Coalbrookdale Much Wenlock Stove Operating Instructions Manual

Coalbrookdale Much Wenlock Stove Operating Instructions Manual

Freestanding much wenlock stove with boiler

Advertisement

THE MUCH
WENLOCK
Consumer Protection Act 1987
As manufacturers and suppliers of cooking and heating products, in
compliance with Section 10 of the Consumer Protection Act 1987,
we take every care to ensure as far as is reasonably practicable, that
these products are so designed and constructed as to meet the
general safety requirement when properly used and installed. To this
end, our products are thoroughly tested and examined before
despatch.
IMPORTANT NOTICE:
Any alteration that is not approved by Aga-Rayburn,
could invalidate the approval of the appliance, operation of the warranty and
could also affect your statutory rights.
Control of Substances - Health and Safety
Important
This appliance may contain some of the materials that are indicated
below. It is the Users/Installers responsibility to ensure that the
necessary personal protective clothing is worn when
The appliance user should check with their installer that the
chimney has been examined and confirmed for soundness,
the chimney has been swept prior to the stove installation
and is free of any obstructions.
This appliance has obtained approval of HETAS LTD for
burning smokeless fuels only, and may be used for any of
the following:
1. Space heating and combined domestic hot water supply
and radiators.
2. Space heating and heating of pipes and radiators only.

Operating Instructions

for Freestanding
Much Wenlock Stove
with Boiler
handling, where applicable, the pertinent parts that contain any of
the listed materials that could be interpreted as being injurious to
health and safety, see below for information.
Firebricks, Fuel beds, Artificial Fuels - when handling use
disposable gloves.
Fire Cement - when handling use disposable gloves.
Glues and Sealants - exercise caution - if these are still in liquid
form use face-mask and disposable gloves.
Glass Yarn, Mineral Wool, Insulation Pads, Ceramic Fibre,
Kerosene Oil - may be harmful if inhaled, may be irritating to skin,
eyes nose and throat. When handling avoid inhaling and contact with
skin or eyes. Use disposable gloves, face-masks and eye protection.
After handling wash hands and other exposed parts. When disposing
of the product, reduce dust with water spray, ensure that parts are
securely wrapped.
The HETAS LTD. appliance approval only covers use of
smokeless fuels in this appliance. It does not cover use of
other fuels either alone or mixed with smokeless fuels, nor
does it cover instructions for use of other fuels.
UNDER NO CIRCUMSTANCES MUST THE
APPLIANCE BE FIRED DRY AS DAMAGE
WARNING
BOILER MODEL
WILL OCCUR
10/00 EOPI 33732

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Much Wenlock Stove and is the answer not in the manual?

Questions and answers

Summary of Contents for Coalbrookdale Much Wenlock Stove

  • Page 1: Operating Instructions

    Operating Instructions THE MUCH for Freestanding WENLOCK Much Wenlock Stove with Boiler handling, where applicable, the pertinent parts that contain any of Consumer Protection Act 1987 the listed materials that could be interpreted as being injurious to As manufacturers and suppliers of cooking and heating products, in health and safety, see below for information.
  • Page 2: Recommended Fuels

    RECOMMENDED FUELS Smokeless Manufactured Natural “Phurnacite Plus” Anthracite Large Nuts “Centurion” Welsh Dry Steam Coal “Coalite” Nuts (Large Nuts) “Maxibrite” “Phurnacite” “Sunbrite” Doubles “Extracite” “Blazebrite” “Taybrite” PETROLEUM COKE MUST NOT BE USED. NOTE: Pureheat fuel must not be used with this appliance.
  • Page 3: Water Heating

    TO REGULATE BURNING Maximum burning rate is obtained with the ashpit door spinwheel set at eight turns open. Minimum burning rate is half turn open. Adjust as required to suit the fuel and the heating desired. A fully fuelled fire will last four hours (when burning solid fuel) at the maximum recommended burning rate before re- fuelling is required.
  • Page 4: Fume Emission

    RATES. TO REMOVE SHALE OR STONE FROM THE FIREBED, OPEN THE FIREDOOR AND RAKE THE FIRE UPWARDS WITH A POKER TO BRING THE SHALE OR STONE TO THE TOP AND REMOVE WITH TONGS. THE TYPE OF FUEL AND THE ASHPIT DOOR SPINWHEEL SETTING, GOVERN THE FREQUENCY OF FUELLING.
  • Page 5 Insert provided flexible brush through the appliance front and blanking plate to clean top of boiler flueway. Fig. 8. Access to rear boiler flueway with flexible flue brush is made through the firedoor opening and rear boiler access hole. Fig. 9. Brush deposits into firebox and replace flue blanking plate.
  • Page 6: Spare Parts

    FIREGUARD SPARE PARTS Part No Description No. Req. HS5M-MW209 Front firebar 1-Set HS5B-MW212 Bottomgrate (upper) HS5B-MW213 Bottomgrate (lower) HS1M-90295 Ashpan HSFM-37539 Firedoor Glass Panel Firedoor Rope Seal JTHR-20389 (980mm length) Ashpit Door Rope Seal JTHR-26389 (840mm length)
  • Page 8 For further advice or information contact your local distributor/stockist With Aga-Rayburn’s policy of continuous product improvement, the Company reserves the right to change specifications and make modifications to the appliance described and illustrated at any tim Manufactured By Aga-Rayburn Station Road Ketley Telford Shropshire TF1 5AQ www.aga-rayburn.co.uk...
