.
Page 45 Controls and features Tune adjust in radio mode • Press to move to the next SEEK SEEK frequency down the band (whether or not a listenable TUNE TUNE station is located there). Hold the control to move through the frequencies quickly. •...
Page 46 Controls and features Seek function in radio mode • Press to find the next listenable station down the frequency band. • Press to find the next listenable station up the frequency band. SEEK SEEK TUNE TUNE Seek function in tape mode •...
Page 47 Controls and features Scan function in tape mode Press the SCAN control to hear a short sampling of all selections on the tape. (The tape scans in a forward direction. At the end of the tape’s first side, direction automatically reverses to the opposite side of the tape.) To stop on a particular selection, press the control again.
Page 48 Controls and features Starting autoset memory preset 1. Select a frequency using the AM/FM select controls. 2. Press the AUTO control. 3. When the first six strong stations AUTO are filled, the station stored in memory preset control 1 will start playing.
Page 49 Controls and features Press the TREB control then press: • to decrease the treble output • to increase the treble output. Speaker balance adjust Speaker sound distribution can be FADE adjusted between the right and left speakers. Press the BAL control then press: •...
Page 50 Controls and features Tape/CD select • To begin tape play (with a tape loaded into the audio system) TAPE while in the radio or CD mode, press the TAPE control. Press the button during rewind or fast forward to stop the rewind or fast forward function.
Page 51 Controls and features Eject function Press the EJ control to stop and eject a tape. Press the EJ control to stop and eject a CD. Dolby noise reduction Dolby noise reduction operates in tape mode. Dolby noise reduction reduces the amount of hiss and static during tape playback.
Page 52 Controls and features Setting the clock To set the hour, press and hold the CLK control and press SEEK: AUTO • to decrease hours and • to increase hours. SEEK SEEK TUNE TUNE To set the minute, press and hold the CLK control and press TUNE: AUTO •...
Page 53 Controls and features The CLK button will allow you to switch between media display mode AUTO (radio station, stereo information, etc.) and clock display mode (time). When in clock mode, the media information will display for 10 seconds, when the radio is turned on, and then revert to clock information.
Page 54 Controls and features To turn on the rear seat controls, SIDE 1-2 COMP SHUFFLE press the memory preset controls 3 and 5 at the same time. The will appear in the display. Pressing 3 and 5 at the same time again will turn the rear seat controls off.
Page 55 Controls and features Turning the speakers on and off Press to turn all speakers on or off. - VOLUME + MODE SEEK MEMORY Using headphones Plug a 3.5 mm headphone (not included) into the jack. Press the speaker on/off control to operate the headphones. The rear speakers will cut out once the speaker on/off control is pressed.
Page 56 Controls and features Memory preset control Push the MEMORY control - VOLUME + successively to allow rear seat MODE passengers to scroll through the 6 memory presets in AM, FM1 or FM2. SEEK MEMORY Push the MEMORY control in CD changer mode (if equipped) to advance to the next disc.
Page 57 Controls and features MACH Audio System with AM/FM Stereo/Cassette/Single CD DISC VOL - PUSH ON MUTE TAPE DOLBY B NR AUTO SEEK TUNE SCAN BASS TREB FADE SIDE 1-2 COMP SHUFFLE Volume/power control Press the control to turn the audio VOL - PUSH ON system on or off.
Page 58 Controls and features AM/FM select The AM/FM select control works in radio, tape and CD modes. AM/FM select in radio mode This control allows you to select AM or FM frequency bands. Press the control to switch between AM, FM1 or FM2 memory preset stations. AM/FM select in tape mode Press this control to stop tape play and begin radio play.
Page 59 Controls and features Tune adjust for CD changer (if equipped) • Press to select the previous SEEK SEEK disc in the CD changer. (Play will begin on the first track of the TUNE TUNE disc unless the CD changer is in shuffle mode.
Page 60 Controls and features Seek function for CD changer (if equipped) • Press to seek to the previous track of the current disc. If a selection has been playing for three seconds or more and you press , the CD changer will replay that selection from the beginning.
Page 61 Controls and features Setting memory preset stations 1. Select the frequency band with the AM/FM select control. 2. Select a station. Refer to Tune adjust or Seek function for more information on selecting a station. 3. Press and hold a memory preset SIDE 1-2 COMP SHUFFLE...
Page 62 Controls and features Press the BASS control then press: • to decrease bass output and • to increase bass output. Treble adjust The treble adjust control allows you BASS TREB to increase or decrease the audio system’s treble output. Press the TREB control then press: •...
Page 63 Controls and features Speaker fade adjust Speaker sound can be adjusted FADE between the front and rear speakers. Press the FADE control then press: • to shift sound to the front • to shift sound to the rear. Tape/CD/CD changer (if equipped) select •...
Page 64 Controls and features Fast forward The fast forward control works in tape and CD modes. • In the tape mode, tape direction will automatically reverse when the end of the tape is reached. • In CD mode, pressing the control for less than three seconds results in slow forward action.
Page 65 Controls and features Compression adjust Compression adjust brings soft and COMP loud CD passages together for a more consistent listening level. Press the COMP control to activate and deactivate compression adjust. Shuffle feature The shuffle feature operates in CD SHUFFLE mode and plays all tracks on the current disc in random order.
Page 66 Controls and features To set the minute, press the AUTO clock/RDS control until SELECT MIN is displayed and press: • to decrease minutes and • to increase minutes. Radio Data System (RDS) feature This feature allows your audio AUTO system to receive text information from RDS-equipped FM radio stations.
Page 67 Controls and features Press and hold the control for three seconds to turn the feature on or off. Press the control to scroll through the following selections: RDS traffic announcement • Press the RDS control until AUTO TRAFFIC is displayed. •...
Page 68 Controls and features • Use the SEL control to select the program type. With the feature on, use the SEEK or AUTOSET or SCAN control to find the desired program type from the following selections: • Classic • Country • Info •...
Page 69 Controls and features Mute mode Press the control to mute the playing media. Press the control again to return to the playing media. MUTE Rear seat controls (if equipped) The Personal Audio System, a feature of the optional Premium - VOLUME + MODE AM/FM Stereo/Cassette/Single CD and the MACH Audio System with...
Page 70 Controls and features To activate the Personal Audio - VOLUME + System, press the speaker/ MODE headphone control. Press the MODE control to change audio sources (for headphone mode only). Use the SEEK MEMORY SEEK, VOLUME and MEMORY controls to make adjustments to the playing media.
Page 71 Controls and features Using headphones Plug a 3.5 mm headphone (not included) into the jack. Press the speaker on/off control to operate the headphones. The rear speakers will cut out once the speaker on/off control is pressed. The front speaker will remain playing for the front passengers. Press the control again to deactivate the headphones.
Page 72 Controls and features Seek function • In radio mode, press to find - VOLUME + the next listenable station down MODE the frequency band. • In radio mode, press to find SEEK MEMORY the next listenable station up the frequency band. •...
Page 73 Controls and features 2. Press to eject the magazine. 3. Turn the magazine (A) over. 4. Using the disc holder release knob (C), pull the disc holder (B) out of the magazine. If you pull too hard on the disc holder, the disc holder may come completely out of the magazine.
Page 74 Controls and features 5. Line up the CD with the groove of the disc holder. Ensure that the label on the CD faces downwards. 6. Press in on the disc holder until it locks securely into the magazine. If the disc holders are not fully locked into the magazine, the unit will not operate.
Page 75 Controls and features If your changer does not work, it may be that: • A disc is already loaded where you want to insert a disc. • The disc is inserted with the label surface downward. • The disc is dusty or defective. •...
Page 76 Controls and features Radio frequency information The Federal Communications Commission (FCC) and the Canadian Radio and Telecommunications Commission(CRTC) establish the frequencies AM and FM stations may use for their broadcasts. Allowable frequencies are: AM 530, 540–1600, 1610 kHz FM 87.7, 87.9–107.7, 107.9 MHz Not all frequencies are used in a given area.
