Body Solid PowerLine PFID-130X Owner's Manual

Incline/decline bench
Hide thumbs

Advertisement

Quick Links

PFID-130X
INCLINE/DECLINE BENCH
Owner's Manual
WWW.BODYSOLID.COM
¡
¢
£
¤
¢
¢
¥
¦

Advertisement

loading
Need help?

Need help?

Do you have a question about the PowerLine PFID-130X and is the answer not in the manual?

Questions and answers

Related Manuals for Body Solid PowerLine PFID-130X

Summary of Contents for Body Solid PowerLine PFID-130X

  • Page 1 PFID-130X INCLINE/DECLINE BENCH Owner’s Manual WWW.BODYSOLID.COM ¡ ¢ £ ¤ ¢ ¢ ¥ ¦...
  • Page 2 THERE IS A RISK ASSUMED BY INDIVIDUALS WHO USE THIS TYPE OF EQUIPMENT. TO MINIMIZE RISK, YOU MUST FOLLOW THESE RULES: Inspect equipment before each workout. Check that all nuts, bolts, screws and pop pins are in place and fully tightened. Also, before use, check cables for sign of wear. Replace all worn parts immediately.

  • Page 3: Table Of Contents

    PFID-130X TABLE OF CONTENTS • SAFETY INSTRUCTIONS....... PAGE 4 • PREPARATION........PAGE 5 • HARDWARE LIST........PAGE 6 • HARDWARE ILLUSTRATION....PAGE 7 • PART LIST / ILLUSTRATION....PAGE 10 • ASSEMBLY INSTRUCTIONS....PAGE 12 • EXPLODED VIEW........PAGE 20 •...

  • Page 4: Safety Instructions

    PFID-130X SAFETY INSTRUCTIONS When using exercise equipment, The PFID-130X is designed for your enjoyment. By you should always take basic following these precautions and using common sense, precautions including the you will have many safe and pleasurable hours of following: healthful exercise with your Powerline Flat/Incline/ Decline Bench.

  • Page 5: Preparation

    The bottles that are marked “Poison” is your touch up paint. Keep away from children. Set up the PFID-130X on a solid, fl at surface. A smooth, fl at surface under the machine helps keep it level. : Obtain assistance! If you feel like you can’t assemble the PFID-130X by yourself then do Provide ample space around the machine.

  • Page 6: Hardware List

    PFID-130X HARDWARE LIST PART # SIZE DESCRIPTION QUANTITY...

  • Page 7: Hardware Illustration

    PFID-130X HARDWARE ILLUSTRATION Part #1 M8X20mm hex head bolt Qty.6 Part #2 M8X45mm hex head bolt Qty.1 Part #3 M10X65mm hex head bolt Qty.1 Part #4 M10X70mm hex head bolt Qty.2 Part #5 M10X80mm hex head bolt Qty.2...
  • Page 8 PFID-130X HARDWARE ILLUSTRATION CONT. Part #6 M10X145mm hex head bolt Qty.2 Part #7 M10 nylon lock nut Qty.7 Part #8 M8 spring washer Qty. 7 Part #9 M8 washer (I.D.) Qty.7 Part #10 M10 washer (I.D.) Qty.14...
  • Page 9 PFID-130X HARDWARE ILLUSTRATION CONT. Part #11 quick release ring pin Qty.1 Part #12 t-handle ball pin Qty.1 Part #13 1”X1” end cap Qty.4 Part #14 45MMX45MM end cap Qty.2 Part #15 2”X2” end cap Qty.1 Part #16 1”X2” end cap Qty.1...

  • Page 10: Part List / Illustration

    PFID-130X PART LIST Part A Part B Part C mainframe seat frame back frame [1pcs] [1pcs] [1pcs] Part D Part E Part F base frame back support u-base frame [1pcs] [2pcs] [1pcs]...
  • Page 11 PFID-130X PART LIST CONT. Part G Part H Part I roller rods leg adjuster back pad [2pcs] [1pcs] [1pcs] Part J Part K Part L seat pad roller adjuster rod [1pcs] [4pcs] [1pcs]...

  • Page 12: Assembly Instructions

    PFID-130X STEP 1 BE CAREFUL TO ASSEMBLE ALL COMPONENTS IN THE SEQUENCE THAT THEY ARE PRESENTED. NOTE: finger tighten all hardware in this step. DO NOT wrench tighten until the last step. some components may be pre-assembled. nylon lock nuts will not fully screw onto bolts, must wrench tighten.
  • Page 13 PFID-130X STEP 1 Above shows STEP 1 assembled and completed...
  • Page 14 PFID-130X STEP 2 BE CAREFUL TO ASSEMBLE ALL COMPONENTS IN THE SEQUENCE THAT THEY ARE PRESENTED. NOTE: finger tighten all hardware in this step. DO NOT wrench tighten until the last step. some components may be pre-assembled. nylon lock nuts will not fully screw onto bolts, must wrench tighten.
  • Page 15 PFID-130X STEP 2 Above shows STEP 2 assembled and completed...
  • Page 16 PFID-130X STEP 3 BE CAREFUL TO ASSEMBLE ALL COMPONENTS IN THE SEQUENCE THAT THEY ARE PRESENTED. NOTE: finger tighten all hardware in this step. DO NOT wrench tighten until the last step. some components may be pre-assembled. nylon lock nuts will not fully screw onto bolts, must wrench tighten.
  • Page 17 PFID-130X STEP 3 Above shows STEP 3 assembled and completed...
  • Page 18 PFID-130X STEP 4 BE CAREFUL TO ASSEMBLE ALL COMPONENTS IN THE SEQUENCE THAT THEY ARE PRESENTED. NOTE: finger tighten all hardware in this step. DO NOT wrench tighten until the last step. some components may be pre-assembled. nylon lock nuts will not fully screw onto bolts, must wrench tighten.
  • Page 19 PFID-130X STEP 4 Above shows STEP 4 assembled and completed...

  • Page 20: Exploded View

    PFID-130X EXPLODED VIEW...
  • Page 21 PFID-130X NOTES...

  • Page 22: Contact Page

    PFID-130X please write your serial number in the boxes below S/N # Body-Solid ® Built for Life 1900 S. Des Plaines Ave. Forest Park, IL 60130 Phone:(708)427-3555 Fax:(708)427-3556 Hours: M-F 8:30 - 5:00 CST www.bodysolid.com Copyright 2011. Body-Solid. All rights reserved. Body-Solid reserves the right to change design and speci cations when we feel it will improve the product.
