HD Audio Converter
Incorporates HDMI
HDMI Input to HDMI, Optical, Coaxial, and 3.5mm Audio Outputs
Monoprice Product ID 10251
The Monoprice HD Audio Converter taps into the incoming HDMI® signal to produce Digital Optical,
Digital Coaxial, and Analog 3.5mm TRS stereo audio outputs. The original, unaltered HDMI
audio/video signal is sent to your display as normal, while the audio outputs can be connected to your
home theater audio system for a superior audio experience. The converter supports all HDMI 3D
video modes and high-definition, multichannel audio, including Dolby TrueHD™ and DTS-HD Master
Audio™.
•
Converts HDMI audio to Digital Optical Toslink, Digital Coaxial, and 3.5mm stereo TRS
outputs
•
Supports all HDMI 3D video modes
Frame packing
1920x1080p@23.98/24Hz
1280x720p@59.94/60Hz
1280x720p@50Hz
•
225MHz pixel clock rate (per channel)
•
6.75Gbps total bandwidth/data throughput
•
HDCP compliant
•
Supports high-definition lossless compressed audio formats, including Dolby TrueHD and
DTS-Master Audio
•
Gold plated connectors for smooth, corrosion-free connections
®
technology
INTRODUCTION
FEATURES
Side-by-Side (Half)
1920x1080i@59.94/60Hz
1920x1080i@50Hz
1
Top-and-Bottom
1920x1080p@23.98/24Hz
1280x720p@59.94/60Hz
1280x720p@50Hz
Advertisement
Table of Contents
Related Manuals for Monoprice 10251
Summary of Contents for Monoprice 10251
- Page 1 Monoprice Product ID 10251 INTRODUCTION The Monoprice HD Audio Converter taps into the incoming HDMI® signal to produce Digital Optical, Digital Coaxial, and Analog 3.5mm TRS stereo audio outputs. The original, unaltered HDMI audio/video signal is sent to your display as normal, while the audio outputs can be connected to your home theater audio system for a superior audio experience.
- Page 2 PACKAGE CONTENTS Please take an inventory of the package contents to ensure you have all the items listed below. If anything is missing or damaged, please contact Monoprice Customer Service for a replacement. • 1x HD audio converter • 1x 3.5mm to RCA adapter cable •...
- Page 3 INSTALLATION Using a High Speed HDMI cable (not included) connect the HDMI output on your source device to the HDMI IN port on the front of the converter. Using a High Speed HDMI cable (not included) connect the HDMI input on your display to the HDMI OUT port on the back of the converter.
- Page 4 output mode. If you select a mode that is not supported you will either hear only noise out of the speakers or will hear nothing at all. NOTES • All specifications are subject to change without notice. • The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