Page 77 Controls and features TURN SIGNAL CONTROL • Push down to activate the left turn signal. • Push up to activate the right turn signal. POSITIONS OF THE IGNITION 1. ACCESSORY, allows the electrical accessories such as the radio to operate while the engine is not running.
Page 78 Controls and features SPEED CONTROL To turn speed control on • Press ON. Vehicle speed cannot be controlled until the vehicle is traveling at or above 48 km/h (30 mph). Do not use the speed control in heavy traffic or on roads that are winding, slippery, or unpaved.
Page 79 Controls and features To set a speed • Press SET/SET ACC/SET ACCEL. For speed control to operate, the speed control must be ON and the vehicle speed must be greater than 48 km/h (30 mph). COAST If you drive up or down a steep hill, your vehicle speed may vary momentarily slower or faster than the set speed.
Page 80 Controls and features You can accelerate with the accelerator pedal at any time during speed control usage. Releasing the accelerator pedal will return your vehicle to the previously programmed set speed. To set a lower set speed • Press and hold CST/COAST. Release the control when the desired speed is reached or •...
Page 81 Controls and features Pressing OFF will erase the previously programmed set speed. To return to a previously set speed • Press RES/RSM/RESUME. For RES/RSM/RESUME to operate, the vehicle speed must be faster than 48 km/h (30 mph). COAST Indicator light This light comes on when either the SPEED SET ACC/SET ACCEL or RES/RSM/...
Page 82: Roadside Emergencies
Controls and features TILT STEERING WHEEL Pull the tilt steering control toward you to move the steering wheel up or down. Hold the control while adjusting the wheel to the desired position, then release the control to lock the steering wheel in position. Never adjust the steering wheel when the vehicle is moving.
Page 83 Controls and features Push (tap) the end of the stalk briefly for a single swipe (no wash). Push and hold for three swipes with wash. Push and hold for a longer wash (up to ten seconds). Speed dependent wipers When the windshield wiper control is set on the intermittent settings, speed-sensitive front wipers automatically adjust as the vehicle’s speed changes.
Page 84 Controls and features Radio control features • Press BAND/MODE to select AM, FM1, FM2, TAPE or CD (if equipped). In Radio mode: NEXT • Press MEM/NEXT to select a preset station from memory. MODE In Tape mode: • Press MEM/NEXT to listen to the next selection on the tape. In CD mode: •...
Page 85 Controls and features Storage compartment (if equipped) Press the OPEN control to open the storage compartment. The door will open slightly and can be moved to full open. Installing a garage door opener (if equipped) The storage compartment can be converted to accommodate a variety of aftermarket garage door openers: •...
Page 86 Controls and features • Place the provided height adaptors onto the back of the GARAGE control as needed. • Press the GARAGE control to activate the transmitter. Moon roof (if equipped) You can move the moon roof back to open the glass panel or tilt up to ventilate the vehicle.
Page 87 Controls and features Do not let children play with the moon roof. They may seriously hurt themselves. Electronic compass/temperature display (if equipped) Outside air temperature The outside temperature display is contained in the overhead console. OPEN The temperature display can be turned off and on by pressing the MODE control on the overhead console.
Page 88 Controls and features Compass zone adjustment 1. Determine which magnetic zone you are in by referring to the zone map. 2. Press and hold the MODE control until VAR appears in the display, then release. The display should show the current zone number. 3.
Page 89 Controls and features Compass calibration adjustment Perform this adjustment in an open area free from steel structures and high voltage lines: • Press and hold the MODE control until CAL appears in the display (approximately eight seconds) and release. • Drive the vehicle slowly (less than 5 km/h [3 mph]) in circles until CAL indicator turns off in about 2–3 complete circles.
Page 90 Controls and features Programming 1. Prepare for programming the HomeLink Universal Transceiver by erasing the three factory default PLAY codes by holding down the two outside buttons until the red light begins to flash after 20 seconds. Release both buttons. 2.
Page 91 Controls and features • press and re-press the hand-held transmitter button every two seconds until the red light changes from a slow to a fast flash. Operating the HomeLink Universal Transceiver Once programmed, the HomeLink Universal Transceiver can be used in place of hand-held transmitters.
Page 92 Controls and features door openers may require this procedure to be done a third time to complete the training). The 2nd or 3rd press from step 3 will activate the door. The HomeLink Universal Transceiver has now been trained to the receiver. The remaining two buttons may now be programmed if this has not previously been done.
Page 93 Controls and features To record a message: 1. Press and release the REC button one time to start recording. PLAY (An audible tone will sound, confirming the onset of recording). 2. Press and release the REC button a second time to end recording.
Page 94 Controls and features If the DEL button is inadvertently pressed or the time allotted (five seconds) has passed, the indicator light will flash amber and an “error” tone will sound. AUTOLAMP DELAY SYSTEM (IF EQUIPPED) The autolamp sets the headlamps to turn on and off automatically. The autolamp may be set to: •...
Page 95 Controls and features AUTOMATIC DIMMING REAR VIEW MIRROR The autolamp/automatic dimming mirror is equipped with an automatic dimming feature. This feature will change from the normal DELAY AUTOLAMP MAX. state to the non-glare “active” state when bright lights (glare) reach the mirror.
Page 96 Controls and features One touch down • Press AUTO completely down and release quickly. The driver’s window will open fully. Depress again to stop window operation. One touch down can be deactivated during operation by pushing up on AUTO the power window control. Window lock The window lock feature allows only the driver to operate the power...
Page 97 Controls and features CHILDPROOF DOOR LOCKS When these locks are set, the rear doors cannot be opened from the inside. The rear doors can be opened from the outside when the doors are unlocked. The childproof locks are located on rear edge of each rear door and must be set separately for each door.
Page 98 Controls and features Heated outside mirrors (if equipped) Both mirrors are heated automatically to remove ice, mist and fog when the rear window defrost is activated. Do not remove ice from the mirrors with a scraper or attempt to readjust the mirror glass if it is frozen in place.
Page 99 Controls and features Use only soft cups in the cupholder. Hard objects can injure you in a collision. Auxiliary power point The power point is an additional power source for electrical accessories. Rear console features The rear console incorporates the following features: •...
Page 100 Controls and features CENTER ARMREST/REAR CUPHOLDER (IF EQUIPPED) Do not attempt to raise the console armrest when the rear cupholder is in use. If you find resistance when raising the armrest, make sure the cupholder is fully closed or else damage may occur to the armrest.
Page 101 Controls and features The liftgate door and window should be closed before driving your vehicle. If not, possible damage may occur to the liftgate door lift cylinders and attaching hardware. Make sure that the liftgate door and/or window are closed to prevent exhaust fumes from being drawn into the vehicle.
Page 102 Controls and features 1. Remove the shade from the vehicle and extend it with the smooth grain facing you. 2. Wrap the vinyl around the roller tube twice. Tuck the edges of the vinyl inside the end cap with each wrap.
Page 103 Controls and features Unlocking the doors Press this control to unlock the driver’s door. The interior lamps will illuminate. Press the control a second time within five seconds to unlock all doors. Locking the doors Press this control to lock all doors. To confirm all doors are closed and locked, press the control a second time within five seconds.
Page 104 Controls and features Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Memory seat feature (if equipped) The remote entry system can also control the memory seat feature. Press the control once to unlock the driver’s door and move the memory seat feature to the corresponding...
Page 105 Controls and features Replacing the battery The transmitter is powered by one coin type three-volt lithium battery CR2032 or equivalent. Typical operating range will allow you to be up to 10 meters (33 feet) away from your vehicle. A decrease in operating range can be caused by: •...
