Summary of Contents for DigiWeight DWP-1000R
- Page 1 Floor / Pallet Scale DWP-1000R DWP-5500R (Floor Scale) DWP-10000R DWP-102E (Indicator) DWP-11KR User Manual A12-51007 V1.0...
-
Page 2: Table Of Contents
Content CHAPTER 1 MAIN SPECIFICATION CHAPTER 2 INSTALLATION 2.0 SCALE BASE SET UP 2.1 FRONT AND BACK VIEW OF INDICATOR 2.2 KEY FUNCTIONS 2.3 CONNECTING LOAD CELL TO INDICATOR CHAPTER 3 OPERATION 3.1 POWER ON & ZERO SETTING 3.2 MANUAL ZERO SETTING 3.3 TARE 3.4 ACCUMULATING 3.5 COUNTING... - Page 3 Chapter 1 Main Specification 1. Model: DWP-5500R Floor / Pallet scale Grade Ⅲ, n=5000 2. Accuracy: 3. Sample Rate: 10 times / second 4. Load cell sensitivity 1.5～3mV / V 5. Scale interval: 1/2/5/10/20/50 for option 6. Display: 6 bits LED，6 state indicating signals 7.
-
Page 4: Chapter 2 Installation
Chapter 2 Installation 2.0 SCALE BASE SETUP a. Open the scale base box (Box 1) with a knife very carefully. Sharp blade may scratch the scale surface. b. Take out the scale feet (total 4 feet packed in the box inside the scale base) Floor / Pallet Scale - 3 -... -
Page 5: Key Functions
c. Screw each foot onto the load cell at each corner of the scale base. d. Take out the indicator from Box 2. Plug the scale serial cable into the socket on the back of the indicator. And use a screw driver to tighten the two screws of the plug. e. -
Page 6: Connecting Load Cell To Indicator
2.3 CONNECTING LOAD CELL TO INDICATOR 1. The 9-pin socket is used to hook up load cell, please refer to graph 2-3. 2. The 4-pin shielded cable is used, and the indicator does not have the function of long distance compensation. -
Page 7: Accumulating
3.4 COUNTING FUNCTION (WHEN F3 KEY=1) Sampling: Tare the weight of any container that is used and leave the container on the scale. Place samples on the scale. The quantity of the samples should match the options for the pre-set values: 10, 20, 50, 100 or 200 pieces. - Page 8 the high-limit and the low-limit are set as same value, the indicator will set alarm for one key point. If the high-limit is set higher than the low-limit, the indicator will set alarm for a weighing range. To set check-weighing parameters: when the indicator is off, turn it on and press [ZERO] key when the indicator is still warming up.
- Page 9 SLP 5: The indicator will enter sleep mode if it is idle for 5 minutes. SLP 10: The indicator will enter sleep mode if it is idle for 10 minutes. Press [FUN] to select and [TARE] to move to the next parameter. 4.3 “F3 KEY”...
-
Page 10: Chapter 5 Calibration
Press [FUN] to confirm and go to label format selection. Options: 1/2 “P11 FL”: Weight adjustment for acceleration of gravity change. “P12 KB”: on: keyboard beep is on; off: keyboard beep is off “P13 UT”: Unit Setting. Default unit: lb/kg Lb on/off U1 on/off U2 on/off (Unit 1 or Unit 2 setting)
