- Page 1 MR SERIES LOUDSPEAKERS OWNER’S MANUAL MR25 MR26 MR28 MR38 MR308II MR310II S E R I E S MR Center...
- Page 2 In the case of the M5, do not place the speaker closer than 3 inches (75mm) to the wall behind it if possible.
- Page 3 MR SERIES LOUDSPEAKERS CONNECTIONS To connect the loudspeaker systems to the receiver or amplifier, use two- conductor insulated wire. Your JBL dealer can recommend suitable cables, or you can buy wire at most hardware or electronic stores. We recommend #16 AWG wire as a mini- mum size.
- Page 4 part of the outer insulation; or a print- ed “+” marking on one of the insula- tors. It does not make any difference which of the two strands of wire go to (+) and (–) on the speakers and amplifier, as long as all speakers used in your system are connected identically.
-
Page 5: Power Handling
Consult the owner’s manual of the amp/receiver for clarification. POWER HANDLING Thanks to their high efficiency, the JBL MR Series Loudspeakers will produce reasonable volume levels in a room of moderate size with very lit- tle amplifier power. However, using a... -
Page 6: General Care
Do not push on the center area of the grille. NOTE: The M5 grille is non- removable. Do not attempt to pry the grille from the cabinet as this will void your warranty. The rear... - Page 7 Specifications Application High Frequency Dome Transducer Midrange Transducer (Nitrile Polymer Fibre Cone) Low Frequency Transducer (Nitrile Polymer Fibre Cone) Crossover Frequency Frequency Response (– 6 dB) Sensitivity (1 Watt/1 Meter) Nominal Impedance Recommended Amplifier Power* External Dimensions Height Width Depth External Dimensions Height Width...
-
Page 8: Specifications
For this reason, JBL MR Series Loudspeakers may differ in some respect from their published specifications and descriptions, but will always equal or exceed the original specifications unless otherwise stated.