Page 106 Controls and features Programming remote transmitters It is necessary to have all (maximum of four — original and/or new) of your remote transmitters available prior to beginning this procedure. To program the transmitters yourself: • Insert a key in the ignition and turn from 3 (OFF) to 4 (ON) eight times in rapid succession (within 10 seconds) with the...
Page 107 Controls and features The battery saver will shut off the interior lamps 40 minutes after the ignition has been turned to the OFF position. Keyless entry system (if equipped) With the keyless entry keypad, you can: 7 8 9 0 •...
Page 108 Controls and features If you wish to erase your personal code, use the following instructions: Erasing personal code 1. Enter the factory-set code. 2. Press 1/2 within five seconds of step 1. 7 8 9 0 3. Press the 7/8 and 9/0 controls at the same time within five seconds of step 2.
Page 109 Controls and features • you shift into or through R (Reverse) • the brake pedal is released The autolock feature repeats when: • any door is opened and then closed • the brake pedal is released Deactivating autolock Before following the activation or deactivation procedures, make sure that the ignition is OFF and all vehicle doors and liftgate window are closed.
Page 110 Controls and features If autolock/relock has been changed, the horn will chirp to confirm procedure is complete. SECURILOCK PASSIVE ANTI-THEFT SYSTEM The SecuriLock passive anti-theft system provides an advanced level of vehicle theft protection. Your vehicle’s engine can only be started with the two special SecuriLock electronically coded keys provided with your vehicle.
Page 111 Controls and features Theft indicator The theft indicator on the instrument cluster will operate as follows: • When the ignition is OFF, the theft indicator will flash briefly every two seconds to indicate the SecuriLock system is protecting your vehicle. •...
Page 112 Controls and features 3. Within five seconds of turning the ignition to OFF, insert the second previously programmed SecuriLock key into the ignition and turn the ignition from OFF to ON (maintain ignition in ON for at least one second but no more than five seconds).
Page 113: Seating And Safety Restraints
Seating and safety restraints SEATING Adjustable head restraints Your vehicle’s seats may be equipped with head restraints which are vertically adjustable. The purpose of these head restraints is to help limit head motion in the event of a rear collision. To properly adjust your head restraints, lift the head restraint so that it is located directly behind your head or as close to that position as possible.
Page 114 Seating and safety restraints Always drive and ride with your seatback upright and the lap belt snug and low across the hips. Reclining the seatback can reduce the effectiveness of the seat’s safety belt in the event of a collision. Lift handle to move seat forward or backward.
Page 115 Seating and safety restraints Reclining the seatback can reduce the effectiveness of the seat’s safety belt in the event of a collision. The control is located on the outboard side of the seat cushion. Press front to raise or lower the front portion of the seat cushion.
Page 116 Seating and safety restraints Using the manual lumbar support (if equipped) Turn the lumbar support control toward the front of vehicle to move the lumbar support forward for more direct support. Turn the lumbar support control toward the rear of vehicle to move the lumbar support back for less direct support.
Page 117 Seating and safety restraints To return the seat to the upright position: • Press downward on the upper corner of the seatback and hold. • Pull the release handle upward to unlatch the seat. • Rotate the seatback upward until the seatback latches in the upright position.
Page 118 Seating and safety restraints All occupants of the vehicle, including the driver, should always properly wear their safety belts, even when an air bag SRS is provided. It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed.
Page 119 Seating and safety restraints After any vehicle collision, the seat belt system at all outboard seating positions (except driver, which has no “automatic locking retractor” feature) must be checked by a qualified technician to verify that the “automatic locking retractor” feature for child seats is still functioning properly.
Page 120 Seating and safety restraints The front and rear outboard safety restraints in the vehicle are combination lap and shoulder belts. The front passenger and rear seat outboard safety belts have two types of locking modes described below: Vehicle sensitive mode The vehicle sensitive mode is the normal retractor mode, allowing free shoulder belt length adjustment to your movements and locking in response to vehicle movement.
Page 121 Seating and safety restraints • Grasp the shoulder portion and pull downward until the entire belt is extracted. • Allow the belt to retract. As the belt retracts, you will hear a clicking sound. This indicates the safety belt is now in the automatic locking mode.
Page 122 Seating and safety restraints Front safety belt height adjustment Your vehicle has safety belt height adjustments for the driver and front passenger. Adjust the height of the shoulder belt so the belt rests across the middle of your shoulder. To lower the shoulder belt height, push the button and slide the height adjuster down.
Page 123 Seating and safety restraints Conditions of operation If... Then... The driver’s safety belt is not The safety belt warning light buckled before the ignition switch illuminates1-2 minutes and the is turned to the ON position... warning chime sounds 4-8 seconds. The driver’s safety belt is buckled The safety belt warning light and while the indicator light is...
Page 124 Seating and safety restraints The following are reasons most often given for not wearing safety belts: (All statistics based on U.S. data) Reasons given... Consider... Crashes are rare 36 700 crashes occur every day. The more we events drive, the more we are exposed to rare events, even for good drivers.
Page 125 Seating and safety restraints Do not sit on top of a buckled safety belt to avoid the Belt Minder chime. Sitting on the safety belt will increase risk of injury in an accident. To disable (one time) or deactivate the Belt Minder feature please follow the directions stated below.
Page 126 Seating and safety restraints 4. Turn on the parklamps/headlamps, turn off the parklamps/headlamps. 5. Buckle then unbuckle the safety belt three times, ending with the safety belt unbuckled. • After step 5 the safety belt warning light will be turned on for three seconds.
Page 127 Seating and safety restraints Refer to Cleaning and maintaining the safety belts in the Maintenance and care section. AIR BAG SUPPLEMENTAL RESTRAINT SYSTEM (SRS) 50 60 70 o o o UNLEADED FUEL ONLY 0 0 0 0 0 0 VOL – PUSH ON R.
Page 128 Do not attempt to service, repair, or modify the Air Bag Supplemental Restraint System or its fuses. See your Ford or Lincoln-Mercury dealer.
Page 129 Seating and safety restraints Children and air bags For additional important safety information, read all information on safety restraints in this guide. Children must always be properly restrained. Accident statistics suggest that children are safer when properly restrained in the rear seating positions than in the front seating position.
Page 130 Seating and safety restraints The air bags inflate and deflate rapidly upon activation. After air bag deployment, it is normal to notice a smoke-like, powdery residue or smell the burnt propellant. This may consist of cornstarch, talcum powder (to lubricate the bag) or sodium compounds (e.g., baking soda) that result from the combustion process that inflates the...
Page 131 Seating and safety restraints • a readiness light and tone. • diagnostic module. • and the electrical wiring which connects the components. The diagnostic module monitors its own internal circuits and the supplemental air bag electrical system warning (including the impact sensors), the system wiring, the air bag system readiness light, the air bag back up power and the air bag ignitors.
Page 132 Do not attempt to service, repair, or modify the air bag Supplemental Restraint System, its fuses or the seat cover on a seat containing an air bag. See your Ford or Lincoln Mercury dealer. All occupants of the vehicle including the driver should always wear their safety belts even when an air bag SRS is provided.
Page 133 Seating and safety restraints The air bag SRS is designed to activate when the vehicle sustains lateral deceleration sufficient to cause the sensors to close an electrical circuit that initiates air bag inflation. The fact that the air bags did not inflate in a collision does not mean that something is wrong with the system.
Page 134 Seating and safety restraints • A series of five beeps will be heard. The tone pattern will repeat periodically until the problem and light are repaired. If any of these things happen, even intermittently, have the SRS serviced at your dealership or by a qualified technician immediately. Unless serviced, the system may not function properly in the event of a collision.
Page 135 Seating and safety restraints Children and safety belts If the child is the proper size, restrain the child in a safety seat. Children who are too large for child safety seats (as specified by your child safety seat manufacturer) should always wear safety belts. Follow all the important safety restraint and air bag precautions that apply to adult passengers in your vehicle.
Page 136 Seating and safety restraints SAFETY SEATS FOR CHILDREN Child and infant or child safety seats Use a safety seat that is recommended for the size and weight of the child. Carefully follow all of the manufacturer’s instructions with the safety seat you put in your vehicle. If you do not install and use the safety seat properly, the child may be injured in a sudden stop or collision.
Page 137 Seating and safety restraints Ford recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position which is capable of providing a tether anchorage. For more information on top tether straps, refer to Attaching safety seats with tether straps.
Page 138 Seating and safety restraints 2. Pull down on the shoulder belt and then grasp the shoulder belt and lap belt together. 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions.
Page 139 Seating and safety restraints 5. To put the retractor in the automatic locking mode, grasp the shoulder portion of the belt and pull downward until all of the belt is extracted and a click is heard. 6. Allow the belt to retract. The belt will click as it retracts to indicate it is in the automatic locking mode.
Page 140 Tether anchorage hardware kits (part number 613D74) including instructions, may be obtained at no charge from any Ford or Lincoln/Mercury dealer. Tighten the anchor according to specifications. Otherwise, the safety seat may not be properly secured and the child may be...
Page 141: Starting
Starting PREPARING TO START YOUR VEHICLE Engine starting is controlled by the powertrain control system. This system meets all Canadian Interference-Causing Equipment standard requirements regulating the impulse electrical field strength of radio noise. When starting a fuel-injected engine, avoid pressing the accelerator before or during starting.
Page 142 Starting 2. Make sure the headlamps and vehicle accessories are off. • Make sure the parking brake is set. • Make sure the gearshift is in P (Park). 3. Turn the key to 4 (ON) without turning the key to 5 (START). If there is difficulty in turning the key, firmly rotate the steering wheel left and right until the key turns...
Page 143 Starting Make sure the corresponding lights illuminate briefly. If a light fails to illuminate, have the vehicle serviced. • If the driver’s safety belt is fastened, the light may not illuminate. STARTING THE ENGINE 1. Turn the key to 5 (START) without pressing the accelerator pedal and release as soon as the engine starts.
Page 144 Starting To prevent electrical shock, do not use your heater with ungrounded electrical systems or two-pronged (cheater) adapters. Guarding against exhaust fumes Although odorless and colorless, carbon monoxide is present in exhaust fumes. Take precautions to avoid its dangerous effects. If you ever smell exhaust fumes of any kind inside your vehicle, have your dealer inspect and fix your vehicle immediately.
Page 145: Driving
Driving BRAKES Your service brakes are self-adjusting. Refer to the scheduled maintenance guide for scheduled maintenance. Occasional brake noise is normal and often does not indicate a performance concern with the vehicle’s brake system. In normal operation, automotive brake systems may emit occasional or intermittent squeal or groan noises when the brakes are applied.
Page 146 Driving ABS warning lamp warning lamp in the instrument cluster momentarily illuminates when the ignition is turned to the ON position. If the light does not illuminate momentarily at start up, remains on or continues to flash, the ABS needs to be serviced. With the ABS light on, the anti-lock brake system is disabled and normal braking is still effective unless the...
Page 147 Driving The BRAKE warning lamp in the instrument cluster illuminates and remains illuminated (when the BRAKE ignition is turned ON) until the parking brake is released. Always set the parking brake fully and make sure that the gearshift is securely latched in P (Park). The parking brake is not recommended to stop a moving vehicle.
Page 148 Driving • high crown in center of road • high crosswinds • wheels out of alignment • loose or worn components in steering linkage AIR SUSPENSION SYSTEM (IF EQUIPPED) The load leveling feature of the air suspension automatically keeps the vehicle at a constant level if a load is added or removed from the vehicle.
Page 149 Driving In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a seat belt. Your vehicle has special design and equipment features to make it capable of performing in a wide variety of circumstances. These special design features, such as larger tires and increased ground clearance, give the vehicle a higher center of gravity than a passenger car.
Page 150 Driving 2. Insert the key and turn it to OFF. Apply the brake pedal and shift to N (Neutral). 3. Start the vehicle. If it is necessary to use the above procedure to move the gearshift lever, it is possible that a fuse has blown or the vehicle’s brakelamps are not operating properly.
Page 151 Driving Understanding gearshift positions P (Park) Always come to a complete stop before shifting into P (Park). Make sure the gearshift lever is securely latched in P (Park). This position locks the transmission and prevents the rear wheels from turning. Always set the parking brake fully and make sure the gearshift lever is latched in P (Park).
Page 152 Driving The transmission control indicator light (TCIL) will illuminate on the instrument cluster. Drive – Not shown on the display. Activate by pressing the transmission control switch on the end of the gearshift lever with the gearshift in position. The O/D OFF indicator will illuminate on the instrument cluster.
Page 153 Driving Forced Downshifts To gain acceleration in (Overdrive) or Drive (O/D OFF) when passing another vehicle, push the accelerator to the floor. The transmission will downshift to the appropriate gear: third, second or first gear. Driving with a 5–speed automatic transmission (if equipped) Understanding gearshift positions Hold the brake pedal down while you move the gearshift lever from P (Park) to another position.
Page 154 Driving (Overdrive) The normal driving position for the best fuel economy. Transmission operates in gears one through five. (Overdrive) can be deactivated by pressing the transmission control switch on the end of the gearshift ON/OFF lever. The transmission control indicator light (TCIL) will illuminate on the instrument cluster.
Page 155 Driving 1 (First) Use 1 (First) to provide maximum engine braking on steep downgrades. Upshifts can be made by shifting to 2 (Second) or to (Overdrive). Selecting 1 (Low) at higher speeds causes the transmission to shift to a lower gear and will shift to 1 (First) after the vehicle decelerates to the proper vehicle speed.
Page 156 Driving Positions of the Control-Trac system The Control-Trac system functions in three modes: • The 4WD AUTO mode provides four-wheel drive with full power delivered to the rear axle, and to the front axle as required for increased traction. This is appropriate for normal on-road operating conditions, such as dry road surfaces, wet pavement,...
Page 157 Driving If your vehicle is equipped with 4WD or AWD, a spare tire of a different size than the road tires should never be used. Such a tire could result in damage to driveline components and make the vehicle difficult to control. Utility and four-wheel drive vehicles are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed to perform satisfactorily under...
Page 158 Driving Shifting from 4WD LOW to 4WD AUTO or 4WD HIGH 1. Bring the vehicle to a stop. 2. Depress the brake. 3. Place the gearshift in N (Neutral). 4. Move the 4WD control to the 4WD AUTO or 4WD HIGH position. Driving off-road with 4WD Your vehicle is specially equipped for driving on sand, snow, mud and rough terrain and has operating characteristics that are somewhat...
Page 159 Driving Do not spin the wheels at over 56 km/h (35 mph). The tires may fail and injure a passenger or bystander. Sand When driving over sand, try to keep all four wheels on the most solid area of the trail. Do not reduce the tire pressures but shift to a lower gear and drive steadily through the terrain.
Page 160 Driving When climbing a steep hill, start in a lower gear rather than downshifting to a lower gear from a higher gear once the ascent has started. This reduces the strain on the engine. When descending a steep hill, avoid sudden braking. Shift to a lower gear when added engine braking is desired.
Page 161 Driving Utility and four-wheel drive vehicles are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed to perform satisfactorily under off-road conditions. Avoid sharp turns or abrupt maneuvers in these vehicles.
Page 162 Driving gear and drive steadily through the terrain. Apply the accelerator slowly and avoid spinning the wheels. Mud and water If you must drive through high water, drive slowly. Traction or brake capability may be limited. When driving through water, determine the depth; avoid water higher than the bottom of the hubs (if possible) and proceed slowly.
Page 163 Driving If vehicle speed drops more than 16 km/h (10 mph), the speed control will cancel automatically. Resume speed with accelerator pedal. If speed control cancels after climbing the hill, reset speed by pressing and holding the SET ACCEL button (to resume speeds over 50 km/h [30 mph]).
Page 164 Driving • Payload: Combined maximum allowable weight of cargo, passengers and optional equipment. The payload equals the gross vehicle weight rating minus base curb weight. • GVW (Gross Vehicle Weight): Base curb weight plus payload weight. The GVW is not a limit or a specification. •...
Page 165 Driving limitations. Replacement tires with a higher limit than the originals do not increase the GVWR and GAWR limitations. The Certification Label, found on the inside pillar of the driver’s door, lists several important vehicle weight rating limitations. Before adding any additional equipment, refer to these limitations.
Page 166 Driving Calculating the load your vehicle can carry/tow 1. Use the appropriate maximum gross combined weight rating (GCWR) chart to find the maximum GCWR for your type engine and rear axle ratio. 2. Weigh your vehicle as you customarily operate the vehicle without cargo.
Page 167 Driving • Thoroughly prepare your vehicle for towing. Refer to Preparing to tow in this chapter. • Use extra caution when driving while trailer towing. Refer to Driving while you tow in this chapter. • Service your vehicle more frequently if you tow a trailer. Refer to the severe duty schedule in the Scheduled Maintenance Guide.
Page 168 Driving Trailer towing table (4x4 and AWD automatic transmission) GCWR (Gross Combined Weight Rating)/Trailer Weights 4.0L 4 082 0-2 132 3.55 4.64 (50) SOHC (9 000) (0-4 700) 4.0L 4 535 0-2 585 3.73 4.64 (50) SOHC (10 000) (0-5 700) 4 535 0-2 522 5.0L...
Page 169 Driving Safety chains Always connect the trailer’s safety chains to the frame or hook retainers of the vehicle. To connect the trailer’s safety chains, cross the chains under the trailer tongue and allow slack for turning corners. If you use a rental trailer, follow the instructions that the rental agency gives to you.
Page 170 Driving Driving while you tow When towing a trailer: • Ensure that you turn off your speed control. The speed control may shut off automatically when you are towing on long, steep grades. • Consult your local motor vehicle speed regulations for towing a trailer. •...
Page 171 Driving • Do not allow waves to break higher than 15 cm (6 inches) above the bottom edge of the rear bumper. Exceeding these limits may allow water to enter critical vehicle components, adversely affecting driveability, emissions, reliability and causing internal transmission damage. Replace the rear axle lubricant anytime the axle has been submerged in water.
Page 172: Roadside Emergencies
In the United States, this card is found in the Owner Guide portfolio in the glove compartment in Ford vehicles and is mailed to you if you own a Mercury or Lincoln. In Canada, it is found in the Roadside Assistance book in the glove compartment.
Page 173 In the United States, you may purchase additional roadside assistance coverage beyond this period through the Ford Auto Club by contacting your Ford or Lincoln Mercury dealer. HAZARD FLASHER Use only in an emergency to warn traffic of vehicle breakdown, approaching danger, etc.
Page 174 Roadside emergencies The fuel pump shut-off switch is located in the passenger’s foot well, by the kick panel. Use the following procedure to reset the fuel pump shut-off switch. 1. Turn the ignition to the OFF position. 2. Check the fuel system for leaks. 3.
Page 175 Roadside emergencies FUSES AND RELAYS Fuses If electrical components in the vehicle are not working, a fuse may have blown. Blown fuses are identified by a broken wire within the fuse. Check the appropriate fuses before replacing any electrical components. Always replace a fuse with one that has the specified amperage rating.
Page 176 Roadside emergencies Passenger compartment fuse panel The fuse panel is located on the left hand side of the instrument panel facing the driver’s side door. Pull the panel cover outward to access the fuses. To remove a fuse use the fuse puller tool provided on the fuse panel cover.
Page 177 Roadside emergencies The fuses are coded as follows: Fuse/Relay Fuse Amp Passenger Compartment Fuse Panel Location Rating Description 7.5A Power Mirror Switch, Power Antenna, Memory Seat 7.5A Blower Motor Relay, Air Bag Diagnostic Monitor 7.5A Left Stop/Turn Trailer Tow Connector Left Headlamp Data Link Connector (DLC) 7.5A...
Page 178 Roadside emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Panel Location Rating Description Flasher (Hazard) Auxiliary Power Socket — Not Used 7.5A Clutch Pedal Position (CPP) Switch, Starter Interrupt Relay, Anti-Theft 7.5A Generic Electronic Module (GEM), Instrument Cluster, Securi-Lock Battery Saver Relay, Electronic Shift Relay, Interior Lamp Relay, Electronic Shift Control Module DRL, Backup Lamps Switch, DTR Sensor...
Page 179 Roadside emergencies Power distribution box The power distribution box is located in the engine compartment. The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads. Always disconnect the battery before servicing high current fuses. Always replace the cover to the Power Distribution Box before reconnecting the battery or refilling fluid reservoirs.
Page 180 Roadside emergencies MEGAFUSE The high-current fuses are coded as follows: Fuse/Relay Fuse Amp Power Distribution Box Description Location Rating 60A** I/P Fuse Panel 40A** Blower Motor Relay 50A** 4 Wheel Anti-Lock Brake System (4WABS) Module 30A** Power Windows, Power Moon Roof, Power Seat 50A** Ignition Switch, Starter Relay...
Page 181 Roadside emergencies Fuse/Relay Fuse Amp Power Distribution Box Description Location Rating 10A* Powertrain Control Module 30A* 4 Wheel Anti-Lock System (4WABS) Module 15A* Rear Wiper Motor 20A* Fuel Pump Relay and RAP Module 15A* Horn Relay 15A* Parklamps Relay and Mainlight Switch 30A* Mainlight Switch and Multifunction Switch 15A*...
Page 182 Roadside emergencies Spare tire information Your vehicle is equipped with a spare tire that must be used for emergencies only. The spare tire for your vehicle is not as wide as a regular tire and is designed for emergency use only. Replace this tire with a full-size tire as soon as possible.
Page 183 Roadside emergencies Stowing the spare tire 1. Lay the tire on the ground with the valve stem facing up. 2. Slide the wheel under the vehicle and install the retainer through the wheel center. 3. Turn the jack handle clockwise until the tire is raised to its original position underneath the vehicle.
Page 184 Roadside emergencies When one of the rear wheels is off the ground, the transmission alone will not prevent the vehicle from moving or slipping off the jack, even if the transmission is in P (Park). 3. Block the diagonally opposite wheel.
Page 185 Roadside emergencies • Front • Rear To lessen the risk of personal injury, do not put any part of your body under the vehicle while changing a tire. Do not start the engine when your vehicle is on the jack. The jack is only meant for changing the tire.
Page 186 Roadside emergencies 10. Lower the wheel by turning the jack handle counterclockwise. 11. Remove the jack and fully tighten the lug nuts in the order shown. 12. Stow the flat tire, jack and lug wrench. Make sure the jack is fastened so it does not rattle when you drive.
Page 187 Roadside emergencies Preparing your vehicle 1. Use only a 12–volt supply to start your vehicle. 2. Do not disconnect the battery of the disabled vehicle as this could damage the vehicle’s electrical system. 3. Park the booster vehicle close to the hood of the disabled vehicle making sure the two vehicles do not touch.
Page 188 Roadside emergencies 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery. 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor/fuel injection system.
Page 189 Roadside emergencies • Engines except 4.0L SOHC • 4.0L SOHC 5. Ensure that the cables are clear of fan blades, belts, moving parts of both engines, or any fuel delivery system parts. Jump starting 1. Start the engine of the booster vehicle and run the engine at moderately increased speed.
Page 190 Roadside emergencies 3. Once the disabled vehicle has been started, run both engines for an additional three minutes before disconnecting the jumper cables. Removing the jumper cables Remove the jumper cables in the reverse order that they were connected. 1. Remove the jumper cable from the ground metal surface. •...
Page 191 Roadside emergencies 2. Remove the jumper cable on the negative (-) connection of the booster vehicle’s battery. 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery.
Page 192 Roadside emergencies WRECKER TOWING If you need to have your vehicle towed, contact a professional towing service or, if you are a member, your roadside assistance center. It is recommended that your vehicle be towed with a wheel lift or flatbed equipment.
Page 193: Maintenance And Care
Maintenance and care SERVICE RECOMMENDATIONS To help you service your vehicle: • We highlight do-it-yourself items in the engine compartment for easy location. • We provide a Scheduled Maintenance Guide which makes tracking routine service easy. If your vehicle requires professional service, your dealership can provide necessary parts and service.
Page 194 Maintenance and care Do not start your engine with the air cleaner removed and do not remove it while the engine is running. OPENING THE HOOD 1. Inside the vehicle, pull the hood release handle located under the steering column on the instrument panel.
Page 195 Maintenance and care IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 4.0L SOHC V6 engine 1. Windshield washer fluid reservoir 2. Automatic transmission fluid dipstick 3. Engine oil filler cap 4. Engine oil dipstick 5. Brake fluid reservoir 6. Power distribution box 7.
Page 196 Maintenance and care 5.0L V8 engine 1. Engine coolant reservoir 2. Windshield washer fluid reservoir 3. Engine oil filler cap 4. Automatic transmission fluid dipstick 5. Brake fluid reservoir 6. Power distribution box 7. Battery 8. Power steering fluid reservoir 9.
Page 197 Maintenance and care 3. Set the parking brake and ensure the gearshift is securely latched in P (Park). 4. Open the hood. Protect yourself from engine heat. 5. Locate and carefully remove the engine oil level indicator (dipstick). • 4.0L V6 engine •...
Page 198 Maintenance and care 6. Wipe the indicator clean. Insert the indicator fully, then remove it again. • If the oil level is between the MIN and MAX marks, the oil level is acceptable. DO NOT ADD OIL. • If the oil level is below the MIN mark, add enough oil to raise the level within the MIN-MAX range.
Page 199 Maintenance and care Engine oil and filter recommendations Look for this certification trademark. Use SAE 5W-30 motor oil certified for gasoline engines by the American Petroleum Institute (API). Motor oil displaying the API certification trademark will meet all requirements for your vehicle’s engine. Ford oil specification is WSS-M2C153-G.
Page 200 Maintenance and care BRAKE FLUID Checking and adding brake fluid Brake fluid should be checked and refilled as needed. Refer to the Scheduled Maintenance Guide for the service interval schedules. 1. Clean the reservoir cap before removal to prevent dirt or water from entering the reservoir.
Page 201 Maintenance and care WINDSHIELD WASHER FLUID Checking and adding washer fluid Check the washer fluid whenever you stop for fuel. The reservoir is highlighted with a symbol. If the level is low, add enough fluid to fill the reservoir. In very cold weather, do not fill the reservoir all the way.
Page 202 Maintenance and care A 50/50 mixture of distilled water and Ford Premium Engine Coolant provides: • maximum cooling system efficiency. • freeze protection down to -36° C (-34° F). • boiling protection up to 129° C (265° F). • protection against rust and other forms of corrosion. •...
Page 203 Maintenance and care Automotive fluids are not interchangeable; do not use engine coolant, antifreeze or windshield washer fluid outside of its specified function and vehicle location. Adding engine coolant Use only Ford Premium Engine Coolant E2FZ-19549-AA (in Canada, Motorcraft CXC-10) or a premium engine coolant that meets Ford specification ESE-M97B44-A.
Page 204 Maintenance and care Plain water may be added in an emergency, but you must replace it with a 50/50 mixture of engine coolant and distilled water as soon as possible. Check the coolant level in the reservoir before you drive your vehicle the next few times (with the engine cool).
Page 205 Maintenance and care Coolant refill capacity To find out how much fluid your vehicle’s cooling system can hold, refer to Refill capacities in the Capacities and specifications chapter. Fill your engine coolant reservoir as outlined in Adding engine coolant in this chapter. Severe climates If you drive in extremely cold climates (less than –36°...
Page 206 Maintenance and care CHECKING AND ADDING POWER STEERING FLUID Check the power steering fluid. Refer to the Scheduled Maintenance Guide for the service interval schedules. If adding fluid is necessary, use only MERCON ATF. • 4.0L SOHC V6 engine • 5.0L V8 engine 1.
Page 207 Maintenance and care 6. If the fluid is low, add fluid in small amounts, continuously checking the level until it reaches the correct operating range. Be sure to put the cap back on the reservoir. TRANSMISSION FLUID Checking automatic transmission fluid Refer to your Scheduled Maintenance Guide for scheduled intervals for fluid checks and changes.
Page 208 Maintenance and care Low fluid level Do not drive the vehicle if the fluid level is at the bottom of the dipstick and the ambient temperature is above 10°C (50°F). COLD DO NOT ADD Correct fluid level The transmission fluid should be checked at normal operating temperature 66°C-77°C (150°F-170°F) on a level surface.
Page 209 Maintenance and care High fluid level Fluid levels above the safe range may result in transmission failure. An overfill condition of transmission fluid may cause shift and/or engagement concerns and/or possible damage. High fluid levels can be caused by COLD DO NOT ADD an overheating condition.
Page 210 Maintenance and care CHECKING AND ADDING TRANSFER CASE FLUID (IF EQUIPPED) 1. Clean the filler plug. 2. Remove the filler plug and inspect the fluid level. 3. Add only enough fluid through the filler opening so that the fluid level is at the bottom of the opening.
Page 211 Maintenance and care BATTERY Your vehicle is equipped with a Motorcraft maintenance-free battery which normally does not require additional water during its life of service. However, for severe usage or in high temperature climates, check the battery electrolyte level. Refer to the Scheduled Maintenance Guide for the service interval schedules.
Page 212 Maintenance and care When lifting a plastic-cased battery, excessive pressure on the end walls could cause acid to flow through the vent caps, resulting in personal injury and/or damage to the vehicle or battery. Lift the battery with a battery carrier or with your hands on opposite corners.
Page 213 Maintenance and care • Always dispose of automotive batteries in a responsible manner. Follow your local authorized standards for disposal. Call your local authorized recycling center to find out more about recycling automotive batteries. RECYCLE WINDSHIELD WIPER BLADES Check the wiper blades at least twice a year or when they seem less effective.
Page 214 Maintenance and care INFORMATION ABOUT UNIFORM TIRE QUALITY GRADING New vehicles are fitted with tires that have a rating on them called Tire Quality Grades. The Quality grades can be found where applicable on the tire sidewall between tread shoulder and maximum section width.
Page 215 Maintenance and care The traction grade assigned to this tire is based on straight-ahead braking traction tests, and does not include acceleration, cornering, hydroplaning or peak traction characteristics. Temperature A B C The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 216 Maintenance and care them as indicated in the Scheduled Maintenance Guide. If you notice that the tires wear unevenly, have them checked. • Four tire rotation Replacing the tires Replace the tires when the wear band is visible through the tire treads.
Page 217 Maintenance and care Make sure that all replacement tires are of the same size, type, load-carrying capacity and tread design (e.g., “All Terrain”, etc.), as originally offered by Ford. Do not replace your tires with “high performance” tires or larger size tires.
Page 218 Maintenance and care WHAT YOU SHOULD KNOW ABOUT AUTOMOTIVE FUELS Important safety precautions Do not overfill the fuel tank. The pressure in an overfilled tank may cause leakage and lead to fuel spray and fire. The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap.
Page 219 Maintenance and care • Avoid inhaling fuel vapors. Inhaling too much fuel vapor of any kind can lead to eye and respiratory tract irritation. In severe cases, excessive or prolonged breathing of fuel vapor can cause serious illness and permanent injury. •...
Page 220 Maintenance and care Choosing the right fuel Use only UNLEADED FUEL. The use of leaded fuel is prohibited by law and could damage your vehicle. Do not use fuel containing methanol. It can damage critical fuel system components. Your vehicle was not designed to use fuel or fuel additives with metallic compounds, including manganese-based compounds containing MMT.
Page 221 Maintenance and care your fuel supplier about gasolines that meet the World-wide Fuel Charter. Cleaner air Ford approves the use of reformulated “cleaner-burning” gasolines to improve air quality. These gasolines may contain oxygenates up to 10% ethanol or 15% MTBE. Running out of fuel Avoid running out of fuel because this situation may have an adverse affect on powertrain components.
Page 222 Maintenance and care The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap. Otherwise, fuel may spray out and injure you or others. If you do not use the proper fuel filler cap, excessive pressure or vacuum in the fuel tank may damage the fuel system or cause the fuel system to work improperly in a collision, which may result in...
Page 223 Maintenance and care The amount of empty reserve varies and should not be relied upon to increase driving range. When refueling your vehicle after the fuel gauge indicates empty, you might not be able to refuel the full amount of the advertised capacity of the fuel tank due to the empty reserve still present in the tank.
Page 224 Maintenance and care Driving style — good driving and fuel economy habits Give consideration to the lists that follow and you may be able to change a number of variables and improve your fuel economy. Habits • Smooth, moderate operation can yield up to 10% savings in fuel. •...
Page 225 Maintenance and care Conditions • Heavily loading a vehicle or towing a trailer may reduce fuel economy at any speed. • Carrying unnecessary weight may reduce fuel economy (approximately 0.4 km/L [1 mpg] is lost for every 180 kg [400 lb] of weight carried). •...
Page 226 Maintenance and care • Do not turn off the ignition while your vehicle is moving, especially at high speeds. • Have the items listed in your Scheduled Maintenance Guide performed according to the specified schedule. The scheduled maintenance items listed in the Scheduled Maintenance Guide are essential to the life and performance of your vehicle and to its emissions system.
Page 227 Maintenance and care If the vehicle’s powertrain system or its battery has just been serviced, the on-board diagnostics system is reset to a “not ready for I/M test” condition. To ready the on-board diagnostics system for I/M testing, a minimum of 30 minutes of city and highway driving is necessary as described below: •...
Page 228 Maintenance and care Replacing headlamp bulbs To remove the headlamp bulb: 1. Make sure headlamp switch is in OFF position, then lift hood and open the hinged headlamp cover. 2. Disconnect the electrical connector from the bulb by pulling rearward. 3.
Page 229 Maintenance and care If the bulb is accidentally touched, it should be cleaned with rubbing alcohol before being used. 1. With the flat side of the new bulb’s plastic base facing upward, insert the glass end of the bulb into the lamp assembly. You may need to turn the bulb left or right to align the grooves in the plastic base with the tabs in the lamp assembly.
Page 230 Maintenance and care 4. Rotate bulb socket counterclockwise about ⁄ turn and remove from lamp assembly. 5. Carefully pull bulb straight out of socket and push in the new bulb. 6. Install bulb socket in lamp assembly by turning clockwise. 7.
Page 231 Maintenance and care Replacing license plate lamp bulbs 1. Remove two screws and the license plate lamp assembly from the liftgate. 2. Remove bulb socket from lamp assembly by turning counterclockwise. 3. Pull the bulb out from socket and push in the new bulb. 4.
Page 232: Customer Assistance
Maintenance and care Function Number of bulbs Trade number Map lamps 168 (T10) Ashtray lamp All replacement bulbs are clear in color except where noted. To replace all instrument panel lights - see your dealer. AIMING THE HEADLAMPS The headlamps on your vehicle are properly aimed at the assembly plant. If your vehicle has been in an accident the alignment of your headlamps should be checked by a qualified service technician.
Page 233 Maintenance and care Waxing your vehicle Waxing your vehicle on a regular basis will reduce minor scratches and paint damage. Wax when water stops beading on the surface. This could be every three or four months, depending on operating conditions. Use only carnauba or synthetic-based waxes.
Page 234 Maintenance and care • 5.0L • 4.0L SOHC • Never wash or rinse the engine while it is running; water in the running engine may cause internal damage. Cleaning the wheels Wash with the same detergent as the body of your vehicle. Do not use acid-based or alcohol-based wheel cleaners, steel wool, fuel or strong detergents.
Page 235 Maintenance and care Underbody Flush the complete underside of vehicle frequently. Keep body drain holes unplugged. Inspect for road damage. Cleaning non-painted plastic exterior parts Use vinyl cleaner for routine cleaning. Clean with a tar remover if necessary. Do not clean plastic parts with thinners, solvents or petroleum-based cleaners.
Page 236 Maintenance and care Do not use chemical solvents or strong detergents when cleaning the seat mounted side air bag. Such products could contaminate the side air bag system and affect performance of the side air bag in a collision. Cleaning the instrument panel Clean with a damp cloth, then dry with a dry cloth.
Page 237 Maintenance and care refer to the Safety belt maintenance section in the Seating and safety restraints chapter. Cleaning leather seats (if equipped) To clean, simply use a soft cloth dampened with water and a mild soap. Wipe the leather again with a damp cloth to remove soap residue. Dry with a soft cloth.
Page 238: Capacities And Specifications
Capacities and specifications MOTORCRAFT PART NUMBERS Component 4.0L SOHC V6 engine 5.0L V8 engine Air filter element FA-1658 FA-1658 Fuel filter FG-986B FG-986B Battery BXT-65-650 BXT-65-650 Oil filter FL-1A FL-820S PCV valve EV-225 EV-152 Spark plugs* AGSF-22PP AWSF-32EE** * Refer to Vehicle Emissions Control Information (VECI) decal for spark plug gap information.
Page 239 Capacities and specifications Fluid Ford Part Application Capacity Name Transmission Motorcraft 4R70W 13.1L fluid MERCON V Automatic with (13.9 quarts) 5.0L V8 engine (AWD) 5R55E 9.5L Automatic with (10.0 quarts) 4.0L SOHC V6 engine (4x2) 5R55E 9.8L Automatic with (10.3 quarts) 4.0L SOHC V6 engine (4x4) Transfer case...
Page 240 Capacities and specifications Ensure the correct automatic transmission fluid is used. Transmission fluid requirements are indicated on the dipstick or on the dipstick handle. MERCON and MERCON V are not interchangeable. DO NOT mix MERCON and MERCON V. Refer to your Scheduled Maintenance Guide to determine the correct service interval.
Page 241 Capacities and specifications LUBRICANT SPECIFICATIONS Ford part Ford part Ford Item name or number specification equivalent High Performance ESA-M6C25-A Brake fluid DOT 3 Motor C6AZ-19542-AB and DOT 3 Vehicle Brake Fluid Body hinges, latches, door striker plates and rotors, seat DOAZ-19584-AA Multi-Purpose ESB-M1C93-B or...
Page 242 Capacities and specifications Ford part Ford part Ford Item name or number specification equivalent Motorcraft SAE Front axle 80W-90 XY-80W90-QL WSP-M2C197-A (4X4) Premium Rear Axle Lubricant Transfer case Motorcraft XT-2-QDX MERCON (4X4) MERCON ATF Transfer case XG-1-C or Premium Front Output XG-1-T or ESA-M1C75-B Long-Life Grease...
Page 243 Capacities and specifications ENGINE DATA Engine 4.0L SOHC V6 engine 5.0L V8 engine Cubic inches Required fuel 87 octane 87 octane Firing order 1-4-2-5-3-6 1-3-7-2-6-5-4-8 Spark plug gap 1.3-1.4 mm 1.3-1.4 mm (0.052-0.056 inch) (0.052-0.056 inch) Ignition system EDIS EDIS Compression ratio 9.7:1 9.15:1...
Page 244 Capacities and specifications...
Page 245: Certification Label
Capacities and specifications IDENTIFYING YOUR VEHICLE Certification label The National Highway Traffic Safety MFD. BY FORD MOTOR CO. IN U.S.A. Administration Regulations require DATE: XXXXX GVWR:XXXXX LB/ XXXXX KG that a Certification Label be affixed FGAWR: XXXXXX/XXXXXXX RGAWR: XXXXXXX/XXXXXXX THIS VEHICLE CONFORMS TO ALL APPLICABLE FEDERAL to a vehicle and prescribe where the MOTOR VEHICLE SAFETY STANDARDS IN EFFECT ON THE Certification Label may be located.
Page 246: Customer Assistance
You may purchase Ford ESP from any participating Ford and Lincoln/ Mercury and Ford of Canada dealer. There are several plans available in various time, distance and deductible combinations which can be tailored to fit your own driving needs. Ford ESP also offers reimbursement benefits for towing and rental coverage.
Page 247 Away from home If you own a Ford or Mercury vehicle and are away from home when your vehicle needs service, or if you need more help than the dealership could provide, after following the steps described above, contact the Ford Customer Assistance Center to find an authorized dealership to help you.
Page 248 P.O. Box 2000 Oakville, Ontario L6J 5E4 1-800-565-3673 (FORD) In order to help you service your Ford or Lincoln Mercury vehicle, please have the following information available when contacting a Customer Assistance Center: • Your telephone number (home and business) •...
Page 249 Unresolved warranty repair concerns or vehicle performance as designed concerns on Ford and Lincoln Mercury cars and Ford and Lincoln Mercury light trucks which are within the terms of any applicable written new vehicle warranty are eligible for review, except those involving: •...
Page 250 • a Ford or Lincoln Mercury dealership representative Consumer candidates for Board membership are recruited and trained by an independent consulting firm. The dealership Board member is chosen from Ford and Lincoln Mercury dealership management, recognized for their business leadership qualities. What the Board needs...
Page 251 Customer assistance • a brief summary of the action taken by the dealer(s) and Ford Motor Company • the names (if known) of all the people you contacted at the dealership(s) • a description of the action you expect to resolve your concern You will receive a letter of explanation if your application does not qualify for Board review.
Page 252 Customer assistance You may also contact the North American Customer Assistance Center at 1-800-392-3673 (Ford), TDD for the hearing impaired: 1-800-232-5952 or by writing to the Center at the following address: Ford Motor Company Customer Assistance Center 16800 Executive Plaza Drive P.O.
Page 253 Customer assistance The use of leaded fuel in your vehicle without proper conversion may damage the effectiveness of your emission control system and may cause engine knocking or serious engine damage. Ford Motor Company/Ford of Canada is not responsible for any damage caused by use of improper fuel.
Page 254 FORD ACCESSORIES FOR YOUR VEHICLE A wide selection of Ford accessories are available for your vehicle through your local authorized Ford, Lincoln Mercury or Ford of Canada dealer. These quality accessories have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and aerodynamic appearance of your vehicle.
Page 255 Customer assistance Comfort and convenience Cargo nets Cargo organizers Cargo shades Engine block heaters Home link visor Tire step Travel equipment Auto headlamps with daytime running lamps (DRL) Daytime running lights Factory luggage rack adaptors Fog lights Heavy-duty battery Interior mirror, electrochromic with compass (with and without temperature display) Removable luggage rack Removable luggage rack adapters...
Page 256 Customer assistance Door edge guards Front end covers (full and sport) Hood deflectors Locking gas cap Lubricants and oils Molded splash guards Molded vinyl floor mats Rear air deflectors Side window air deflectors Touch-up paint Universal floor mats For maximum vehicle performance, keep the following information in mind when adding accessories or equipment to your vehicle: •...
Page 257 Customer assistance ORDERING ADDITIONAL OWNER’S LITERATURE To order the publications in this portfolio: Make checks payable to: HELM, INCORPORATED P.O. Box 07150 Detroit, Michigan 48207 For a free publication catalog, order toll free: 1-800-782-4356 Monday-Friday 8:00 a.m. - 6:00 p.m. EST, for credit card holders only Obtaining a French owner’s guide French Owner’s Guides can be obtained from your dealer or by writing to...
Page 258: Reporting Safety Defects
Reporting safety defects REPORTING SAFETY DEFECTS (U.S. ONLY) If you believe that your vehicle has a defect that could cause a crash, or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Ford Motor Company.
Page 259: Index
Index Air bag supplemental acid, treating emergencies ..210 restraint system ....126,130 charging system and child safety seats ....128 warning light ......11 description .......126,130 jumping a disabled battery ..185 disposal ........133 maintenance-free ....210 driver air bag ....128,131 replacement, specifications ...237 indicator light ....9,130,132 servicing ........210 operation ......128,131 voltage gauge ......16...
Page 260 Index washing ........231 Defrost waxing ........232 rear window ......33 wheels ........233 Dipstick windows ........236 automatic wiper blades ......234 transmission fluid ....206 woodtone trim ......236 engine oil .........195 Climate control (see Air Doors conditioning or Heating) ....22 door ajar warning .....12 Clock ........41,51,64 lubricant specifications ..240 Compass, electronic ....86...
Page 261 Index Foglamps ........21 trip odometer ......15 Four-Wheel GAWR Drive vehicles ....11,12,154 (Gross Axle Weight Rating) ..162 control trac ......33,154 calculating .......165 description .......155,156 definition .........162 driving off road ....157,160 driving with a heavy load ..162 electronic shift ......33 location ........162 preparing to GVWR (Gross drive your vehicle ....147...
Page 262 Index lighting up Load limits .........162 panel and interior .....22 GAWR ........162 location of components ....8 GVWR ........162 Jump-starting your vehicle ..185 trailer towing ......162 Keyless entry system ....106 Loading instructions ....164 autolock ........107 Locks keypad ........106 autolock ........107 locking and unlocking doors ..107 childproof ........96 programming entry code ..106 doors ..........95...
Page 263 Index Relays ........174 Speed control ......77 Remote entry system ..101,102 Speedometer .......14 illuminated entry ....105 Starting your vehicle ..140,142 locking/unlocking doors ..102 jump starting ......185 panic alarm ......102 Steering wheel replacement/additional controls ........82 transmitters ......104 tilting .........81 replacing the batteries ...104 Tachometer .........15 Reverse sensing system .....33 Tilt steering wheel ......81...
Page 264 Index rear wiper/washer .....82 liftgate reservoir .....200 Windshield washer fluid and operation ........81 wipers ..........82 replacing wiper blades ...212 checking and adding fluid ..200 Wrecker towing ......191 checking and cleaning ....212...
Page 265: Filling Station Information
Filling station information Item Information Required fuel Unleaded fuel only - 87 octane Fuel tank capacity 75.5L (21.0 gallons) Engine oil capacity (includes filter 4.7L (5.0 quarts). Use change) Motorcraft SAE 5W-30 Super Premium Motor Oil, Ford specification WSS-M2C153-G. Tire size and pressure Refer to the Certification Label on inside of driver’s door.

This manual is also suitable for:

2000 sable

Mercury Mountaineer 2000 Owner's Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Mercury Mountaineer 2000

Summary of Contents for Mercury Mountaineer 2000

This manual is also suitable for:

Table of Contents
